FASANO TOOLS FG 178/SF Operator's manual

The reproduction of this document (even in partial form) is prohibited without the Fasangas S.r.l. authorization
BRAKE BLEEDER
12V DC
BRAKE BLEEDER
Rev.
1 012021
FG 178/SF

Before using the tool, carefully read the warnings and instructions contained in this manual.
Improper or unsafe use of this tool can be dangerous or cause death or serious bodily injury. This
warning and instruction manual is an integral part of the product and must be kept by the user for any
future consultation. It contains important information on the safe use of the product.
Use destination.
This tool and its accessories must be used only for the purpose for which they were designed. Any
use other than that indicated could cause damage to people, animals or things and is considered an
improper and unreasonable act. The manufacturer cannot be held responsible for any damage
caused by improper, erroneous and unreasonable use, such as: failure to comply with the instructions
and warnings provided, use of non-original accessories, unauthorized modifications or interventions
on the product, etc.
Model: FG 178/SF
Type: automatic brake bleeder
Power supply: 12V DC
Tank capacity: 5 liters
Size: 830x330x290 mm
Weight: 13.20 kg (29 lbs)
Max. working pressure: 2 bar
Automatic stop at 10% of the tank
ACCESSORIES:
12V power cable
fluid supply hose
2 adapters for master cylinder cap
Bleeding bottle
lateral support brackets for fluid supply hose and 12V power cable
When using the tool, always follow the following safety instructions to reduce the risk of personal injury:
Always wear safety goggles with side protection in accordance with current regulations.
Always use protective gloves when using the tool in accordance with current regulations.
Always use protective clothing when using the tool in accordance with current regulations.
WARNINGS
TECHNICAL FEATURES
F
G
1
7
8
/
S
F
B
R
A
K
E
B
L
E
E
D
E
R
IMPORTANT SAFETY INSTRUCTIONS

ATTENTION:
Always ensure that the fluid control valve is close before use. This bleeder operates under pressure. It is
FILLING PROCEDURE
ATTENTION
POWER SWITCH MUST BE OFF
1. Remove ne fluid cap at the back of the unit and fill the unit with new brake fluid
2. To fill in just enough fluid for each service is recommended to prevent contamination from the air.
OPERATING INSTRUCTION
IMPORTANT: Each time the bleeder is filled with new brake fluid, air must be purged from the fluid supply hose before
connecting to the vehicle. Hold over a waste oil container (to collect any brake fluid that is forced out). Connect the unit
to battery. Switch on the power switch to allow air to escape. When brake fluid is free flowing, turn off power switch.
1. Install adaptor to the master cylinder of the brake system.
2. Connect the bleeder to the battery and connect quick coupler to the adaptor. The unit woking pressure is setted at 2
bar. Adjust pressure regulator on the panel while the power is on to accommodate the requirement of different
vehicles. The excess fluid will be return back to the new fluid tank.
3. Open brake nipple and connect to the bleeding bottle. Switch on the power and fluid control valve to start brake fluid
change. Once seeing new fluid coming into the bottle, turn off the power. Repeat process on all 4 wheels (in any
order).
4. Once process is complete, turn off the power and fluid control valve to release the pressure. Disconnect hose
assembly from the adaptor and take adaptor off vehicle. Replace the master cylinder cap on the vehicle.
DESCRIPTION AND OPERATION
F
G
1
7
8
/
S
F
B
R
A
K
E
B
L
E
E
D
E
R

5. Dispose waste brake fluid safely.
IMPORTANT: After each service, pressure must be released by closing fluid control valve.
When the tool is not usable and not repairable, dispose it according to regulations of the place in order to safeguard the environment.
This product complies with the dispositions of the following European Directives and Harmonized Standards:
2014/30/EU EN 55014-1:2006+A1+A2
EMC Directive EN 55014-2:1997+A1+A2
This instrument is warranted to be free from defects in materials and workmanship (for a normal use of service) for a
period of one year. Any instrument found detective within one year from the delivery date and returned to the factory with
transportation charges prepaid, will be repaired, adjusted, or replaced at no charge to the original purchaser. This warranty
e defect has been caused by a misuse or abnormal
operating conditions, the repair will be billed to the customer at a nominal cost.
EU DECLARATION OF CONFORMITY
WARRANTY
F
G
1
7
8
/
S
F
B
R
A
K
E
B
L
E
E
D
E
R
DISPOSAL INFORMATIONS
