USB-AC51
Dual Band Wireless-AC600 USB Wireless
Adapter
Fast Small Stylish
Advanced AC
Performance

USB AC51 Key Selling Points
Extreme 11ac Speed
Dual-band 150Mbps + 433Mbps data rate
5GHz super transferring speed for both High quality web
surfing and HD entertainment
Smallest Style Design
Penny size perfect fit for any portable device without
unplugging while transporting
ASUS Unique high-efficiency antenna Design
ASUS Antennas use the latest technology to provide a
stronger receiving device comparing to others

APPEARANCE

Appearance
LED Indicator
2.4 GHz antenna
5 GHz antenna
30.98 mm
16 mm
8.64 mm

MEDIA REVIEW

“# 1 Ranking in the Class AC580” -
SmallNetBuilder.com
http://www.smallnetbuilder.com/rankers/wireless-
adapter-bridge/result/1799-asus-usbac51

5 GHz Performance from Small Net Builder

SPECIFICATION

Specification
Network Standard
IEEE802.11a, IEEE802.11b, IEEE802.11g, IEEE802.11n, IEEE802.11ac
Interface
USB
2.0
Chipset
MT
7610U
Antenna
Internal
antenna x 2 (2.4GHz x 1 and 5GHz x 1)
Applications
Ethernet
adapter
Operating
Frequency
Selectable dual
-band: 2.4GHz/ 5Ghz
Operating Channels
2.4GHz: US/ 11; EU/13
5GHz: US/36~48/149~165; EU/ 36~48
Data Rate
802.11ac: Up to
433Mbps
802.11n: Up to
150Mbps
802.11g
: Up to 54Mbps
802.11b: Up to 11Mbps
Support OS
Windows
Vista(x86/x64)/Win7(x86/x64)/Win8/Linux/Mac 10.6~9
Encryption
64/128
-bit WEP, WPA, WPA2, TKIP, AES, WPA/ WPA2-PSK
Certifications
FCC,
NCC, IC, CE
Physical
Specifications
Dimensions
: 30.98 x 16 x 8.64 mm (PCB: 26mm)
Weight
: 4 gram
Package Contents
Quick
Start Guide x1
Warranty
Card x1

USB-AC51
Competitor Analysis

USB-AC51 Competitor Analysis
ASUS Netgear EDiMAX DLink Linksys
Model Name
USB-AC51 A6100-10000S EW-7811utc DWA-171 AE6000
WLAN
Standard IEEE 802.11a/b/g/n/ac IEEE 802.11a/b/g/n/ac IEEE 802.11a/b/g/n/ac IEEE 802.11a/b/g/n/ac IEEE 802.11a/b/g/n/ac
Main Chipset MTK MT7610U Realtek RTL8811AU Realtek RTL8811AU Realtek RTL8811AU
rev A1 MTK rev B1 MTK MT7610U
Operating
Frequency 2.4G / 5G 2.4G / 5G 2.4G / 5G 2.4G / 5G 2.4G / 5G
Size
Dimensions:
30.98 x 16 x 8.64 mm
(1.21 x .630 x .340 in)
Weight: 4 g (.14 oz)
Dimensions:
36.1 x 18.4 x 8.1 mm
(1.42 x .724 x .318 in)
Weight: 8 g (.28 oz)
Dimensions:
40 x 16 x 7 mm
(1.57 x .630 x .276 in)
Weight: 3 g (.11oz)
Dimensions:
35.6 x 17.8 x 7.6 mm
(1.4 x .7 x .3 in)
Weight: 5.67 g (.20oz)
Dimensions:
35.1 x 14.99 x 7.8 mm
(1.38 x 0.59 x 0.31 in) ;
Weight: 0.01Ibs
Data Rate 150 Mbps/433 Mbps 150 Mbps/433 Mbps 150 Mbps/433 Mbps 150 Mbps/433 Mbps 150 Mbps/433 Mbps
OS Support
Microsoft®Windows®
7, 8, XP,
Vista®: (32/64-bit)
Mac10.6~8, Linux
Microsoft®Windows®7, 8, XP,
Vista®: (32/64-bit)
Microsoft®Windows®7, 8, XP,
Vista®: (32/64-bit)
Microsoft®Windows®7, 8, XP,
Vista®: (32/64-bit)
Microsoft®Windows®7, 8,
XP, Vista®: (32/64-bit)

Performance Comparison (Internal Test)
Compete Product
ASUS USB-AC51
Linksys AE6000
Netgear A6100
Testing Equipment
IBM R61 CPU: Intel® Core™2 Duo T8100 2.1GHz, RAM:1GB__ XP
ASUS A45V CPU: Intel® Core™ i7 3610QM 2.3 GHz 2.3 GHz , RAM:8GB__Win7
ASUS RT-AC66U Firmware Version 3.0.0.4.362
Location
1. 3 Meters LOS
2. 31 Meters + 14 Meters NLOS
3. 20 Meters Separate Room

Location 1 –3 Meters LOS (2.4 GHz)
Performance Comparison

Location 1 –3 Meters LOS (5 GHz)
Performance Comparison

Performance Comparison
Location 2 –31 Meters + 14 Meters NLOS (2.4 GHz)

Performance Comparison
Location 2 –31 Meters + 14 Meters NLOS (5 GHz)

Performance Comparison
Location 3 –20 Meters Separate Room (2.4 GHz)

Performance Comparison
Location 3 –20 Meters Separate Room (5 GHz)
