TN0020A
Operation Manual
(1/6)

DAB TUNING RANGE
174.928 - 239.200 MHz
1-Rating
FM TUNING RANGE
12.0V (10.5～16.0V) - ground
4
2.1mA or less
4.0Ａ or less
(Vcc=13.2V, 0.5W output
531 - 1602 kHz (9kHz step
87.5 - 108 MHz (50kHz step
AM TUNING RANGE
RATED VOLTAGE
LOAD IMPEDANCE
BACK UP CURRENT
RATED CURRENT
(2/6)

■AUDIO controls
④BACK Transition to previous screen
②VOL DOWN Short Push: Decrease Volume Down step
Long Push: Decrease Volume Down continuously
③HOME Short Push: Transition to home screen
Long Push: AA/CP voice recognition
2-Button Function Spec
Button No. Button Name Operation
①VOL UP Short Push: Increase Volume Up step
Long Push: Increase Volume Up continuously
3
4
2
(3/6)

【操作手順】[Operation procedure]
①起動
(ACC-ON)
ACC-ON後、TO OTA画面が表示された事を確認。
After the ACC-ON, confirm that Toyota screen is displayed.
②数秒後に"CAUTION"画面に遷移します。
The screen is changed to "CAUTION" screen after a few seconds.
*初回のACC-ON時はやや時間を要します。
Note: It takes a little longer for the first time of ACC-ON.
③数秒後に”Continue”ボタンを押して、MENU画面に遷移させます。
Press the "Continue" button on the face panel after a few seconds
to move MENU screen.
Menu creen Display
④画面内のラジオモードウィンドウを押すと、"FM1 "画面に遷移します。
When the Radio Mode Window on the screen is pressed,"FM1" screen is displayed.
⑤下記画面に遷移したら、”<”釦 若しくは、”>”釦を押下してください。
これで、SEEKが始まります。
Confirm that the screen is changed as below,
Please push down the ”<”button or ”>”button.
This will start to SEEK.
※AM/DABモードも同様の手順です。
※Same as AM/DAB mode.
3-Radio operation procedure
Press anywhere in
this area
Push this button
Push this button
(4/6)

【操作手順】[Operation procedure]
①起動
(ACC-ON)
⑦画面の”Add Device”釦を押下してください。
ACC-ON後、TO OTA画が表示された事を確認。
Please press the ”Add Device” button of the screen
After the ACC-ON, confirm that Toyota screen is displayed.
②数秒後に"CAUTION"画面に遷移します。
The screen is changed to "CAUTION" screen after a few seconds. ⑧画面の”Search Device”釦を押下してください。
*初回のACC-ON時はやや時間を要します。
Please press the ” earch Device” button of the screen
Note: It takes a little longer for the first time of ACC-ON.
③数秒後に”Continue”ボタンを押して、MENU画面に遷移させます。 ⑨下記画面に遷移したらBluetooth端末（iPhone、 iPodなど)をペアリング
Press the "Continue" button on the face panel after a few seconds モードに設定してください｡
to move MENU screen.
Confirm if screen is changed as below,
Please set iPhone or iPod in pairing mode.
Menu creen Display
④下のスワップして、NOTIFICATION画面に遷移させます。
Swipe down on the face panel to move to Notification screen.
※Displays when you have more than one pairing equipment
※複数のペアリング機器がある場合の表示
⑩接続したiPhone又はiPodを選択します。
elect the iPhone or iPod to connect.
⑤”Setting”ボタンを押して、SETTINGS画面に遷移させます。
Please press the " etting" button on the face panel to move to ettings screen
※ 電話機の表示にしたがって操作してください
※ Operate the phone after the message on the screen
⑪完了すれば"Connection Completed"の画面になります｡
”Connection Completed” is displayed if completed.
⑥”Settings”画面に遷移することを確認し、画面上の"Bluetooth"釦を選択。
Confirm if ” ettings” screen is displayed, select the ”Bluetooth” button on the display.
4-Operating manual (Bluetooth/Handsfree)
Push this button
Push this button
Push this button
Push this button
Push this button
(5/6)
