Federal Signal Corporation FT100C-V Manual

Limited Warranty: This product’s limited warranty can be
found at www.fedsig.com/SSG-Warranty.
FT100C-V
Weather Resistant VoIP Telephone
25500867 Rev A0 1123
SAFETY MESSAGES TO INSTALLERS AND USERS :
• Read and understand instructions before installing or operating equipment.
• Do not install this device near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including ampliers) that produce heat.
• Only use attachments and accessories specied by the manufacturer.
• Refer all servicing to qualied service personnel.
• Prior to installation, consult local building and electrical code requirements.
• WARNING: ELECTRICAL HAZARD — This product should be installed by a licensed electrician according to all
electrical and building codes.
• WARNING: DISLOCATION HAZARD — To prevent injury, this apparatus must be securely attached to the oor or
wall in accordance with the installation instructions.
Table 1 Specications
Electrical Performance
Ringer Output >80 dB
Microphone Noise reducing dynamic
Receiver Hearing and compatible
Category
Ethernet I/F 10/100 MBPS
Protocol SIP RFC 3261 compatible
Power Input
- Method #1
- Method #2
802.3 AF compliant PoE switch or power injector
24 Vdc at 1A power adapter
CODECS Supported G711, A-LAW AND µ-LAW
G722.1 (SIREN7)
G722.2 (AMR-WB)
G729.1 (G729J AND G729EV)
Relay Contact Fuse protected to 1 A at 30 Vdc
Environmental
Weather and Corrosion Resistant Enclosure NEMA 3R
Temperature -22° to +140°F (-30° to +60°C)
Humidity 0 to 100% RH
Mechanical
Hook Switch (Cradle Switch) Life >1 000 000 Operations

2Federal Signal signaling.fedsig.com
Body Construction GE VALOX™357 engineering polymer
Faceplate Steel, corrosion protected and powder coated
Dimensions (H X W X D) 12 X 9.6 X 3.9 inches (305 x 245 x 99 mm)
Net Weight Including Mounting Plate 7 lb (3.2 kg)
Shipping Dimensions 15 X 11.5 X 5 inches (381 x 293 x 127 mm)
Shipping Weight Including Mounting Plate 8 lb (3.7 kg)
Handset Material High impact ABS
Standard Mounting Vertical wall
Wiring Access 7/8" opening for owner-supplied tting
Hardware Material Stainless steel
Table 2 A-Compliance
FCC Part 15, Class A
ICES-003 Class A
IEC 61000-6-2: 2005
60950-1
CISPR 22: 2008
Weatherproof Enclosure Type 3R
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation.
GENERAL: The Federal Signal FT100C-V telephone is designed to provide safe, reliable communication in areas prone to
high humidity, chemical vapors, dust, and physical abuse.
The FT100C-V Telephone is compatible with most SIP-based IP PBX servers that comply with SIP RFC 3261. Users can
remotely monitor and program settings through a web browser to congure telephones on their network.
Features
• Enclosure
• VALOX™body construction
• Weather and corrosion resistant
• Spring-loaded hinged door
• Temperature range -22˚ to +140˚F ( -30˚ to +60˚C)
• 12-key teleseal keypad
• Waterproof connections and stainless steel ttings for longer life
• Corrosion protected and powder coated steel faceplate
• Magnetic reed hook switch — no moving parts
• Easily mounted on any sturdy, vertical structure
• Noise reducing microphone allows a high level of intelligibility in locations with high background noise
• Heavy duty K-type industrial handset
• Handset retainers to maintain on-hook status
• Modular parts for easy service
• Compatible with inductively coupled hearing aid devices
• Adaptive full duplex operation
• Compatible with most SIP-based IP PBX servers that comply with SIP (RFC 3261)
• Network web management interface
• The discovery utility makes it easy to detect, locate, and launch the web-based conguration screens

3
Federal Signal signaling.fedsig.com
• Product self-diagnostic testing available through web interface
• Network-adjustable speaker volume and microphone sensitivity sets the default levels. User-adjustable volume
control on Handset
• PoE 802.3af enabled (Power-over-Ethernet) or alternate power source
• Web-based user interface allows remote setup of network, product operations, updates, self-diagnostics, and other
functional access
• Auxiliary relay – multiple activation selectable through web interface.
• Dual speeds of 10 Mbps and 100 Mbps
• Network/Web management
• Dial Out Extension supports the addition of comma delimited pauses before sending additional DTMF tones
• Network downloadable product rmware
• Tamper proof design
• Autoprovisioning and Device Conguration Export/Import saves setup time on multiple deployments
• Congurable audio les
• Event Monitoring / Triggers (Refer to VoIP Conguration Guide – Part Number 25500857)
• Peer-to-peer capable
Supported Protocols
The WRT-VoIP Telephone with Keypad supports:
• SIP (Session Initiation Protocol)
• HTTP Web-based conguration
• Provides an intuitive user interface for easy system conguration and verication of WRT-VoIP Telephone with
Keypad operations.
• DHCP Client
• Dynamically assigns IP addresses in addition to the option to use static addressing.
• TFTP Client
• Facilitates hosting for the autoprovisioning conguration le.
• RTP
• Facilitates autoprovisioning conguration values on boot.
• Audio Encodings
• PCMU (G.711 mu-law)
• PCMA (G.711 A-law)
• G722.1 (Siren7)
• G722.2 (AMR-WB)
• G729.1 (G729J & G729EV)
Supported SIP Servers
As a SIP device, this product will operate with most IP PBX servers.
Installation
The Voice-over-IP (VoIP) FT100C-V Telephone is a Power-over-Ethernet (PoE 802.3af) and Voice-over-IP (VoIP) two-way
communications devices that easily connect into existing local area networks (LANs) with a single cable connection.

4Federal Signal signaling.fedsig.com
Figure 1 illustrates how the FT100C-V-VoIP Telephone can be installed as part of a VoIP phone system.
Figure 1 Typical VoIP Installation
Figure 2 Features
Figure 3 Dimensions

5
Federal Signal signaling.fedsig.com
ELECTROSTATIC HAZARD: The VoIP PCBA is susceptible to damage from electrostatic discharge (ESD) and is
protected by a metal shield. If it is necessary to remove the shield, take suitable precautions.
SHOCK HAZARD: If using an auxiliary power supply, ensure that it is unplugged during installation to avoid an
accidental shock or circuit damage.
NOTES:
• Determine if power to operate the telephone will be provided via the Ethernet or if external power will be required. If
external power is required, install an auxiliary power supply
• To maintain Ingress Protection / NEMA ratings, use appropriately rated hardware and waterproong techniques.
• Choose a wall location that is free of obstructions and permits space for conduit runs.
• Ensure that mounting can support 7 lb (3.2 kg) and any additional foreseeable load.
To install the telephone:
1. Separate the faceplate from the housing.
2. Use the template provided or the enclosure itself to locate and drill holes for the mounting screws.
3. Secure the unit to the wall with user-supplied 1/4"or M8 screws.
4. Bring the network cable into the enclosure through the conduit entrance and plug into the RJ-45 connector on the
PCBA. See Figure 4.

6Federal Signal signaling.fedsig.com
Figure 4 Wiring
5. If using an alternate power supply, connect the supply to the terminal block J9. Before doing so, determine if
power is supplied over the Ethernet cable.
6. Connect the on-board relay if utilized.
7. Reconnect the faceplate harness.
8. Ensure that all connections are secure.
9. Verify that the telephone is properly connected by pressing the RESET switch for less than ve seconds to
announce the IP address. LEDs on the RJ45 connector indicate network connection and activity.
10. Replace the faceplate.
11. Set up and congure the telephone if changes are required to the default settings.
12. Call to and from another telephone, preferably a VoIP device, to test the unit.
Operation
FT100C-V-VoIP telephones may be set up for either keypad dialing or auto-dialing.
If the telephone is congured for keypad, dialing operation is identical to most other single-line telephones.
If the telephone is congured for auto dialing, lift the handset and press the number assigned to the extension to be
dialed.
FT100C-V VoIP telephones dial the programmed number when the handset is lifted.

7
Federal Signal signaling.fedsig.com
Adjust the receiver volume with the switch in the handset.
Setup
Connections
Figure 6 shows the pin connections on the J9 (terminal block). This terminal block can accept a wire range from 16 AWG
to 26 AWG.
NOTE: As an alternative to using PoE power, 24 V at 1 A can be supplied to the terminal block.
Figure 5 Terminal Block Connections
Connecting a Device to an Auxiliary Relay
The FT100C-V Telephone incorporates one on-board relay located on the PCBA, which enables users to control a low
current external relay or device. An external relay can control a ringer, strobe light, door lock or any other apparatus.
The on-board relay is protected by a 1 A, non-replaceable fuse. Power switched by the relay should not exceed 0.5 A at
30Vdc. The PCBA is not designed to handle AC voltages.
The relay circuitry contains a non-replaceable 250 VAC 1 A fuse. If the fuse blows, the board must be returned to
Federal Signal or an approved service center for repair.
The telephone relay activation time is selectable through the web interface. The relay is controlled by DTMF tones
generated from the phone to which the VoIP phone is connected no matter which one initiated the call. The DTMF tones
are selectable from the web interface as well.
NOTE: The three-digit code for the auxiliary relay must be sent in conformance with RFC2833 DTMF generation.

8Federal Signal signaling.fedsig.com
See Figure 6 and Table 3 to identify the connector locations and functions.
Figure 6 Connector Locations
Table 3 Connector Functions
Connector Function
J1 PoE Network Connection (RJ-45)
J2 Hands free Microphone Interface/LED Interface
J3 Not used
J4 JTAG Interface
J5 Handset/Reed Switch Interface
J6 Speaker Interface
J7 Keypad Interface
J8 RS232 Port
J9 Terminal Block (see Figure 5)
J10 Not used
J11 Handset V.C. Interface
J12 ISP-DIP/Debug UART
Network Connectivity and Data Rate
When you plug in the Ethernet cable or power supply, the square, green Link light above the Ethernet port indicates that
the network connection has been established. (See Figure 7.) The Link light changes color to conrm the auto-negotiated
baud rate:
• This light is yellow at 10 Mbps.

9
Federal Signal signaling.fedsig.com
• It is orange at 100 Mbps.
Verify Network Activity
The square, yellow Activity light blinks when there is network activity.
Figure 7 Network Activity
Reset Switch
When the telephone is operational and linked to the network, use the Reset Test Function Management (RESET) switch
(Figure 8) on the Telephone board to announce the telephone’s IP address, and verify that the audio is working. The
message comes through the handset receiver.
Figure 8 RESET Switch

10 Federal Signal signaling.fedsig.com
Announcing the IP Address
To announce a telephone’s current IP address, press and release the RESET switch (SW1). Do not hold the button for
more than ve seconds.
NOTES:
• The telephone will use DHCP to obtain the new IP address (DHCP-assigned address or default to 10.10.10.10 if a
DHCP server is not present).
• Pressing and holding the RESET switch for longer than ve seconds restores the telephone to the factory default
settings.
Restore the Factory Default Settings
When troubleshooting conguration problems, it is sometimes convenient to restore the device to a known state.
NOTE: Each telephone is delivered with factory set default values.
To set the factory default settings:
1. Press and hold the RESET switch (SW1) for more than ve seconds.
2. The telephone announces that it is restoring the factory default settings.
The telephone uses DHCP to obtain the new IP address (DHCP-assigned address or default to 10.10.10.10 if a DHCP
server is not present).
Adjust the Volume
You can adjust the volume through the Device Conguration Page.
For further instructions, reference 25500857 FT VoIP Telephone Setup Guide.
Field Repairs
Field repairs must be carried out only by qualied technicians using OEM parts. Substitution of parts voids the warranty
and may pose a hazard to users of the equipment.
ELECTROSTATIC HAZARD: The VoIP PCBA is susceptible to damage from electrostatic discharge (ESD) and is
protected by a metal shield. If it is necessary to remove the shield, take suitable precautions.
To make repairs to the telephone:
1. Disconnect the telephone IP Cable and Aux Power if necessary.
2. Carefully remove the front cover assembly and separate it from the housing by disconnecting the harness plugs.
Note that the handset and all electronics are attached to the front plate.
3. Perform the necessary repairs or adjustments.
4. Carefully replace the front plate and install all the screws. Do not overtighten the cover screws. There is a exible
gasket between the cover and the body; excessive tightening of the screws deforms the gasket and reduces the
weather resistance of the set.
Handset Replacement
Refer to the instruction sheet included with the replacement handset.
To replace the handset:
1. Disconnect the handset wiring from the PCBA.

11
Federal Signal signaling.fedsig.com
2. If the phone is equipped with an armored cord handset, remove the anchor screw from the armored cord lanyard.
3. Loosen the handset cable gland and pull out the cord.
4. Install the new replacement handset and tighten the gland.
5. Rewire the handset cord to the PCBA.
Ringer Replacement
To replace a ringer:
1. Disconnect the ringer wiring from the terminal block on the PCBA.
2. Remove the screws that hold the ringer to the housing.
3. Install the new ringer and gasket.
4. Reconnect the ringer wiring to the terminal block.
Main Circuit Board Replacement
To replace the circuit board:
1. Label any wiring attached to the circuit board. Disconnect the wiring and ribbon cable.
2. Remove the two screws holding the circuit board in place. Carefully remove the board.
3. Install the new board and reconnect the wiring.
4. If the conguration had been changed from the factory default settings, reprogram the telephone.
5. Make and receive calls from another telephone to test it.
Maintenance and Service
Technical Assistance: Contact our Technical Support Team at [phone] or [email protected].
Repair Service: A return authorization is required. Contact your Authorized Distributor or Federal Signal Customer
Support. Defective products under warranty will be repaired or replaced at Federal Signal’s discretion.
Product Returns: Returns require authorization from Federal Signal. Contact your Authorized Distributor for more
information on our return policy or to request a return.
Ordering Replacement Parts
Table 4 Replacement parts
Description Part Number
Handset 4' Curly Cord C/W VC, Tx and Rx P007228
PCBA- VoIP P007395

2645 Federal Signal Drive, University Park, Illinois 60484
Additional translations available at signaling.fedsig.com
Traducciones adicionales disponibles en signaling.fedsig.com
Customer Support 1-800-344-4634+1-708-534-4756, [email protected]
Technical Support 1-800-755-7621+1-708-587-3587, signalsuppor[email protected]
signaling.fedsig.com
