Feider Machines FMT400 User manual

1
ORIGINAL INSTRUCTIONS
INSTRUCTIONS MANUAL
MULTI TOOLS
FMT400
Warning: read the following instructions before using the machine
BUILDER SAS
32, rue Aristide Bergès - ZI 31270 Cugnaux – France
Made in PRC

2
CONTENTS
1. SAFETY WARNINGS 3
2. YOUR PRODUCT 6
3. ASSEMBLY 7
4. OPERATION 9
5. MAINTENANCE AND STORAGE 11
6. DISPOSAL 11
7. DECLARATION OF CONFORMITY 12
8. WARRANTY 13
9. PRODUCT FAILURE 14
10. WARRANTY EXCLUSIONS 15

3
1. SAFETY WARNINGS
WARNING Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference. The term "power tool" in the warnings
refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit.Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you
to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase
the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords
increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use
of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating a power tool.
Do not use a power tool while you are tired or under the influence of drugs, alcohol or
medication. A moment of inattention while operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions
will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position connecting to power
source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger
on the switch or energizing power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better control of
the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves

4
away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of tools allow you to become complacent and
ignore tool safety principles. A careless action can cause severe injury within a fraction of a second.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot
be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the power tool
before making any adjustments, changing accessories, or storing power tools. Such preventive
safety measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with
the power tool or these instructions to operate the power tool. Power tools are dangerous in the
hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts
and any other condition that may affect the power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the power tool
for operations different from those intended could result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery
handles and grasping surfaces do not allow for safe handling and control of the tool in unexpected
situations.
6) Service
a) Have your power tool serviced by a qualified repair person using only identical replacement
parts.This will ensure that the safety of the power tool is maintained.
Residual risks
Some dust created by power sanding, sawing, and grinding, drilling, and other construction
activities contains chemicals known to cause cancer, birth defects or other reproductive harm.
Some examples of these chemicals are:
-Lead from lead-based paints.
-Crystalline silica from bricks and cement and other masonry products.
-Arsenic and chromium from chemically treated lumber.
Your risk from these exposures varies, depending on how often you do this type of work. To reduce
your exposure to these chemicals: work in a well-ventilated area, and work with approved safety
equipment, such as those dust masks that are specially designed to filter out microscopic particles.
Wear also a correct eyes protection.

5
Symbols
Refer to the instruction handbook/booklet
Wear eyes protection
Wear ear protection
Wear respiratory protection.
Class II protection
Intended use
This tool is intended to be used for the sanding of little surfaces, corners, edges, for stripping, cutting
little pieces in metal, wood or plastics.
Do not use this tool for others purposes. Misuse will create accidents and injuries. It is intended only
for a domestic use. Do not use it for commercial purposes.

6
2. YOUR PRODUCT
a. Description
1. Lever of the spindle
2. ON/OFF switch
3. Speed setting button
4. Supply cord
5. Dust extractor (1)
6. Dust extractor (2)
7. HSS Segmented Saw Blade
3-1/8"
8. Wood/plastic blade (small
9. Oscillating spindle
10. Wood/plastic blade (medium)
11. Wood/plastic blade (big)
12. Blades for wood and plastics
13. Sand paper
14. Sanding pad
15. Switch ON/OFF
a. Technical data
Model
FMT400
Power
400W
Voltage
230-240V˜ 50Hz
Sound power level
LwA = 95dB(A) K= 3dB(A)
Sound pressure level
LpA= 84dB(A) K= 3dB(A)
Vibration
5.87m/s² K= 1.5 m/s²
Information:
The declared vibration total value has been measured in accordance with a standard test
method and may be used for comparing one tool with another;
The declared vibration total value may also be used in a preliminary assessment of
exposure.
Warning:
that the vibration emission during actual use of the power tool can differ from the
declared total value depending on the ways in which the tool is used; and
of the need to identify safety measures to protect the operator that are based on an
estimation of exposure in the actual conditions of use (taking account of all parts of the
operating cycle such as the times when the tool is switched off and when it is running
idle in addition to the trigger time).

7
3. ASSEMBLY
NOTE: The tool must be always switched off and unplugged before installation.
a. Installation of accessories
-Pull the lever to open the oscillating spindle.
-Slide the accessory on the spindle.
-Be sure that the holes of the accessory are engaged on the pins of the flange. Close the
lever to lock the accessory in place.

8
-When use the sanding pad, put on it a sanding paper.
-Be sure that the large part of the accessory is placed outside of the tool (as showed in the
picture).
b. Dust extractor
-Install the hole of the extractor dust around the flange. Screw it with in place with the pre-
installed screw.
-Install the tube on the dust extractor. You will able to install your vacuum device on it.
-After install the dust extractor, you will able to install the desired accessory as explained
above.

9
c. Disassembly
Switch off and unplug the tool
When use the sander, remove the sanding paper first.
Pull le lever of the spindle. Remove the accessory.
4. OPERATION
a. Starting and stopping
-Be sure that the assembly is correct.
-Plug the tool to a socket.
-Push forward the switch button to start the operation.
-To stop the operation, push backward the switch button.
b. Speed setting
Set the speed of the tool by using the speed setting button.
Start the job by putting this button on 1 and increase the speed according the operation to do.
There are 6 levels of speed, 1 is the lowest and 6 is the highest speed.
c. Applications

10
Cutting
Use a flush cutting saw blade (or “e-cut blade”) for making precise cuts in tight areas, close to
edges, plunge or flush to a surface. It is important not to force the tool during the flush cutting. If
you are experiencing a strong vibration in your hand during the cut, it indicates too much
pressure on the tool. Back off on the pressure and let the speed of tool do the work. For typical
uses for flush cutting saw blade.
NOTE: It is suggested that you have a piece of scrap material supporting the blade when
making a flush cut. If you need to rest the blade on a delicate surface, you need to use
cardboard or masking tape to protect the surface.
Use the segmented saw blade for making continuous precise cuts in wood, plaster or drywall
material. Applications include cutting for electrical boxes, repairing flooring, cutting flooring for
venting, and more.
Sanding
With sanding accessories, this tool is a detail sander. It is suitable for dry sanding of wood,
plastic, and metal surfaces, especially in corners, edges and hard to reach areas.
Tips:
1. Work with the complete surface of the sandpaper, not only with the tip.
2. Sand with continuous motion and light pressure. Do not apply excessive pressure. Let tool do
the work.
3. Always secure small work pieces.
4. Select suitable abrasive paper for best results.
Selecting the sanding sheet
-A sanding sheet should be selected depending on the material to be worked and the required
rate of material removal.
Grain size 80: For face-sanding and levelling small irregularities
Grain size 120: For face-sanding and levelling small irregularities
Grain size 180: For finish- and fine-sanding of wood
Scrapping
Scraper blades are suitable for removing vinyl, varnish, paint layers, carpeting, caulk and other
adhesives.
Use a rigid scraper blade to remove harder materials, such as vinyl flooring, carpeting and tile
adhesives in a large area.
Use a flexible scraper blade (not included) to remove softer material such as caulk.
Tips:
1. When removing strong, tacky adhesive, grease the scraper blade surface to reduce gumming
up.
2. Begin with light pressure. The oscillating motion of accessory only occurs when pressure is
applied to the material to be removed.
3. If you are removing caulk from a delicate surface, such as a bath tub or tile back splash, we
recommend taping to protect the surface that the blade will rest on.

11
5. MAINTENANCE AND STORAGE
Maintain your tool regularly. This will keep your tool in good working order and extend its lifespan.
Do not use abrasive, caustic agents to clean the tool. These types of products will damage your tool.
Do not perform repairs by yourself. Repairs and inspection must be carried out by a competent
person or at an authorized service center (please contact you service dealer).
a. After each use
Check the accessories, cable and body of the tool (cleanliness, wear, damage, etc.). If you notice
damage, wear, or malfunction, do not use the tool and bring it to a qualified service for inspection
and reparation.
b. Maintenance
There is no specific maintenance to be performed by the user. After each season, please bring
the tool to an authorized service center to perform a general cleaning and the following operations:
Lubrication
Mechanical check of motor, spindle, bearings and housing.
Electrical check.
Electrical and mechanical performance.
c. Spare Parts
You can order the spare parts directly from our Service Center.
d. Storage
- After use and cleaning, please store your tool.
- Store the tool and accessory in a clean, dry place, preferably in its box.
- The tool must be stored away from children and pets.
- Avoid exposing the tool to direct sunlight.
6. DISPOSAL
Electrical products should not be discarded with household products. According to
the European Directive 2012/19/EU on waste electrical and electronic equipment and its
implementation into national law, electrical products used must be collected separately and disposed
of at collection points provided for this purpose. Talk with your local authorities or dealer for advice on
recycling.

12
7. DECLARATION OF CONFORMITY
BUILDER SAS
32, rue Aristide Bergès - ZI 31270 Cugnaux – France
Declares that the machine
Designation: MULTITOOLS
Model: FMT400
Serial number: 20210163965- 20210164464
Is in conformity with the European Directives:
Machine Directive 2006/42/EC
EMC Directive 2014/30/EU
RoHS Directive (EU)2015/863 amending 2011/65/EU
This product is also in conformity with the following standards:
EN62841-1:2015
EN62841-2-4:2014
EN 55014-1:2017
EN 55014-2:2015
EN61000-3-2:2014
EN IEC 61000-3-2:2019
EN61000-3-3:2013
EN61000-3-3:2013/A1:2019
Responsible of the technical documentation: Olivier Patriarca
Philippe MARIE / PDG
Cugnaux, 01/01/2021

WARRANTY
The manufacturer guarantees the product against defects in material and workmanship for a period of 2
years from the date of the original purchase. The warranty only applies if the product is for household use.
The warranty does not cover breakdowns due to normal wear and tear.
The manufacturer agrees to replace parts identied as defective by the designated distributor. The
manufacturer does not accept responsibility for the replacement of the machine, in whole or in part , and/or
ensuing damage.
The warranty does not cover breakdowns due to:
• insu󰀩cient maintenance.
• abnormal assembly, adjustment or operations of the product.
• parts subject to normal wear and tear.
The warranty does not extend to:
• shipping and packaging costs.
• using the tool for a purpose other than that for which it was designed.
• the use and maintenance of the machine done in a manner not described in the user manual.
Due to our policy of continuous product improvement, we reserve the right to alter or change specications
without notice. Consequently, the product may be di󰀨erent from the information contained therein, but a
modication will be undertaken without notice if it is recognized as an improvement of the preceding
characteristic.
READ THE MANUAL CAREFULLY BEFORE USING THE MACHINE.
When ordering spare parts, please indicate the part number or code, you can nd this in the spare parts list
in this manual. Keep the purchase receipt; without it, the warranty is invalid. To help you with your product,
we invite you to contact us by phone or via our website:
• +33 (0)9.70.75.30.30
• https://services.swap-europe.com/contact
You must create a "ticket" via the web platform.
• Register or create your account.
• Indicate the reference of the tool.
• Choose the subject of your request.
• Describe your problem.
• Attach these les: invoice or sales receipt, photo
of the identication plate (serial number), photo
of the part you need (for example: pins on the
transformer plug which are broken).
8. WARRANTY
13

WHAT TO DO IF MY MACHINE BREAKS DOWN?
If you bought your product in a store:
a) Empty the fuel tank.
b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case,
the repairer will refuse the machine.
Go to the store with the complete machine and with the receipt or invoice.
If you bought your product on a website:
a) Empty the fuel tank.
b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case,
the repairer will refuse the machine.
c) Create a SWAP-Europe service ticket on the site: https://services.swap-europe.com When making the
request on SWAP-Europe, you must attach the invoice and the photo of the nameplate (serial number).
d) Contact the repair station to make sure it is available before dropping o󰀨 the machine.
Go to the repair station with the complete machine packed, accompanied by the purchase invoice and the
station support sheet downloadable after the service request is completed on the SWAP-Europe site
For machines with engine failure from manufacturers BRIGGS & STRATTON, HONDA and RATO, please
refer to the following instructions.
Repairs will be done by approved engine manufacturers of these manufacturers, see their site:
• http://www.briggsandstratton.com/eu/fr
• http://www.honda-engines-eu.com/fr/service-network-page;jsessionid=5EE8456CF39CD572AA2AEEDFD
290CDAE
• https://www.rato-europe.com/it/service-network
Please keep your original packaging to allow for after-sales service returns or pack your machine
with a similar cardboard box of the same dimensions.
For any question concerning our after-sales service you can make a request on our website https://
services.swap-europe.com
Our hotline remains available at [phone].
9. PRODUCT FAILURE
14

THE WARRANTY DOES NOT COVER:
• Start-up and setting up of the product.
• Damage resulting from normal wear and tear of the product.
• Damage resulting from improper use of the product.
• Damage resulting from assembly or start-up not in accordance with the user manual.
• Breakdowns related to carburetion beyond 90 days and fouling of carburetors.
• Periodic and standard maintenance events.
• Actions of modication and dismantling that directly void the warranty.
• Products whose original authentication marking (brand, serial number) has been degraded, altered or
withdrawn.
• Replacement of consumables.
• The use of non-original parts.
• Breakage of parts following impacts or projections.
• Accessories breakdowns.
• Defects and their consequences linked to any external cause.
• Loss of components and loss due to insu󰀩cient screwing.
• Cutting components and any damage related to the loosening of parts.
• Overload or overheating.
• Poor power supply quality: faulty voltage, voltage error, etc.
• Damages resulting from the deprivation of enjoyment of the product during the time necessary for repairs
and more generally the costs related to the immobilization of the product.
• The costs of a second opinion established by a third party following an estimate by a SWAP-Europe repair
station
• The use of a product which would show a defect or a breakage which was not the subject of an immediate
report and/or repair with the services of SWAP-Europe.
• Deterioration linked to transport and storage*.
• Launchers beyond 90 days.
• Oil, petrol, grease.
• Damages related to the use of non-compliant fuels or lubricants.
* In accordance with transport legislation, damage related to transport must be declared to carriers within 48
hours maximum after observation by registered letter with acknowledgement of receipt.
This document is a supplement to your notice, a non-exhaustive list.
Attention: all orders must be checked in the presence of the delivery person. In case of refusal by the
delivery person, it you must simply refuse the delivery and notify your refusal.
Reminder: the reserves do not exclude the notication by registered letter with acknowledgement within 72
hours.
Information:
Thermal devices must be wintered each season (service available on the SWAP-Europe site). Batteries must
be charged before being stored.
10. WARRANTY EXCLUSIONS
15
