FeiYu Tech Hornet-OSD User manual

GuilinFeiyuElectronicTechnologyCo., Ltd.http://www.feiyudz.cnEmail:[e-mail]
GuilinFeiyuElectronicTechnologyCo., Ltd.http://www.feiyudz.cnEmail: [e-mail] Page1
Hornet-OSD Manual
Dear customers:
Hello!ThankyouforpurchasingtheOSD of GuilinFeiyuElectronicTechnologyCo,
Ltd. Inordertoachievefull potential andsafeoperationof thisproduct,pleasecarefully
readthis manual priortoinstallation.
Preface
TheHornet-OSDoverlaysflighttelemetryinformationontoyourvideoimage.The
telemetryinformationdisplayedincludesflightaltitude, flight speed, flightdirection,and
homedirectionandsoon.Youalsocansavethe telemetryinformationtoaMICROSD
card(youshouldbuythecard byyourself, forwedon t offerit,pictureisshownasbelow ),
thenrealizingtrace playbackvia FYGCS.TheHornet-OSD canbeconnectedtothe
FY-21AP, FY-31APandFY-3ZT systemstodisplayautopilottelemetricdata,ortoaGPS
receivertodisplaypositioningdata.
Hornet-OSDautomaticallyadaptstoeitherPALorNTSCvideoinputandconfirms if
there is a MICROSD cardornot.Theadaptiveprocessesarewithinabout 20seconds.
Workingstatusexplanation:
Afterconnectingthepowersupply,theindicatorLEDlightwillbeactivated.The
Hornet-OSDwillautomaticallydetecttheincomingvideo(NTSCorPAL).The"NTSC"or
"PAL"will overlaidonthescreenwhenthevideosignalisdetected.IfData isreceived
fromtheautopilot(FY-21AP,FY31AP,FY-3ZT orGPS module)theLEDindicatorof
Hornet-OSDwill begintoflash.Ifnot,theHornet-OSD will automaticallyrestartafter
waitingfor20seconds.
Once theinputvideoisdetectedevenifthereisinterruptiontothevideosignal,the
telemetrydata of theHornet-OSD will continue tobetransmittedvia thevideostream.
InterfaceSchematic Diagram:
1.DANGER:The three “VCC”ports(positive) for VideoIn, Video Out and PowerIn areall
inter- connected.Thereforeyouareallowed toconnect ONEinputvoltageonly. DO NOT
input morethanone powersupplyor damagetotheOSDwill occur.
2.It isrecommended topowertheOSD independentlytoensureacleanvideodisplay.
3.NotethatpowertotheOSDisnot suppliedbytheAutopilotmodule.Powerisviathe12volt
input.
ListofInterfaces
PORT ConnectionDescription
Videoin Cameraor videoinputport
Videoout OSDOverlaidvideooutput,connect tovideotransmitteror videoscreen
SW RC receiverswitchinputtocontrolOSD display
Power OSDvideooverlayboardandcameraandvideotransmitterpowersupply.
Datain FY-21AP/FY-31AP/FY-3ZT/GPS datainterface
CurrentSensor Current sensor input for measuringthebatteryvoltageandcurrent.
Detaileddescriptionof the “Videoin”port
GND Connect tothecameraGND
VCC
Connect tocamera spowersupply “VCC”.
(Note:Power issuppliedfromtheOSDtotheCamera.Donotinputanyother
power supplythroughthisport ordamage willoccur).
VideoIN Videoinput(Connect tothecameravideosignaloutput).
Detaileddescriptionof the “Videoout”port
GND Connect tovideotransmitterGND
VCC
Connect tovideotransmitterpowersupplyinput “VCC”.
(Note:Power issuppliedfromtheOSDtothevideotransmitter.Donotinput
anyother powersupplythroughthisport ordamagewilloccur).
VideoOut Videooutput (connect tovideotransmittervideoinput).
Detaileddescriptionof the “SW”port
GND Connect tothepower “GND”port oftheRCreceiver.
PWMIN
Connect tothesignalport ofyour RC receiver (youneedto
designatetoafree
channel).
Detaileddescriptionof the “Power”port
GND Connected tothepower “GND”thatsupplytotheOSDcontrol board.
VCC
Connect tothepower “VCC”thatsupplytotheOSDcontrolboard(Safeinput
range: DC6Vto12V)
Note:thispowersupplyissent directlytoyourVideoCameraandVideo
Transmitter.E.g. ifyouareusinga12 volt VideoCameraandTransmitter,the
inputvoltageshouldalsobe12volt.
Detaileddescriptionof the “Data in”port
GND FY-21AP/FY-31APGND,orthe GNDoftheGPS
+3.3V UseonlytosupplypowertotheFY-GPS module.
(DO NOT connectthisporttotheFY-21AP/ FY-31APortheFY-3ZT).
DataTX Connect tothe “RX1”dataoutputportoftheFY-21AP/FY-31AP/FY-3ZT, or
the “RX”port oftheGPS module.
DataRX Connect tothe “TX1”dataoutputportoftheFY-21AP/FY-31AP/FY-3ZT, or
the “TX”port oftheGPS module.
Detaileddescriptionof the “CurrentSensor”port
ENGVCC Connect tobatterypositive (Red)
CUR AD Connect tothecurrentsensor outputsignal (White)
+5V +5Vpowersuppliedtothecurrentsensor fromOSD(Yellow)
ENGGND Connect tobatterynegative(Black)
CurrentSensor
Applicationdiagram
TheHornet-OSDcandirectlyconnect tothedataoutputportofFY-21AP, FY-31APor
FY-3ZT, orseparatelyconnect totheoutputport of GPS module,andthenoverlaytheflight
datainformationtothevideosignal.The applicationdiagramisshownasbellow.
Note Themodules intheimaginarylineframemeansthat youcan chooseanyone ofthese
modulestoconnect.
Introductionforthe flightStateofFY-21AP/FY-31APor FY-3ZT
NameIntroduction
RC ManualFlight. Autopilotdeactivated.
ABMAutobalance mode
FAF For FY-21AP:FixedAltitudeflyingmode;for FY-3ZT/FY-31AP:Airrouteflymode
RTL AutoReturnMode
ACMAutoCircleMode
Figure4. ConnectionSchematicDiagram
GND VCC
①
Video IN
GND VCC
①
Video Out
GND VCC
①
GND PWM
ENGGND +5V CUR AD ENGVCC
GND +3.3Data TX Data RX
CurrentSensor
Datain
SW
Power
Videoout
Videoin
Feiyu Tech
MICRO SD card
Figure3.CurrentSensor
Red
White
Yellow
Black
BatteryPositiveInput
OutputtoECSNegative
BatteryNegative Input
OutputtoECSPositive

GuilinFeiyuElectronicTechnologyCo., Ltd.http://www.feiyudz.cnEmail:[e-mail]
GuilinFeiyuElectronicTechnologyCo., Ltd.http://www.feiyudz.cnEmail: [e-mail] Page2
Interfaceintroduction
Thetelemetrydata displayisasfollows:
1
Attitudemeasurement
error coefficient
（refertotheprompt）11
Relative altitude(Unit :m)
2 GPS speed(Unit:km/h)12 Horizonposition display
3
Current latitudeandlongitudeofthe
plane(Format: “dddmm.mmm”) 13
The angleofturningtothereturnpoint
(Unit:deg)
4 Totalflighttime(Format: “mm.ss”)14 Courseangleofflight(Unit:deg)
5 Flightmode15 Operatingtemperature(Unit: ℃)
6 Distancetotake-off Point(Unit:m)16
The batteryvoltageofthevideo
transmitter(Unit:V)
7 Power batteryvoltage(Unit:V)17
The batterypower consumed
(Unit:mA/ h)
8 Climbrate(Unit:m/s) 18
‘Radar aircraft Positionrelativeto
‘Radar Homeposition
9
The quantityofsatelliteused for
positioning 19
‘Radar Homeposition
10 Power batterycurrent(Unit:A)
Error CoefficientAssessment（Attitude measurementerror coefficient assessment）
1. Attitudemeasurementerrorcoefficientisanassessment(ECA)oftheaircraftattitudeas
measuredbyFY-21AP, FY-31APorFY-3ZT.
2. “0”valueisnormal,maximumvalueis “1000”.
3. The highertheECAis, themoreerrorinautopilotattitudecontrol willbe.
4. If thiscoefficientcontinuestoincreaseto1,000intheflight,thisindicatesthe
FY-21AP,FY-31APorFY-3ZTdonotmeettherequirementsofautomatedflight,soflight
control willbetransferredbacktoyou(manualflightor RCmode).
5. Thisisusuallycausedbyinstallationsthatresult inhigh vibrationsorshocktothe FY-21AP,
FY-31APorFY-3ZT.Youwillneedtocheckoradjusttheautopilotinstallationtoreduce
vibration.
lDisplay Modesselection
TheOSD canbecontrolledtoshowdifferentdisplayinformationviaonespare
channel of your radioRx.Thereare5optionaldisplaymodescontrolledbythedifferent
PWMsignals.Youcanusedefaultmodeifyoudonot wanttochange thedisplaymodes.
Howtochangethedisplaymodes:
Youcanusea2-wayswitchtochangethedisplaymodes, thePWMsignalof the
2-wayswitchis900μs ～1200μsand1800μs ～2100μs(inordertodescribethe
frequencyrangeconveniently,thePWMsignal “900μs ～1200μs”mightbecalled “L”
forshort ,and“1800μs ～2100μs”mightbecalled “H”forshort. ).
Thedefaultmodeis “A.Allinformationdisplayed”,ifyou wanttochangeto “B.
Default ModeWithartificialhorizon”,justoperateasfollowing:first theswitchisrequired
tobeplayedto “L”,thento “H”,youhavechangedthedisplaymodeforonetimebythis.
Savetheinformationafterchanging.WhentheOSD powersdownandrestarts,itwill
continue tokeepinthedisplayModeB.
Thatistosay,youcanchangethedisplaymodeforonetime byswitchingthe “L”to
“H”,thefivedisplaymodescanbeselectedbycircling inturn likethis. (Note:thefifth
displaymodeis “E. RemoveAllInformation”)
ModeBisdefault whenajumperisusedintheSWconnectorandpowerforthe
Hornet-OSD.
lThe modesare shown asbelow:
ModeA:All InformationDisplayed
ModeB:PartialDisplayWith ArtificialHorizon
Note: 9:Relativealtitude (Unit:meter)
A. Whenconnect withthe autopilot orFY-31AP willdisplaythebarometeraltitude.
B. WhenonlyGPS ReceiverisconnectedtotheHornet,GPS Altitudewillbe
displayed.
Mode C:RadarPositioningFunction
Mode D:BriefMode
lData recordofFY-21AP, FY-31AP,FY-3ZTand GPSmodule
Hornet-OSDcanautomaticallyrecordtheinformationof FY-21AP,FY-31AP,FY-3ZT
orGPS ReceiverconnectedtoitviaaninsertedMICROSD card.
Data naming:
IfnodataisreceivedbyHornetOSD,therecordeddataisnotedat “FEIYU***.txt”.
(“*** ”isarunningnumberfrom000to999),forexample, “FEIYU001.txt”.If4GPS
satellitesormorearedetected,thefilewillautomaticallyberenamedafterthedateand
timeof flight(month,day,hourandminute).Forexample,ifthedateisNov 14,eight
minutespasseight,the namewill be “11140808.txt”.
lFlightmode
WhenintheNAVmode(forFY-21AP:FixedAltitudeflyingmode;for
FY-3ZT/FY-31AP:Airrouteflymode),it willdisplaynotonlytheletter “NAV ”onthe
overlayinterface, butalsothecurrent waypointeverytwoseconds, socirculates.
---END---
Note:Wereservetherighttochangethismanual at anytime!And the newest
editionwillbeshown onourwebsite.
