Feniex S-2009 User manual
FENIEX. 2016 INSTRUCTION MANUAL
WEB. www.feniex.com
Feniex Product Copyrights This price List and the mentioned Feniex products include or describe copyrighted Feniex material. Laws in the
United States and other countries preserve for Feniex Industries and its licensors certain exclusive rights for copyrighted material, including the
exclusive right to copy, reproduce in any form, distribute and make derivative works of the copyrighted material. Accordingly, any copyrighted
material of Feniex and its licensors contained herein or in the Feniex products described in this Price List may not be copied, reproduced,
distributed, merged or modied,transmitted, transcribed, stored in retrieval system or translated into any language or computer language, in any
form or by any means, without prior written permission of Feniex Industries, Inc.. Feniex and the stylized Feniex logo are registered in the U.S.
Patent & Trademark Oce.
This instruction manual serves as a
guide for the Triton Speaker.
IMPORTANT! Please read through all
provided instructions and any listed
warnings in regards to product use.
Triton Speaker
Instruction Manual
V.2
TRITON
Model # - S-2009
V2.0
TM
FENIEX. 2016 INSTRUCTION MANUAL
WEB. www.feniex.com
2
Safety Regulations 3
Warranty 3
Service after Expiration 3
Copyright 3
Feniex Product Copyright 3
Equipment Dimensions 4
Features & Specications 5
Wiring Diagram
Triton Speaker 6
Mounting Instructions 7
Table of Contents
Operational times are from 10 a.m. to 5 p.m.
central time, Monday through Friday. Please
do not send in product without contacting
support rst for a RMA number.
Service After Expiration
Feniex Industries will still provide service for
all products after expiration of the warranty.
For any issues, call the customer support
line. In some instances it may be necessary
for the product to be shipped, freight prepaid
and insured for loss or damage to Feniex
headquarters.
Copyright
This instruction manual and the Feniex
products described in this instruction
manual may include or describe copyrighted
Feniex material. Laws in the United States
and other countries preserve for Feniex
Industries and its licensors certain exclusive
rights for copyrighted material, including
the exclusive right to copy, reproduce in
any form, distribute and make derivative
works of the copyrighted material.
Accordingly, any copyrighted material of
Feniex and its licensors contained herein
or in the Feniex products described in this
instruction manual may not be copied,
reproduced, distributed, merged or modied
in any manner without the express written
permission of Feniex Industries, Inc.
Feniex Product Copyrights
The products described in this document
are the property of Feniex Industries, Inc. It is
furnished by express license agreement only
and may be used only in accordance with the
terms of such an agreement. Products and
documentation are copyrighted materials.
Making unauthorized copies is prohibited by
law. No part of the product or documentation
may be reproduced, transmitted, transcribed,
stored in retrieval system or translated into any
language or computer language, in any form or
by any means, without prior permission from
Feniex Industries, Inc.
Safety Regulations
The following provides all the information
necessary to safely operate the previously
listed products of Feniex Industries, Inc.
Please read this manual thoroughly before
installing or operating your new product
in order to prevent any damage or injury.
Failure to follow the listed instructions in
this manual may result in damage to your
products or personal injury.
• Proper installation of this product
requires good knowledge of automotive
systems, electronics and procedures.
• Please guarantee all vital components
of the vehicle are not in danger of being
damaged by drilling holes necessary
for installation. Check all sides of the
mounting surface before drilling any
holes into the vehicle.
• Do not install this product in any way
that interferes with the deployment of
the air bag. Doing so may damage the
eectiveness of the air bag and can
lead to serious personal and vehicle
injury. The installer will assume full
responsibility of proper installation of the
new unit.
• Please clean the mounting surface
before installation of the unit when using
tape, brackets, magnet, Velcro or suction
cups.
• The product’s ground wire must be
connected directly to the Negative (-)
battery post for eective use of the
unit. Please follow all wiring guidelines
provided to guarantee long lifespan
and productivity. Failing to follow these
instructions may result in damage to the
product.
Warranty
Feniex Industries, Inc. warrants to the original
purchaser that the product shall be free from
defects in material and workmanship for sixty
(60) months from the date of purchase for all
LED products. Feniex Industries warranties
speakers, sirens and controllers for 24
months; switches and ashers for 12 months.
If a warranty problem occurs, please contact
customer support at 1.800.615.8350 or
visit the web site at www.Feniex.com. If the
product needs to be returned for repair or
replacement, call our customer support line
to receive a return merchandise authorization
number.
Warning! Utilizing non-factory screws and
mounting brackets may result in loss of warranty
coverage.
V2.0
TM
FENIEX. 2016 INSTRUCTION MANUAL
WEB. www.feniex.com 3
Safety Regulations & Warranty
V2.0
TM
FENIEX. 2016 INSTRUCTION MANUAL
WEB. www.feniex.com
4
Equipment Dimensions
7 in
7 5/8 in
Front View
Side View
Screw protrusion adds
7/8 of an inch
3 1/16 in
V2.0
TM
FENIEX. 2016 INSTRUCTION MANUAL
WEB. www.feniex.com
5
Features & specications
Triton System Specication
Neodymium Magnet
Impedance of 11 0hms
85 degree sound dispersion
Dimensions: 7”LX7”WX3”H
Power Raiting: 1000 Watts
Please Note! The Triton does not have a positive or negative speaker output wire.
V2.0
TM
FENIEX. 2016 INSTRUCTION MANUAL
WEB. www.feniex.com
6
Wiring Diagram
Step 1: The Triton speakers do not include
a siren unit. To activate the speaker, follow
OEM instructions for installing the siren
unit.
Please Note! The Triton doesn’t have a
positive or negative speaker output wire.
Step 2: To power a unit, extend both wires
to the output terminal of the siren system.
Follow siren OEM instructions to properly
connect the speaker unit to the siren
system. The Triton speaker does not have
a positive or ground wire.
Triton
Siren
Amplier
Speaker Output (From Siren)
Speaker Output (From Siren)
Typhoon 100W System Specication:
Brown
Blue
Wire Color: Function:
Figure 1.0
V2.0
TM
FENIEX. 2016 INSTRUCTION MANUAL
WEB. www.feniex.com
7
See the illustrations below for mounting
information.
Step 1: Clean the selected mounting
surface area.
Step 2: Using a 10 mm wrench, remove
the three bolts connecting the speaker to
the provided L-Shaped bracket. This will
detach the speaker from the bracket (see
gure 3.0 & 3.1).
Step 3: Place the L-Shaped bracket against
the selected mounting surface and mark
the spot for at least two mounting holes
(see gure 3.2).
Step 4: Drill a minimum of two, 0.25” holes
in the mounting surface, making sure not
to damage any vital components of the
mounting surface.
Step 5: Utilizing bolts larger than 0.25”,
secure the L-bracket to the surface mount.
Step 6: To install the speaker to the
bracket, pass the speaker wires through an
existing hole on the bottom of the bracket
(see gure 3.2).
Step 7: To reattach the speaker to the
bracket, place the three provided bolts
through the back of the L-bracket and
fasten the bolts.
L-Shaped Bracket:
Top View
Figure 3.2
Figure 3.3
L-Shaped Bracket: Front View Figure 3.1
L-Shaped
Bracket
Figure 3.0
Speaker
Triton Mounting Instructions
Screws
Table of contents
Other Feniex Speakers manuals
