Ferax BCD-1013 User manual

1 nstruktionsbok


Manual


Code no. 19694-0209

31
ENGLISH
Original instructions
CONTENTS
1. Introduction..........................................31
2. Technical specifications.......................31
3. Contents of packing .............................31
4. Product information .............................32
5 Safety instructions................................32
5.1 Specific safety instructions ..................32
5.2 Important safety notes on charger and
batteryblok ...........................................32
5.3 Electrical safety....................................33
5.4 Replacing cables or plugs ....................33
6 Mounting accessories...........................34
6.1 Fitting and removing drill cutters ........34
6.2 Connecting and removing the battery..34
7 Operation..............................................34
7.1 Adjusting the speed..............................34
7.2 Adjusting the torque ..............................35
7.3 Driving and removing screws..............35
7.4 Drilling.................................................35
7.5 Environment.........................................35
7.6 Charging the battery.............................35
8 Service & maintenance ........................36
8.1 Cleaning ...............................................36
8.2 Lubrication...........................................36
8.3 Faults....................................................36
8.4 Environment.........................................36
8.5 Guarantee .............................................36
Spare parts list...............................................55
EC conformity declaration............................56
1. INTRODUCTION
Read the operating instructions care-
fully before using this device.
Familiarise yourself with its functions
and basic operation. Service the device as per
the instructions to ensure that it always fun-
ctions properly. The operating instructions and
the accompanying documentation must be kept
in the vicinity of the device.
2. TECHNICAL SPECIFICATIONS
Voltage .......................................... V 10.8
Charger voltage............................. V 230
Charger frequency........................Hz 50
Battery output ............................. Ah 1.3
Charging time............................hour 3-5
Drill speeds ...................................... 2
No-load speed
Position I..................................r/min 0- 350
Position II.................................r/min 0-1250
Chuck capacity...........................mm 10
Lpa (acoustic pressure)..........dB(A) 68 +3
Lwa (acoustic power) ............dB(A) 79 + 3
Vibration ................................... m/s22.25+1.5
Vibration level
The vibration emission level stated in this
instruction manual has been measured in accor-
dance with a standardised test given in EN
60745; it may be used to compare one tool
with another and as a preliminary assessment
of exposure to vibration when using the tool for
the applications mentioned.
• Using the tool for different applications, or
with different or poorly maintainted accesso-
ries, may significantly increase the exposure
level.
• The times when the tool is switched off or
when it is running but not actually doing the
job, may signifi cantly reduce the exposure
level.
Protect yourself against the effects ofvibra-
tion by maintaining the tool and its acces-
sories, keeping your hands warm, and orga-
nizing your work patterns.
3. CONTENTS OF PACKING
1 Cordless drill
1 Battery
1 Battery charger
12 Bits
1 Operating instructions
1 Safety instructions

32
Check the appliance, any loose parts and acces-
sories for damage caused during transport.
4. PRODUCT INFORMATION
1
3
2
46
5
Fig. 1
1. On/off switch
2. Speed selector switch
3. Torque setting ring
4. Chuck
5. Battery
6. Direction switch
5. SAFETY INSTRUCTIONS
Explanation of the symbols
Denotes risk of personal injury, loss
of life or damage to the tool in case
of nonobservance of the instructions
in this manual.
Indicates electrical shock hazard.
The number of revolution of the
machine can be electronically set.
Do not use in rain.
Indoor use only
Li-Ion batteries can be recycled.
Drop them off at a disposal center for
chemical wastes, so that they can be
recycled or disposed of in an eco-
friendly manner.
Do not dispose of in household
waste.
Faulty and/or discarded electrical or
electronic apparatus have to be col-
lected at the appropriate recycling
locations.
5.1 Specific safety instructions
• This appliance is not intended for use by
persons (including children) with reduced
sensory or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instructions con-
cerning use of the appliance by a person
responsible for their safety.
• Childrenshouldbesupervisedtoensurethat
they do not play with the appliance.
• Holdthemachinebytheinsulatedgripping
surfaces where the accessory may contact
hidden wiring or the mains cable. If the
accessory contacts a ‚live‘ wire, the exposed
metal parts of the machine can also become
‚live‘. Risk of electric shock.
5.2 Important safety notes on charger
and batteryblok
If you come into contact with acid
from the battery block, rinse it off
with water immediately. If acid gets
into your eyes, rinse out your eyes at

33
once with water and contact a doctor immedia-
tely!
• Readandnotetheoperatinginstructionsand
safety notes for the charger and battery block
before use!
• NB!Onlyusethechargerandbatteryblock
that were supplied by the manufacturer - oth-
erwise you will risk an accident.
• Protectthecharger,batteryblockandpower
tool from moisture, e.g. rain or snow.
• Always check that all cables are connected
correctly before using the charger.
• Ifyoudiscoverthatacableisdamaged,you
should not use the charger again. Have the
damaged cable replaced immediately.
• When the charger is not in use, the mains
plug should be removed from the power
socket. Do not pull out the plug by grasping
the cable.
• Ifthechargerhasbeendroppedorhasother-
wise been exposed to high mechanical stres-
ses, you should have it checked for damage
by an authorised dealer before using it again.
Damaged parts should be repaired.
• Exercise caution when handling the bat-
tery block and do not drop it or expose it to
impacts.
• Neverattempttorepairthechargerorbattery
block yourself. Repairs must always be car-
ried out by an authorised dealer - otherwise
you risk an accident.
• Before cleaning or servicing the charger or
battery block, always pull the plug from the
charger socket.
• Never charge the battery block when the
ambient temperature is below 5 °C or above
40°C.
• The air vents in the charger must never be
blocked.
• Thebatteryblockmustnotbeshort-circuited.
A short-circuit will cause a high
current to flow. This may result in
overheating, the danger of fire or
explosion of the battery block.
This may damage the battery block or the
user may risk an accident.
Therefore:
•Do not connect any cables to the poles of
the battery block.
•Take care that there are no metal objects
(nails, paper clips, coins, etc.) on the con-
tact surface of the battery block.
•Donotexposethebatteryblocktowateror
rain.
•Only use the battery block supplied in
combination with this cordless drill/ screw-
driver so as to avoid faults and/or risks to
persons.
• Adamagedbatteryblockoronethatcanno
longer be charged must be disposed of as spe-
cial waste. Do not discard it with household
waste.
• Neverthrowthebatteryblockontoafireor
into water. This will risk explosion!
5.3 Electrical safety
Always check that the voltage on the
batterypack corresponds to the volta-
ge on the rating plate. Also check that
your mains voltage corresponds to
the input voltage of the battery char-
ger.
The battery charger is double insula-
ted in accordance with EN60335;
therefore no earth wire is required.
5.4 Replacing cables or plugs
Immediately throw away old cables or plugs
when they have been replaced by new ones. It
is dangerous to insert the plug of a loose cable
in the wall outlet.
• Removethebattery block.Whenthe power
tool is not being used, prior to maintenance
and when changing tools such as the clam-
ping chuck, and drill.
• Thetoolissuitableforuseasascrewdriver

34
and drill. Any other application is specifically
excluded.
6. MOUNTING ACCESSORIES
Prior to mounting an accessory
always remove the battery.
6.1 Fitting and removing drill cutters
(Fig. 2)
4
9
Cordless drill
230
V
~
50
Hz 10.8
V
0
-
350
/
min
/
0
-
1250
/
min
Fig. 2
In addition to drills, the tool can also acco
modate screwdriver bits with a hexagonal shaft.
• Loosen the drill chuck (4) by rotating the
hand-grip (9).
• Insert the shaft of the drill cutter into the
chuck.
• Tightenthedrillchucksothatthedrillcutter
is firmly clamped.
• Rotatethedrillchuckintheoppositedirec-
tion when you wish to change the cutter.
6.2 Connecting and removing the bat-
tery (Fig. 3)
5
10
Fig. 3
Ensure that the exterior of the battery
block or tool is clean and dry before
connecting the charger.
• Ensurethatthedirectionreversingswitch(6
Fig. 1) is in the central position in order to
prevent the appliance from being switched on
unexpectedly.
•Insertthebattery(5)intothebaseoftheapp-
liance, as shown on the illustration. Push the
battery until it latches in.
•Pressthelockingbuttons(10)onbothsides
before removing the battery, and disengage
the battery from the base of the appliance.
7. OPERATION
Always follow the safety notes and
the relevant safety code.
Hold the appliance firmly and press the drill
steadily onto the workpiece. Do not overload
the appliance. Only use drills with no visible
wear. Worn drills will have a bad effect on the
functioning of the appliance.
7.1 Adjusting the speed (Fig. 4)
6
Cordless drill
230
V
~
50
Hz 10.8
V
0
-
350
/
min
/
0
-
1250
/
min
Fig. 4
• Forslowdrillingorfordrivingorremoving
screws, set the speed selection switch (2) to
‘1’.
• Forfastdrillingsetthespeedselectionswitch
to ‘2’.

35
Never switch over when the motor is
running!
7.2 Adjusting the torque
• Setthetorqueadjustmentring(3)tothedesi-
red position. The available torque settings are
indicated on the adjustment ring by the num-
bers 1 to 22 and by dots between the figures
to define intermediate settings (22 in total).
• You should preferably choose as low a set-
ting as possible when using the screwdriver.
Select a higher setting if the motor slips.
7.3 Driving and removing screws
• Setthedirectionreversingswitch(6)toposi-
tion ‘R’ in order to drive screws.
• Setthedirectionreversingswitchtoposition
‘L’ in order to remove screws.
7.4 Drilling
• Rotatethetorqueadjustmentring(3)tothe
drilling position.
Ensure that the direction reversing
switch (6) is always set to ‘R’ during
drilling.
7.5 Switching the device on and off (Fig. 1)
• Depresstheon/offswitch(1).Itregulatesthe
speed of the appliance by transmitting power
to the switch.
• Release the on/off switch (1) to halt the drill
chuck immediately which will no longer run on.
• Move the direction reversing switch (6) to
the centre in order to lock the appliance in its
disabled state.
Only lay down the appliance when it has stop-
ped running completely. Do not place it on a
dusty surface as particles of dust could get into
the mechanism.
7.6 Charging the battery
• Placethebatteryinsidethecharger,asshown
on the illustration. Pay attention to + and -
pole markings.
• Insertthechargerplug intoapower socket.
The red rapid charging lamp should now be
illuminated.
• As soon as the green trickle charging lamp
lights up, charging has been completed and
the device is ready for operation.
Only use the charger in a dry envi-
ronment at temperatures between
5˚Cand40˚C.
The battery in your drill was not charged up at
the factory. Before using it for the first time,
you should charge it for approx. 1 – 2 hours so
that it reaches full capacity. The final capacity
of the battery is reached after 4 – 5 battery
cycles.
One advantage of using Lithium-Ion batteries
is that, until the battery is almost empty, hardly
any power fading is noticeable. The machine
can be used until you start noticing that the
power of the drill is elapsed. The battery is
discharged now and needs to be charged.
Lithium-Ion cells can be stored for a long peri-
od without losing much of their charge. When
the machine is not being used over a longer
period of time, it is best to store the battery in
charged condition.
When the cordless drill is not being
used over a longer period of time, the
battery has to be charged fully first.
The battery has to be stored in char-
ged condition.

36
8. SERVICE & MAINTENANCE
Make sure that the machine is not
live when carrying out maintenance
work on the motor.
The machines have been designed to operate
over a long period of time with a minimum of
maintenance. Continuous satisfactory opera-
tion depends upon proper machine care and
regular cleaning.
8.1 Cleaning
Keep the ventilation slots of the machine clean
to prevent overheating of the engine. Regularly
clean the machine housing with a soft cloth,
preferably after each use. Keep the ventilation
slots free from dust and dirt. If the dirt does not
come off use a soft cloth moistened with soapy
water. Never use solvents such as petrol, alco-
hol, ammonia water, etc. These solvents may
damage the plastic parts.
8.2 Lubrication
The machine requiers no additional lubrication.
8.3 Faults
Should a fault occur, e.g. after wear of a part,
please contact the service address on the war-
ranty card. In the back of this manual you find
an exploded view showing the parts that can be
ordered.
8.4 Environment
To prevent damage during transport, the app-
liance is delivered in a solid packaging which
consists largely of reusable material. Therefore
please make use of options for recycling the
packaging.
Faulty and/or discarded electrical or
electronic apparatus have to be col-
lected at the appropriate recycling
locations.
8.5 Guarantee
Warranty conditions and product liability apply
according to national legislation.

55
BCD- 1013 DIAGRAM

56
BCD- 1013 PART LIST
No. Description Specication Qty
1 Left housing 1
2 Right housing 1
3 screw M5×23 1
4 Keyless Chuck 1
5 Gear box Ass’Y 1
6 Spring 2
7 Speed change level 1
8 Label 1
9 screw ST3×16 7
10 Stapming spring plate 1
11 F/R level 1
12 LED light 1
No. Description Specication Qty
13 Lucid paster 1
14 Brand level 1
15 Fastener 2
16 screw ST2.6×5 2
17 Battery indicator PCB 1
18 Switch Ass’Y 1
19 Contact plate holder 1
20 Contact plate 2
21 Battery pack 1
22 Rear housing 1
23 screw ST3×16 4


�TM
ARETE S UPP LIES S . L .
www.aretesupplies.co m
Cordless drill
BCD-1013
