FERRANTI GREAT DANE User manual

ASSEMBLY MANUAL
INSULATED DOG HOUSE
MODEL GREAT DANE
Ferranti s.r.l. Unipersonale
Via Vicinato n. 43 - Frazione Fratta - 06036 Montefalco (PG) - Italy
Tel. [phone]
[email protected] - www.ferrantinet.com
Rel. 08-2022 - Rev. 0
EN - Translation from the original language (Italian)
126x103
208x103
ASSEMBLY MANUAL
INSULATED DOG HOUSE
MODEL GREAT DANE
Dear Customer,
Thank you for purchasing a FERRANTI product.
OBLIGATION
Please consult this assembly manual carefully
before proceeding with any operation on the
product.
INTRODUCTION
This assembly manual reects the technique at the time of purchase
and the specications in force at the current date of edition; it contains
the information necessary for correct installation, cleaning and disposal
of the product at the end of its life.
FERRANTI S.R.L. reserves the right to make modications, changes or
improvements to the manual or to the product at any time and without
notice.
Use only the original mounting components provided.
ATTENTION
The manufacturer is not liable for damage to
property, persons and animals caused by ac-
cidents due to failure to comply with the in-
structions in this assembly manual.
The images are purely indicative and do not constitute a commit-
ment for the manufacturer and/or the Distributor. Any proposal by the
Customer regarding improvements to be made to the product will be wel-
comed by FERRANTI S.R.L., which will evaluate their implementation.
INTENDED USE (PERMITTED USE).
The product in question has been designed for the housing and keep-
ing of animals. This type of dog house is the ideal shelter for large
dogs, of giant size (kg 40-75, cm 55-85) of the following types: Alano,
Bernese Mountain Dog, Rottweiler, Newfoundland, Male Dobermann,
Irish Greyhound, Corsican Dog, Neapolitan Masti󰀨, Maremma Sheep-
dog, Bull masti󰀨. It is durable, insulated and easily washable.
IMPROPER USE (NOT PERMITTED).
Any use other than the permitted one is to be considered “improper
use”; the Manufacturer therefore declines all responsibility for any dam-
age caused to property, animals and/or persons.
GENERAL DESCRIPTION
The insulated dog house, model Great Dane, consists of:
- insulated panels, thick 3.5 cm, framed in sheet metal
- 56x166 cm man-height door, with sturdy lock holder bolt
- Sliding hatch with gate 30 x 50 h, rimmed with metal anti-bite plate
- Internal platform in marine plywood raised above the ground by 7
cm, removable and washable.
OVERALL DIMENSIONS
126 x 103 208 x 103
External (WxDxH) 126 x 103 x 180 cm 208 x 103 x 180 cm
Interior (WxDxH) 119 x 95 x 167/155 cm 199 x 95 x 167/155 cm
W = Width / D = Depth / H = Height
Other dimensions on request.
UNPACKING
► Place the structure near the nal installation site and on a stable
and horizontal area of the ground.
►Remove the packaging materials taking care not to damage the
components.
ATTENTION
DANGER! Keep out of the reach of chil-
dren and animals.
Packaging materials (plastic bags, straps, etc.) can be a source of
danger to health (e.g. su󰀨ocation).
►Divide the packaging materials according to their type and dispose
of them in accordance with the provisions in force regarding the
disposal of waste.
RECYCLING
All the packaging materials are recyclable and
must be disposed of in accordance with the lo-
cal legislation.

ASSEMBLY MANUAL
INSULATED DOG HOUSE
MODEL GREAT DANE
Ferranti s.r.l. Unipersonale
Via Vicinato n. 43 - Frazione Fratta - 06036 Montefalco (PG) - Italy
Tel. [phone]
[email protected] - www.ferrantinet.com
Rel. 08-2022 - Rev. 0
EN - Translation from the original language (Italian)
Fig. 1 ASSEMBLY DIAGRAM
STANDARD EQUIPMENT
1Bracket
2Screws M8x50
3Nuts M8
4Screws M8x60
5
Expanded
gaskets/rhom-
boid washers
INSTALLATION
2x The assembly operations must be performed
by at least two persons.
For the assembly of the products, the use of Perso-
nal Protective Equipment is always recommended:
work gloves to protect the hands from the danger of
being cut.
RECOMMENDED TOOLS
Slotted Screwdriver - Cross Head Screwdriver - Wrench - Cutter.
Note: Tighten the screws completely only at the end and after checking
the square of the structure.
RECOMMENDED TOOLS
Slotted Screwdriver - Cross Head Screwdriver - Wrench - Cutter.
Note: Tighten the screws completely only at the end and after checking
the square of the structure.
1A − Assembly of the rear wall to the side panels
►Remove the brackets (1), screws (2) and nuts (3) from the kit
supplied.
1) Place the brackets (1) in the inner part at the holes provided
on the wall (B).
Note: to facilitate insertion, it is advisable to force the panel frames
with a screwdriver, at the points highlighted by the arrows.
2) Secure with the screws (2) and nuts (3).
3) Attach the front wall (C) to the side walls (B) in the same way.
1B − Roof assembly
►Remove the screws (4) and gaskets (5) from the kit supplied.
1) Place the roof (D) over the structure; in the inner part of the bed,
attach the brackets (1) as indicated in point 1).
2) Secure with screws (4) and gaskets (5).
The 200x300 model has an extra bracket to be attached on the
wall (A).
1C − Assembly of the platform
►Open the door and pass the platform (E) inside the bed and place
it in contact with the base.
CLEANING
CLEANING
Clean the structure periodically (or in the presence of
obvious dirt). Sanitise, disinfect and clean the inside of the
kennel with suitable products that are not harmful to the he-
alth of the person and the animal.
SCRAPPING AND DISPOSAL
RECYCLING
The materials that compose the structure must be dispo-
sed of according to the type and procedures provided for
by the legislation in force in the country of installation.
For further detailed information on the disposal of this product, contact
the municipal o󰀩ce, the local waste disposal service or the store where
it was purchased.
1
2
3
4
5
A
C
D
B
B
1
2
3
A
B
External
Interior
Interior
1
4
3
D
A
D
45
D
E
1A
1C
1B
External
2x
