Field Controls FC95HRV Operation and Specification sheet

69-Field
0412
Heat Recovery Ventilators
Operation and nstallation Manual
This product earned the ENERGY STAR by
meeting strict energy efficiency guidelines set by
Natural Resources Canada and the US EPA. It
meets ENERGY STAR requirements only when
used in Canada.
*
FC95HRV*
FC155HRV
FC200HRV*
FC150ERV

Getting to Know your eat and Energy Recovery Ventilator
Ventilation and Control Options
ow the Dehumidistat Works (Colder Climates)
Glossary and Additional Information
Warranty........................................................................................3
ealthy ome System™ Control ( SC)
Dehumidistat .................................................................................4
Dehumidistat Ventilation Control .................................................5
Optional Vent Timer Control ........................................................6
Maintenance Routine for RV .....................................................7
Technical Data - Model FC95 RV ...........................................8-9
Technical Data - Model FC155 RV ..........................................10
Technical Data - Model FC200 RV ..........................................11
Technical Data - Model FC150ERV...........................................12
Installation Methods....................................................................13
Installation Diagrams.............................................................14-16
Installation
Suspend the Unit with the Adjustable anging Straps ...............17
Drain Connection and Grilles .....................................................18
Weatherhood Installation ............................................................19
Installation of the Dehumidistat or
Dehumidistat Ventilation Control ...............................................20
Installation and Operation of 20 Minute and
20/40/60/ Minute Timers.............................................................21
Installation of the ealthy ome System Control ( SC) ..22-23
Installation of the SC with the D 1
and 20/40/60 Minute Timers (test a)...........................................24
Installation of the D VC Ventilation Control
with 20/40/60 Minute Timers (test c)..........................................25
Interlocking RV/ERV to an Air andler/Furnace Blower
Setting “Standby” when using a Main Control
Operating the RV/ERV without a Main Control and
Adding Dry Contacts..................................................................26
Balancing the Air Flows..............................................................27
Balancing the Air Flows with a Pitot Tube.................................28
Air Flow Balancing using the Door Ports ...................................29
Balancing Dampers .....................................................................30
Troubleshooting your RV/ERV System...................................31
Wiring Diagram ..........................................................................32
2
Table of Contents
MPORTANT -
PLEASE READ TH S MANUAL
BEFORE NSTALL NG UN T.
CAUTION
Before installation, careful consideration must be
given to how this system will operate if connected
to any other piece of mechanical equipment, i.e. a
forced air furnace or air handler, operating at a
higher static. After installation, the compatibility of
the two pieces of equipment must be confirmed, by
measuring the air flows of the HRV, by using the
balancing procedure found in this manual.
NEVER install a ventilator in a situation where its
normal operation, lack of operation or partial
failure may result in the backdrafting or improper
functioning of vented combustion equipment.
WARNING
• Disconnect the power from the unit before
cleaning or servicing.
• To prevent electrical shock, it is extremely
important to confirm the polarity of the power line
that is switched by the safety (disconnect) switch.
The hot line (black) is the proper line for switching.
Use either a voltmeter or test lamp to confirm the
absence of a voltage between the disconnect
switch and ground (on the cabinet) while the door
is open. This procedure must be followed, as
dwellings are occasionally wired improperly.
Always enure the proper grounding of the unit.
ATTENTION
• Do not apply electrical power to the unit until after
the completion of the installation (including the
installation of low voltage control wiring).
• Ensure the nstallation and wiring is in
accordance with CEC, NEC, and local electrical
codes.
• Due to ongoing research and product
development, specifications, ratings, and
dimensions are subject to change without notice.
• Plug the unit into a standard designated (120
VAC) electrical outlet with ground.
•The use of an extension cord with this unit is not
recommended. f the installation requires further
wiring, have a licensed electrician make all of the
electrical connections. The recommended circuit is
a separate 15 amp/120 volt circuit.
NOTE
• Due to ongoing research and product
development, specifications, ratings, and
dimensions are subject to change without notice.

3
Thank you for purchasing a Field Control eat/Energy Recovery
Ventilator ( RV/ERV). The RV/ERV provides fresh air to your
home while recovering energy from the air it exhausts.
There are numerous benefits to a properly installed, operated, and
maintained RV/ERV:
• Exhausts the stale, contaminated air, found in today’s tight
buildings.
• Recovers the majority of the energy contained in the exhausted
stale air.
• Uses the recovered energy to preheat or precool the fresh outdoor
air introduced into the house
• Distributes the fresh air throughout your home.
Getting to Know your Heat and Energy Recovery Ventilator (FC Series)
Optional Controls are available to adjust the amount of ventilation
in your home:
• The ealthy ome System™ Control ( SC) will automatically
deliver fresh air to your home.
• The Dehumidistat Control (D I) can be used in conjunction with
the SC to provide additional ventilation for high indoor
humidity levels.
• The Dehumidistat Ventilation Control (D VC) is a manual
control which features ON/OFF, igh speed, Low Speed, and an
electronic dehumdistat.
*Refer to the individual control pages of this manual for more
information about these controls.
Ventilation and Control Options*
igh indoor humidity levels, during the heating season, have
become a problem in many well insulated, tight homes. Excessive
condensation on the windows is a visual sign of high indoor
humidity levels. igh indoor humidity levels can result in mold and
mildew and the eventual degradation of the building structure itself.
Your RV/ERV reduces indoor humidity levels when the
outdoor air is drier than the indoor air. These conditions usually
occur during the heating season when outdoor temperatures are less
than 15°C (59°F). During the heating season, the operation of the
RV/ERV may reduce indoor humidity levels sufficiently to
eliminate the need for further dehumidification.
If your home requires further dehumidification, use the
dehumidistat feature located on any optional main control (refer to
the Oper tion nd Inst ll tion M nu l for Optional Control
information). This feature aggressively addresses high indoor
humidity levels by initiating high speed ventilation when the indoor
humidity levels rise above the adjustable set point on the control.
Refer to the main control instructions located in the Oper tion nd
Inst ll tion M nu l for instructions on how to set the dehumidistat.
The dehumidistat function on the main control should be set to OFF
for all seasons except the heating season, because a dehumidifying
effect occurs only when the outdoor air is dryer than the indoor air.
Set the R level to 80 to turn the dehumidistat OFF. (Refer to the
control instructions for information on how to set the
Dehumidistat).
DEHUMIDISTAT DISABLE - automatically disables the
dehumidistat function on the main control when outdoor
temperatures exceed 15°C (59°F) for a full 24 hour period. All other
RV features and functions operate normally while the
dehumidistat function is disabled.
DEHUMIDISTAT RE-ENABLE - automatically re-enables the
dehumidistat function if either the outdoor temperature drops below
15°C (59°F) for a full 24 hour period or if the RV is reset
(unplugged for 30 seconds).
How the Dehumidistat Works (Colder Climates)
DEFR ST M DE - To ensure reliable operation during cold
weather, the RV automatically cycles through its defrost mode
when the outdoor temperatures drop below freezing.
HRV/ERV - a eat Recovery Ventilator ( RV/ERV) is designed
to provide fresh air into a building while exhausting an equal
amount of stale air. During the winter months, heat recovered from
the stale air, before it is exhausted to the outdoors, warms the
incoming cold fresh air. During the summer months, when the
indoor space is air conditioned, the RV/ERV helps to cool the
incoming fresh air with the cool exhausted stale air.
SELF-TEST - Each time the RV/ERV is powered/energized, the
self-test function automatically initiates. The RV/ERV cycles
through the available speeds and tests the damper motor operation.
The RV/ERV defaults back to the previous operational mode and
speed selection after the self-test (approximately 60 seconds in
duration).
STANDBY - The RV/ERV is powered/energized and waiting for
ventilation to be initiated by an external control.
TIMERS - These optional controls may be installed at specific
exhaust locations (bathrooms etc.) to initiate high speed ventilation.
eat Recovery Ventilators ( RV) carry a Lifetime Warranty on the
heat recovery core and a 5 (five) year replacement parts warranty.
Energy Recovery Ventilators (ERV) carry a 5 (five) year warranty
on the energy recovery core and a 5 (five) year replacement parts
warranty.
Glossary and Additional nformation
Warranty

Your RV/ERV system produces a dehumidifying effect when
outdoor humidity levels are lower than indoor humidity levels.
These conditions occur normally when outdoor termperatures are
below 60°F. An additional dehumidification effect is achievable
with the Optional Dehumidistat (Part D 1).
The Optional D 1 Control may be combined with the ealthy
ome System Control ( SC). The D 1 will initiate high speed
ventilation when the moisture level in the home exceeds the set
point on the control. Once the humidity in the house is reduced,
the RV will revert back to the SC automatic setting. The
Dehumidistat should be set to OFF for all seasons except the
heating season.
Dehumidistat (Part DH1)
Healthy Home System Control (HHSC)



Dehumidistat ndicator
LEDs
Set to the desired humidity
level. igh speed ventilation
will initiate when the indoor
moisture level exceeds the set
point on the control.
Dehumidistat
Adjust button
The ealthy ome System Control ( SC) activates the
RV/ERV automatically to deliver fresh air into your home.
Setting the Control
The duration of the ventilation rate is adjustable on the SC.
Your installer sets up this control during the installation of your
system . Refer to the instructions that came with the SC for the
setup information.
The Healthy Home System™ Control (HHSC)
4

The Dehumidistat Ventilation Control offers ON/OFF, igh
Speed/Low speed plus an electronic dehumidistat.
Key Features
• 2 Speed Fan setting (Low/ igh)
• Electronic Dehumidistat
• Instruction Card is inserted in the control
• Slim-line design
• Connect to 3 wire 20 gauge low voltage wire.
Turning on the Control
Press and release the ON/OFF button. The "ON Indicator Light"
will illuminate.
Adjusting the Ventilation Speed
The unit will normally operate at low speed. Press and release the
SPEED button to initiate high speed ventilation. The " igh Speed
Indicator LED" will illuminate.
Humidity Control
Your unit will produce a dehumidifying effect when outdoor
humidity levels are lower than indoor humidity levels. Never use
the dehumidistat feature when outdoor temperatures are above
59° F (15° C).
Setting the Dehumidistat
Press and release the DE UMIDISTAT button until the
DE UMIDISTAT LED is at the desired setting. After 5 seconds
the dehumidistat light will either flash or be on continuous.
A flashing light indicates the humidity level is higher than the
setting and the unit is operating on high speed ventilation. A
continuous light indicates the humidity level is lower than the
setting.
5
The Dehumidistat Ventilation Control Part #DHVC




nstruction card
Dehumidistat
ndicator LEDs
ON/OFF
button
High/Low
Speed
button
High Speed
ndicator LED
On
indicator
light
* nstall a jumper between 2 (ON) and 3 (RED) on the
HRV/ERV terminal block to configure the ON/OFF
button to ON/STANDBY. Refer to “Setting Standby
when using a Main Control” in this manual.
ATTENTION

The timer will override the Operational Mode (regardless of the
setting) and initiate high speed ventilation. Upon completion of the
timer cycle, the RV/ERV returns to your selected Operational
Mode and speed setting.
Lifestyle 20/40/60 Minute Timer
Initiates high speed ventilation for 20, 40 or 60 minutes. The
20/40/60 Minute Status Lights indicate high speed operation.
Lockout Mode is useful if you wish to disable the timer. Set
lockout by holding the Select Button for 5 seconds. Unlock by
holding for 5 seconds.
Optional Vent Timer Control (VTC)
Select Button
20/40/60 Minute
Status Lights
f the system does not have a main control
installed, the HRV/ERV Terminal Block must have
a jumper installed between 2 (ON) and 3 (RED).
Refer to “Operating the HRV/ERV without a Main
Control” in this manual.
ATTENTION
6

1. nspect Exterior Hoods at least once a month.
Make sure exhaust and fresh air supply hoods are not blocked or
restricted by leaves, grass, or snow. In winter, it is especially
important to make sure snow is not blocking the hoods or that frost
has not built up on the wire mesh (bird screen).
WARNING: Block ge of hoods m y c use n imb l nce.
2. Clean Air Filters (clean twice a year)
The standard filters equipped with your RV are removable and
washable.
a) simply open access door and slide core out
b) remove filter clips
c) once clips are removed filters can be taken off the core to be
rinsed with water or a combination of mild soap and water. Do
not clean in the dishwasher
d) to re-assemble, place clean filter(s) (wet or dry) back into their
positions against the core and return clips to their original
position
e) slide core back into its’ original position
3. Clean Core Twice a Year
a) open access door.
b) carefully grip ends of core and pull evenly outward. Core may
be snug, but will slide out of the channel
c) once removed from the cabinet remove filters
d) wash core in warm soapy water (do not use dishwasher)
e) install the clean filters
f) install clean core
Note: Core inst ll tion l bel on the outer end of the core.
To install the clean core:
a) first mount the bottom flange of the core guide into the bottom
channel approximately 1/4” (6mm)
b) mount the left or right side flange of the core guide
approximately 1/4” (6mm) followed by the other side
c) mount the top flange of the core guide into the top channel
approximately 1/4” (6mm).
d) with all four corners in place and the core straight and even,
push hard in the centre of the core until the core stops on the
back of the cabinet.
NOTE: Core will ppe r to stick out from c binet pproxim tely 1/8”
(3mm). This is designed this w y so th t the ccess door will fit tight
g inst the core.
4. Motors - Maintenance Free
5. Drain (condensate) Line - Clean once a year
Inspect drain line, drain spout, and “P” trap for blockage, mould or
kinks. Flush with warm soapy water and replace if worn, bent or
unable to clean.
6. Clean Duct Work if Required
The duct work running to and from the RV may accumulate dirt.
Wipe and vacuum the duct once every year. You may wish to
contact a eating/Ventilation company to do this.
7. General Maintenance - Twice a Year
Wipe down the inside of the cabinet with a damp cloth to remove
dirt, bugs, and debris that may be present.
8. Cleaning the Fans
Fans may accumulate dirt causing an imbalance and/or excessive
vibration of the RV. A reduction in the air flow may also occur.
In new construction this may result within the first year due to
heavy dust and may occur periodically after that over time
depending on the outdoor conditions.
• unplug the RV and open the service door
• remove the core
• remove ducting (metal and/or flexible insulated type) from
the red and/or blue ports which are connected immediately
in-line with the fan assembly
• use a small brush, such as an old toothbrush or pipe cleaner,
and insert first
(a) through the large opening of the fan
assembly and then
(b) through the smaller opening in the end
of the fan assembly.
• scrub individual fan blades until clean. Avoid moving or
damaging balancing flat weight, clip is usually found on one
or more of the fan blades
• vacuum and wipe
• reassemble making sure ducting is reattached firmly and
insulation and moisture barrier are sealed and taped
Before ttempting this t sk, thought should be given to h ving
qu lified service technici n complete the service work.
Maintenance Routine for HRV
Electric shock hazard. Can cause
injury or death. Before attempting to
perform any service or maintenance,
turn the electrical power unit OFF at
disconnect switch(es). Unit may have
multiple power supplies.
WARNING
7

THERMALLY CONDUCT VE, PATENTED ALUM NUM CORE
The cross-flow heat recovery core transfers heat between the two
airstreams. It is easily removed for cleaning or service.
MOTORS AND BLOWERS
Each air stream has one centrifugal blower driven by a common PSC
motor. The unit has a 2 speed fan operation.
F LTERS
Washable air filters in exhaust and supply air streams.
MOUNT NG THE HRV
Four threaded inserts at corners of the cabinet designed to accept the “S”
hooks and hanging straps supplied with the unit.
DEFROST
Recirculating defrost system.
CASE
Twenty gauge prepainted galvanized steel (G60) for superior corrosion
resistance. Insulated to prevent exterior condensation. Drain connections
2 - 1/2" (12 mm) OD.
WE GHT 52 lbs. (23.6 kg) SH PP NG WE GHT 56 lbs (25.4 kg)
ELECTRON CS
• Built-in Relay for Interfacing to furnace
OPT ONAL CONTROLS
# DHVC Ventilation Control
• 2 Speed Fan setting (Low/ igh) • Dehumidistat
#HHSC Healthy Home System Control
• Automatically activates the unit to deliver fresh air into your home
#DH1 Dehumidistat
• Initiates high speed ventilation when the indoor humidity level exceeds
the set point
OPT ONAL T MERS
#VTC Ventilation Timer Control - Initiates high speed ventilation
for 20, 40, or 60 minutes, (3 wire) 20 gauge wire (min.) 100'
length
OPT ONAL ACCESSOR ES
#WH 185 Weatherhoods, Two - 5” (125 mm) c/w 1/4” (6 mm) mesh
screen
WARRANTY
Units carry a LIFETIME warranty on the
heat recovery core and a 5 year
replacement parts warranty.
All units conform to CSA and UL standards.
Date: ___________________________________________
Tag: _____________________Qty:___________________
Project: _________________________________________
Engineer: _______________________________________
Contractor: ______________________________________
Supplier: ________________________________________
Quote#: _________________________________________
Submitted by: ____________________________________
*Sensible Efficiency – thermal **Latent Efficiency – moisture
Note: Effectiveness - b sed on temp. differenti l between the 2 irstre ms
Efficiency – t kes into ccount ll power inputs
Performance (HV certified)
Net su ly air flow in cfm (L/s) against external static ressure
E.S.P
(external static pressure) [c m (L/s)]
@0.1" (25 Pa) 76 (36)
@0.2" (50 Pa) 73 (34)
@ 0.3" (75 Pa) 70 (33)
@ 0.4" (100 Pa) 66 (31)
@ 0.5" (125 Pa) 60 (29)
Max. Temperature Recovery 88%
Sensible Effectiveness
@ 60 cfm (28 L/s) 32°F (0°C) 88%
*Sensible Efficiency
@ 60 cfm (28 L/s) 32°F (0°C) 75%
*Sensible Efficiency
@ 61 cfm (29 L/s) -13°F (-25°C) 68%
VAC @ 60HZ 120
WATTS / Low speed. 59
WATTS / High speed 150
Amp rating 0.9
Static Pressure (in w.g.)
Air Flow(cfm)
Speed 2
Speed 1
20
30
40
50
60
70
0 0.1 0.2 0.3 0.4 0.5 0.6
80
1 - Low Speed
2 - High Speed
Removable
Heat Recovery
Core
Drain Pan
Drain spout
FRONT TOP
minimum
18 inches (459 mm)
required for
service access
Threaded
inserts (4)
at corners
SUPPLY
Fresh air
from outside
5" round collar
SUPPLY
Fresh air
to building
6" round
(conv. to oval)
collar
EXHAUST
Stale Air
to outside
5" round collar
EXHAUST
Return air
from building
6" round (conv. to oval)
collar
18.5"
(470 mm)
18.5"
(470 mm)
16"
(406 mm)
SIDE
Hanging
straps (4)
24.5"
(622 mm)
D MENS ONS FC95HRV inches (mm)
Model FC95HRV
8

Port Configuration and Airflow Model FC95HRV
In order to make the RV as space efficient as possible, the
INDOOR supply and return ports are converted from round to oval
shape. Overall size of the port remains the same. Simply bend a
standard duct fitting to the correct shape, and attach to the oval
port using the same method as for a round port.
FC95HRV Air Flow
Stale air enters the FRONT-RIG T side port. The air passes down
the front half of the core, then up the back half of the core and out
the RIG T-REAR port.
Fresh outdoor air enters the LEFT-REAR port and passes down
the back half of the core. Then the fresh outdoor air passes up the
front half of the core and out the LEFT-FRONT port. This
configuration allows the air to actually travel through the core
twice, which makes the FC95 RV nearly as efficient as a double
core unit.
Round port bent to oval
9

THERMALLY CONDUCT VE, PATENTED ALUM NUM CORE
The cross-flow heat recovery core transfers heat between the two
airstreams. It is easily removed for cleaning or service.
MOTORS AND BLOWERS
Each air stream has one centrifugal blower driven by a common PSC
motor. 2 speed fan operation.
F LTERS
Washable air filters in exhaust and supply air streams.
MOUNT NG THE HRV
Four threaded inserts at corners of the cabinet designed to accept the “S”
hooks and hanging straps supplied with the unit.
DEFROST
Recirculating damper defrost system.
CASE
Twenty gauge prepainted galvanized steel (G60) for superior corrosion
resistance. Insulated to prevent exterior condensation. Drain connections
2 - 1/2" (12 mm) OD. Balancing ports are located in the door.
WE GHT 71 lbs. (32.5 kg) SH PP NG WE GHT 73 lbs. (33.5 kg)
ELECTRON CS
• Built-in Relay for Interfacing to furnace
OPT ONAL CONTROLS
# DHVC Ventilation Control
• 2 Speed Fan setting (Low/ igh) • Dehumidistat
#HHSC Healthy Home System Control
• Automatically activates the unit to deliver fresh air into your home
#DH1 Dehumidistat
• Initiates high speed ventilation when the indoor humidity level exceeds
the set point
OPT ONAL T MERS
#VTC Ventilation Timer Control - Initiates high speed ventilation
for 20, 40, or 60 minutes, (3 wire) 20 gauge wire (min.) 100'
length
OPT ONAL ACCESSOR ES
#WH 186 Weatherhoods, Two - 6” (150 mm) c/w 1/4” (6 mm) mesh
screen
D MENS ONS FC155HRV inches (mm)
Model FC155HRV
All units conform to CSA and UL standards.
Date: ___________________________________________
Tag: _____________________Qty:___________________
Project: _________________________________________
Engineer: _______________________________________
Contractor: ______________________________________
Supplier: ________________________________________
Quote#: _________________________________________
Submitted by: ____________________________________
*Sensible Efficiency – thermal **Latent Efficiency – moisture
Note: Effectiveness - b sed on temp. differenti l between the 2 irstre ms
Efficiency – t kes into ccount ll power inputs
Performance (HV certified)
Net su ly air flow in cfm (L/s) against external static ressure
E.S.P
(external static pressure) [c m (L/s)]
@0.1" (25 Pa) 144 (68)
@0.2" (50 Pa) 134 (63)
@ 0.3" (75 Pa) 125 (59)
@ 0.4" (100 Pa) 113 (53)
@0.5" (125 Pa) 92 (43)
@ 0.6" (150 Pa) 73 (34)
Max. Temperature Recovery 78%
Sensible Effectiveness
@65 cfm (31 L/s) 32°F (0°C) 73%
*Sensible Efficiency
@ 65 cfm (31 L/s) 32°F (0°C) 64%
*Sensible Efficiency
@ 68 cfm (32 L/s) -13°F (-25°C) 66%
VAC @ 60HZ 120
WATTS / Low speed. 49
WATTS / High speed 120
Amp rating 1.4
2
1
20
40
60
80
100
120
140
160
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7
Static Pres sur e (in w .g.)
Air Flow (cfm)
2 - High Speed
*1 - Low speed
*Manufacturers Data
2
WARRANTY
Units carry a LIFETIME warranty on the heat
recovery core and a 5 year replacement parts
warranty.
BALANCING DAMPER
33 5/8"
(850mm)
STALE AIR
FROM INSIDE
FRESH AIR
FROM OUTSIDE
STALE AIR
TO OUTSIDE
FRESH AIR
TO INSIDE
14 3/4"
(375)
19"
(483)
*All Duct Connections 6" (150mm)
CONDENSATE DRAINS
FILTERS
BLOWERS
*NOTE: Front clearance of 25 inches (635 mm)
is recommended for servicing unit.
RECIRCULATING
DEFROST
DAMPER
MOTOR
CORE
BALANCING DAMPER
10

D MENS ONS FC200HRV
inches (mm)
Model FC200HRV
All units conform to CSA and UL standards.
THERMALLY CONDUCT VE, PATENTED ALUM NUM CORE
The cross-flow heat recovery core transfers heat between the two
airstreams. It is easily removed for cleaning or service.
MOTORS AND BLOWERS
Each air stream has one centrifugal blower driven by a common PSC
motor. 2 speed fan operation.
F LTERS
Washable air filters in exhaust and supply air streams.
MOUNT NG THE HRV
Four threaded inserts at corners of the cabinet designed to accept the “S”
hooks and hanging straps supplied with the unit.
DEFROST
Recirculating damper defrost system.
CASE
Twenty gauge prepainted galvanized steel (G60) for superior corrosion
resistance. Insulated to prevent exterior condensation. Drain connections 2
- 1/2" (12 mm) OD. Balancing ports are located in the door.
WE GHT 71 lbs. (32.5 kg) SH PP NG WE GHT 73 lbs (33.5 kg)
ELECTRON CS
• Built-in Relay for Interfacing to furnace
OPT ONAL CONTROLS
# DHVC Ventilation Control
• 2 Speed Fan setting (Low/ igh) • Dehumidistat
#HHSC Healthy Home System Control
• Automatically activates the unit to deliver fresh air into your home
#DH1 Dehumidistat
• Initiates high speed ventilation when the indoor humidity level exceeds
the set point
OPT ONAL T MERS
#VTC Ventilation Timer Control - Initiates high speed ventilation
for 20, 40, or 60 minutes, (3 wire) 20 gauge wire (min.) 100'
length
OPT ONAL ACCESSOR ES
#WH 186 Weatherhoods, Two -6” (150 mm) c/w 1/4” (6 mm) mesh
screen
Date: ___________________________________________
Tag: _____________________Qty:___________________
Project: _________________________________________
Engineer: _______________________________________
Contractor: ______________________________________
Supplier: ________________________________________
Quote#: _________________________________________
Submitted by: ____________________________________
*Sensible Efficiency – thermal **Latent Efficiency – moisture
Note: Effectiveness - b sed on temp. differenti l between the 2 irstre ms
Efficiency – t kes into ccount ll power inputs
Performance (HV certified)
Net su ly air flow in cfm (L/s) against external static ressure
E.S.P
(external static pressure) [c m (L/s)]
@ 0.1" (25 Pa) 207 (97)
@0.2" (50 Pa) 200 (94)
@ 0.3" (75 Pa) 184 (87)
@ 0.4" (100 Pa) 171 (80)
@0.5" (125 Pa) 152 (71)
@0.6" (150 Pa) 130 (61)
@ 0.7" (175 Pa) 116 (55)
@ 0.8" (200 Pa) 86 (40)
Max. Temperature Recovery 74%
Sensible Effectiveness
@ 66 cfm (31 L/s) 32°F (0°C) 74%
*Sensible Efficiency
@ 66 cfm (31 L/s) 32°F (0°C) 64%
*Sensible Efficiency
@ 109 cfm (51 L/s) -13°F (-25°C) 62%
VAC @ 60HZ 120
WATTS / Low speed. 87
WATTS / High speed 164
Amp rating 1.4
LOW
Hi 1
Hi 2
Hi 3
40
60
80
100
120
140
160
180
200
220
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9
Static Pressure (in w.g.)
Air Flow (cfm)
Hi 3 - High Speed
Hi 2 - Medium High Speed
Hi 1 - Medium Speed
Low - Low speed
*Manufacturers Data
WARRANTY
Units carry a LIFETIME warranty on the heat
recovery core and a 5 year replacement parts
warranty.
BALANCING DAMPER
33 5/8"
(850 mm)
STALE AIR
FROM INSIDE
FRESH AIR
FROM OUTSIDE
STALE AIR
TO OUTSIDE
FRESH AIR
TO INSIDE
14 3/4"
(375 mm)
19"
(483 mm)
*All Duct Connections 6" (150 mm)
CONDENSATE DRAINS
FILTERS
BLOWERS
*NOTE: Front
clearance
of 25 inches
(635 mm)
is recommended
for servicing unit.
RECIRCULATING
DEFROST
DAMPER
MOTOR
CORE
BALANCING DAMPER
All Duct Connections 6” (160 mm)
NSTALLER SELECTABLE H GH SPEED SETT NGS
Adjustable DIP switches are located on the circuit board. i3 is
the factory setting. Refer to the Operation and Installation
manual for the adjustment instructions.
11

12
STALE AIR
TO OUTSIDE
FRESH AIR
FROM OUTSIDE
STALE AIR
FROM INSIDE FRESH AIR
TO INSIDE
14
3
/4"
(375)
19"
(483)
*All DuctConnections6"(150mm)
FILTERS
BLOWERS
*NOTE: Frontclearance
of 25 inches(635 mm)
is recommended
for servicingunit.
MOTOR
ENTHALPIC CORE
33-5/8"
(850)
BALANCING
DAMPER
BALANCING
DAMPER
CORE
Model FC150ERV
D MENS ONS FC150ERV inches (mm)
Date: ___________________________________________
Tag: _____________________Qty:___________________
Project: _________________________________________
Engineer: _______________________________________
Contractor: ______________________________________
Supplier: ________________________________________
Quote#: _________________________________________
Submitted by: ____________________________________
All units conform to CSA and UL
standards.
Static Pressure (in w.g.)
Air Flow (cfm)
20
40
60
80
100
120
140
160
180
200
220
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
1 - Low speed
2 - High Speed
2
1
*Sensible Efficiency – thermal **Latent Efficiency – moisture
Note: Effectiveness - b sed on temp. differenti l between the 2 irstre ms
Efficiency – t kes into ccount ll power inputs
Performance
Net su ly air flow in cfm (L/s) against external static ressure
E.S.P
(external static pressure) [c m (L/s)]
@ 0.1" (25 Pa) 151 (71)
@0.2" (50 Pa) 140 (66)
@ 0.3" (75 Pa) 131 (62)
@0.4" (100 Pa) 123 (58)
@ 0.5" (125 Pa) 107 (50)
@ 0.6" (150 Pa) 98 (46)
@ 0.7" (175 Pa) 81 (38)
@0.8 " (200 Pa) 60 (28)
Sensible Effectiveness
@ 64 cfm (30 L/s) 32°F (0°C) 81%
*Sensible Efficiency
@64 cfm (30 L/s) 32°F (0°C) 69%
Total Efficiency 50%
@ 64 cfm (30L/s) 95°F (35°C) 47%
VAC @ 60HZ 120
WATTS / Low speed. 63
WATTS / High speed 173
Amp rating 1.4
LATENT RECOVERY/MO STURE TRANSFER CORE
The cross-flow energy recovery core transfers heat and water vapor
between the two airstreams. It is easily removed for cleaning or service.
MOTORS AND BLOWERS
Each air stream has one centrifugal blower driven by a common PSC
motor. 5 speed fan operation.
F LTERS
Washable air filters in exhaust and supply air streams.
MOUNT NG THE ERV
Four threaded inserts at corners of case designed to accept the "S" hooks
and hanging straps supplied with the unit.
CASE
Twenty gauge prepainted galvanized steel (G60) for superior corrosion
resistance. Insulated to prevent exterior condensation. Door balancing
ports.
WE GHT 75 lbs. (34Kg) SH PP NG WE GHT 77lbs. (35Kg)
ELECTRON CS
•Built-in Relay for Interfacing to furnace
OPT ONAL CONTROLS
# DHVC Ventilation Control
• 2 Speed Fan setting (Low/ igh) • Dehumidistat
#HHSC Healthy Home System Control
• Automatically activates the unit to deliver fresh air into your home
#DH1 Dehumidistat
• Initiates high speed ventilation when the indoor humidity level exceeds
the set point
OPT ONAL T MERS
#VTC Ventilation Timer Control - Initiates high speed ventilation
for 20, 40, or 60 minutes, (3 wire) 20 gauge wire (min.) 100'
length
OPT ONAL ACCESSOR ES
#WH 186 Weatherhoods, Two - 6” (150 mm) c/w 1/4” (6 mm) mesh
screen
WARRANTY
Units carry a five (5) year warranty
on the enthalpic (ERV) core and a 5
year replacement parts warranty.

13
The Three Methods of nstallation
The following three installation methods are for the
RV/ERV system:
• The Simplified installation.
• The Partially Dedicated Installation
• The Fully Dedicated Installation
Simplified nstallations
The Simplified Installation draws stale air from the cold air
return duct of the air handler/furnace and introduces an
equal amount of fresh air farther downstream into the cold
air return. Refer to "Simplified Inst ll tion Di gr ms".
The air handler/furnace blower must be running when the
unit is operating for this system to be effective. Refer to
"Interlocking the HRV/ERV to n Air H ndler/Furn ce
Blower".
Partially Dedicated nstallations
The Partially Dedicated Installation draws stale air from
specific points in the house and introduces an equal amount
of fresh air into the cold air return. Refer to "P rti lly
Dedic ted Inst ll tion Di gr ms".
Stale air ducts should be installed in areas of the home
where the poorest indoor air quality exists (bathrooms and
kitchen). Each location with a stale air duct should have a
timer to initiate high speed ventilation. Refer to "Option l
Timers" in this manual.
The air handler/furnace blower should be running when the
RV is operating to evenly distribute the fresh air
throughout the house. Refer to "Interlocking the HRV/ERV
to n Air H ndler/Furn ce Blower".
Fully Dedicated nstallations
The Fully Dedicated Installation draws stale air from
specific points in the house and delivers fresh air to specific
locations of the house. This system is not connected to an
air handler/furnace. Refer to "The Fully Dedic ted
Inst ll tion Di gr ms" in this manual.
Stale air ducts should be installed in areas of the home
where the poorest indoor air quality exists (bathrooms and
kitchen). Each location with a stale air duct should have a
timer which will initiate high speed ventilation. Refer to
"Optional Timers" in this manual.
Fresh air ducts should be installed to all bedrooms and
living areas, excluding bathrooms, kitchen and utility areas.
Grilles should be located high on a wall or in ceiling
locations. Grilles that diffuse the air comfortably are
recommended. Refer to "Grilles" in this manual. Special
care should be taken in locating grilles if the floor is the
only option available. Areas such as under baseboard
heaters will help to temper the air.
Optional in-line duct heaters are available for mounting in
the supply duct work to add heat if required.
nstalling the Ducting Between the HRV/ERV &
Living Areas in the House
A well designed and installed ducting system will allow the
RV/ERV to operate at its maximum efficiency.
All ducts should be kept short and have as few bends or
elbows as possible to maximize airflow. Forty-five degree
elbows are preferred to 90° elbows. Use "Y" tees instead of
straight tees whenever possible.
All duct joints must be fastened with screws, rivets or duct
sealant and wrapped with mastic or quality duct tape to
prevent leakage. Mastic is preferred but if duct tape is used,
we recommend aluminum foil duct tape.
Galvanized (rigid) ducting from the RV/ERV to the living
areas in the house is recommended whenever possible
although flexible duct can be used in moderation if
necessary.
A short length (approximately 12 inches or 300mm) of non-
metallic flexible insulated duct should be connected
between the RV/ERV and the supply/exhaust duct system
to avoid possible noise transfer through the duct system.
All ducts running through attics and unheated spaces must
be sealed and insulated to code.
nstallation Methods
ATTENTION
Applications such as greenhouses, atriums,
swimming pools, saunas, etc. have unique
ventilation requirements which should be
addressed with an isolated ventilation system.

DIRECT CONNECTION of both the HRV SUPPLY AIR STREAM and
EXHAUST AIR STREAM to the FURNACE COLD AIR RETURN
Installation Notes
• Unit is normally balanced on HIGH speed with the furnace blower ON.
• A minimum separation of 40 inches (1m) is recommended between the
two direct connections.
• The exhaust air connection should be upstream of the supply air
connection to prevent exhausting any fresh air.
• Weatherhood arrangement is for drawing purposes only. Six feet (2m)
minimum separation is recommended. The Weatherhood must also be 18"
(460mm) above grade minimum.
• The airflow must be confirmed on site using the balancing procedures found in this manual
Spring-Loaded Backdraft Damper
Install the Backdraft Damper with the leaf hinge vertical.
The damper is installed on the “Stale Air to Outside Collar”.
4” (102mm) Backdraft Damper Part No. 99-RSK4
5” (127mm) Backdraft Damper Part No. 99-RSK5
6” (152mm) Backdraft Damper Part No. 99-RSK6
8” (203mm) Backdraft Damper Part No. 99-RSK8
The Stale Air to Outside air duct requires
a Backdraft Damper. This damper prevents
outdoor air from entering the HRV
during the operation of the Furnace/
Air Handler while the HRV is in standby,
OFF or Recirculate.
WARNING
RETURN AIR
40" (1m) MINIMUM
Outdoors
Cool Air
Return
3' min.
recommended
Forced Air
Furnace
Dampers for
balancing
airflows
Backdraft
Damper
Leaf Hinge
Simplified nstallation Diagrams
Simplified nstallation (Return/Return Method)
Key Points
• The RV/ERV must be balanced.
• It is mandatory that the furnace blower run continuously or
RV/ERV operation be interlocked with the furnace
blower. (Refer to “Interlocking the RV/ERV to an Air
andler/Furnace Blower.”)
• The duct configuration may change depending on the
RV/ERV model. See specifications for your unit.
• Check local codes / authority having jurisdiction for
acceptance.
• A backdraft damper is required in the exhaust air duct to
prevent outdoor air from entering the unit when the
Furnace/Air andler is running and the unit is in Standby,
OFF or Recirculate.
Sizing the Ductwork
It is the responsibility of the installer to ensure all ductwork is
sized and installed as designed to ensure the system will
perform as intended.
The amount of air (cfm) that an RV/ERV will deliver is
directly related to the total external static pressure (E.S.P.) of
the system. Static pressure is a measure of resistance imposed
on the blower by length of duct work plus the number of
fittings used in the duct work.
DIRECT CONNECTION o the SUPPLY AIR STREAM and
EXHAUST AIR STREAM to the FURNACE COLD AIR RETURN.
14
(not included)

DIRECT CONNECTION of the SUPPLY AIR STREAM to the FURNACE COLD AIR RETURN
(Stale air drawn from key areas of home)
Forced Air
Furnace
Outdoors
EXHAUST AIR from various parts of home.
i.e. bathrooms (if required), kitchens (if required).
Cool Air
Return
Return Air
3' min.
recommended
Installation Notes
• Unit is normally balanced on HIGH speed with the furnace blower ON.
• Weatherhood arrangement is for drawing purposes only. Six feet (2m)
minimum separation is recommended. The Weatherhood must also be 18"
(460mm) above grade minimum.
• The airflow must be confirmed on site using the balancing procedures
found in this manual.
Dampers for
balancing
airflows
Backdraft
Damper
leaf hinge
Spring-Loaded Backdraft Damper
Install the Backdraft Damper with the leaf hinge vertical.
The damper is installed on the “Stale Air to Outside Collar”.
4” (102mm) Backdraft Damper Part No. 99-RSK4
5” (127mm) Backdraft Damper Part No. 99-RSK5
6” (152mm) Backdraft Damper Part No. 99-RSK6
8” (203mm) Backdraft Damper Part No. 99-RSK8
The Stale Air to Outside air duct requires
a Backdraft Damper. This damper prevents
outdoor air from entering the HRV during
the operation of the Furnace/Air Handler
while the HRV is in standby, OFF or
Recirculate.
WARNING
Partially Dedicated nstallation Diagrams
Partially Dedicated System
This installation enables stale air to be drawn from the
poorest air quality areas of the home (bathrooms, kitchen).
Key Points
• The RV/ERV must be balanced.
• It is recommended that the furnace blower run
continuously or RV/ERV operation be interlocked
with the furnace blower to evenly distribute the fresh air
throughout the house.(Refer to “Interlocking the
RV/ERV to an Air andler/Furnace Blower.”)
• The duct configuration may change depending on the
RV model. See specifications for your unit.
• Check local codes/authority having jurisdiction for
acceptance.
• A backdraft damper is required in the exhaust air duct to
prevent outdoor air from entering the unit when the
Furnace/Air andler is running and the unit is in
Standby, OFF or Recirculate.
Sizing the Ductwork
It is the responsibility of the installer to ensure all
ductwork is sized and installed as designed to ensure the
system will perform as intended.
The amount of air (cfm) that an RV/ERV will deliver is
directly related to the total external static pressure (E.S.P.)
of the system. Static pressure is a measure of resistance
imposed on the blower by length of duct work plus the
number of fittings used in the duct work.
15
(not included)

Outdoors
Installation Notes
• Unit is normally balanced on HIGH speed with the furnace blower ON.
• Weatherhood arrangement is for drawing purposes only. Six feet (2m) minimum separation
is recommended. The Weatherhood must also be 18" (460mm) above grade minimum.
• The airflow must be confirmed on site using the balancing procedures found in this manual.
Dampers for
balancing
airflows
Stale air from various
parts of home.
i.e. bathrooms (if required)
Kitchens (if required)
Fresh air to house -
main living areas.
bedrooms, livingroom,
rec. room, etc.
Fully Dedicated nstallation Diagrams
Fully Dedicated System
This is a stand alone RV/ERV system which
is not connected to a force air system. Stale air
is drawn from key areas of the home (bathroom,
kitchen) while fresh air is supplied to main
living areas.
Key Points
• The RV/ERV must be balanced.
• The duct configuration may change
depending on the RV/ERV model. See
specifications for your unit.
• Check local codes / authority having
jurisdiction for acceptance.
16

nstallation
STEP 4. Level the unit from left to right and front to back.
-Adjust the unit down by lifting up on the buckle.
- Adjust the unit up by pulling down vertically on the and
Loops while lifting up the bottom of the cabinet.
Location
Install the unit in a heated space that provides convenient space for
service access. A typical location is in either a mechanical room or
an area close to the outside wall within close proximity to where
the weatherhoods are mounted. If a basement area is inconvenient
or non- existent, install the unit in a utility or laundry room.
Attic installations are not recommended due to:
A) the complexity of work to install
B) freezing conditions in the attic
C) difficulty of access for servicing and cleaning
Leave sufficient clearance at the front of the access door for
servicing the air filters and core. The recommended clearance is a
minimum of 25" (635 mm) for opening and closing the door. Field
Controls provides four straps for hanging the unit from the
basement floor joists.
Hand Loops
Buckles
Pull down on the hand
loops while lifting
the bottom of the unit.
Improper installation, adjustment, alteration,
service or maintenance can cause property
damage, personal injury or loss of life.
Installation and service must be performed by
a qualified installer or service agency.
WARNING
Unit must be installed level to ensure proper
condensate drainage. Due to the broad range of
installation and operational conditions, consider
the possibility of condensation forming on either
the unit or connecting ducting. Objects below the
installation may be exposed to condensate.
CAUTION
Hand Loops
Screws (not included)
Buckles
Joist
Washers (not included)
Hanging Strap grommets
“S” hooks
Note:This illustration of the unit may
vary from the unit you are installing.
DETAIL
Suspend the Unit with the Adjustable Hanging Straps
STEP 1. Insert the screws and washers (not included) through
the anging Strap grommets and fasten to the joists.
STEP 2. Unscrew the 4 machine screws located on the upper
side of the unit. Attach the "S" hooks and reinsert the machine
screws.
STEP 3. ook the bottom grommets of the straps through the "S"
hooks. Pull down vertically on the hand loops while lifting up the
bottom of the cabinet. Repeat at opposite end of the unit.
Hand Loops
Straps
STEP 5. Fold the hand loops and excess strap and secure with a
nylon tie (not included).
Use 4 screws and 4 washers (not incldued) to attach the hanging
straps to the floor joists. The washer must be wider than the eyelet
of the grommet on the hanging strap.
By design, the adjustable hanging straps reduce the possibility of
noise, resonance, and harmonics.
Note: Do not pull the
and Loops in a
horizontal or lateral
direction during the
installation/adjustment
process.
17

Drain Connection (HRV only)
Grilles
Drain Connection
The RV may produce some condensation during a defrost cycle.
This water should flow into a nearby drain, or be taken away by a
condensate pump.
The RV cabinet has prepunched holes for the drain (see below).
Insert the drain spout through the hole in the drain pan. Be sure to
install the "O ring" which seals each spout to the pan. AND
TIG TEN the washer and lock nut which hold the drain spout in
place.
Construct a P-Trap using the plastic tee connector. Cut two lengths
of 1/2" drain hose (not included) and connect the other ends to the
two drain spouts. Position the "T" fitting to point upward and
connect the drain line. Tape or fasten base to avoid any kinks. Pour
a cup of water into the drain pan of the RV after the drain
connection is complete. This creates a water seal which will
prevent odors from being drawn up the hose and into the fresh air
supply of the RV.
Adjustable grilles should be used to balance the flow rates into and
out of various rooms. The grilles should not be adjusted after
balancing the unit.
Grilles or diffusers should be positioned high on the wall or in the
ceiling. Kitchen Exhaust grilles must never be connected to the
range hood. They should be installed at least 4 feet (1.2 m)
horizontally away from the stove.
Field supplied balancing dampers should be installed external to
the unit to balance the amount of stale air being exhausted with the
amount of fresh air being brought into the house. Refer to Air flow
Balancing section.
The Techgrille
The TEC GRILLE is a round, fully adjustable grille, which
provides superior, quiet air distribution.
4” (100 mm) Part No. 99-EAG4
5” (125 mm) Part No. 99-EAG5
6” (150 mm) Part No. 99-EAG6
The HRV and all condensate lines must be
installed in a space where the temperature is
maintained above the freezing point or freeze
protection must be provided.
CAUTION
DRAIN
SPOUT
ZIP TIE
TO DRAIN
TEE
CONNECTOR
DRAIN
SPOUT
PRE-PUNCHED HOLES(2)
DRAIN PAN DRAIN PAN
1/2 "I.D.
DRAIN HOSE
DRAIN HOSE PLUMBING
DRAIN
SPOUT
DRAIN
SPOUT
TO DRAIN
1/2" HARD PIPE
TEE
JOINT
PRE-PUNCHED HOLES(2)
DRAIN PA N D RAINPA N
HARD PIPE PLUMBING
Drain trap and tubing MUST be below
bottom of door with 1/4" per foot
downwards slope away from unit.
CAUTION
Note: Secondary drain pan may be req ired to protect from
condensate leakage.
CAUTION
Do not mount exhaust grille within 4’
(1.2m) (horizontally) of a stove to prevent
grease from entering the unit.
18

19
Weatherhood nstallation
nstalling the Ducting from the
Weatherhoods to the HRV/ERV
The inner and outer liners of the flexible insulated duct must be
clamped to the sleeve of the weatherhoods (as close to the outside
as possible) and the appropriate port on the RV/ERV. It is very
important that the fresh air intake line be given special attention to
make sure it is well sealed. A good bead of high quality caulking
(preferably acoustical sealant) will seal the inner flexible duct to
both the RV/ERV port and the weatherhood prior to clamping.
To minimize air flow restriction, the flexible insulated duct that
connects the two outside weatherhoods to the RV/ERV should
be stretched tightly and be as short as possible.
Twisting or folding the duct will severely restrict air flow.
ard (rigid) ducting which has been sealed and insulated should be
used for runs over 10’ (3.3 m). Refer to your building code.
ntake Weatherhood Requirements
• Should be located upstream (if there are prevailing winds)
from the exhaust outlet
• At least 6' (2 m) from the exhaust weatherhood
• At least 6' (2 m) away from dryer vents and furnace exhaust
(medium or high efficiency furnaces)
• A minimum of at least 6' (2 m) from driveways, oil fill pipes,
gas meters, or garbage containers
• At least 18" (460 mm) above the ground, or above the depth
of expected snow accumulation
• At least 3' (1 m) from the corner of the building
• Do not locate in a garage, attic or crawl space
Exhaust Weatherhood Requirements
• At least 6' (2 m) from the ventilation air intake
• At least 18" (460 mm) above ground or above the depth of
expected snow accumulation
• At least 3' (1 m) away from the corner of the building
• Not near a gas meter, electric meter or a walkway where fog
or ice could create a hazard
• Not into a garage, workshop or other unheated space
When installing the weatherhood, its outside perimeter must be
sealed with exterior caulking.
Weatherhoods
Fixed covered weatherhoods have a built-in bird screen with a 1/4"
(6mm) mesh to prevent foreign objects from entering the
ductwork.
5” (125 mm) Part No.W 185
6” (150 mm) Part No.W 186
Weatherhood nstallation
1. Thermal Collar slides over galvanized
sleeve of Weatherhood.
2. Fasten Thermal Collar to Belt.
3. Slide the Insulated Flexible Ducting over
theWeatherhood's galvanized sleeve and
fasten it to the Thermal Collar.
4. Hood is hinged to allow for easy access
for cleaning of bird screen.
W
TI 15
0
1/4" (6 mm) SCREEN
(front view)
EXTERIOR
WALL
SCREEN
(side view)
COLLAR IS SUPPLIED TO
ENSURE VAPOUR BARRIER
IS 100% SEALED TO
WALL PLATE
12" galvanized
pipe supplied
36" (1m)
recommended min.
36" (1m)
recommended min.
6' (2m)
recommended min.
18" (460mm) min. 18" (460mm) min.
OUTSIDE CORNER
INTAKE
EXHAUST
INSIDE CORNER
CAUTION
Weatherhood arrangement - requires a minimum of
6' (2m) separation and a minimum of 18" (460mm)
above the ground, or above the depth of expected
snow accumulation.
ATTENTION
Local codes may require greater distances for
exhaust and intake.

20
nstallation of the Dehumidistat or Dehumidistat Ventilation Control
Standard Series Controls may be installed onto a flush mounted
2" x 4" electrical switch box or it may be surface mounted onto a
wall.
Only 1 master control should be installed to a ventilation system
(the Face Plate on this illustration may not be exactly the same as
yours).
1. Remove the Oper ting Instructions C rd from the top of the
Control (Figure A).
2. Separate the F ce Pl te from the B ck Pl te by firmly pulling
apart (Figure B). Be careful not to damage Face Plate Contact
Pins.
3. Place the B ck Pl te of the control in the desired location on
the wall and pencil mark the wall in the center of the Wire
Opening, Top Screw Hole and Bottom Screw Hole (Figure C).
4. Remove the B ck Pl te and drill a 3/8" opening in the wall to
allow for the Wire Opening and a 1/8" hole for the W ll
Anchors for the top and bottom screw holes (Figure D).
5. Pull 3/20 wire through the opening in the wall and the Wire
Opening of the B ck Pl te (Figure C).
6. Connect Red, Green and Yellow to the Wiring Termin ls
located on the B ck Pl te (Figure C).
7. Secure a single wire to the Wire Ret iner located on the B ck
Pl te (Figure C).
8. Attach the B ck Pl te to the wall using the 2 supplied screws
and anchors.
9. Attach the F ce Pl te to the B ck Pl te (Figure B).
Note: Be careful to correctly align the F ce Pl te to avoid
damaging the F ce Pl te Cont ct Pins.
10. Insert the Oper ting Instructions C rd into the control (Figure
A).
11. Connect the 3/20 wire to the Termin l Block located on
ventilator (Figure E).




ATTENTION
Pay special attention not to damage the Contact
Pins when attaching and detaching the Face Plate.
(Figure B)
Operating
nstructions Card
Figure A -
Face Plate
Figure E
Terminal Block located
on ventilator
• Yellow to YELLOW #4
• Red to RED #3
• Green to GREEN #5
Use 3/20 wire
Red #3
Yellow #4
Green #5
Back
Plate
Figure B
Face Plate
Contact
Pins
Face
Plate
Separate the
Face Plate from
the Back Plate.
Side View
P
Figure C
Front View of Back Plate
Wire
Opening
Wiring
Terminals
Wire
Retainer
TOP
Top Screw
Hole
Bottom
Screw Hole
Drill a 1/8” hole
for the Top Screw
and Anchor
Figure D
Drill holes in wall
Drill a 3/8” hole
for the Wire
opening
Drill a 1/8” hole
for the Bottom
Screw and
Anchor
F
Correct Installation
of Back Plate
Wall Face
Dehumidistat Sensor
Openings to room
air allow accurate
sensor readings.
Figure F
Back
Plate
Face Plate
Contact
Pins
Face
Plate
