Fieldmann FZG 2001 User manual

FZG 2001

EN 2
FZG 2001
English .................................................................................................................................................................................3–14
Čeština.............................................................................................................................................................................15–26
Slovenčina .....................................................................................................................................................................27–38
Magyarul ........................................................................................................................................................................39–50
Polski ................................................................................................................................................................................. 51–63

EN
GAS GRILL USER'S MANUAL
3
Table of Contents
GAS GRILL
USER’S MANUAL
Thank you for purchasing this Gas grill. Before you start using it, please carefully read
this user’s manual and save it for possible future use.
CONTENTS
1. GENERAL SAFETY INSTRUCTIONS ........................................................................................................................ 4
Safety First!........................................................................................................................................................................4
General information...................................................................................................................................................6
2. USER’S MANUAL............................................................................................................................................................ 7
Grill and gas cylinder positioning.......................................................................................................................7
BBQ...................................................................................................................................................................................... 7
Gas cylinder.................................................................................................................................................................... 7
Connecting the pressure cylinder ......................................................................................................................7
Regulator and Hose ...................................................................................................................................................7
Gas leak testing..........................................................................................................................................................10
Lighting Instructions for barbecue....................................................................................................................10
Things to consider when barbecuing............................................................................................................. 11
Cleaning and maitenance.................................................................................................................................. 11
Storage ............................................................................................................................................................................11
Servicing .........................................................................................................................................................................12
Trouble shooting .........................................................................................................................................................12
Specifications...............................................................................................................................................................12
3. PARTS DIAGRAM FOR FZG 2001.........................................................................................................................13
4. PROTECTION OF THE ENVIRONMENT..............................................................................................................14
5. DISPOSAL........................................................................................................................................................................14

EN 4
FZG 2001
General safety instructions
1. GENERAL SAFETY INSTRUCTIONS
Warning: Indicates a risk of injury, death or damage to the tool if it is not observed.
Read the user‘s manual.
In accordance with the basic safety standards of European directives in force.
Caution! Hot surface.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odour continues, immediately call your gas supplier or fire department.
WARNING!
Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage.
Read the installation, operation, and maintenance instructions thoroughly before installing or servicing this
equipment.
Failure to follow these instructions could result in fire or explosion which could cause property damage,
personal injury, or death
DANGER!
DO NOT use gas grill for indoor cooking or heating. TOXIC fumes can accumulate and cause asphyxiation.
NOT to be used in or on boats or recreational vehicles.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. IF YOU ARE ASSEMBLING THIS UNIT FOR SOMEONE ELSE,
GIVE THIS MANUAL TO HIM OR HER TO SAVE FOR FUTURE REFERENCE.
IMPORTANT NOTICE: READ ALL INSTRUCTIONS PRIOR TO ASSEMBLY AND USE!
WARNING
DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
An gas cylinder not connected for use shall NOT be stored in the vicinity of this or any other appliance.
Safety First!
Read and understand all warnings and precautions prior to operating your grill.

EN
GAS GRILL USER'S MANUAL
5
General safety instructions
DANGER
To prevent fire or explosion hazard when testing for a leak:
1. Always perform“leak test”before lighting the grill, each time the cylinder is connected for use.
2. No smoking. Do not use or permit sources of ignition in the area while conducting a leak test.
3. Conduct the leak test outdoors in a well-ventilated area.
4. Do not use matches, lighters, or a flame to check for leaks.
5. Do not use grill until any and all leaks are corrected. If you are unable to stop a leak, disconnect the propane
supply. Call a gas appliance serviceman or your local propane gas supplier.
WARNING
1. For use outdoors only.
2. Read the instruction literature before using the appliance.
3. WARNING: Accessible parts may be very hot. Keep young children away.
4. This appliance must kept away from flammable materials during use.
5. Do not move the appliance during use.
6. Turn off the gas supply at the gas cylinder after use.
7. Do not modify the appliance.
8. This grill is for outside use only, and shall not be used in a building, garage, or any other enclosed area.
9. This grill is for use with propane gas only (propane gas cylinder not included).
10. Never attempt to attach this grill to the self-contained propane system of a camper trailer, motor home or
house
11. Never use charcoal or lighter fluid.
12. The use of alcohol, or prescription or non-prescription drugs may impair the consumer’s ability to properly
assemble or safely operate the appliance.
13. Do not use gasoline, kerosene, or alcohol for lighting!
14. Always place your grill on a hard, level surface far away from combustibles. An asphalt or blacktop surface
may not be acceptable for this purpose.
15. DO not attempt to move the grill while it is lit.
16. Do not leave a lit grill unattended especially keep children and pets away from grill at all times.
17. Do not operate grill in high winds.
18. Do not use the grill unless it is COMPLETEY assembled and all parts are securely fastened & tightened.
19. Keep all combustible items and surfaces at least 24 inches (61cm) away from the grill at all times. DO NOT
use this gas grill or any gas product under any overhead or near any unprotected combustible constructions
20. Place dust cap on cylinder valve outlet whenever the cylinder is not in use. Only install the type of dust cap
on the cylinder valve outlet that is provided with the cylinder valve. Other types of caps or plugs may result in
leakage of propane.
WARNING
1. Do not store spare LP cylinder within 10 feet (3m) of this appliance
2. Do not store or use gasoline or other flammable liquids or vapors within 25 feet (8m) of this appliance.
3. When cooking with oil/grease, do not allow the oil/grease to exceed 350°F (177°C).
4. Do not leave oil/grease unattended.

EN 6
FZG 2001
General safety instructions
CAUTION
Do not touch metal parts of grill until it has completely cooled (about 45 min.) to avoid burns, unless you are
wearing protective gear (potholders, gloves, BBQ mittens, etc.).
Do not use in an explosive atmosphere. Keep grill area clear and free from combustible materials, gasoline
and other flammable vapors and liquids.
Do not alter grill in any manner.
Clean and inspect the hose before each use of the appliance. If there is evidence of abrasion, wear, cuts,
or leaks, the hose must be replaced prior to the appliance being put into operation. The replacement hose
assembly shall be that specified by the manufacturer.
Move gas hoses as far away as possible from hot surfaces and dripping hot grease.
Never keep a filled container in a hot car or car trunk. Heat will cause the gas pressure to increase, which
may open the relief valve and allow gas to escape.
CAUTION
Liquid propane (LP) gas is flammable and hazardous if handed improperly. Become aware of the
characteristics before using any LP product.
LP Characteristics: Flammable, explosive under pressure, heavier than air, and settles and pools in low
areas.
In its natural state propane has no odor. For your safety, an odorant is added that smells like rotten cabbage.
Contact with LP can cause freeze burns to skin.
This grill is shipped from the factory for LP gas use Only.
Never use an LP cylinder with a damaged body, valve, collar, or footing.
Dented or rusted LP cylinders may be hazardous and should be checked by your LP gas supplier.
CAUTION
It is essential to keep the grill’s valve compartment, burners, and circulating air passages clean. Inspect grill
before each use.
General information
PROPANE GAS CYLINDER NEEDED TO OPERATE:
This Gas Grill is NOT for commercial use!
If outdoor cooking gas appliance is not in use the gas MUST be turned off at the supply cylinder.
The pressure regulator and hose assembly supplied with the gas grill MUST be used.
Your barbecue can be used with gas cylinders between 1 kg and 15 kg.
Follow the technical information as stated in the instruction manual and Check with your local gas supplier
to have a suitable gas cylinder for your barbecue.

EN
GAS GRILL USER'S MANUAL
7
User’smanual
2. USER’S MANUAL
Grill and gas cylinder positioning
BBQ
Place the BBQ on a firm, flat and fire-proof surface.
Make sure to maintain a safety clearance of at least 60 cm
from nearby combustible surfaces.
Never move the BBQ when it is lit or still hot from grilling.
Gas cylinder
Position the gas cylinder in such a way that it is not exposed to continuous sunlight or other sources of heat.
The gas cylinder should be placed next to the BBQ when it is being used, not under it.
Make sure that the gas hose does not come into contact with any part of the BBQ that will become hot during
use. Ensure that it is not under tension, kinked or in danger of being damaged by other objects.
Connecting the pressure cylinder
This appliance is only suitable for use with low-pressure butane or propane gas or LPG mixtures, fitted with
the appropriate low-pressure regulator via a flexible hose.
The hose should be secured to the regulator and the appliance with hose clips. Make sure the flexible hose
could not come in contact with hot surface and avoid twisting.
Please consult your LPG dealer for information regarding a suitable regulator for the gas cylinder.
Regulator and Hose
Use only regulators and hose approved for LP Gas at the above pressures.
The use of the wrong regulator or hose is unsafe; always check that you have the correct items before
operating the barbecue.
The hose used must conform to the relevant standard for the country of use. Worn or damaged hose must
be replaced. Ensure that the hose is not obstructed, kinked, or in contact with any part of the barbecue other
than at its connection.
The length of flexible hose shall not exceed 1.5m. The hose should certified according to applicable EN
Standard and comply with local code.
Important:
Make sure that the regulator is set to OFF before starting to connect the gas cylinder.
The appearance of regulators and their method of connection varies from country to country.
The following table explains the connection of 6 types of regulator (A-F).

EN 8
FZG 2001
User’smanual
1.
A
1. Check the rubber seal on the regulator. If it has
been damaged in any way, the regulator must be
replaced.
2. Connect the gas hose to the regulator (if it is not
already attached) and tighten the hose clamp.
Connect the regulator to the gas cylinder by
screwing it into the valve connector. The pictured
regulator has a left-hand thread.
B
1. Make sure that the regulator is set to OFF. Lift
up the spring-loaded locking collar and fit the
regulator onto the top of the gas cylinder.
2. Push the locking collar down until you hear
a click.
C
Connect the regulator to the gas cylinder by turning
the lock nut clockwise.
Twist the regulator so that the ventilation hole (c1) is
at the bottom.
D
Connect the regulator to the gas cylinder by turning
the lock nut anticlockwise.
Twist the regulator so that the ventilation hole (c1) is
at the bottom.

EN
GAS GRILL USER'S MANUAL
9
User’smanual
E
Make sure that the regulator is set to OFF.
Push the regulator down onto the valve until it clicks
into place.
F
1. Make sure that the regulator is set to OFF. Lift up
the spring-loaded locking collar and push the
regulator down onto the gas cylinder.
2. Push the locking collar down to lock the regulator
onto the gas cylinder.
2. Connect the gas hose to the BBQ and tighten the
hose clamp.
The picture shows the connection of a gas hose
in accordance with Swedish standards. In some
countries the gas hose is of a larger diameter and is
pushed all the way onto the connector.
3. Make sure that the gas control knobs are set to
OFF.
4. Open the gas cylinder by turning the handwheel
anticlockwise.

EN 10
FZG 2001
User’smanual
Gas leak testing
Always test for gas leaks before using the BBQ after the gas cylinder has been connected.
Do not smoke while checking for gas leaks.
Do the gas leak test outdoors.
Never use a lit match, cigarette lighter or other naked flame to localise a gas leak.
How to perform a gas leak test:
1. Mix up a solution of water and some washing-up
liquid.
2. Spray or brush some of the soapy water solution
onto the points shown in the picture.
If you detect any leaks (if you find bubbles appearing),
make sure that they are sealed before starting to use the
product. If you are unsure about using the bbq,
contact a qualified service technician before using the
product.
Lighting Instructions for barbecue
Put 1.5V battery of typ AAA inside before light.
1. Read and follow the operator’s instructions in owner’s manual before lighting.
2. Make sure the control knobs are in OFF position, open gas bottle valve according to instructions.
3. Push the ignitor and turn the knob anti-clockwise to the MIN position, this will light the burner. If not repeat
this process.
4. Adjust the heat by turning the knob to the MAX/MIN position.
5. To turn the grill off. Turn the cylinder valve or regulator switch to the OFF position and then turn the control
knob on the appliance clockwise to the OFF position.
WARNING!
If the burner fails to ignite, turn the control knob off (clockwise) and also turn the cylinder valve off. Wait five
minutes before attempting to relight with ignition sequence.
Clean your barbecue after each USE. DO NOT use abrasive or flammable cleaners, as it will damage the
parts of the product and may start a fire. Clean in warm soapy water.
