Fieldmann FZH 5035 User manual

FAST ČR, a.s., U Sanitasu 1621,
251 01 Říčany, Czech Republic
www. eldmann.eu
IBefore you begin, please check to ensure you have all the parts.
Read ALL the directions before beginning.
NO Description QTY
1 Shower head 1
2 Elbow Fitting 1
3 Handle 1
4 Hose Connecting 1
5Teon 1
6 Setscrew 4
7 Drain Screw 1
8 Foot Shower 1
II Installation
In order to use our products properly and get the most satisfaction and pleasure, please pay attention to the following
details.
1. Thesolarshowermustbeinstalledonsolidground(concreteoor)orconcretebasetomakesureitsstabilization
and safety for user.
2. The solar shower is equipped with base plate, which has 4 prefabricated holes for screws installation on solid
ground or portable base.
3. For easy installation, please separately buy our portable base. Just screw the solar with the base and you could
enjoy the warm water.
4. Please install the solar shower at the location where has the most sunshine.
5. Please connect inlet of the solar shower to tap water system of your home. It is better to have the inlet of solar
shower connected to your garden tap then to the tap water system.
6. Please pay attention that it is necessary to have a tap installed before the inlet of solar shower.
7. To prevent the scalding from the hot water, extra attention to the following.
Beforeturnonthesolarshower,pleasemakesurethevalveisatthecoldwaterposition(blue),thenturnonthe
valveandgraduallyadjustthewatertowardthehotwaterposition(red),untilreachthemostcomfortabletempera-
ture.
8. Warning! Under the exposure of the very strong sun radiations, the water temperature coming from the solar
showermayreach60˚Cor140˚F.
ground
Drain Screw
Hose connecting
Washer
Foot Shower
Handle
Cover
Screw
Main Body
Shower Head
couper 2
couper 1
skim 2
skim 1
Elbow Fitting
USER MANUAL FOR
SOLAR SHOWER FZH 5035

FAST ČR, a.s., U Sanitasu 1621,
251 01 Říčany, Czech Republic
www. eldmann.eu
Inlet Port
Gasket
Portable base
On/Off
Cover Screw
Handle
Shower head
Fitting
step 1
step 4
step 2
step 5
step 3
step 6
Note: Portable base is not included in the shower, please buy separately
III Initial set up of the shower
1. Turn and lift shower handle to FULL ON HOT position.
2. Tightenthebottomdrainscrewtomakesureitissealedandnowaterleaks.
3. Turnonwatersupplytogardenhosetollshower.Showerwilltakeabout2~4minutestoll.NOTE:Filling
tubewithvalveinhotpositionensuresnoairpocketsaretrappedinshower.Thisprocedureisusedforinitial
set up only.
4. Whenwaterowsfromshowerhead,turnshowerhandleo󰀨.Turningtheshowero󰀨allowsthewatertobegin
heating.
5. Shower is ready to absorb sunlight and heat your water. NOTE: Depending on available sunlight and outside
temperature,itmaytakeup3hoursorlongertofullyheatthewater.Usingtheshowertoosoonwillyieldless
heatedwater.Arecentlyusedshower(thathasnotbeenemptied)willtakelesstimeasitwillhaveretained
some hot water.
6. Simply lift the handle to its ON position and you are ready to enjoy your sun-warmed water! NOTE: The faucet
connected to garden hose must be turned on for shower to run.
7. Turno󰀨watersupplytoshowerwhendone.
WARNING: IF SHOWER HAS NOT BEEN USED FOR MORE THAN THREE DAYS, WE
RECOMMEND RUNNING the SHOWER FOR 2 MINUTES TO REMOVE STAGNANT
WATER. STAGNANT WATER IN WARM ENVIRONMENT CAN PROVIDE A GROWTH
ENVIRONMENT FOR HAZARDOUS BACTERIA.
IV Remarkforo󰀨-seasonstorageprotection:
1. After the pool season, please clean the solar shower with soft cloth.
2. Pleaseclosethegardentapwhichisconnectedtotheinletofsolarshower.Andpleasemakethecoldand
hotwatervalvein“OPEN”position,thenunscrewthebottomdrain,tomakesurethatallwaterinsolarshower
can be fully drained out.
3. Whilethesolarshowerisunderthedryandfrozenenvironment,thecoldandhotwatervalveshouldbein
“OPEN”position.Thedamagecausedbyfrozentemperaturewillnotbecoveredbyourwarranty.
Warning:
1. Thedamagecausedbyusingmudwater,saltwaterorfrozentemperaturewillnotbecoveredbyourwarranty.
2. Wipeshowero󰀨afteruse.
3. DO NOT use the solar shower with base in high wind conditions. Wind may cause the shower to become
unstable and fall over hurting you, children or property.
THIS IS NOT a recreational device. DO NOT climb on, hang from solar shower or stand on base. Use only as
intended.
4. Keep small parts, hardware and plastic bags out of the reach of children.
