figgers F-Buds Pro User manual

F-Buds Pro
User Manual
Bluetooth Touch Control Long Life Battery Water Resistent
50+

Left Right
Product overview
L
M
S
Ear caps
We provide three sizes of ear caps (large, medium
and small). Please use the proper size of ear caps
to fit your ears to get a better wearing experience.
Magnetic Contacts
Earphone Cap
Microphone
Charging Case Indicator Light
MFB Touch Button
Indicator Light of Earphones

Settings Bluetooth
F-Buds Pro
Bluetooth
Now discoverable as”Qi iPhone”.
MYDEVICES
Earphone operation
Pairing Manual
1.Take out the two earbuds from the charging case
and peel off the insulating film.
2. Put the two earphones back into the charging
chamber and cover. (The earphones will be charging)
3. Open the cover of the charging chamber, and the
earphones will automatically turn on and interconnect.
Will be in the waiting mode to be paired. (the white
light flashes)
4.After successful paired the indicator of the right
earbud will go off and the indicator of left earbud
White indicator light flashes.
5.Turn on the Bluetooth function on your phone and
search【F-Buds Pro】and connect it.

iOS and the Android users can triple touch
the left or right haptic button to turn on the
voice assistant.
Siri and other Voice Assistant
Open the charging chamber and it will turn
on automatically; or touch the button for 3
seconds to turn it on. (The white light will be
on for 1 second)
Turn ON
Turn OFF
Put the earphones into the charging chamber
and cover. It will turn off automatically. Or it
will turn off automatically after 5 minutes of
disconnection of Bluetooth.

LED indicator
Charging for case
Earbuds indicator
Status Light
Turn on The white light flashes slowly after it is on for one second
Turn off The earphone will turn off after the white light flashes for 1 second
Music play No light
Low battery The white light flashes once per 3 seconds
Charging
White light on
Full battery White light off
Status Light
Charging case charging Orange indicator light flashes
Full battery
No light
Charging for earbuds Blue indicator light flashes
Low Battery Blue indicator light flashes
The earphones searching
for each other
The earphone is connected to
the phone successfully(Standby)
The white lights of both earphones
flash once circularly in 6 seconds.
The earphones
pairing successfully
The light of the main earphone flashes,
The light of the vice earphone goes out
The white lights of both
earphones flash slowly

Restore factory setting
Charge
Charging Case
Orange indicator light flashes when battery is
low, please charge in time.
1.Plug the TYPE-C cable into the charging interface
and the charging case will charge automatically .
(When it is greater than 5V 1A, the charging case
will adapt to the charger's current limit automatically)
2.If you do not use the charging case for a long time,
please charge it to a fully charged state at least
every 3 months.
White indicators flash when battery is low,
please charge in time.
1.Put both earbuds into the charging case,
they will charge automatically.
2.Charging will stop when earbuds are fully charged.
Charging earbuds
Note: Please put both earbuds in the charging
case to fully charge them on first use.
1.Restore factory setting when the earbuds can’t
turn or show no response.
2. Hold the power button for 10 seconds.

Power on Open the charging chamber and it will turn on automatically
Power off Put the earphones into the charging chamber
and cover. It will turn off automatically.
Previous track double tap left earbud MFB Button
Next track double tap right earbud MFB Button
Volume - Hold and press left earbud MFB Button
Volume +
Hold and press right earbud MFB Button
Play / Pause single tap any MFB Button
Answer the call single tap any MFB Button
Enable ENC function at the same time
Hang up hold and press any MFB Button for about 2s
Reject call hold and press any MFB Button
for about 2s
Voice activated assistant tap any MFB Button 3 times
Button control
Note
In the left mono-earbud mode, the next
song and volume + functions are not supported.
In the right mono-earbud mode, the previous
song and volume- functions are not supported.

Specifications
Version V5.0
Support A2DP, AVRCP, HFP, HSP
Transmission distance 10m
Frequency range 2.402GHz~2.480GHz
Speaker Φ 6mm*2
Impedance 16Ω
Standby time 50 hours
Talk time 4 hours
Playing time 4 hours
Earphone battery capacity 40mAh
Fully charged time 1 hour
Charging case battery capacity 300mAh
Charging time of charging case About 1 hour
Weight (single earbud) 4.5 g

r
(FIGGERS Wireless Super Charger Not Included)
Wireless Charging
Enjoy the convenience of wireless charging
and free charging devices provided by
airports, hotels, and cafe shops around the
world.
Designed for the modern life,
never be strangled by
charging cables.

Signal transmission distance shown as below:
≤10m Signals is in normal transmission.
10m Signals will be interrupted.
Waterproof
√
×
swimming or diving rain or water
having a bath
Waterproof for daily life, you cannot submerge
earbuds into water. Ideal for sweating it out at
the gym, or you can wear these earbuds while
washing face, showering, running in the
rain. Please do not use them while you are
diving or swimming.

There is a built-in lithium battery in this
product. To avoid explosion, do NOT
expose the product to strong sunlight,
fire or throw it into fire.
Battery Warning ！
Attentions
1.Please do not use this product while diving as water
will block signal.
2.Do not use corrosive liquid to clean this product.
3..If this product is accidentally exposed to chemicals,
clean it with water
4.Do not use this product under extreme circumstances
for temperature below -10 degree Celsius or above
60 degree Celsius .
5.To avoid explosion, please do not throw this product
into fire.
6.To avoid scratches, please do not touch the earbuds
with sharp objects.
7.Do not insert objects into the earbuds, otherwise it
would cause damage to the internal components.
8.Do not disassemble the earbud.
9. Please keep regular charge to earbuds, don’t leave
them become empty battery status to keep their lifetime.
10. Please do not charge products with power
adapter over 2A current. Excessive current may
cause the damage to battery.
