FIJA DEL INITIAL User manual

INITIAL
MESH WINTER SAFETY COVER
TECHNICAL NOTICE Installation / Use / Upkeep / Maintenance / Safety tips
Compliant with the NF P 90-308 standard (December 2006)
Winter safety cover for swimming pools, designed to prevent access to
the pool for children under the age of 5.
READ carefully and keep for future reference.
The user must be provided with the notice after assembly.
Safety cover for swimming pools, designed to prevent access to the pool during winter for
children under the age of 5. Another safety system must be used while the pool is in use.

2h
Description
IN ORDER FOR YOUR COVER TO COMPLY WITH THE NF P 90-308 STANDARD
◘ Concrete deck
thickness
minimum 10 cm
(350 kg
concrete)
Fabric compliant with the NF P 90-308 stan-
dard : resistance to tearing and abrasion
◘ The deck must extend at least 90 cm around the full circumference of the pool.
◘ No variations in the height of sur-
round caps is accepted.
TOOLS REQUIRED FOR ASSEMBLY ASSEMBLY INFO
TRANSPORT
PACKAGING (e.g. - for a 5 x 10 m pool with a Ø3 m ladder)
THE USER MUST BE PROVIDED WITH THE NOTICE AFTER ASSEMBLY
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
1 box of 0.80 x 0.60 x 0.40 m
Total weight: 30 to 50 Kg
The goods are transported at the risk and peril of the recipient. If the reci-
pient notes any damage that has occurred during transport when receiving
the goods, they must immediately note their reservations on the carrier's
delivery note. They must confirm these reservations within 48 hours by
sending a registered letter to the carrier.
Ø6 concrete
Ø12 concrete
Ø12 wood
DELIVERED ITEMS
10 cm minimum
◘water level ◘ The pool must be equipped
with an overflow system or a
water level regulator.
O Eyelet Peg An-
chorage
Concrete Anchorage Wood Anchorage
Tensioning spring

AA
A = 35 cm
Installation
The cover must have a standard and regular 35 cm overlap (approx.) around the full circumfe-
rence of the pool.
Use weights to prevent the cover from slipping into the pool.
Use chalk or a string-line
TRACING THE ANCHOR LINE AND ANGLES
INSTALLING THE COVER
Rectangular shape: Free-form shape:

12
7
8
56
Ø6 Ø12 Ø12
34
7 cm7 cm
3 cm
60°
EYELET PEG / ANCHORAGE
RECTANGULAR POOL
Clean the drill holes with a vacuum cleaner.
Drill then install by following the order shown on the
diagrams.
Regularly check that the cover is taut
Description
EYELET PEG O
(CONCRETE) CONCRETE ANCHORAGE WOOD ANCHORAGE

3
17 4
16
18
20
22
24
26
25
21
19
23
5
6
7
8
911 13 14 12
10
15
1
2
FREE-FORM POOL
Installation
Regularly check that the cover is taut
Drill then install by following the order shown on the
diagrams.

11
22
10 10
1
4
23
20 min
20 min
Description
CLOSING UP THE POOL
OPENING UP THE POOL
Attach all anchorages
Unhook all the anchorages.
Slide the cover onto the deck.
Clean and dry the anchorages.
Clean and dry the cover before folding and storing in a dry place.
Pack everything away in the storage bag (OPTIONAL) and store in a dry, ventilated room away
from light.
Attach the cover to the anchorages in chronological order.

Installation
UPKEEP (USER'S RESPONSIBILITY)
WINTERING
The correct upkeep of your winter cover is the best way to guarantee a long product lifetime.
Regularly clean the cover with a hose so that leaves do not accumulate and rot on top.
Do not use abrasives or solvents to clean the cover.
MAINTENANCE
All maintenance operations must be performed by a professional, who will contact the manufactu-
rer if necessary (details on the back of the document).
Only use original spare parts.
Regularly check the condition of the cover (eyelet pegs, springs, cover seams ...) at the beginning
and end of wintering, or following any type of accident.
Replace the defective parts if they are damaged.
In windy regions, particular attention must be paid to the cover rubbing on the surround caps.
- Close the cover.
- Do not lower the water level.
- Turn off the filtration.
- Remove snow regularly.
Warning, a covering of snow of more than 20 cm on the cover may cause irreversible damage to
your equipment.
Installing a "Support cable" is recommended.
- In very windy conditions weigh down the edges of the cover with water bladders or sandbags.

.This cover is not a substitute for common sense or individual responsibility. It is
also not intended to replace the supervision of responsible parents and/or adults
who remain the essential factor for the protection of young children.
· Respect the water levels defined by the manufacturer.
· Warning; safety can only be guaranteed with a closed and locked cover that has been
correctly installed in accordance with the manufacturer's instructions.
· The cover must be systematically installed even when the home is left momentarily.
· Ensure that no foreign objects or swimmers are in the pool before and during operations
with the cover
· Store the tools for manoeuvring the cover out of children's reach.
· The implementation of the mechanism should only be undertaken by a responsible adult.
· Climbing, walking or jumping on the safety cover are prohibited.
· If a malfunction occurs that prevents the pool from being covered and secured, or if pool
equipment is temporarily unavailable, take every possible measure to prevent young children
from accessing the pool until the cover is able to be repaired.
· Carefully observe the pool during opening or closing operations.
· A child can drown in less than 3 minutes; no means of protection will ever replace the
supervision and vigilance of a responsible adult.
Dear clients,
Thank you for the confidence you have placed in us by choosing one of our covers.
You are advised to carefully read the following recommendations.
·Your pool could be a serious danger to your children. Drowning can occur very quickly.
ZA La basse croix rouge 35530 Brécé - FRANCE - phone: + 33 (0)2 99 370 370
2019 01 A-DOTE12345
Swimming pool
manufacturer and installer
SAFETY TIPS
MEMORISE THE EMERGENCY SERVICES' TELEPHONE NUMBERS AND DISPLAY THEM NEAR
THE POOL.
- FIRE BRIGADE: 18 (FOR FRANCE) OR 112 FROM A MOBILE PHONE
- AMBULANCE SERVICE: 15 (FOR FRANCE)
- POISON CONTROL CENTRE:
Children who are near a swimming pool must be constantly and actively watched, even if they
know how to swim.
The physical presence of a responsible adult is essential when the pool is uncovered.
Learn life-saving techniques
