S.R.Smith Power Tower PT-6002 User manual
2
3
Contents
IMPORTANT SAFETY INFORMATION4
FCC WARNING4
SPECIFICATIONS 5
INSTALLATION GUIDELINES 6
9
9
ELECTRICAL PROTECTION MEASURES 10
WIRELESS REMOTE OPERATION 11
12
4
IMPORTANT SAFETY INFORMATION
FCC WARNING
ELECTRICAL SHOCK HAZARD – SWITCH DOES NOT TURN OFF INPUT POWER.
DANGER – FAILURE TO FOLLOW THESE WARNINGS, INSTRUCTIONS, AND THE
OWNER’S MANUAL MAY RESULT IN SERIOUS INJURY OR DEATH.
ELECTRICAL RATINGS
5
SPECIFICATIONS
ELECTRICAL RATINGS
CONSTRUCTION
Maximum Soil Height:
Do NOT allow fill to
exceed this level
Optional PT-BASE for
new installations or when
previous 2000/6000
Series illuminator base is
not available.
CAUTION: THE EQUIPMENT AND
CONTROLS SHALL BE LOCATED NOT
LESS THAN 1 M HORIZONTALLY
FROM THE SPA OR HOT TUB
ATTENTION: MAINTENIR UNE
DISTANCE MINIMALE, MESURÉE
DANS UN PLAN HORIZONTAL, DE 1 M
ENTRE LA CUVE DE RELAXATION ET
LES APPAREILS ET COMMANDES
6
•
•
Figure A
Figure A
Figure A
INSTALLATION GUIDELINES
Circuit #1
Low Voltage
Output
Terminals
Circuit #2
Low Voltage
Output
Terminals
12VAC Conduit Hole: At Least
12" of Free 12VAC Cord Should
Be Protruding Past Hole
Electrical Conduit Hole:
Electric Conduit Should
Protrude1" Or Less
Use Sweep Ells Or Heat
Bend For Gentle Radius
(2x) 60W Transformers
(behind bracket)
6A Output fuse
locations for
circuits 1 & 2
High Voltage
Input Terminals
RF Receiver & Antenna
Overview of internal component loca ons
FIGURE A: Op onal part PT-BASE
7
Connect 120VAC power INPUT wiring to the unit’s 3-wire cage clamp.
Figure B
Figure C.
A en on – Do Not Lose the provided Installa on Tool, it is required for removal of the input wires should
service or replacement be required.
FIGURE B (Steps 6a-6e): Installa on tool use – Insert fully, lever towards
the le , insert wire, release tension by moving tool to the right, remove
tool, & pull test wire
FIGURE C (Steps 7 & 8): Cage clamp shown with 120VAC
input wires in place (connected and dressed, right side)
8
12V Power Output Terminals
Circuit 1 = left bank, Circuit 2 = right bank
Figure D
Do not exceed 60W load.
Figure E
Figure F
12V or 13V AC Low voltage accommodations
Figure G
FIGURE D: Low Voltage Output
connecon terminal
FIGURE E: Lever terminal in open posion
FIGURE F: Low voltage light cord shown
connected
FIGURE G: Red-Blue or
Red-Yellow wires used for 12V
or 13V output.
Note:
9
STAND-ALONE ENVIRONMENT & OPERATION
INSTALLING THE PT-6002 UNIT TO THE PT-BASE
TOGGLE SWITCH OPERATION
Manual Operation
Remote On/Off Operation
ON
OFF
REMOTE
ON
OFF
REMOTE
10
ELECTRICAL PROTECTION MEASURES
11
WIRELESS REMOTE OPERATION
Note:
Sleep Mode
To Turn On Using the Wireless Remote Operation: Zone 1
To Turn On Using the Wireless Remote Operation: Zone 2
Color Changing Operation
NEW FEATURE
1-Button - Color Sync / Reset Operation
Performance Note:
PAIRING CODE CHART
DIP Switch 1 2 3 4
OFF OFF OFF OFF
ON OFF OFF OFF
OFF ON OFF OFF
ON ON OFF OFF
OFF OFF ON OFF
ON OFF ON OFF
OFF ON ON OFF
ON ON ON OFF
OFF OFF OFF ON
ON OFF OFF ON
OFF ON OFF ON
ON ON OFF ON
OFF OFF ON ON
ON OFF ON ON
OFF ON ON ON
ON ON ON ON
12
WARRANTY INFORMATION
srsmith.com
Questions?
1-800-824-4387
www.srsmith.com.
TROUBLESHOOTING
