Filamos SSB 05.1 DUO User manual

Concrete Spraying Machine - SSB 05.2 Series
PRODUCER: FILAMOS, s. r. o.
Hate 546, 261 01 Pribram, Czech Republic
Tel: + 420 318 637 763, Fax: + 420 318 624 181
www.filamos.com
User Manual
Concrete Spraying Machine
SSB 05.1 DUO
SSB 05.2 COM-F

Concrete Spraying Machine –SSB 05.1
2
CONTENT PAGE
I. Preface..........................................................................................3
II. Use................................................................................................3
III. Machine Operating........................................................................3
IV. Description....................................................................................6
V. Technical Data..............................................................................8
VI. Accessories.................................................................................10
VII. Material .......................................................................................10
VIII. Executions...................................................................................10
IX. Markings .....................................................................................11
X. Testing........................................................................................11
XI. Delivery.......................................................................................12
XII. Warranty .....................................................................................12
XIII. Packaging ...................................................................................12
XIV. Transport.....................................................................................12
XV. Storing.........................................................................................13
XVI. Servicing .....................................................................................13
XVII. List of Standards.........................................................................13
XVIII. Supplements...............................................................................13

Concrete Spraying Machine –SSB 05.1
3
I. Preface
This user manual is necessary to get basic information about safety use of
concrete spraying machine SSB 05.2 (further only machine), made by producer
FILAMOS, s.r.o., Hate 546, 261 01 Pribram, Czech Republic. Other information,
recommendations and technical parameters are mentioned in the Operating and
maintenance instructions made by producer. The user manual is obligatory for all
users that use this machine.
II. Use
Concrete spraying machine SSB 05.2 is designed for spraying of concrete and
refractory mixtures in a so-called dry method.
This machine finds its main applications in the spraying of refractory concrete
mixtures during the lining of metallurgic and glassworks furnaces, heating plant
boilers, coke-oven batteries, etc.; in the metallurgic, chemical and glass working
industries. It is also used to maintain concrete structures (e.g. road and railroad
bridges, abutment walls, cooling towers, water reservoirs, sewerage plants, etc.);
during the construction and reconstruction of buildings and during the
reinforcement and bracing of tunnel vaults and sewers.
The machine is designed for the operation in the places free of a danger from the
methane explosion (SNM-0) and other inflammable gasses as stated in CSN EN
1127-2.
The machine may be used in media with temperatures ranging from +5 to +40 °C.
III. Machine Operating
Start operating –opening and adjusting compressed air, then turning on the
electric motor.
Presence of the machine operator is not necessary unless during refilling of the
mixture and its application.
Finish operating –it is necessary to empty the feeding hopper and blow
compressed air distribution system by air. To switch off the electric motor
thereafter and close the compressed air cock.
Workmen have to be introduced with:
-User manual
-Operating and maintenance instructions
-Operating rules applied to the construction place
Workmen are obliged to use personal protective equipment stated in Operating
and maintenance instructions (crash helmet, ocular protection and respirator

Concrete Spraying Machine –SSB 05.1
4
against cement dust, convenient work clothes and shoes, work gloves). Workmen
are obliged to do daily notes into the operating diary.
Safety instruction concerning:
-Assembly and the installation –Assembly of the machine is carried out at the
producer and the transport to the client is performed in already assembled form
of the machine. The check of the machine integrity, complexity of the
equipment of the machine is performed in the place of operation. Machine is
switch to the electrical supply and to the compressed air supply after setting to
the place of application.
-Setting to the operation –Machine and its accessories must be appropriately
assembled before setting to the operation. All necessary assembly and
following checking operation steps must be carried out according to the
Operation and Maintenance Manual provided by the producer.
-Operation of the machine –Machine must be used only in accordance with the
Operation and the Maintenance Manual provided by the machine producer.
Machine is operated by one operator who is responsible for the faultless
conditions of the machine at the same time.
-Manipulation –Machine can be transported by the suitable transport means
defined by the site manager. Total weight of the machine is 470 kg (DUO)/560
kg (COM-V) with tolerance ± 5 %. Each machine is equipped with catching
loops for the connection to lifting machine. Manipulation must be careful
without any dynamic crashes.
-Assembly and disassembly –Disassembly of the hoses is done in case of each
transfer to the other operation place Transfer of the machine in assembled
mode is done by mechanical transport means (crane truck, truck). It is
necessary so that there is no pressure of the compressed air in the machine as
well as the switch off the electric supply is done before any disassembly of the
machine.
-Adjustment –It means setting up according to the Operation and the
Maintenance Manual. Simple steps without any influence to the safety of the
equipment must be done by the operators according to the local conditions.
Other procedures must be left to the specialised service according to the
Operation and the Maintenance Manual.
-Maintenance –small and operational steps are done by the operators according
to the time order in the Operational Manual. Procedures requiring higher
specific knowledge are done by the authorised service agencies for those
machines.

Concrete Spraying Machine –SSB 05.1
5
-Disposal –Disposal of the machine is comprised of decomposition of the
parts to:
- Steel material polluted by the dangerous substances
- Colour metals
- Plastics, rubber and the parts polluted by the dangerous substances
must be disposed off in accordance to the Act about the liquidation of
the dangerous substances
Training Instructions
There are only mentally and physical competent workmen older than 18 years
with theoretical and practical skills qualified to operate the machine.
Other Ways of Use
The Machine cannot be used for any other purpose than transport of dry concrete
mixes, fire-resistant mixes and similar materials. If used for any other purpose, the
manufacturer does not assume any liability for damages caused by or to the
Machine. It is not presumed that the equipment should be operated by any
unqualified operating staff and, therefore, the Operating and Maintenance
Instructions are compiled in a manner and to an extent inevitably necessary for a
safe operation of the Machine by a trained member of the staff.

Concrete Spraying Machine –SSB 05.1
6
IV. Description
The Machine comprises the following main parts:
-the Machine drive (electromotor, gearbox, speed variator, if any)
-basic frame
-dosing drum (rotor) with wearing plates
-the Machine head with upper sealing plate, lower sealing plate and exhauster,
-feeder and vibrator,
-rippling equipment,
-tightening bolts,
-exhauster with a filtration bag,
-air distribution and manometers,
-electrical installations,
-central lubricating system (if any),
-bantam wheels (rail undercarriage, frame),
-accessories DN 25, DN 32, DN 40, DN 50 (hoses, quick couplers, nozzle,
sealing plates, etc.)
The Machine drive is executed by the slipping gear-box with:
- 2-speed electric motor (DUO)
- with 1-speed electric motor equipped with frequency invertor (COM-F)
The bearing part of the dosing part, the Machine drive and air distribution are
situated on the frame. The bantam wheels are screwed on the basic frame sides.
The dozing drum is fixed on the top part of the bearing part shaft by a square(end)
and tightening nut.
The Machine head is installed on the 4 tightening bolts. The sealing plate is
mounted on its bottom side and its bottom side rests on the dosing drum. The air
intake is installed on the Machine head upper side as well as the feeder and
exhaust with the filtration bag.
The bottom sealing plate is fixed on the frame on which the dosing drum is rested
as well as the exhauster and bottom exhaust.
The Machine feeder is complimented by vibrator for acceleration of filling of the
transported mix, and a sifter.
The Machine head is mounted on by four tightening bolts serving to control
(adjust) thrust of the sealing plates to the dozing drum.
The exhausts with filtration bags serve to capture air remains and dusty particles
from the dosing drum cylinders.
The air distribution comprises the main intake and four controlling cocks. The
main intake is provided with a controlling cock and quick coupler for connection
of the pressured air DN 40 hose. The controlling cocks serve to intake air to the

Concrete Spraying Machine –SSB 05.1
7
Machine head (primary (upper) air), to the exhauster (secondary (bottom) air), to
clean the Machine and control the pneumatic vibrator. The controlling cocks for
the air intake to the head (primary (upper) air) and to the exhauster (secondary
(bottom) air) are equipped with manometers.
The central lubrication system comprises the lubricating equipment and tank,
controlling automatic system, outputs and pipe. The lubrication system transports
the lubricant (grease) or oil between the areas of sealing and wearing plates and so
avoids their excessive friction. Type of plastics lubricator –A00 (Mogul, Madit,
Slovnaft).
The models without central lubrication system are equipped with the manual lever
press lubricator for sealing and wearing plates.
The control of the Machine is concentrated on the electric motor cover side. The
compressed air intake is situated on the cover side.
The whole Machine is placed on the frame with bantam wheels. Alternatively can
be used a solid frame or a rail undercarriage.
Working Principle
The concrete spraying machine SSB 5.2 works on the principle of pneumatic
transport.
Dry-gunning
The dry mixture for spraying or transportation is poured in the machine and
smoothly fills the cylinders of the rotor below the hopper. To fill a mixture into
the rotor more easily, a vibrator and a rippling are fitted in the hopper.
The rotating movement of the rotor moves the mixture along by 180 degrees in
the clockwise direction. The mixture is thus blown out from individual cylinders
of the rotor into transport hoses. As the mix passes through the blower into the
transport hoses, lower pressure air is added to enhance the continuous flow of the
material in hoses. The hoses are equipped with the spraying nozzles at the end,
into which the mixing water is fed at the same time to wet the transported mixture.
The required wetting of the mixture is controlled with the supply cock.

Concrete Spraying Machine –SSB 05.1
8
Drive and Output Control
The Machine is propelled by electric motor.
I. Two-speed Electric Motor (DUO)
The machine is propelled by two-speed electric motor with slide-on gearbox.
The machine output (rotor speed) is controlled by two-position switch.
II. Electric Motor with a frequency invertor (COM-F)
The electric motor is fitted with frequency invertor It is connected to the frontal
gearbox, which is keyed to the bearing part of the dosing drum with an output hollow
shaft.
The output is changed by means of the invertor
V. Technical Data
SSB 05.1 DUO : 4/6 poles electric motor 2,6/1,87 kW.
Rotor revolutions: 8/12 rpms/min.
Performance parameter
Parameter
Rotor 1,9L
Rotor 3,9L
Rotor 6,9L
Drum volume /dm3/
1,9
3,9
6,9
Drum rpm /min-1/
8
12
8
12
8
12
Theoretical output m3x h-1 *
0,8
1,2
1,8
2,7
3,3
5,0
SSB 05.2 COM-F: 4 poles electric motor 3 kW with frequency invertor
Rotor revolutions in the range: 5 - 13 rpms/min.
Performance parameter
Parameter
Rotor 1,9L
Rotor 3,9L
Rotor 6,9L
Drum volume /dm3/
1,9
3,9
6,9
Drum rpm /min-1/
5
13
5
13
5
13
Theoretical output m3x h-1 *
0,6
1,5
1,2
3,0
2,1
5,4
Note: The drum should be selected with a view to the performance required.
The actual output of the machine depends on the kind and composition of the
mixture to be transported, its moisture content, transport distance, transport hoses
inner diameter, the compressed air pressure and quantity and the way of filling the
machine hopper.

Concrete Spraying Machine –SSB 05.1
9
Technical parameters
Parameter
Air consumption [m3x min-1]
(distance 40 m)
4-5 (DN 32/DN 40)
6-8 (DN 50)
Air pressure [MPa]
0,5 - 0,6
Minimum water pressure at nozzle [MPa]
0,3
Max. moisture of material [%]
6
Granularity of transported material max. [mm]
8 (DN 25/DN 32)
16 (DN 40/DN 50)
Inner diameter of transport hoses [mm]
DN 25/32/40/50
Water inlet - inner diameter [mm]
DN 20
Horizontal transport distance max. [m]
max. 300
Vertical transport distance max. [m]
max. 100
Mains connection
3x400 V / TN-S
Max. deviation of voltage system
± 10 %
Coverage
IP 55
The transporting distance and height are directly affected by:
-The composition and water content of the conveyed mixture (with mixtures
consisting mostly of fine fractions should be tested individually,
-Sufficient amount of compressed air,
-Transport hoses or piping (for larger distances these must be straight with no
bends).
The compressed air must be always dry!
Principal dimensions
SSB 05.2 COM-F
Parameter
Length [mm]
1540
Width [mm]
710
Height [mm]
1230
Weight (with no accessories) [kg]
420
SSB 05.1 DUO
Parameter
Length [mm]
1370
Width [mm]
710
Height [mm]
1230
Weight (with no accessories) [kg]
410

Concrete Spraying Machine –SSB 05.1
10
VI. Accessories
The machine is delivered with optional accessories set corresponding with
required output.
Each type of accessories set differs from each other by an inner diameter of
transport hose. Marking DN xx (e.g. DN 40 = transport hose with an inner
diameter 40 mm).
Accessories
Rotor 1,9L
Rotor 3,9L
Rotor 6,9L
DN 25
X
---
---
DN 32
X
X
---
DN 40
X
X
---
DN 50
---
---
X
Standard set of accessories consists of:
- End hose with the nozzle –20 m
- Extension hose –20 m
- Water hose –20 m
- Upper sealing plate –3 pcs
- Lower sealing plate –3 pcs
- Nozzle ending –2 pcs
The set of accessories can be adjusted according to the customer’s requirements
(length of hoses, number of sealing plates etc.).
VII. Material
The material used in manufacturing the machine conforms to the valid
manufacturing documentation as regards chemical composition and mechanical
properties.
Aggregate properties for sprayed concrete conform to standards ČSN EN 12620 a
ČSN EN 13055-1.
VIII. Executions
All parts have been manufactured according to production blue-prints. Intolerance
dimensions conform to standards CSN ISO 2768-1.
The electric wiring conforms to standards CSN EN 60204-1. Protection against
the dangerous touch voltage is secured by an automatic switch off the source.

Concrete Spraying Machine –SSB 05.1
11
Metal-coating of parts performed in accordance with manufacturing
documentation and standards CSN EN 12 329. Before assembly, the coreless parts
were treated with primer on contact surfaces.
Welds were performed in accordance with blue-prints and standards CSN EN ISO
9692-1.
The product has the surface treatment of 3rd degree of rust aggressive
surroundings protection and the paint complies with CSN ISO 3864.
IX. Markings
The machine has a rating plate with the following data:
-Name and residence of manufacturer,
-CE mark –declaration of conformity,
-manufacturer’s number and year of production,
-rated air pressure,
-rated water pressure,
-input,
-rated voltage,
-weight of machine.
Electric motor and gearbox have their own rating plates.
X. Testing
The properties of the machine are checked in the manufacturing plant by means of
a functional test: running empty and under pressure of 0,3 MPa with sealing in
operation mode. Each machine has been tested.
The test consists of the following checks:
-functionality and tightness of the dosing drum and sealing plates (with
exhaust sealed, tightened clamping bolts and machine at the rest),
-loading of the electric motor at idle run with tightened clamping bolts,
-direction of dosing drum rotation (the direction of clock hands). The
direction is marked by the arrow-head on the machine head,
-functionality and tightness of the air distribution system,
-functionality of the vibrator and the rippling.
The execution of the tests is recorded in the „CERTIFICATE OF QUALITY
AND COMPLETENNES“.

Concrete Spraying Machine –SSB 05.1
12
XI. Delivery
Each product is delivered assembled with the following documentation:
-User manual
-Operating and maintenance instructions
-Report of initial control of electric equipment
-Certificate of quality and completeness –Warranty certificate
-Spare parts catalogue
XII. Warranty
The warranty period is 12 months from the date of the machine delivery.
Otherwise according to conditions in purchase contract.
The manufacturer provides no warranty:
-If the product is used for purposes or in a manner other than specified in
the User manual and Operating and Maintenance Instructions,
-If the product is not being given proper care (poor storage, assembly,
incorrect operating),
-If the product has been changed, modified or repaired without the
manufacturer’s previous consent,
-If the machine has been damaged by incorrect electrical connection,
-If the product has been damaged by a third person or vis major,
-If warranty is being claimed without Warranty Certificate,
-On the sealing plates, wearing plates, dosing drum, blower, transport
hoses and the nozzle since theirs lifetime depends on the abrasiveness of
the transported material.
XIII. Packaging
The machine is supplied on standard pallets, covered with plastic foil. If different
packaging is requested, this must be included in the purchase contract. The
standard accessories are placed on the pallet with the machine, or placed in the
machine loading hopper. All casings are disposable and charged to the customer.
XIV. Transport
The machine is transported by usual transportation means. When being
transported, the machine should be fixed to avoid spontaneous movement and
damage.

Concrete Spraying Machine –SSB 05.1
13
XV. Storing
The machine and accessories must be stored in spaces protected against the
elements, excessive dampness, acid vapours, oils and fungi.
XVI. Servicing
Servicing is carried out in accordance with the servicing conditions given in the
Operating and Maintenance Instructions.
XVII. List of Standards
At the Machine design and conformity review the following Standards have been
used: Directive of the European Community No. 98/37/ES –Mechanical
Equipment, Basic Requirements according to Appendix No. 1 to NV 24/2003 Sb.,
Czech National Standards (ČSN) EN ISO 12100–2, ČSN EN 294, ČSN EN 418,
ČSN EN 811, ČSN EN 953, ČSN EN 983, ČSN EN 1037, NV 178/2001 Coll.,
NV 502/2000 Coll., ČSN EN 1127-2, ČSN EN 12620, ČSN EN 13055-1,
ČSN ISO 2768-1, ČSN EN 60204-1, ČSN EN 12329, ČSN EN ISO 9692-1 and
ČSN ISO 3864.
XVIII. Supplements
Appendix No. 1: Machine Assembly
The End
Pribram –November 2006
Prepared by: Ing. Jiri Labuda
Company: FILAMOS, s.r.o., Hate 546, 261 01 Pribram, Czech Republic

Concrete Spraying Machine –SSB 05.1
14
Appendix No. 1: Machine Assembly SSB 05.2 (COM-F)
1. Tightening bolts
2. Dosing drum
3. Blower
4. Eyes for lifting-up with the crane
5. Gearbox
6. Lower air regulation
7. Vibrator regulation
8. Upper air regulation
9. Water separator
10. Electromagnetic valve
11. Main Air source
12. Automatic lubrication system
13. Electric energy connection
14. Remote control connection
15. Controlbox
16. Air vibrator
17. Hopper
Optional components such as frequnecy invertor, remote controler, water separator,
electromagnetic valve, automatic lubrication system are not mounted in the standard
configuration of the machine. Machine is being equipped with such components on customers
demand.
5
13
16
17
1
2
3
8
10
14
6
4
15
7
9
12
11
