Fimer TRIO-20.0-TL-OUTD User manual

Solar Inverter
TRIO-20.0/27.6-TL-OUTD
Quick Installation Guide
In addition to what is explained in this quick installation guide, the safety and installation information provided in the product manual must be read and
followed. The technical documentation for the product is available at the website.
The device must be used in the manner described in the manual. If this is not the case the safety devices guaranteed by the inverter might be
ineffective.

2
1. Labels and Symbols
The labels on the inverter have the Agency marking, main technical data and identification of the equipment and manufacturer
A
Inverter model
B
Inverter part number
C
Inverter serial number
D
Week/Year of manufacture
E
Main technical data
Fimer S.p.A.
Via Tortona, 25 - I 20144 Milano (MI)
B
C
D
V dc max
V dc Operating Range
V acr
f r
I ac max
Pacr (cos = ±0.9)φ
P acr (cos = 1) φ
MODEL:
TRIO-XX.X-TL-OUTD-XXX-400
Made in Italy
DIN V VDE 0126-1-1
PROTECTIVE CLASS: I
INVERTERSOLAR
V dc MPP
I dc max
I sc max
IP65
-25 to +60 °C
-13 to +140 °F
10 minutes
A
E
The labels attached to the equipment must NOT be removed, damaged, dirtied, hidden,etc...
If the service password is requested, the field to be used is the serial number -SN: YYWWSSSSSS- of the upper part (inverter)
In the manual and/or in some cases on the equipment, the danger or hazard zones are indicated with signs, labels, symbols or icons.
Always refer to instruction manual
,3;;
Protection rating of equipment Positive pole and negative pole of the
input voltage (DC)
General warning - Important safety
information Temperature range Always use safety clothing and/or personal safety devices
Hazardous voltage Without isolating transformer Point of connection for grounding
protection
Hot surfaces Direct and alternating currents,
respectively Time need to discharge stored energy
2. Inverter Models and Components
The models of inverter to which this guide refers are available in 2 power ratings: 20 kW / 27.6 kW.
For inverters of equal output power, the variant between the various models is the layout of the wiring box.
TRIO-XX.X-TL-OUTD TRIO-XX.X-TL-OUTD-S2 TRIO-XX.X-TL-OUTD-S2F TRIO-XX.X-TL-OUTD-S2X
CARD
COM
CARD
10 16
17
11
09 1213
Standard wiring box version:
- DC cable infeed cable gland
- DC cable connection terminal block
CARD
COM
CARD
10 1614 17 11
09 1213
S2 wiring box version:
- DC cable infeed cable gland
- DC cable connection terminal block
- AC+DC disconnect switch
CARD
COM
CARD
10 19 1614 1722
09 1213
S2F wiring box version:
- Quick fit connectors
- String protection fuses
- AC+DC disconnect switch
CARD
COM
CARD
10 1614 1722
09 15 12
13 18
19
S2X wiring box version:
- Quick fit connectors-
- String protection fuses
- DC overvoltage surge arresters
- AC overvoltage surge arresters
- AC+DC disconnect switch
Main components
09 Communication board 13 DC input terminal board 17 AC output terminal board
10 Service cable glands 14 AC+DC disconnect switch 18 AC overvoltage surge arresters
11 DC cable glands 15 DC overvoltage surge arresters 19 Input connectors
12 Jumpers 16 AC cable gland 22 String fuses
3. Choice of installation location
Environmental checks
-Consult the technical data to check the environmental parameters to be observed
-Installation of the unit in a location exposed to direct sunlight must be avoided as it may cause:
1. power limitation phenomena in the inverter (with a resulting decreased energy production by the system)
2. premature wear of the electrical/electromechanical components
3. premature wear of the mechanical components (gaskets) and of the user interface (display)
-Do not install in small closed rooms where air cannot circulate freely
-To avoid overheating, always make sure the flow of air around the inverter is not blocked
-Do not install in places where gases or flammable substances may be present
-Do not install in rooms where people live or where the prolonged presence of people or animals is expected, because
of the noise (about 50dB(A) at 1 m) that the inverter makes during operation
-Avoid electromagnetic interference that can compromise the correct operation of electronic equipment, with
consequent situations of danger.
Installations above 2000 metres
On account of the rarefaction of the air (at high altitudes), particular conditions may occur:
-Less efficient cooling and therefore a greater likelihood of the device going into derating because of high internal temperatures
-Reduction in the dielectric resistance of the air that, in the presence of high operating voltages (DC input), can create electric arcs (discharges) that can
reach the point of damaging the inverter.
All installations at altitudes of over 2000 metres must be assessed case by case with the FIMER Service department.

3
Installation position
-Install on a wall or strong structure suitable for bearing the weight
-Install in safe, easy to reach places
-If possible, install at eye-level so that the display and status LEDs can be seen easily
-Install at a height that considers the heaviness of the equipment
-Install vertically with a maximum inclination of +/- 5°
-To carry out maintenance of the hardware and software of the equipment, remove the covers on the
front. Check that there are the correct safety distances for the installation that will allow the normal
control and maintenance operations to be carried out
-Comply with the indicated minimum distances
-For a multiple installation, position the inverters side by side
-If the space available does not allow this arrangement, position the inverters in a staggered
arrangement as shown in the figure so that heat dissipation is not affected by other inverters
Final installation of the inverter must not compromise access to any disconnection devices that may
be located externally.
Please refer to the warranty terms and conditions available on the website and evaluate any possible
exclusion due to improper installation.
4. Instruments
LEDs and BUTTONS, in various combinations, can be used to view the status or carry out complex actions that are described more fully in the manual.
LED
POWER
GREEN On if the inverter is
working correctly. Flashes when
checking the grid or if there is
insu󰀩cient sunlight.
LED
ALARM
YELLOW The inverter has de-
tected an anomaly. The anomaly
is shown on the display.
LED
GFI
RED Ground fault on the DC side
of the PV generator. The error is
shown on the display.
The operating parameters of the equipment are displayed through the display (23): warnings, alarms, channels, voltages, etc.
Description of symbols and display fields:
b1 RS485 data transmission b13 Daily energy produced
b2 RS485 line present b14 PV voltage > Vstart
b3 Radio line present. b15 DC voltage value
b4 Bluetooth line present (*) b16 DC current value
b5 WiFi line present (*) b17 DC/DC circuit part
b6 Warning b18 DC/AC circuit part
b7 Temperature derating b19 AC voltage value
b8 Instantaneous power b20 AC current value
b9 MPP scan running b21 Connection to the grid
b10 Graphic display b22 Grid status
b11 Power graph b23 Cyclic view on/o󰀨
b12 Total energy (*) NOT available
5. Lifting and transport
Transport and handling
Transport of the equipment, especially by road, must be carried out with by suitable ways and means for protecting the
components (in particular, the electronic components) from violent shocks, humidity, vibration, etc.
Lifting
Where indicated and/or where there is a provision, eyebolts or handles, which can be used as anchorage points,
are inserted and/or can be inserted.
The ropes and means used for lifting must be suitable for bearing the weight of the equipment.
Unpacking and checking
The components of the packaging must be disposed on in accordance with the regulations in force in the country
of installation.
When you open the package, check that the equipment is undamaged and make sure all the components are present.
If you find any defects or damage, stop unpacking and consult the carrier, and also promptly inform the Service FIMER.
Weight of the equipment units
Mass weight
Lifting
points n°#
Minimum
rope height
Holes or Eyebolts
UNI2947
INVERTER unit TRIO-20.0: 60 kg
TRIO-27.6: 65 kg 4
1.200 mm
M 12 - assembly kit with 4 handles
and 2 eyebolts (to order: TRIO
HANDLING KIT)
WIRING BOX
unit
Standard / -S2: 7 kg
-S2F / -S2X: 15 kg 2 - -
POWER ALARM GFI ESC UP DOWN ENTER
DC
AC
25 23 24
ESC
It is used to access the main menu, to go back
to the previous menu or to go back to the
previous digit to be edited.
UP It is used to scroll up the menu options or
to shift the numerical scale in ascending order.
DOWN
It is used to scroll down the menu options
or to shift the numerical scale in descending
order.
ENTER
It can be used to conrm an action, to access
the submenu for the selected option (indicated
by the > symbol) or to switch to the next digit
to be edited.
DC
AC
b1
b2
b3
b4 b6
b7 b9 b10
b17
b16
b14
b13
b12
b11 b15 b18
b20 b22
b21
b19
b23
b8
b5
POWER ALARM GFI ESC UP DOWN ENTER
POWER ALARM GFI ESC UP DOWN ENTER
M12
TRIO
TRIO
M12
80
cm
50
cm
50cm 50cm
80
cm
50
cm
50cm 50cm

4
6. List of supplied components
Components available for all models Quantity
Connector for connecting the
configurable relay 2
Connector for the connection of the
communication 4
L-key, TORX TX20 1
Two-hole gasket for M25 signal cable
glands and cap 2+2
Two-hole gasket for M20 signal cable
glands and cap
1+1
Bracket for wall mounting 1
Components available for all models Quantity
Jumpers for configuration of the
parallel input channels 2
Quick Installation Guide 1
Additional components for (-S2F/-S2X) models Quantity
Female quick fit connectors 8 (20.0kW)
10 (2 7.6k W )
Male quick fit connectors 8 (20.0kW)
10 (27. 6 kW)
Fuses gPV - 1000V DC - 15.0 A 16 (20 kW)
20 (27.6 kW)
7. Assembly instruction
01 Bracket 08 Front cover 15 DC overvoltage surge arresters 22 String fuses
02 Wiring box 09 Communication board 16 AC cable gland 23 Display
03 Inverter 10 Service cable glands 17 AC output terminal board 24 Keypad
04 Cover 11 DC cable glands 18 AC overvoltage surge arresters 25 LEDpanel
05 Clamp screw 12 Jumpers 19 Input connectors (MPPT1) 26 Heatsink
06 Handles 13 DC input terminal board 20 Input connectors (MPPT2) 27 Locking screw
07 Connector screws 14 AC+DC disconnect switch 21 Anti-condensation valve
• With the help of a spirit level
mark the 2 holes in the vertical
strip (A) to ensure it is mounted
vertically. Drill a hole with a bit
which is suitable for the depth
required by the plug and fit the
plugs into the holes, using the
spirit level to check it is vertical
• Tighten the pin (B) on the (A)
vertical strip
• Position the bracket (C) in the
slot on the vertical strip (A) and
mark the 4 holes, using a spirit
level to check it is horizontal
• Position the bracket (D) in the
slot on the strip (A) and mark
the 2 holes, using a spirit level
to check it is horizontal
• Drill with a bit which is suitable
for the depth required by the
plug and fit the plugs into the
holes just made
• Fit the bracket (C) into the slot of
the (A) and tighten the screws,
using a spirit level to check it is
horizontal
• Fit the bracket (D) into the slot of
the (A) and tighten the screws,
using a spirit level to check it is horizontal
• Fasten the Wiring Box (02) inserting the head of the rear screws into the slots in the bracket, remove the front cover and carry out all the necessary
connections.
NOTE –DThe inverter does not need to be installed (03) at this stage
• Unscrew the connection screws (07) and remove the cover (04) so that you can access the connector between the Wiring Box and the Inverter
• Mount the inverter by putting the heads of the rear screws into the slots in the bracket. To make this operation easier, handles (06) or 2 eyebolts (M12) can
be fitted in the side holes. The threaded wall plug in the lower part of the heat sink makes contact with the pin (B), keeping the inverter in the ideal position.
• Use the prefitted screw or insert the coupling screw (05) (optional coupling screw) and tighten it bringing the Wiring Box towards the inverter until it makes
easy contact.
• Tighten the 2 internal screws (07) fully to the centring pins in the Wiring Box ensuring the gasket adheres correctly
• Fix the assembled inverter to the bracket by tightening the locking screw (27) located at the bottom.
• Remove the coupling screw (05) used for coupling carefully as it could come out from below
NOTE –DThe rear coupling screw (05) is not included in the inverter supply. It can be purchased separately and used as a fitting tool during
installation. This tool must be extracted from the wiring box after assembly and can be used in other installations. Before removal, make sure that the
connection screws (07) are tightened and that the assembled inverter is secured to the wall bracket. Be careful when removing the coupling screw
as it is free to come out from below.
POWER ALARM GFI ESC UP DOWN ENTER
TRIO
STANDARD / S2
S2X / S2F
09 13 12 17
10 11 14 16
09 15 13 12 18
10 14 17 16
10 11 14 16 21
26
01
03
06
27
23
25
24
04
05
C
A
D
B
09
02
08
07 22
2B 2D2C
IN2 2E
-
+
1A
1E IN1
1B 1C 1D
-
- - -
+
+
- -
++ +
2A
-
+ +
10 19 20 14 16 21

5
8. DC input configuration
All versions of the inverter are equipped with two input channels (therefore with double maximum power
point tracker MPPT) independent of each other, which can however be connected in parallel using a single
MPPT.
- Configuration of parallel-connected channels
This configuration involves the use of the two input channels (MPPT) connected in parallel. This means
that the jumpers (12) between the two channels (positive and negative) of the DC input terminal board (13)
must be installed and that the switch a01 situated on the communication card (09) must be set to “PAR”.
- Configuration of independent channels (default configuration)
This configuration involves the use of the two input channels (MPPT) in independent mode. This means
that the jumpers (12) between the two channels (positive and negative) of the DC input terminal board (13)
must not be installed and that the switch a01 situated on the communication card (09) must be set to “IND”
9. Input connection (DC)
WARNING –BCheck for correct polarity in the input strings and absence of any leakage to ground in the PV generator.
When exposed to sunlight, the PV panels supply DC direct voltage to the inverter.
The inside of the inverter may only be accessed after the equipment has been disconnected from the grid and from the photovoltaic generator.
The inverter is only to be used with photovoltaic units with ground insulated input poles unless accessories allowing grounding of the inputs have
been installed. In this case it is compulsory to install an isolation transformer on the AC side of the system.
- Connection of inputs on the Standard and S2 models
For these two models, connection with the DC input terminal board (13) is made by inserting the cables in the DC cable glands
(11). The maximum accepted cable cross-section ranges from 10 to 17 mm, whereas each individual terminal of the terminal
board accepts a cable with cross-section of up to 50 mm2 (tightening torque 6Nm).
Unscrew the cable gland, remove the cover, insert the cable of suitable cross-section and connect it to the terminals on the
DC input terminal board (13). Once the connection to the terminal board is complete, screw in the cable gland firmly (tightening
torque 5.0Nm) and check the tightness.
- Connection of inputs on the S2F / S2X model
WARNING –BReversing polarity may result in serious damage. Always check the polarity before connecting up each
string! Each input is equipped with protection fuses: check that the fuse current rating is properly sized for the photovoltaic
modules installed.
For string connections using the S2F / S2X wiring box, the quick fit connectors (multicontact or weidmuller) situated at the bottom
of the mechanics are used.
For each input channel, there are two groups of connectors:
- Input connectors (MPPT1) (19) with codes 1A, 1B, 1C, ...
- Input connectors (MPPT2) (20) with codes 2A, 2B, 2C, ...
Connect all the strings included in the design of the system and always check the tightness of the connectors.
ATTENTION –AIn these versions of the wiring box, you MUST directly connect the individual strings coming into the
inverter (do not make field switchboards for parallel strings). This is because the string fuses (22), situated on each input,
are not sized to take strings in parallel (array).
If some string inputs are not used, check that there are covers on the connectors and install them if they are missing.
This operation is necessary for the tightness of the inverter and to avoid damaging the free connector that could be used at a later date.
10. Line cable and protection devices
Load protection breaker (AC disconnect switch) and line cable sizing
To protect the AC connection line of the inverter, we recommend installing a device for protection against over current and leakage with the following characteristics:
TRIO-20.0-TL-OUTD TRIO-27.6-TL-OUTD
Type Automatic circuit breaker with differential thermal magnetic protection
Voltage/Current rating 400V /40A 400V /63A
Magnetic protection characteristic
B/C
Number of poles 3/4
Type of differential protection A/AC
Differential sensitivity 300mA
FIMER declares that the FIMER transformerless inverters, in terms of their construction, do not inject continuous ground fault currents and therefore there
is no requirement that the differential protection installed downstream of the inverter be type B in accordance with IEC 60755 / A 2.
Characteristics and sizing of the line cable
For the connection of the inverter to the grid, you can choose between a star connection (3 phases + neutral) and a delta connection (3 phases).
The cross-section of the AC line conductor must be sized in order to prevent unwanted disconnections of the inverter from the grid due to high impedance
of the line that connects the inverter to the power supply point
Cross-section of the line conductor (mm2) Maximum length of the line conductor (m)
TRIO-20.0-TL-OUTD TRIO-27.6-TL-OUTD
10 42m 30m
16
70m 50m
25 100m 78m
35 138m 98m
The values are calculated in nominal power conditions, taking into account:
1. a power loss of not more than 1% along the line. 2. copper cable, with EPR/XLPE insulation, laid in free air
13
CARD
COM
CARD
MEMORY
1
1
a01
+
12
CARD
COM
CARD
MEMORY
1
1
a01
+
13 12
1411
1213
1422
1213
Max 35mm
2
20 ÷ 32 mm

6
11. Output connection (AC)
For the connection of the inverter to the grid, you can choose between a star connection (3 phases + neutral) and a delta connection (3 phases).
WARNING –BIn any case, connection of the inverter to ground is mandatory.
To prevent electrocution hazards, all the connection operations must be carried out with the disconnect switch downstream of the inverter (grid side)
open and locked.
For all models, connection with the AC output terminal board (17) is made by inserting the cables in the AC cable gland (16).
The maximum accepted cable cross-section ranges from 20 to 32 mm, whereas each individual terminal of the terminal board
accepts a cable with cross-section of up to 35 mm2 (tightening torque 2.5Nm).
Unscrew the cable gland, remove the cover, insert the cable of suitable cross-section and connect the conductors(Neutral, R, S,
T and Ground) to the terminals on the AC output terminal board (17).
Be careful not to change round one of the phases with neutral!
Once the connection to the terminal board is complete, screw in the cable gland firmly (tightening torque 7.5Nm) and check the tightness.
Before connecting the inverter to the distribution grid it is necessary to set the country standard by manipulating the two rotary switches a05.
12. Setting the grid standard
Before connecting the inverter to the distribution grid it is necessary to set the country standard by manipulating the two rotary switches a05:
Table: country standard and language
Switch
Country Grid Standard
(name displayed)
Display
language
Switch Country Grid Standard
(name displayed)
Display
language
1 2 1 2
00NON-ASSIGNED ENGLISH 23TURKEY HV@400V ENGLISH
01GERMANY VDE 0126@400V ENGLISH 24CEI-016 @ 400V ITALIAN
04UL 1741 @ 277V Three Phase ENGLISH 25EN50438 generic @ 400V ENGLISH
05ENEL@400V (ENEL) ENGLISH 28FRANCE VFR 2019 @ 230V ENGLISH
06SPAIN@400V (RD 1699) SPANISH 29THAILAND MEA @ 230V ENGLISH
08UK - G59@400V (UK G59) ENGLISH 2 C VDE 0126 3W @ 230V ENGLISH
09IRELAND@400V (IRELAND) ENGLISH 2 D THAILAND PEA @ 220V ENGLISH
0 A AUSTRALIA@400V (AS 4777) ENGLISH 2 E SINGAPORE @ 230V ENGLISH
0 B ISRAEL@400V (ISRAEL) ENGLISH 2 F CHINA HV @ 230V ENGLISH
0 C GERMANY - BDEW@400V (BDEW) GERMAN 36DUBAI MV ENGLISH
0 D FRANCE@400V (FRANCE) FRENCH 37DUBAI LV EX ENGLISH
0 E NETHERLANDS@400V DUTCH 46GERMANY–VDE AR-N-4105@230V ENGLISH
0 F GREECE@400V (GREECE) ENGLISH 47UK – G99 @ 230V ENGLISH
10PORTUGAL@400V (PORTUGAL) ENGLISH 49EN 50549-1/2019 (LV)@230V ENGLISH
11CORSICA@400V (CORSICA) FRENCH 4 A EN 50549-2/2019(MV)@230V ENGLISH
12HUNGARY@400V (HUNGARY) ENGLISH
CARD
COM
CARD
a05
12
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
12
13CHINA@400V (CHINA) ENGLISH
14KOREA@380V (KOREA) ENGLISH
15TAIWAN@40 0V (TAIWAN) ENGLISH
16CHECA REPUBLIC@400V (CZECH) CZECH
17GERMANY-VDE AR-N-4105@400V GERMAN
18CEI-021@400V EXT. prot. (CEI021 EX) ITALIA N
1 B SOUTH AFRICA@400V (S.AFRICA) ENGLISH
1 C SPAIN RD 1565@400V (RD 1565) SPANISH
1 D BELG C10-11 100% @ 400V (C1011 100) FRENCH
1 E BELG C10-11 110% @ 400V (C1011 110) FRENCH
1 F BRAZIL@380V (BRAZIL) ENGLISH
20TURKEY LV@400V (TURKEY LV) ENGLISH
21ROMANIA@400V ENGLISH
22SLOVENIA @400V ENGLISH
READ THE MANUAL –EThe settings become fixed after 24 hours of operation of the inverter (the PV generator simply has to be under power).
The standard for the Italian grid which must be set during installation is 1 -8 (CEI-021 @ 400V EXTERNAL Protection)
13. Connection of the communication and control signals
The following table shows the main components and the connections available on the control and communication board. Each cable that must be
connected to the communication board must go through the three service cable glands (10).
Ref. inverter Ref. manual Description
S5 a01 Switch for setting parallel-connected or independent input channels
S7 e S8 a05 Rotary switches for setting the standard of the country and the language
of the display
S3 a07 Switch for setting analogue sensor 1 to Volts or mA
S1 a08 Switch for setting analogue sensor 2 to Volts or mA
J2 a09
Terminal block connecting to the configurable relay that allows connection
of external devices which, according to the mode selected in the menu
SETTINGS>Alarm can, for example, signal malfunctions. The operating
modes that can be set are: Production; Alarm; Alarm (configurable);
Crepuscolar
J3 a10 Terminal block for connection of: Environmental sensors; Environmental
sensor power supply (24Vdc); Tachometer signal (WIND version)
J4 a11
Terminal block for connection of: PC RS485 serial connection (to connect
local or remote monitoring systems); PMU serial connection (to manage
active/reactive power infeed by the grid company); Remote ON/OFF.
S2 a12 Switch for setting the termination resistance of the RS485 (PMU) line
S4 a13 Switch for setting the termination resistance of the RS485 (PC) line
J7 e J8 a14 Connection of the RS485 (PC) line on RJ45 connector
J5 e J6 a16 Connection of the RS485 (PMU) line on RJ45 connector
READ THE MANUAL –EThe RS485 PMU communication line can be configured to operate with a ModBus communication protocol.
READ THE MANUAL –EPlease refer to the manual for details of the connections and functions available on the control and communication board
17
N R S T
CARD
COM
CARD
a01
a05
a07
a08
a09 a10 a11 a13 a12
a01
a14
a16

7
14. Commissioning
FORBIDDEN –HDo not place objects of any kind on the inverter during operation!
Do not touch the heatsink while the inverter is operating!Some parts may be very hot and cause burns.
The inverter commissioning procedure is as follows:
-Turn the AC+DC disconnect switch (14) to the ON position.
If there are two separate external disconnect switches (one for DC and the other for AC), first close the AC disconnect switch and then the DC disconnect
switch. There is no order of priority for opening the disconnect switches.
-When the inverter has power, the first check performed is the one relating to the input voltage:
1. If the DC input voltage is lower than the Vstart voltage (voltage required to begin the inverter’s grid connection) the b14 icon remains off and the “Waiting sun”
message is displayed b10.
2. If the DC input voltage is higher than the Vstart voltage the b14 icon is displayed and the inverter goes to the next stage of the controls.
In both cases the voltage levels and input current are displayed in the b15 and b16 fields.
-The inverter performs a control of grid parameters. The b22 icon, which represents the grid distribution, can have different statuses:
3. not present, if the mains voltage results as absent.
4. flashing, if the mains voltage is present but outside the parameters dictated by the standard of the country of installation.
5. turns on, if the mains voltage is present and within the parameters dictated by the standard of the country of installation. In this condition, the inverter starts the
sequence of grid connection.
If the input voltage and the grid voltage are within the inverter operating intervals, connection to the grid will commence. After the inverter is
connected, the icons on the whole line b21 will come on steady.
Once the connection sequence has been completed, the inverter starts to operate and indicates its correct operation by making a sound and
by the green LED coming on steady on the LED panel (25).
If the inverter signals any errors/warnings the messages and their codes will be indicated on the display (23). This state will also cause switching
of the multi-function relay (set to alarm mode in the menu SETTINGS>Alarm) which activates any external signalling device that may be connected.
15. Structure of the display menu
The display (23) has a section b10 (graphic display) for moving through the menu using the buttons of the LED panel (25). Section b10 consists of 2 lines
with 16 characters per line:
Viewing of the GENERAL
INFORMATION is cyclic.
This information relates to the
input and output parameters
and the inverter identification
parameters.
By pressing ENTER it is possible
to lock scrolling on a screen to
be constantly displayed.
Press ESC to access the three
main menus, which have the
following functions:
• STATISTICS>Displays the
statistics;
• SETTINGS>Modify the
settings of the inverter
• INFO>View service messages
for the operator
READ THE MANUAL –E
Refer to the manual for
details regarding use and
functions available in the
menu.
16. Characteristics and technical data
TRIO-20.0-TL-OUTD TRIO-27.6-TL-OUTD
Input
Rated input DC power (Pdcr)20750 Wp 28600 Wp
Maximum Input Power (Pdcmax)22700 Wp 31000 Wp
Rated Input Voltage (Vdcr) 620 V
Input Activation Voltage (Vstart)360 V (adj. 250...500 V)
Input operating range (Vdcmin...Vdcmax)0.7 x Vstart...950 V
Input voltage interval for MPP 200...950V
Maximum Input Power for each MPPT 12000 W 16000 W
Input voltage Range for Operation at rated power with configuration of the MPPTs in parallel 440...800 V 500...800 V
DC Power Limitation for each MPPT with Independent Configuration of
MPPT at Pacr,max unbalance example
12000 W [480V≤VMPPT≤800V]
the other channel: Pdcr-12000W
[350V≤VMPPT≤800V]
16000 W [500V≤VMPPT≤800V]
the other channel: Pdcr-16000W
[400V≤VMPPT≤800V]
Absolute Maximum Input Voltage (Vmax,abs)1000 V
Power derating vs. Input voltage (parallel or independent MPPT configuration) Linear Derating From MAX to Null [800V≤VMPPT≤950V]
Number of Independent MPPTs 2
Maximum current for each MPPT
25.0 A 32.0 A
Maximum Backfeed current (from AC to DC side) Negligible
STATISTICS
Total
Partial
Today
Last 7 days
Last month
Last 30 days
Last 365 days
User Period
SETTINGS
Address
Display Set.
Service
New PW
Cash
Time
Language
V Start
Autotest
Alarm
Remote Control UV Prot. Time
MPPT
PMU RS485 prot.
PMU RS485 baud
Power Reduction
INFORMATION
Part No.
Serial No.
Firmware
Country Select
Press
ESC
*1
*1 Available only for grid standard CEI-021
GENERAL INFORMATION
(cycle view)
Structure of the main menu
password 0000
Inverter OK
Date Time
Type OUTD
P/N -XXXX-
Pout XXXXXW
COSp X.XXX
Regulation Type
Tamb XX.X°C
Tinv XX.X°C
Ppk XXXXXW
PpkDay XXXXXW
VoutR XXXV
Vout avg XXXV
VoutS XXXV
Vout avg XXXV
VoutT XXXV
Vout avg XXXV
VoutRS XXXV
VoutST XXXV
VoutTR XXXV
IoutR XX.XA
FoutR XX.XXHz
IoutS XX.XA
FoutS XX.XXHz
IoutT XX.XA
FoutT XX.XXHz
Vin1 XXXV
Iin1 XX.XA
Vin2 XXXV
Iin2 XX.XA
Pin1 XXXXXW
Pin2 XXXXXW
Riso X.XM©
Ileak XmA

FIMER_TRIO-20.0_27.6_Quick Installation Guide_EN_RevE
8
For more information
please contact your
local FIMER
representative or visit:
fimer.com
We reserve the right to make technical changes or
modify the contents of this document without prior notice.
With regard to purchase orders, the agreed particulars
shall prevail. FIMER does not accept any responsibility
whatsoever for potential errors or possible lack of
information in this document.
We reserve all rights in this document and in the
subject matter and illustrations contained therein. Any
reproduction, disclosure to third parties or utilization of
its contents – in whole or in parts – is forbidden without
prior written consent of FIMER. Copyright© 2021 FIMER.
All rights reserved.
19-03-2021
TRIO-20.0-TL-OUTD TRIO-27.6-TL-OUTD
Number of Pairs of DC Connections at Input
1 for each MPPT (Standard and -S2 versions)
4 for each MPPT (-S2F / -S2X versions)
1 for each MPPT (Standard and -S2 versions)
5 for each MPPT (-S2F / -S2X version s)
Type of Input DC Connectors Tool Free PV Connector WM / MC4 (Screw Terminal Block on Standard and -S2 versions)
Type of photovoltaic panels that can be connected at input according to IEC 61730 Class A
Input protection
Reverse polarity protection Protection for Inverter only, from current limited source, for standard and
-S2 versions, and for versions with fuse with max 2 strings connected
Input Overvoltage Protection - Varistors 2 for each MPPT
Input Overvoltage Protection - DIN rail surge arrester (-S2X version) 3 (Class II) for each MPPT
Maximum short-circuit current for each MPPT 30.0A 40.0A
Isolation Control In accordance with the local standard
Characteristics of DC disconnect switch for each MPPT (Version with DC
disconnect switch) 40 A / 1000 V
Fuses (-S2F and -S2X versions) gPV / 1000 V / Max. 20A
Maximum current for each input connector (only versions -S2F/-S2X /-S1J/-S2J) 13.5 A
Output
AC connection to the Grid Three phase 3W or 4W+PE
Rated output voltage (Vacr)400 Vac
Output Voltage Range (Vacmin...Vacmax) 320...480 Vac
(1)
Rated Output Power (Pacr) 20000 W 27600 W
Maximum Output Power (Pacmax) 22000 W (3) 30000 W (4)
Maximum apparent Output Power (Sacmax) 22200 VA 30000 VA
Maximum Output Current (Iacmax)33.0 A 45.0 A
Inrush Current Negligible
Maximum output fault current <63Arms(100mS)
Rated Output Frequency (fr)50 Hz / 60 Hz
Output Frequency Range (
fmin...fmax
) 47...53 Hz / 57...63 Hz (2)
Nominal Power Factor (Cosphiac,r) and adjustable range > 0.995 (adj. ± 0.9, or fixed by display
down to ± 0.8 with max 22 kVA )
> 0.995 (adj. ± 0.9, or fixed by display
down to ± 0.8 with max 30 kVA )
Total Harmonic Distortion of Current < 3%
Type of AC Connections Screw terminal block, maximum cross-section 35 mm2
Output Protection
Anti-Islanding Protection According to local standard
Maximum AC Overcurrent External protection 34.0 A 46.0 A
Output Overvoltage Protection - Varistors 4
Output Overvoltage Protection - DIN Rail surge arrester (-S2X version) 4 (Class II)
Operating performance
Maximum efficiency (ηmax)
98.2%
Weighted efficiency (EURO/CEC) 98.0% / 98.0%
Stand-by Consumption < 8W
Night-time consumption < 1.0 W
Communication
Wired Local Monitoring
PVI-USB-RS485_232 (opt.), PVI-DESKTOP (opt.)
Remote Monitoring PVI-AEC-EVO (opt.), VSN700 Data Logger (opt.)
Wireless Local Monitoring PVI-DESKTOP (opt.) with PVI-RADIOMODULE (opt.)
User Interface Graphic Display
Environmental
Ambient Temperature -25...+60°C /-13...140°F with derating above 45°C/113°F
Relative humidity 0...100% condensing
Noise Emission < 50 db(A) @ 1 m
Maximum Operating Altitude 2000 m / 6560 ft
Environmental pollution classification for external environment 3
Environmental Category External
Physical
Environmental Protection Rating IP 65
Cooling system Natural
Overvoltage Category in accordance with IEC 62109-1 II (DC input) III (AC output)
Dimensions (H x W x D) 1061 x 702 x 292 mm 41.7" x 27.6" x 11.5"
Weight Standard and S2: 67 kg/147lb
S2F / S2X: 75 kg / 165 lb
Standard and S2: 72 kg/158lb
S2F / S2X: 80 kg / 176 lb
Safety
Isolation level Transformerless (TL)
Safety class I
Marking CE (50Hz only)
1. The AC voltage range may vary depending on specific country grid standard 3. Limited to 20000 W for Germany
2. The Frequency range may vary depending on specific country grid standard 4. Limited to 27600 W for Germany
Remark. Features not specifically listed in the present data sheet are not included in the product
