Finkbiner Industries STUDIO HAVOC User manual

STUDIO HAVOC Power Amplifier
User’s Manual Finkbiner Industries LLC
STUDIO HAVOC Power Amplifier (Model 15168): User’s Manual 15225 Revision 0
Finkbiner Industries LLC

www.HavocAmps.com
STUDIO HAVOC Power Amplifier (Model 15168): User’s Manual 15225 Revision 0
2
Table of Contents
WARNINGS................................................................................................3
RISK OF ELECTRICAL SHOCK ..............................................................3
SERVICE AND SUPPORT.....................................................................3
ALLOW ADEQUATE VENTILATION.....................................................3
RISK OF DAMAGE ..............................................................................3
OVERVIEW.................................................................................................4
FEATURES..................................................................................................4
FRONT PANEL............................................................................................5
REAR PANEL ..............................................................................................5
SPECIFICATIONS ........................................................................................7
WARRANTY................................................................................................8
Warranty Coverage...............................................................................8
Items Not Covered................................................................................8
How to obtain warranty service............................................................8
Satisfaction Guarantee..........................................................................8

www.HavocAmps.com
STUDIO HAVOC Power Amplifier (Model 15168): User’s Manual 15225 Revision 0
3
WARNINGS
RISK OF ELECTRICAL SHOCK
Do not open cover, risk of electrical shock inside.
To reduce the risk of fire or electric shock, this
apparatus should not be exposed to rain or moisture
and objects filled with liquids should not be plated on
this apparatus. To prevent the risk of fire hazard,
replace with same type 250 volt fuse.
SERVICE AND SUPPORT
For service or support, contact:
[e-mail]
ALLOW ADEQUATE VENTILATION
Do not block the vents on top of the apparatus. Provide adequate
ventilation to prevent overheating.
RISK OF DAMAGE
Do not power on your STUDIO HAVOC power amplifier without first
plugging in an 8Ω speaker cabinet; damage to your amplifier will
otherwise result.

www.HavocAmps.com
STUDIO HAVOC Power Amplifier (Model 15168): User’s Manual 15225 Revision 0
4
OVERVIEW
Congratulations on your purchase of a STUDIO HAVOC power
amplifier, hand-built and hand-wired by Finkbiner Industries LLC in the
USA. The STUDIO HAVOC power amplifier features one 12AY7 tube
and two EL84 power tubes (Class AB push-pull) with 10 watts of output
power, a VOLUME control to tame the volume, and an 8Ω speaker level
output for connecting to your choice of 8Ω speaker cabinet.
The STUDIO HAVOC power amplifier is perfectly sized for use in
small rooms, apartments, recording studios; anywhere that volume
needs to be manageable with uncompromised tone.
For best results, we of course recommend driving your new STUDIO
HAVOC power amplifier with a HAVOC preamplifier. They are, after
all, designed for each other.
FEATURES
Flat frequency response in the guitar range preserves the tone
that has been crafted in a preamplifier
Low noise design and layout
Line level input
VOLUME control
8Ωspeaker level output
10 watts of all tube Class AB push-pull power
Cathode biased power tubes makes for easy power tube
replacement; no bias adjustment necessary

www.HavocAmps.com
STUDIO HAVOC Power Amplifier (Model 15168): User’s Manual 15225 Revision 0
5
FRONT PANEL
1. VOLUME
The STUDIO HAVOC power amplifier has a single volume
control for fine tuning the power sent to the speaker. Use in
conjunction with the level control from your input device.
2. POWER
It turns it on when you want to rock, and turns it off when you
are finished.
REAR PANEL
3. POWER
Plug the included IEC power cable in here, and plug the other
end into a grounded 120 VAC outlet. Be sure to use a properly
grounded outlet. Do NOT remove the ground pin from the
power cord, due to shock hazard.
3
4
5
1
2
6

www.HavocAmps.com
STUDIO HAVOC Power Amplifier (Model 15168): User’s Manual 15225 Revision 0
6
4. FUSE
The power cord receptacle contains a fuse for protection. Only
replace the fuse when the power cord has been disconnected,
and only with like specifications (see SPECIFICATIONS on page
7). If your amplifier is blowing fuses, send it in for service (see
SERVICE AND SUPPORT on page 3). Do NOT replace with a
larger current rating fuse.
5. SPEAKER OUT
Accepts a 1/4” TS connector, and sends a speaker level signal to
an 8Ω speaker cabinet.Be sure to use an appropriately sized
speaker cable (16 AWG is fairly standard for typical cable
lengths of ten feet or less to 8Ω speakers), NOT a guitar cable.
6. LINE IN (UNBALANCED)
The STUDIO HAVOC power amplifier has a single high(-ish)
impedance (100 KΩ) input for use with line level signals from a
HAVOC preamplifier, stomp box, mixer, or other device. The
input jack accepts a standard 1/4” TS guitar cable.

www.HavocAmps.com
STUDIO HAVOC Power Amplifier (Model 15168): User’s Manual 15225 Revision 0
7
SPECIFICATIONS
MODEL: 15168
INPUT IMPEDANCE: 100 KΩ
OUTPUT POWER: 10 watts
REQUIRED SPEAKER IMPEDANCE: 8Ω
POWER CONSUMPTION: < 50 watts 60 Hz, 120 VAC
FUSE: 5x20mm, 250V, 0.50 amp, ceramic, slow blow
DIMENSIONS: 19” x 8” x 3.5”
WEIGHT: 8 lbs
TUBES: (1) 12AY7, (2) EL84

www.HavocAmps.com
STUDIO HAVOC Power Amplifier (Model 15168): User’s Manual 15225 Revision 0
8
WARRANTY
Warranty Coverage
This warranty covers defects in material and workmanship in HAVOC
amplifiers purchased in the USA for a period of one year from the date
of original purchase. The warranty begins on the date of purchase.
Finkbiner Industries LLC will repair or replace, at its discretion, the
defective product.
Items Not Covered
The warranty does not cover:
1. Damage caused by accident, abuse, modification, misuse,
neglect or occurring during shipment.
2. Damage caused by service or repair performed by persons not
authorized by Finkbiner Industries LLC.
3. Products not purchased from an authorized HAVOC amplifiers
dealer.
4. Products on which the serial numbers have been removed,
defaced, or altered.
How to obtain warranty service
Contact [e-mail] to arrange for warranty service.
Include a copy of your sales receipt.
Satisfaction Guarantee
If you are not satisfied with your HAVOC amplifier for any reason,
contact [email protected] within 30 days of the original date of
purchase to return the product for a full refund of the purchase price,
less shipping costs. The product must be in original, undamaged
condition.
