Finn MBX Series User manual

MBX MIG0912
MBX
Mounting Instructions Guide
9281 LeSaint Drive • Fairfield, Ohio 45014
Phone [phone] • Fax [phone]
Sales: 1-800-543-7166

FOR OFFICE USE ONLY
DATE UPDATE DESCRIPTION CODE
09/12/19 Initial release MR0912

3
SAFETY FIRST
With any piece of equipment, new or used, the most important part of its operation is SAFETY!
FINN Corporation encourages you and your employees to familiarize yourselves with your new
equipment and stresses safe operation. Consult the operations manual and the truck manual.
The symbols below are used to call attention to safety procedures.
Danger indicates an imminently hazardous situation which, if not
avoided, WILL result in death or serious injury.
Warning indicates a potentially hazardous situation which, if not
avoided, COULD result in death or serious injury.
Caution indicates a potentially hazardous situation which, if not
avoided, MAY result in minor or moderate injury.
Notice indicates important information, that if not followed, MAY
cause damage to equipment.
NOTE: This is helpful information.
MOUNTING THE MATERIAL BLOWER
A complete mounting kit is provided with the unit, but the mounting kit is shipped loose.
Before selecting a chassis for the Material Blower, carefully review this manual and consider the
following:
A. Never exceed either the Gross Axle Weight Rating (GAWR) or the Gross Vehicle Weight
Rating (GVWR) for the chassis.
B. Install the Material Blower only onto a vehicle with cab-to-axle dimension sufficient to fully
support the Material Blower frame length.
C. Position the Material Blower such that the required clearance zones are maintained.
Once the proper carrier has been selected, the blower must be securely mounted onto it.
The FINN Material Blower should be mounted by a qualified truck body
installer. Failure to comply could result in personal injury. Failure to
comply could also result in product or property damage.
Install/Mount the FINN Material Blower in compliance with the vehicle
ratings, machine mounting requirements and applicable laws. Failure
to do so could result in personal or property damage.
The mounting of the blower to the truck must allow for tire clearance
as well as frame twist.
Follow mounting instructions given in the Truck Mounting / Loading Information section. Consult
truck manufacturer for proper truck sizing and mounting recommendations. If mounting conditions
require deviation from these instructions, consult the factory.
MOUNTING INSTRUCTIONS MANUAL FOR
FINN MATERIAL BLOWER

4
TRUCK MOUNTING/LOADING INFORMATION
MINIMUM CLEARANCE
FROM BACK OF CAB
13 MIN.
MINIMUM CLEARANCE
FROM BACK OF CAB
<>
CG X
CG Y
FRONT REAR
CG Z
271
USA: 101.5
EU: 99.5
AUS: 97.5
90
TRUCK MOUNT CLEARANCE ZONES
248
237
(10)
729
24
92
44
4
7
CHASSIS CENTER LINE
NOTE: MBX10 shown. MBX16/MBX22 models not shown (mounting/loading info provided).

5
TRUCK MOUNTING/LOADING INFORMATION (CONTINUED)
DESCRIPTION CG X CG Y CG Z WEIGHT MAX CAPACITY
MBX10 (No Material) 146.5 in. 1.4 in. 30.0 in. 13,230 lbs. --
MBX10 (Full, 10 yard)*152.5 in. 1.9 in. 29.5 in. 21,740 lbs. 8,510 lbs.
MBX16 (No Material) 148.8 in. 1.3 in. 33.0 in. 14,050 lbs. --
MBX16 (Full, 16 yard)*158.8 in. 1.4 in. 40.0 in. 27,666 lbs. 13,616 lbs.
MBX22 (No Material) 150.8 in. 1.2 in. 37.0 in. 14,870 lbs. --
MBX22 (Full, 22 yard)*162.8 in. 1.1 in. 51.1 in. 33,592 lbs. 18,722 lbs.
*Assumes a material weight of 851 lbs./cu. yd.
NOTE: All dimensions are in inches; drawings are not to scale.
NOTE: MBX10 shown. MBX16/MBX22 models not shown (mounting/loading info provided).

6
TRUCK MOUNTING/LOADING INFORMATION (CONTINUED)
POSITION TRUCK MOUNTING
BRACKETS IN ANY AVAILABLE
KEYSLOT CONFIGURATION TO
AVOID INTERFERENCE WITH
TRUCK FRAME AND COMPONENTS
TOP OF
FRAME RAIL
3.38 [85.7mm]
0.38 [9.5mm]
GAP
2.50 [63.5mm]
5.00 [127mm]
SPRING HARDWARE HIDDEN FOR CLARITY
OF FRAME HARDWARE LOCATIONS
MATCH THROUGH HOLES:
DRILL 11/16 in. [17.5mm]THROUGH
3X, BOTH SIDES
---------------
FLANGED BOBTAIL FASTENERS
RECOMMENDED: 16mm -OR- 5/8 in.
---------------
ALTERNATIVE ZINC PLATED
HARDWARE
M16 x 2 CLASS 10.9
-OR- 5/8-11 (UNC)GRADE 8
TORQUE TO 212 ft./lb. (287 N-m)
---------------
DO NOT WELD TO CHASIS
< FRONT
SPRING MOUNT

7
TRUCK MOUNTING/LOADING INFORMATION (CONTINUED)
TOP OF
FRAME RAIL
3.00 [76.2mm]
2.50 [63.5mm]
5.00 [127mm]
MATCH THROUGH HOLES:
DRILL 11/16 in. [17.5mm]THROUGH
3X, BOTH SIDES
---------------
FLANGED BOBTAIL FASTENERS
RECOMMENDED: 16mm -OR- 5/8 in.
---------------
ALTERNATIVE ZINC PLATED
HARDWARE
M16 x 2 CLASS 10.9
-OR- 5/8-11 (UNC)GRADE 8
TORQUE TO 212 ft./lb. (287 N-m)
---------------
DO NOT WELD TO CHASIS
REAR >
FIXED MOUNT

8
TRUCK MOUNTING/LOADING INFORMATION (CONTINUED)
The front spring mount and side shift mount can be located in any available configuration to avoid
interference with the truck frame and components. Some example configurations are shown
below.

9
THIS PAGE LEFT BLANK INTENTIONALLY

10
2
3
7
10
5
5
7
9
5
1
6
4
10
9
7
5
1
7
10
5
TORQUE ALL FASTENERS TO 357 ft./lb. (484 N-m)
8
7
7
TRUCK MOUNTING/LOADING INFORMATION (CONTINUED)

11
TRUCK MOUNTING/LOADING INFORMATION (CONTINUED)
TRUCK MOUNTING KIT
Ref. No.
No. Part Number Description Req’d
1 A3450-001 Bracket Assembly, Lower Truck Mount 4
2 A3447-001 Bracket Assembly, Upper Truck Mount 2
3 A3462-001 Bracket Assembly, Truck Mount Stop 2
4 011563 Spring - Compression, Truck Mount 4
5 A3448-001 Square Washer, Truck Mount 16
6 A3453-001 Tube, Spring Spacer 4
7 3/4 - wide - Type A Plain Washer 20
8 3/4- 16 UNF - 7 Hex Bolt - UNC (Regular Thread) 4
9 3/4- 16 UNF - 3 Hex Bolt - UNC (Regular Thread) 6
10 3/4-16 Metal Type Prevailing Torque Type Hex Nut 10
KITS AND MARKERS
A4743-001 Complete Installation Kit
 Standard Hardware Item
