FireBird Combi Range Guide

OIL FIRED BOILERS
THIS MANUAL MUST
REMAIN WITH THE
HOUSEHOLDER ON
COMPLETION OF
INSTALLATION
I.S. EN ISO 9002
INSTALLATION
COMMISSIONING
SERVICING &
USER INSTRUCTIONS
Combi Range

CONTENTS
1
FOREWORD
1. INTRODUCTION
Health & Safety
Fuel Spillage
First Aid
2. TECHNICAL SPECIFICATIONS
2a Boiler Dimensions
2b Boiler Specifications & Recommendations Etc.
2c Oil Burner Performance Specification
2d Boiler control panel wring diagram
2e & f Riello oil burner specification & technical details
2g Control panel layout
3. OPERATING INSTRUCTIONS
3a Boiler controls
3b Operating procedure
3c Burner lock out
3d Boiler operation & control
4. INSTALLATION
4a Standards & Regulations
4b Positioning Boiler
4c Flue Systems
4d Boiler siting regulations & Standards
4e Ventilation and Combustion Air
1. Conventional Flue
2. Balanced Flue
4.f Domestic Htc. & H.w. Systems electrical supply
5. OIL SUPPLY
5a Oil storage tank siting
5b Flexible oil pipe(s)
5c Single pipe system
5d Two pipe systems
5e Tigerloop single pipe systems
6. FLUE SYSTEMS
6a Important notice
6b Balanced flue systems
6c Concentric flue systems
7. COMMISSIONING
7a Procedures
7b Handing over
8. SERVICING
8a Recommended service intervals
8b The oil tank
8c The boiler
8d The Burner
COMBI PART 2.
Sealed system & domestic hot water Page 31
COMBI PART 3.
9. FAULT FINDING
10. SPARE PARTS
10a Riello burner parts illustration
10b Pluming parts illustration
10c Pluming parts description
10d Boiler parts illustration
10e Boiler parts description
10f Control panel illustration
10g Control panel description
Commissioning record Page 48
Service reports Page 49

2
FOREWORD 1INTRODUCTION
This instruction manual is produced for the reference
and guidance of qualified installation engineers. EU
legislation governs the manufacture, operation and
efficiency of all domestic oil boilers. One effect of this
will be that boilers and burners will require to be
supplied as matched units tested and approved to
OFTEC Standard OFS Al00.
FIREBIRD Boilers are full manufacturing members of
OFTEC (Oil Firing Technical Association for the
Petroleum Industry) and are participating in its Boiler
testing and approvals programme to comply with OFS
A100 and EC Efficiency Directive.
Boilers must be installed, commissioned
and serviced by qualified and experienced
OFTEC approved personnel (U.K. only). It
should be noted that it is the
responsibility of the installer to ensure
that the boiler is properly commissioned.
Failure to do so may invalidate the boiler
guarantee and any extended warranty.
All appropriate OFTEC manuals and BS
Standards should be studied and their
requirements adhered to and used in
conjunction with these instructions. This
manual includes a list of some BS
Standards and Building Regulations.
OFTEC is conducting training and registration of
engineers and this is to be commended, as reading of
this manual alone for installation and servicing
procedures cannot replace the critical advantage
provided by training and years of experience.
The Firebird Combi Boiler Range is based on the ‘S’
Range Boilers. All boilers in the range are designed
and manufactured to meet all the latest European
standards and the thermal efficiency requirements of
the Boiler (efficiency) Regulations 1993. All Boilers
can be fitted to a conventional flue or easily adapted
to a room sealed unit by using a Firebird matched
balanced flue kit.
The control panel can be easily accessed by the
simple removal of four screws, then this assembly can
be pulled forward for access to components.
Clean combustion with kitchen-quiet operation is
assured by a highly efficient matching pressure jet
burner which produces very low NOxemissions. The
Combi Range is a dedicated sealed system boiler
having a 12 litre expansion vessel on the 50-70 and
70-90 models, on the 90-120 model ther is a 14 litre
expansion vessel, system filling kit and 3 bar safety
valve all fitted within its cabinet.
A drain-off cock is fitted inside the boiler beside the
burner and there are flow and return connections
provided under top lid of the boiler for connection to
the heating and hot water systems. As all servicing can
be carried out from the front, the boiler many be
fitted under a kitchen worktop.
The burner is factory set for use with kerosene 28
second class C fuel. However, 35 second gas oil
may be used on a conventional flue installation,
a oil pre-heater may be necessary.
GUARANTEE
• All Firebird oil Boilers have a 2 year
comprehensive warranty which extends to
5 year on the boiler shell
• The Guarantee card must be fully
completed and returned to firebird within
28 day’s of installation.
• Consumable components, the nozzles and
the oil hose are excluded.
• The terms laid down on the Guarantee
must be adhered to.
NOTE: Some Firebird boilers are suitable
for conversion to gas. Conversion must only
be undertaken by Firebird approved gas
technicians using a Firebird supplied
conversion kit suitable for the particular
boiler.

Safe use of Kerosene and Gas Oil.
These fuels give off a flammable vapour when heated
moderately. Vapour ignites easily, burns intensely and
may cause explosion. The vapour can follow along at
ground level for considerable distances from open
containers and spillages collecting as an explosive
mixture in drains, cellars, etc.
Fuels remove natural oils and fats from the skin and
this may cause irritation and cracking of skin. Barrier
cream containing lanolin is highly recommended
together with good personal hygiene.
Gas oil may also cause irreversible damage to health
on prolonged or repeated skin contact.
Always store fuels in a properly constructed and
labelled tank. Always handle fuel in open air or well
ventilated space away from sources of ignition and
refrain from smoking.
Always drain fuel using a proper fuel retriever, funnel
or mechanical siphon. Never apply heat to a fuel tank,
container or pipework. Never siphon fuel through
tube by mouth. If accidentally swallowed contact
doctor immediately and do NOT induce vomiting.
Avoid inhaling fuel vapour as this can cause light
headedness and seriously impair judgement.
3
Under the Consumer Protection Act 1987 and
Section 6 of the Health and Safety Act 1974, we are
required to provide information on substances
hazardous to health.
INSULATION AND SEALS
Ceramic Fibre, Alumino - Silicone Fibre material are
used for boards, ropes and gaskets. Known hazards
are that people may suffer reddening and itching of
the skin. Fibre entering the eye will cause foreign
body irritation. It may also cause irritation to the
respiratory tract.
Precautions should be taken by people with a history
of skin complaints or who may be particularly
susceptible to irritation. High dust levels are only
likely to arise following harsh abrasion.
Generally, normal handling and use will not give
discomfort. Follow good hygiene practices, wash
hands before consuming food, drink or using the
toilet.
First Aid - Medical attention should be sought
following eye contact or prolonged reddening of the
skin.
The small quantities of adhesives and sealants used in
the product are cured. They present no known
hazards when used in the manner for which they are
intended.
1. Switch off all electrical and other ignition
sources.
2. Remove all contaminated clothing to safeguard
against fire risk and skin damage. Wash affected
skin throughly with soap and water and remove
clothing to a safe well ventilated area and allow
to air before cleaning.
3. Contain and smother the spill using sand or
other suitable non-combustible material.
4. Do not allow fuel to escape into drains or water
courses. If this happens, contact Fire Brigade
and Local Water Authority.
5. Consult local Authority about disposal of
contaminated soil.
If fuel is accidentally swallowed:-
* Seek medical attention immediately. Do NOT
induce vomiting.
If fuel is splashed into eyes:-
* Wash out with running water for at least ten
minutes and seek medical attention.
1FIRST AID
1FUEL SPILLAGE
1SAFETY
1
HEALTH & SAFETY
INFORMATION
THIS PRODUCT HAS BEEN DESIGNED
TO THE FOLLOWING STANDARDS:
EMC Directive
(Electromagnetic compatibility) 89/336/EC
Standards:
EN 61000-6-1: Electromagnetic Compatibility Generic
Standard - Immunity for residential, commercial and
light industrial environments. (Feb.2001)
EN 61000-6-3: Electromagnetic Compatibility Generic
Standard - Emission standard for residential,
commercial and light industrial environments.
(Feb.2001)
LV Directive
(Low voltage) 73/23/EEC
Standard:
IEC 60335-1: Household and similar electrical
appliances - Safety (May 2001)
Boiler Efficiency Directive 92/42/EEC
Standard:
BSEN 304: Oil boilers with forced draft burners.

2
TECHNICAL SPECIFICATION
4
2-A Diagrams
2-B Technical Specifications and Recommendations
C.
A.
E.
F.
G.
L.
J.
I.
K.
1
5
34
2
B.
D.
A.
1. Mains Feed.
2. D.H.W.
3. 3bar Safety Valve.
4. C.H. Flow.
5. C.H. Return.
H.
W.
C.
Rear View. Top View.
Front View. Side View.
Combi Range Dimensions
Heat Output 50-120,000 Btu/Hr
Electricity Supply 230 v - Boiler~50 Hz
To be fused at 5 amp
System Pipe Connections (on boiler)
Heating Flow 22 mm (28mm - 90-120,00 Btu/Hr)
Heating Return 22 mm (28mm - 90-120,00 Btu/Hr)
Mains Cold Water Boiler
connection 15 mm
Hot Water delivery 15 mm
Safety pressure Relief Valve
Outlet 15 mm
All Copper Tube connections: BS 2871 Copper Tube
Isolating ball valves are fitted to all boiler/system connecting pipework
H. 840mm
W. 610mm
D. 600mm
E. 640mm
F. 650mm
G. 695mm
A. 155mm
B. 750mm
C. 190mm
I. 210mm
J. 185mm
K. 135mm
L. 70mm
50-70 & 70-90 90-120
H. 840mm
W. 670mm
D. 600mm
E. 640mm
F. 650mm
G. 695mm
A. 155mm
B. 750mm
C. 220mm
I. 230mm
J. 185mm
K. 135mm
L. 70mm
Combi Pac
Dimensions
&
Plumbing Point
Dimensions
Domestic Hot
Domestic Cold Feed
945
690 330 680
C.H. Flow
C.H. Return
625
85W
90
W= 655
A= 114
B= 142
120
W= 705
A= 114
B= 162
Combi Pac
Removable slot in
base to allow access
for pipe work from
ground level
(1)
(4)
(3)
(2) (1)
(4)
(3)
(2)
(1)
)
A
A
A

5
2
TECHNICAL SPECIFICATION
Pressure Jet Oil Burner Riello RDB or Ecoflam Flair or Bentone Sterling
Fuel Kerosene Class C2
Domestic Hot Water Plate
Heat Exchanger Giannoni Albion,
SWEP or
Alfa Laval
Circulating Pumps Grundfos UPS 25/60
Flue Pipe Connection
Conventional Flue Socket To take tail piece for 4”(100mm) & 5”(125mm)
S/S Flue Pipe
Balanced Flue Assembly 5”(125mm) Concentric Flue
Weight (Dry) - Incl. Pallet 50-70btu’s - 160 Kg
70-90btu’s - 162 Kg
90-120btu’s - 177 Kg
Water Content - Total 50-70btu’s - 59 Litres
70-90btu’s - 59 Litres
90-120btu’s - 68 Litres
- Primary Tank 50-70btu’s - 40 Litres
70-90btu’s - 40 Litres
90-120btu’s - 44 Litres
Thermostats
Boiler Central heating Control
(Adjustable) 65˚C - 85˚C
Boiler Safety Limit 110˚C
Tank (DHW)-Fixed 78˚C
EA-Fixed 87˚C
Over-run-Fixed 93˚C
Boiler integral Expansion
Vessel nominal capacity 12 & 14 Litres pre-charged to 1 Bar
Heating System (Sealed) Fit in accordance with BS 7074
Part I, BS 5449, OFTEC
Standards, etc.
Max. Operating Pressure 2.5 Bar (Follow all BS & OFTEC Standards)
Max. System Pressure (Cold) 1.5 Bar
Min. System Pressure (Cold) 0.5 Bar + 0.3 Bar
Boiler Test Pressure 4.5 Bar
Safety Valve Operating Pressure 3 Bar
Heating System Pressure Gauge
(mains supply excepted) 0 - 6 Bar Range
Flue Draught Reqd.
(Conventional Flue) Min: 0.040 In WG
Max: 0.15 ln WG
Water side resistance-10˚C Diff 26.8 ins WG
-20˚C Diff 8.6 ins WG
Mains Water Supply Pressure Up to 10 Bar. (Fit pressure
reducing valve as necessary)
Mains Water Supply
Limescale excess - when
over 150/200 ppm Consult Water Authority
Fit appropriate scale reducer
Also refer to Page 35
Domestic Hot Water Guide Performance
50-70,000 Btu’s - 120 Litres at 40˚ Δt at 12 Litres per minute
70-90,000 Btu’s - 120 Litres at 40˚ Δt at 14 Litres per minute
90-120,000 Btu’s - 120 Litres at 40˚ Δt at 18 Litres per minute

2
TECHNICAL SPECIFICATION
6
2-C Burner Settings Firebird Boiler Range Kerosene
Using RDB Range Of Burners (K).
2-D Wiring Diagram Combi Range
The above performance figures are based on ideal laboratory test conditions.
Air shutter settings above may need to be revised to take into consideration
difference in resistances between conventional and balanced flue installations.
Use flue gas analyser to achieve optimum results.
Variations in nozzle throughput, flue type & draught, oil viscosity etc. may
give results differing from these laboratory performance figures.
☛
☛
Range Burner Head Fuel Nozzle P.P. Air CO2 Fg. Smoke
Type Shutter Head No.
50,000 Riello RDB 1. T1 K .5 80’H 7 Bar 2.4 - 11.5 190 0-1
60,000 Riello RDB 1. T1 K .5 80’H 10 Bar 3.9 - 11.5 200 0-1
70,000 Riello RDB 1. T3 K .6 80’H 8 Bar 4.25 - 11.5 210 0-1
70,000 Riello RDB 1. T3 K .6 80’H 8 Bar 4.25 - 11.5 190 0-1
80,000 Riello RDB 1. T3 K .6 80’H 9.5 Bar 4.8 - 11.5 195 0-1
90,000 Riello RDB 1. T3 K .75 80’S 8 Bar 6 - 11.5 210 0-1
90,000 Riello RDB 2. T3 K .75 80’S 8 Bar 6 - 11.5 190 0-1
110,000 Riello RDB 2. T3 K 1.00 80’S 7 Bar 2.6 - 11.5 190 0-1
120,000 Riello RDB 2. T3 K 1.00 80’S 9 Bar 3.5 - 11.5 190 0-1
Burner
Limit Stat Control Stat
C.H. Pump Room Stat Loop
D.H.W. Pump
Early Alert Stat
C.H. Timed Switch
D.H.W. Timed Switch
Relay Tank Stat.
Over Heat Stat.
Flow Switch
Timer Motor
Timer Motor
On Off Timed
E
L
N
12
14
22
24
32
34
1
6
11
11
21
31
4
3
5
7
8
9
210
A2 A1
Non Energised
Energised

2
TECHNICAL SPECIFICATION
7
2-D Wiring Diagram Combi Range
C2
1
C2
1
C2
1C2
1
C21
Room
Stat
Circ
Pump
C.H.
Flow
Switch
Circ
Pump
D.H.W.
N.
Burner
Control
Lock
Out
Limit
Heating
Timer
Hot Water
Timer
L2
N
L1
Limit Early
Alert
Over
Heat
Relay
Tank
Mains
L2
N
L1
4
32
8765
24 21 22 12
11
34 14
A2 31 A1
10 2
1
11
3
9
E
2
43
1
2
43
1
Mains
L2
N
L1
Heating Timer Switch Live
Hot Water Timer Switch Live
External Two
Gang Timer Frost Stat.
Permenant
Live To
Frost Stat.
12
14
22 24 32
34
1 6
11
11 21
31
4 3
5
7 8 9
210
A2 A1
C.H. Timer
Control Stat
Relay Tank Stat (c)
Flow Switch
Flow Switch
Relay Tank Stat
Flow Switch
C.H. Pump
Early Alert Stat -- Burner
D.H.W. Pump
Over Heat Stat
Non Energised
Energised
See sticker on boiler for
Coloured Wiring Diagram
L2
N
L1
L1 = Live
N = Neutral
= Earth
Mains

2
TECHNICAL SPECIFICATION
8
2-E&F Riello Burner Specification
Burner Description
One stage kerosene and oil burner.
In case of BF applications the intake air temperature must not be over 70C
The burner meets protection level of IP 40, EN 60529.
Burnerwith CE marking in conformity with EEC directives: EMC 89/336/EEC,
Low Voltage 73/23/EEC, Machines 98/37/EEC and Efficiency 92/42/EEC.
7. Pump pressure adjustment screw
8. Pressure gauge port
9. Photoresistance
1. Pump
2. Control-box
3. Reset button with lock-out lamp
4. Flange with insulating gasket
5. Air damper adjustment screw
6. Snorkel (BF)
Burner Equipment
Flange with insulating gasket............. No.1
Screw and nut for flange................... No.1
Grill (CF Application)........................ No.1
Bolts for flange to be fixed to boiler..No.4
Hexagonal Key................................... No.1
Screw of by-pass pump..................... No.1
Flexible oil pipe with nipple.............. No.1

2
TECHNICAL SPECIFICATION
9
2-E&F Riello Burner Specification

2
TECHNICAL SPECIFICATION
10
2-E&F Riello Burner Specification
ELECTRODE SETTING
Riello RDB
RIELLO BURNER START-UP CYCLE
Attention
Before assembling or
removing the nozzle
loosen screw (A) and
move electrodes forward.
NOTE: Above information provided relevant to Riello RDB Burner. The
Firebird ‘S’ Range has been tested and will operate equally efficiently
using Ecoflam or Sterling Burners which may also be fitted
as original equipment.
Refer to separate burner instructions booklet packed with boiler. Separate
Riello Burner instructions are also included when these burners are fitted.
Always consult these as variations in specification can occur from time to
time which may not be included in this manual. Information is more
complete in appropriate burner manuals.

The control panel is designed for simplicity of use and is equipped
with adjustable thermostat knob, optional time controls and limit
thermostat reset button as shown above. It also has a built in system
pressure gauge which is connected to the boiler and heating system
water at the safety valve.
When replacing make sure that each thermostat pocket
receives correct phial by marking and noteing carefully each
phial and its correct pocket.
2
TECHNICAL SPECIFICATION
11
2-G Control Panel Layout
The control panel is at the top front of the boiler,
there are four operational indicator lights on the
front of the boiler. See diagram below
Relay Base
Mains Socket
Control Thermostat
Early Alert Thermostat
Over Heat Thermostat
Tank Thermostat
Room
Stat
Circ
Pump
C.H.
Flow
Switch
Circ
Pump
D.H.W.
Burner Socket
Domestic Hot Water Timer
Central Heating Timer
Early
Alert Over
Heat Relay
Tank
4
32
8765
24 2L 22 12
L1
34 14
A2 31 A2
10 2
L
1C
3
9
C2
1C2
1C2 1
C2
1
C2
1
High
Limit
Stat.
High Limit Thermostat
Reset Button
Connection Point For Timer
Control
☛
☛

3
OPERATING INSTRUCTIONS
12
3-A Boiler Controls
Visible on the front boiler casing are
•Central Heating thermostat control.
•Time control - Domestic Hot Water. & Central Heating (optional).
•Limit-stat reset button (see diagram on page 11).
• Pressure Gauge
Also indicator lights. These are:
•Mains ‘on’.
•Burner lockout.
• Domestic Hot Water
• Central Heating
3-B Operating Procedure
To start the boiler follow this sequence:
■Turn on fuel supply.
■Switch on power supply to boiler.
■ Set the boiler thermostat to the required temperature.
■ Set timer - Domestic Hot Water & Central Heating.
The central heating thermostat controls the boiler when in central
heating mode only, thus maintaining the required boiler water
temperature output for central heating.
Domestic hot water temperature is controlled by separate non
adjustable thermostat, plus thermostatic mixing valve. See page 15.
Safe operation is also maintained by the burner control system which
provides the required ignition and shut off sequence.
If the optional timer controls are fitted this will automatically
switch the boiler off and on when cental heating and Domestic
Hot Water is required.
The boiler can be turned off by any of the following means:
■ Turn both timer switches to OFF.
■ Turn OFF the mains electrical supply to the boiler.
WHEN SERVICING ALWAYS SWITCH OFF THE MAINS SUPPLY TO
THE BOILER

3
OPERATING INSTRUCTIONS
13
3-C Burner Lockout
The boiler is factory fitted with a burner control box lockout safety feature
which operates automatically if a fault occurs in the burners operation.
Should this occur, the RED light on the front of the boiler control panel -
See diagram on previous page - will illuminate and its cause must be
investigated. This could be caused by:
A. An interruption in the fuel supply. (Eg. empty oil supply tank)
B. An electrical supply fault.
C. A fault with the burner or its safety control system.
D. The failure of a component. (Eg. photo cell)
E. Worn or dirty oil nozzle.
Before attempting to restart the boiler the front panel and the burner cover
should be removed and a visual check made for any obvious problems such as
oil leaks, loose connections etc.
ENSURE OIL TANK CONTAINS CORRECT GRADE FUEL.
To restart the boiler
1. Press reset button (see diagram above)
2. Ensure that the boiler thermostat, time switch (if fitted) and any external
controls connected to the boiler are set to call for heat.
3. Check that the oil supply valves are open and that there
is sufficient oil in the tank.
4. Check that the burner lockout light is unlit and with the ‘MAINS ON’ the
boiler will be ready to commence its start sequence.
Servicing
The boiler requires servicing on an annual basis to ensure it maintains its
efficiency, continues to perform reliably and as a regular check on its
built-in safety features.
It is important that servicing should be conducted by a competent
engineer, one who is OFTEC trained and registered.
Please note: As a pre-heater kit maybe required to be fitted to the burner when
using 35-second gas oil (only allowed on conventional flue applications) this
means that annual servicing is usually sufficient - although more regular
servicing may be required depending on use.
To reset when Lock-out
light shows:
Press glowing reset button
on burner control box.
Reset Button
Inside Burner Box

3
OPERATING INSTRUCTIONS
14
3-D Boiler Operation and Control
Boiler Operation and Control
Domestic hot water production cycle commences once the timer has been set
and switched on. If boiler and system are cold allow 20 - 30 minutes for
domestic hot water heat store to reach working temperature. Central heating
is controlled by setting the time switch - also located on this panel. The
boiler control system always gives priority to domestic hot water production
by automatically overriding the central heating mode as necessary. The
interruption to central heating lasts only as long as the demand for hot water
continues. This has no significant effect on the heating circuit. Once hot water
demand has ceased the boiler will automatically return to central heating
mode if there is a demand. When hot water only is required turn central
heating timer switch to ‘off’.
If alternative programmer is used then refer to separate programmer
instructions.
By request Combi Boilers are available with built-in timers.
Timer Switch
Pos. A
Constant
Timer Switch
Pos. B
Timed
Timer Switch
Pos. C
Off

3
OPERATING INSTRUCTIONS
15
Domestic Hot Water Operation
Hot water is available on demand by turning on a hot tap. This activates the
flow switch which powers the domestic hot water pump ensuring that all
boiler hot water is diverted to the domestic heat exchanger which heats the
incoming mains water to give instant mains pressure hot water.
Hot water is then mixed with mains cold water by a thermostatic mixing valve
set to ensure that it does not exceed 65°C. This is shown in accompanying
diagrams - Item No. 6.
The burner may continue to run after hot water draw off has ceased - to
ensure the pre-set temperature is restored in the heat store. This may also
occur at any time if the control system senses that there is a need to
replenish the heat store, i.e. if there has been natural temperature drop in
heat store during long periods of low demand for domestic hot water.
Programming Guide
SETTING UP
The outer dial should be set to the current time. Rotate the dial slowly
in a clockwise direction, until the correct hour is aligned with the arrow
head printed on the dial. Note that the outer dial is printed with the 24
hour clock -
8:00 a.m. = 8 on the dial. 8:00 p.m. = 20 on the dial.
Do not attempt to rotate the dial in an anti-clockwise direction.
PROGRAMMING SWITCHING TIMES
Set all tappets between the on and off times required, to the outer
edge of the dial (see figure 1). E.g. to set on at 8:00 a.m. - Off at 1:00 p.m.
push tappets between dial numbers 8 and 13 to outer edge of dial. Set any
other required switching times in a similar manner.
MANUAL SWITCH
Manual switch operation: The manual switch will provide Fixed On / Fixed
Off / Auto control, thereby allowing manual control of the switched output
without disrupting the timed (tappet) settings. Please refer to the illustration
above.
The slide switch can be set in one of the three positions available ‘on’ and ‘off’
are fixed selections - the timer will remain in the on or off condition until you
next use the manual switch to change the setting. ‘auto’ is the normal posi-
tion for the switch, allowing control to be governed by the tappet settings -
in accordance with ‘programming switching times’ above

4INSTALLATION
16
4-A Standards & Regulations
To ensure the highest standards of installation & safety, it is important
that the boiler be installed in compliance with the following regulations
where applicable.
All CURRENT editions of the appropriate Building Regulations:-
Part G & J England & Wales
Part F, Section III Scotland
Part L Northern Ireland
Part J Republic of Ireland
BS 5410 Part 1 1997. Code of practice for Oil Firing Installations.
BS 799 Part 5 1987. Specification for Oil Storage Tanks.
BS 4876 1984. Performance requirements for oil burning appliances.
BS 5449 1990. Specification for Forced circulation hot water central heating
systems for domestic premises.
BS 7074 Part 1 1989. Application, selection and installation of expansion
vessels and ancillary equipment for sealed water systems.
BS 5446 1990. Installation of hot water supplies for domestic purposes.
BS 7593 1992. Code of Practice for treatment of water in heating systems.
BS 715 1989. Metal flue pipes, fittings, terminals and accessories.
BS 1189 1989. Clay flue linings and flue terminals.
BS 4543 part 3 1990. Factory made insulated chimneys for oil fired
appliances.
BS 6700. Design, installation, testing and maintenance of Services supplying
water.
BS 7671.
Current lEE Regulations.
Local Water Undertaking Byelaws.
The Control of Pollution (Oil) Regulations.
In addition, the work must comply with OFTEC Installation
Requirements for oil fired boilers and oil storage tanks.
The installer should also be aware of his/her responsibilities under The
Health and Safety at Work Act. The interests of safety are best served if the
boiler is installed and commissioned by a competent engineer, OFTEC
trained and Registered or trained to other recognised standards.
It is the responsibility of installer and everyone concerned with any aspect
of installation to ensure that all applicable standards and regulations are
fully adhered to.
OFTEC also publish excellent guides including:-
- Safe Working Practices for Oil Firing Technicians'
- OFTEC Technical Book Three (Installation requirements for Oil Fired
Boilers and Oil Storage Tanks)
- OFTEC Technical Book Four (Domestic Heating Systems)
and it is recommended that these should be adhered to.
Copies of British Standards may be purchased direct from:
BSI (Customer Services), 389 Chiswick High Rd.,
London W4 4AL
Tel.: [phone] Fax: [phone]
International and EC Standards are also available from above
OFTEC Publications are available from:-
OFTEC,
Oil Firing Technical Association,
Foxwood House, Dobbs Lane,
Kesgrave, Ipswich.
IP5 2QQ
☛
☛

4INSTALLATION
17
4-B
Positioning Boiler
Ensure that adequate clearance is available for making
the water and flue connections.
As the boiler is serviced from the front,
no headroom clearance is necessary but a clearance of 750mm must be
available at the front of the boiler.
No special hearth is required as the boiler is fully insulated, but the floor
must be level and capable of supporting the weight of the boiler and its
water content.
Sound levels must also be a consideration. Whilst the Firebird Combi Range
are one of the quietest boilers on the market, some householders are
particularly sensitive and the following points should be considered:
1. Tiled surfaces in a small room will amplify noise - particularly if the wall
construction is hollow.
2. If a conventional flue passes through a bedroom it is capable of
transmitting noise.
3. Low level balanced flue terminals can produce exhaust noise on the
outside terminal and this should be considered when siting near adjacent
property.
4. Firebird do not recommend the use of a low level flue’s on
white cased indoor boilers.
5. The Firebird low level concentric flue kit has been specifically designed
for Firebird’s indoor boilers. The use of third party low level flue kits
is not recommended and may affect its warranty.

4INSTALLATION
18
4-C Flue Systems
IMPORTANT
Because of the improved efficiencies of boilers under E.U. Efficiency
requirements and OFS A100 Standard, it is necessary to pay extra special
attention to flues and chimneys. The improved efficiency figures achieved
by modern oil boilers are attained by using more of the heat (higher
temperatures) heretofore allowed into flues and chimneys. This previously
wasted heat helped to keep bad and poorly operating and often uninsulated
flues and chimneys from condensing and causing problems. Please be fully
aware of this when replacing an existing boiler. An old and poorly operating
flue may need to be replaced to take full advantage of improved efficiencies
and to avoid flue gases condensing and appearing as white water vapour
(pluming) at flue (chimney) outlet.
New flues and chimneys should be properly insulated and constructed to
prevent condensation and draughting problems. Every individual concerned
with any aspect of installation should be aware of the foregoing and should
have full knowledge of and work to European, National and Local Govt.
Standards and Building and Installation Regulations.
These manufactures instructions must not in any way be mis-interpreted as
over-riding the above or any statutory regulations. It is absolutely essential
that the boiler is properly installed so that NO FLUE GASES can enter the
building at any time. Flue pipes should be safely sealed into the wall to
prevent flue gases re-entering room or building. Refer also to page 23.
Conventional Brick Chimney With Liner
NOTE:
All brick chimney constructions must com-
ply with current building regulations and
BS 5410: Part 1. Insulated factory made
chimneys should comply with BS 4543.

4INSTALLATION
19
4-D Balanced Flue Siting
Notes: 1. The terminal should be positioned to avoid combustion
products entering the building or accumulating in stagnant
pockets around buildings.
2. The terminal must be protected by a guard if it is less than 2
metres above ground level or in a position where any person
has access to it (i.e. a balcony).
3. A heat protection shield should be fitted if the terminal is less
than 850mm from a plastic or painted gutter or less than
450mm from painted eaves.
Always check for any Building Regulations amendments which may
have been issued after the publication of this manual
A. Below a gutter or
sanitary pipework.
B. Horizontal from
opening, airbrick,
window etc.
C. Above ground or
balcony level.
D. Below eaves or
balcony
E. From an internal
or external corner.
F. From a terminal
facing the terminal.
G. From a surface
facing the terminal.
H. Vertical from
terminals on
the same wall.
I. Horizontal from
terminals on the
same wall.
J.Below an opening, airbrick, window etc.
K. From vertical sanitary pipework.
L. Vertical flue from wall.
Book three Nov. 1997
ABCDE FGH I J K
England & Wales 1991 - 600 - - 600 - - - - 600 -
Scotland 1990 Balanced* 600 - 600 600 600 600 600 1500 600 600 600
Low level* 1000 - 600 1000 600 600 600 1500 600 600 1000
Northern Ireland 1994 - 600 - - 600 - - - - 600 -
Republic of Ireland 1997 - 600 - - 600 - - - - 600 -
*Where the terminal is within 1 metre of any plastic material, such material should be protected from the
effects of combustion products of fuel. There are additional general requirements in most Regulations and
Standards that the flue must be positioned so that it does not cause a nuisance and permits the dispersal of
combustion products.
NOTE: The Buildings Regulations clearances shown above are minimum allowed. Account should
also be taken of prevailing site conditions, as the above minimums may in certain circumstances
need to be increased. If in doubt contact manufacturer for advice.
See note at foot of page
Building Regulations
☛ ☛
