First Alert A-560 User manual

Indoor/Outdoor
Analog Wireless Camera with Receiver
Model A-560
USER'S MANUAL

©2010 Lehigh Consumer Products, LLC
All rights reserved. Distributed by Lehigh Consumer Products, LLC, Macungie, PA 18062. Due to
continuing product development, the product inside the packaging may look slightly different than
the one on the package.
Lehigh Consumer Products, LLC is a subsidiary of Jarden Corporation (NYSE: JAH). To obtain
warranty service, contact the Consumer Affairs Division at 1-800-323-9005, Monday through
Friday, 7:30 a.m - 5:00 p.m., Central Standard Time.
Made in China
M08-0257-004

Table of Contents
Safety ...............................................................................................................................1
Safety Precautions ........................................................................................................................... 1
FCC Compliance ............................................................................................................................. 1
Getting to Know Your A-560 System............................................................................2
Check Package Contents.................................................................................................................. 2
Features............................................................................................................................................ 4
Setting Up Your A-560 System.......................................................................................5
Safety and Installation Tips ............................................................................................................. 5
Device Operating Range.................................................................................................................. 5
Installing the Camera....................................................................................................................... 6
Setting the Camera's Channel.......................................................................................................... 7
Connecting the Receiver to a DVR/VCR and TV........................................................................... 8
Viewing the Cameras on Your DVR/VCR/TV................................................................................ 8
Setting the Receiver's Channel ........................................................................................................ 9
Remote Control.............................................................................................................................. 10
Night Vision................................................................................................................................... 10
Troubleshooting............................................................................................................10
Technical Information...................................................................................................11
Receiver......................................................................................................................................... 11
Camera........................................................................................................................................... 11
Warranty.........................................................................................................................12
Product Limited Warranty.............................................................................................................. 12
Warranty Exclusions...................................................................................................................... 12
Obtaining Service .......................................................................................................................... 13

1
Safety
SAFETY PRECAUTIONS
Do not drop, puncture, or disassemble the camera.
Never tug on the power adapter. Use the plug to remove it from the wall.
Do not expose the camera to high temperatures.
For your own safety, avoid using the camera when there is a storm or lightning.
Use the device with care. Avoid pressing hard on the camera body.
Do not crush or damage the power cable.
FCC COMPLIANCE
This device complies with Part 15 of the FCC Rules. Operation is subjected to the
following two conditions: (1) this device may cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in residential installations. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur with a particular
installation. If this equipment does cause interference to radio or television equipment
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from that to which the
received is connected.
Consult the dealer or an experience radio/TV technician for help.
Notice: Changes or modifications to the product could void the user's
authority to operate the product.

2
Getting to Know Your
A-560 System
Congratulations on purchasing your First Alert Security Camera product. First Alert has
been helping families and businesses stay safe for over 50 years. By having a First Alert
Security Camera, you’re taking the first step in protecting your home or business from
damage or theft. We’re watching, even when you’re not.
CHECK PACKAGE CONTENTS
After unpacking the carton, check the contents for damage. Contact your supplier or dealer
immediately if any part is missing or damaged.
Wireless Receiver (1)
Wireless Camera (2)
Power Supply (3)
Camera Stand (2)
Mounting Kit (2)
AV Cable (1)
Remote (1)
User’s Manual (1)
camera stand
camera antenna
camera lens
IR LEDs

Getting to Know Your A-560 Security System
Model A-560 User's Manual
4
FEATURES
380 TV lines for clear image resolution
4 transmission channels
6 mm lens
Infrared night vision
Wireless transmission up to 330 ft in open field conditions
Sturdy weather resistant casing on camera
Includes audio surveillance capability
receiver antenna
2.4 GHz receiver
power supply AV cable

5
Setting Up Your
A-560 System
SAFETY AND INSTALLATION TIPS
Do not attempt to open the camera. There are no user serviceable parts inside. Refer
servicing to qualified service personnel.
When installing the camera, follow manufacturer’s advice when using power tools,
steps, ladders, etc. and wear suitable protective equipment (e.g., safety goggles)
when drilling holes. Before drilling holes through a ceiling, check for hidden
electricity cables and water pipes. The use of a cable/pipe detector is advisable.
When installing the camera on an external wall, pass the power cable through the
wall as close as possible to the cameras to reduce the chance of tampering with the
cables. After drilling any hole though an external wall for cable, make sure the hole
is sealed up around the cable using a sealant.
DEVICE OPERATING RANGE
The wireless cameras are capable of transmitting up to 330 ft in open field conditions.
However, when installed around your property, any solid objects (e.g., walls, ceiling,
reinforced PVC doors, etc.) placed between the cameras and receiver will reduce the range.
For best transmission, avoid installations where there are very thick walls or major
obstructions between the wireless cameras and receiver. Avoid installing the cameras or
receiver next to a metal radiator, wireless router, or microwave oven.
If the cameras are used with a digital video recorder (DVR) to record or view video on a TV,
ensure the signal reception is the best possible reception (i.e., no interference lines on the
TV). If necessary, reduce the distance between the cameras and receiver. You may find that if
the wireless cameras are installed outside, the maximum operating range without interference
may be less than 50 ft.

Setting Up Your A-560 System
Model A-560 User's Manual
6
INSTALLING THE CAMERA
1Select the position for the camera and secure the camera bracket.
Screws and anchors are supplied. Use an appropriate screw type for the mounting surface
2Loosen the T-bolt.
3Adjust camera to the proper view angle and tighten the T-bolt.
Make sure the lens is upright relative to your subject (antenna should be relatively upright).
4Connect the camera to power using the supplied power cable and adapter.
The power adapter is not weather resistant and need to be sheltered from moisture, rain,
and sunlight.
camera bracket
T-bolt
