FISCHER FIBEROPTIC Series Configuration guide

THE RELIABLE EXPERT
ROBUST
OPTICAL PERFORMANCE
EASY CLEANING
THE RELIABLE EXPERT
CLEANING INSTRUCTIONS
FISCHER FIBEROPTIC SERIES

2
FISCHER FIBEROPTIC SERIES
INTRODUCTION
The Fischer FiberOptic Series push-pull connector solutions are purpose built to withstand the elements of rugged
and harsh environments, providing virtually faultless optical performance. This rugged push-pull fiber optic connec-
tor, for both indoor and outdoor applications, can also be available pre-cabled for maximum performance and time
saving.
Fischer Connectors recommends the following three cleaning options for the Fischer FiberOptic Series.
1. Rapid cleaning(one click cleaning) - FO1, FO2, FO4 and FOH.
2. Field cleaning(Tap water cleaning) - FO1, FO2 and FO4 only.
CAUTION: This cleaning method is NOT recommended for the FOH, as the electrical contacts should be completely dry before
using the connector again.
3. Maintenance cleaning (ultrasonic cleaning)
CAUTION: This cleaning method is recommended for the FO1, FO2 and FO4. However it is possible for the FOH, but only if the
connector is completely dry before using it again because of the electrical contacts.
TABLE OF CONTENTS
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Rapid cleaning (one click cleaning) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Field cleaning (tap water cleaning). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Maintenance cleaning (ultrasonic cleaning) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

3
FISCHER FIBEROPTIC SERIES
RAPID CLEANING (one click cleaning) - FO1, FO2, FO4 & FOH
■Insert IBCTM Brand Cleaner on male contact (receptacles) and perform one click /cleaning per contact
■Remove the IBCTM Brand Cleaner adapter, insert it in the female contacts (plugs) and perform
one click / cleaning per contact
■ Always clean both sides of the connector (if you mate a dirty contact with a clean one,
you pollute both of them)
■If the cleaning is not efficient enough, remove the sleeve holder, manually unscrew it for FO1 or use tweezers for
FO2, FO4 and FOH and repeat the cleaning with the IBCTM Brand cleaner
What you need
■US conec IBCTM Brand Cleaner (H125)
<1
min
■Tweezers
Procedure
FOR RAPID CLEANINGWHEN NOVISIBLE DIRT IS PRESENT ONTHE CONNECTOR

4
FISCHER FIBEROPTIC SERIES
FIELD CLEANING (Tap water cleaning) - FO1, FO2, FO4 only
■Put your connector under running tap water until everything is cleaned
■Remove the sleeve holder, manually unscrew it for FO1 or use tweezers for FO2, FO4 and FOH and repeat the
cleaning with the IBCTM Brand cleaner
■Repeat the tap water operation if needed
■Dry the contacts &connector by spraying canned air on it.
■Dry the sleeve holder by spraying canned air on it
■Insert IBCTM Brand Cleaner on all contacts and perform one click / cleaning per contact
■Reassemble the sleeve holder
■US conec IBCTM Brand cleaner (H125)
<3
min
■Tweezers
■Canned air ■Running Tap water
What you need
Procedure
FO1
FO2, FO4

5
FISCHER FIBEROPTIC SERIES
MAINTENANCE CLEANING (ultrasonic cleaning) - FO1, FO2 &FO4
■Put your connector under running tap water until everything is globally cleaned
■Remove the sleeve holder, manually unscrew it for FO1 or use tweezers for FO2, FO4 and FOH and repeat the
cleaning with the IBCTM Brand cleaner
■Put the connector & the sleeve holder in the ultrasonic bath for ~1 minute.
■Dry the contacts &connector by spraying canned air on it.
■Dry the sleeve holder by spraying canned air on it
■Reassemble the sleeve holder
■Slightly grease the plug sealing plan to recover full sealing capabilities*
■Ultrasonic bath
Recommended bath composition: Isopropyl alcohol
<5
min
■Tweezers
*Grease
What you need
■Canned air ■Running Tap water
Procedure
