Fisher-Price Tuff Stuff B0334 User manual

Model Number: B0334
Instructions
Please keep this instruction sheet for future
reference, as it contains important information.
Requires four “C” batteries (included).
Batteries must be replaced by an adult.
Tool required for battery replacement:
Phillips screwdriver (not included).
D
i
s
c
o
v
e
r
w
h
a
t
’
s
p
o
s
s
i
b
l
e
™
…
w
w
w
.
f
i
s
h
e
r
-
p
r
i
c
e
.
c
o
m
With Wacky Voices!
With Wacky Voices!
With Wacky Voices!
Tape Recorder
Tape Recorder
Tape Recorder
With Wacky Voices!
Tape Recorder
Tuff Stuff
With Wacky Voices!
Tuff Stuff
Tuff Stuff
Tuff Stuff ®

• The Fisher-Price®Tuff
is not recommended f
3 years of age.
• As with all electric pro
should be observed d
use to prevent electric
with an AC adapter.
• Your Tuff Stuff®Tape
used in bathing areas
damp areas when use
• An AC adapter (not in
with 120 volt AC hous
adapter output must b
with negative on oute
• Use only UL/CSA app
If you use an AC adap
than that specified, it
Tuff Stuff®Tape Reco
create a hazardous co
CAUTION - ELE
2

f Stuff®Tape Recorder
for children under
oducts, precautions
during handling and
c shock when used
Recorder must not be
s, outdoors or in other
ed with an AC adapter.
ncluded) can be used
sehold current. The AC
be 6 volt DC, 200mA
r connector.
roved AC adapter.
pter with output other
could damage your
rder and possibly
ondition.
ECTRIC PRODUCT
3

Tuff Stuff®Tape R
IMPORTANT! The play and record buttons
into the cassette compartment.
5
9
MICROPHONE WITH VOICE BUTTON
Press the voice button when recording or to
amplify your voice through the speaker. Speak
into the microphone to record.
SPEAKER
VOICE CHANGE SWITCH
Slide to select five different warping effects.
VOLUME DIAL
Select a comfortable listening level by rotating
the volume dial.
STOP/EJECT
At any time, press the stop/eject button to
stop the tape. Press the stop/eject button
again to open the cassette door.
FAST FORWARD
Press the fast forward button to advance
the tape rapidly.
REWIND
Press the rewind button to rewind the
tape rapidly.
6
1
2
3
4
7
5
4
78
2
6
10
1
3
4

PLAY
Insert a cassette tape into the cassette compart-
ment. Press the play button all the way down.
There is an automatic shut-off when the tape ends.
RECORD
Press the record button on the tape recorder.
Press the voice button and speak into the micro-
phone. There is an automatic shut-off when the
tape ends.
CASSETTE DOOR
Insert a cassette tape to record, listen or sing-along.
POWER JACK
Plug an AC adapter (not included) into the power
jack. Before using an AC adapter, be sure your
child understands the handling and care of an
electrical product (see “AC adapter” instructions).
MICROPHONE STORAGE
Fit the microphone on the back of this toy for
easy storage.
HEADPHONE JACK
Plug headphones (not included) into the
headphone jack for private listening.
BATTERY COMPARTMENT
Located on the back of this toy. Requires four
“C” (LR14) alkaline batteries.
10
11
12
13
14
8
9
5
11
12
13
14
Recorder Features
will not operate unless a cassette tape is inserted

Inserting a Cassette TapeBefore First Time Use
66
Please keep small
parts such as
plastic tabs out of
children’s reach.
Throw the plastic
tab away.
CAUTION
Note: A plastic tab was attached to the toy for
in-store demonstration purposes. Locate the
plastic tab on the back of the toy. Pull and remove
the plastic tab. Throw the plastic tab away.

7
For best performance, we recommend replacing
the batteries that came with this toy with four,
new alkaline “C” (LR14) batteries.
Shown Actual Size
1.5V x 4
“C” (LR14)
Loosen the screws in the battery compartment
door with a Phillips screwdriver.
Lift and remove the battery compartment door.
Insert four “C” (LR14) alkaline batteries, as
indicated inside the battery compartment.
Hint: We recommend the use of alkaline
batteries for longer battery life.
Replace the battery compartment door and
tighten the screws with a Phillips screwdriver.
Do not over-tighten.
2
1
3
4
Inserting a Cassette TapeBattery Replacement

8
AC Adapter (Not Included)
• Do not mix old and new batteries.
• Do not mix different types of batteries:
alkaline, standard (carbon-zinc) or recharge-
able (nickel-cadmium).
• Remove the batteries during long periods of
non-use. Always remove exhausted batteries
from the product. Battery leakage and corro-
sion can damage the product. Dispose of
batteries safely.
• Do not dispose of batteries in a fire.
The batteries may explode or leak.
• Never short circuit the battery terminals.
• Non-rechargeable batteries are not to
be recharged.
• Only batteries of the same or equivalent type
as recommended in the “Battery Installation”
instructions are to be used.
• If removable rechargeable batteries are
used, they are only to be charged under
adult supervision.
• Rechargeable batteries are to be removed
from the product before they are charged.
• If you use a battery charger, it should be
examined regularly for damage to the cord,
plug, enclosure and other parts. Do not use
a damaged battery charger until it has been
properly repaired.
Your Fisher-Price®Tuff Stuff®Tape Recorder may
be used with an AC adapter (not included). If you
will be using this product with an AC adapter,
make sure it has an output rating of 6 volts DC
(Direct Current), 200mA (milli-Amps) minimum.
Output lead must have a 5 mm O.D., 2 mm or
slightly larger I.D. coaxial plug. Use only an AC
adapter approved by a testing agency such as
Underwriters Laboratories. Do not use an exten-
sion cord with the AC adapter. Polarity of the AC
adapter must match Tuff Stuff®Tape Recorder
power jack center terminal, which is positive.
Please refer to the symbol on the back
of the Tuff Stuff®Tape Recorder.
IMPORTANT! An AC adapter (not included) is not
a toy. Disconnect the AC adapter (if used) from the
tape recorder before cleaning.
Battery Information

9
Your Tuff Stuff®Tape Recorder is equipped with a
headphone jack for private listening. Be sure your
stereo headphones are equipped with a 3.5mm pin.
Hint: The speaker does not project sound when a
headphone pin is inserted into the headphone jack.
If tape in the cassette loosens (or appears to be
unraveling), firmly wind it before inserting it into
Tuff Stuff®Tape Recorder.
All cassette tapes include tabs which prevent
them from being accidentally erased. To prevent
Side 1 from being erased, hold the cassette
with the tape opening facing away from you
(Side 1 will be printed on top). Break off the tab
on the right (see illustration). To prevent Side 2
from being erased, break off the tab on the left.
2
1
Cassette Tape Tips
Headphones
(Not Included)
Headphones
(Not Included)

We recommend using only 60 minute cassette
tapes (C-60) for recording or playing, 30 minutes
each side. Cassette tapes longer than 60 minutes
are made with thinner material, which reduces
performance quality and tangles more easily.
Tuff Stuff®Tape Recorder will operate properly with
most commercially available pre-recorded and
blank cassette tapes. We DO NOT recommend
recording on Hi Bias Chromium Dioxide (CrO2)
cassette tapes.
Stop/Eject Button
Press the stop/eject button to open the
cassette door.
Insert a cassette tape into the cassette door
slots, with the tape opening upward and the
desired listening side facing outward.
Press the cassette door closed. If the cassette
door does not close easily, make sure the
cassette tape has been inserted properly.
Hint: To play or record at the beginning of a
cassette tape, rewind it completely.
2
1
3
Inserting a Cassette TapeInserting a Cassette Tape
10

11
Wacky Voice Warping
Use this feature in Broadcast, Sing-Along and
Record modes.
Slide the voice change switch to any of
five positions:
Regular
Hear your own voice with no effects.
Monster
You can sound like a super, scary monster.
Robot
You won’t believe how “high-tech”
you sound!
Chipmunk
Warp your voice to a funny, high pitch.
Alien
You’ll sound like a silly space creature.

12
Broadcast
Hint: It is not necessary to insert a cassette tape
to broadcast.
Slide the voice change switch to any of five
wacky, warped settings.
Press and hold the voice button while speaking
or singing into the microphone.
Adjust the volume dial to the desired
listening level.
2
1
3

13
Sing-AlongSing-Along
IMPORTANT! The play button will not operate
unless a cassette tape is inserted into the
cassette compartment.
Insert a cassette tape into the Tuff Stuff™
Tape Recorder.
Slide the voice change switch to any of five
wacky, warped positions.
Press the play button.
Press and hold the voice button while speaking
or singing on the microphone.
Adjust the volume dial to the desired
listening level.
Press any of the top buttons to stop the tape.
1
2
3
4
5
6

14
Sing-AlongListen
IMPORTANT! The play button will not operate
unless a cassette tape is inserted into the
cassette compartment.
Insert a cassette tape into Tuff Stuff®
Tape Recorder.
Press the play button.
Adjust the volume dial to the desired
listening level.
Press any of the top buttons to stop the tape.
Hint: Insert your own stereo headphone’s pin into
the headphone jack for private listening.
2
1
3
4

1415
Sing-AlongRecord
IMPORTANT! The record button will not
operate when a pre-recorded cassette tape is
inserted into the cassette compartment. Be sure
to use a blank cassette tape.
Insert a blank cassette tape into Tuff Stuff®
Tape Recorder.
Slide the voice change switch to any of the five
wacky, warped positions.
Press the record button to record sounds
or your voice.
Hints:
- For best results, place the microphone close to
the sound source.
- Turn the volume dial down when recording to
avoid feedback or interference.
Hold the microphone and press the voice
button when recording.
Press any of the top buttons to stop the tape.
IMPORTANT! We DO NOT recommend
recording on CrO2 (Hi Bias Chromium Dioxide)
cassette tapes.
2
1
3
4
5

Problem Probable Cause
Does not play or record Weak batteries
Battery placement inc
Voice button on micro
not pressed
Slow or weak sound Weak batteries
Dirty magnetic head
No sound and motor runs Weak batteries
Battery placement inc
Headphones (not incl
being used and soun
project from the spea
Play and record Cassette tape not ins
buttons do not operate
Cassette tape improp
inserted
Record button does Tabs are detached fro
not operate; cannot record cassette tape or a pre
cassette tape is inser
Squealing sound when Microphone is too clo
using the microphone to speaker
Volume is set too hig
If you have any problems with your Fisher-Price®Tuff
Problems and S
16

17
Solution
Replace all four batteries with four,
fresh “C” (LR14) alkaline batteries.
correct Remove the batteries and replace
in correct orientation, as shown
inside the battery compartment.
ophone You must press the voice button on the
microphone to record.
Replace all four batteries with four,
fresh “C” (LR14) alkaline batteries.
Clean the magnetic head as described
in the “Maintenance” instructions.
Replace all four batteries with four,
fresh “C” (LR14) alkaline batteries.
correct Remove the batteries and replace in
correct orientation, as shown inside
the battery compartment.
luded) are Remove the headphone pin (not
d will not included) from the headphone jack.
aker
serted Insert a cassette tape into the
cassette door.
erly Check cassette tape to be sure it is
properly inserted and the cassette door
is closed.
om the Use only commercially available blank
e-recorded cassette tapes.
rted
ose Use microphone further away from
the speaker.
h Turn the volume dial down
when recording.
Stuff®Tape Recorder, please review the following:
Solutions Guide

Note: This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a resi-
dential installation. This equipment generates,
uses and can radiate radio frequency energy and,
if not installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is encouraged
to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equip-
ment and receiver.
• Consult the dealer or an experienced radio/TV
technician for help.
Note: Changes or modifications not expressly
approved by the manufacturer responsible for
compliance could void the user's authority to
operate the equipment.
HeadphonesFCC Note
(United States Only)
18
To maintain performance, we recommend cleaning
the magnetic head each time the batteries are
changed. To clean the magnetic head, purchase a
“cleaning cassette tape”. Insert a “cleaning cassette
tape” (not included) as you would a regular cassette
tape. Press the play button all the way down
and the “cleaning cassette tape” will play through
its cycle.
Maintenance

19
Fisher-Price, Inc., 636 Girard Avenue, East Aurora,
New York 14052, warrants to the original owner that
the Fisher-Price®Tuff Stuff®Tape Recorder is free
from all defects in material and workmanship when
used under normal conditions for a period of one
(1) year from the date of purchase.
Should the product fail to perform properly, we will
repair or replace it at our option, free of charge.
Purchaser is responsible for shipping the product
to Fisher-Price Consumer Relations at the address
indicated above and for all associated freight and
insurance cost. Fisher-Price, Inc. will bear the cost
of shipping the repaired or replaced item to you.
This warranty is void if the owner repairs or modifies
the product. This warranty excludes any liability other
than that expressly stated above including but not
limited to any incidental or consequential damages.
SOME STATES DO NOT ALLOW THE EXCLUSION
OR LIMITATION OF INCIDENTAL OR CONSE-
QUENTIAL DAMAGES, SO THE ABOVE LIMITA-
TION OR EXCLUSION MAY NOT APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC
LEGAL RIGHTS, AND YOU MAY ALSO HAVE
OTHER RIGHTS WHICH MAY VARY FROM
STATE TO STATE.
Headphones
(Not Included)
One (1) Year
Limited Warranty

Fisher-Price, Inc., a subsidiary of Mattel, Inc.
East Aurora, New York 14052, U.S.A.
©2002 Mattel, Inc. All Rights Reserved.
® and ™ designate U.S. trademarks of Mattel, Inc.
Printed in China B0334a-0920
Questions? We'd like to hear from you!
Call Fisher-Price®Consumer Relations, toll-free
at 1-800-432-5437, 8 AM - 6 PM EST Monday
through Friday. Hearing-impaired consumers
using TTY/TDD equipment, please call
1-800-382-7470. Or, write to: Fisher-Price®
Consumer Relations, 636 Girard Avenue,
East Aurora, New York 14052.
For other countries, outside the United States:
Canada: call 1-800-567-7724, or write to:
Mattel Canada Inc, 6155 Freemont Blvd.,
Mississauga, Ontario L5R 3W2.
Great Britain: telephone [phone].
Australia: Mattel Australia Pty. Ltd., 658 Church Street,
Locked Bag #870, Richmond, Victoria 3121 Australia.
Consumer Advisory Service 1300 135 312.
New Zealand: 16-18 William Pickering Drive,
Albany 1331, Auckland.
Consumer Information
