Stainless Steel 1/2” Swing & Swivel Gooseneck Spouts
Product Installation Guide
54380 - 6” Swing Spout
54399 - 8” Swing Spout
54402 - 10” Swing Spout
54410 - 12” Swing Spout
54429 - 14” Swing Spout
54445 - 16” Swing Spout
54437 - 12” Swivel Gooseneck Spout
54453 - 6” Swivel Gooseneck Spout
fisher manufacturing company - toll free: 800-421-6162 fax: [phone]
ANSI/A112.18.1M, ANSI/NSF 61.9
www.noleadfaucet.com
KEEP THIS MANUAL FOR FUTURE REFERENCE
MANFACTURING COMPANY
PO BOX 60, TULARE, CA 93275
[phone], FAX: [phone]
www.fisher-mfg.com
Replacement Parts for Stainless Steel 1/2” Swing
& Swivel Gooseneck Spouts
PART NO. 77976 REV. A
2002
SNAP RING
1600-5000
SPOUT
O-RINGS
10456
LUBE
54445
16” SWING SPOUT
54429
14” SWING SPOUT
54410
12” SWING SPOUT
54402
10” SWING SPOUT
54399
8” SWING SPOUT
54380
6” SWING SPOUT
54437
12” SWIVEL
GOOSENECK
SPOUT
54453
6” SWIVEL
GOOSENECK
SPOUT
41718
2.2 GPM
AERATOR
54763
SPOUT NUT
