FITKIT 10K 3.5HP User manual

USER MANUAL
Model Name - Fitkit 10K 3.5HP
Special tips:
1. Before installation and operation, please read this operation manual carefully.
2. Please save this manual for future reference.
3. Always choose a treadmill that can support at least 20 more kilograms of weight than
your current weight.

- 1 -
Table of Contents
1Brief Description ....................................................................2
2Main Technical Features ........................................................2
3Tips for safety….................................................................... 3-4
4Installation............................................................................ 4
5Use and Operation.................................................................4-6
6Maintenance......................................................................6-8
7Guides for malfunction ..........................................................8-9
8Warranty................................................................................9
9Error and self-inspection.........................................................9-10
10 Installation Sketch.............................................................11-12

- 2 -
1. Brief Description
10K 3.5HP motorized treadmill (diagram 1) can help complete your goal of keeping fit together with
unique and elegant appearance. Easily read panel parameter 。Easily operated folding system
realizes space-saving. Auto speed range 1-14km/h with 3 manual inclines. All makes it a hot home
use fitness equipment.
Meter accessories Safety key
Heart rate sensor
Handle
Pillar accessories
Footplate
Running belt
Running belt adjustor
P o w er s w i t ch
Diagram 1: Fitkit 10K 3.5HP Motorized Treadmill
2. Main Technical Features
Main use: Body and beauty building
This treadmill is for home use
Panel displays speed, time, distance, heart rate, calorie etc.
Display Mode LCD
Input voltage: 220V
Frequency: 50/60Hz
Input current: ≤8A
Temperature for working: 0∽40℃
Speed range: 1∽14km/h
Incline: 3 manual
Program: Time display range: 0:00∽99:59(minute: second);
Distance display range:0.1~99.99kms
Machine size (L*W*H): ：1545*710*1270（mm）
N/W-G/W：47KG/54KG；
Made in China

- 3 -
3. Tips for Safety
3.1 Insert the power plug into the socket directly. Current load should be less than 10A.
3.2 The constant running time is less than 2 hours, max weight is 120kgs.
3.3Place your treadmill on the clean floor not on the thick carpet, otherwise itwill not convenient
for ventilation. Also please don’t put the treadmill in the moist place or outdoors; If there is
something wrong with the electrical wire, please replace it with the electrical wire provided by our
company. For the replacement, please contact with the local distributor.
3.4 The treadmill should be placed in the convenient position for electric socket.
3.5 The freshman should grip the handrails when jogging and running until familiarly. Please don’t
stand on the running belt, after the machine is power on (the safe key is at the appointed position).
Please stand on the footplates besides the treadmill, press the “start” button, it runs at the lowest
speed, at this time you can run on the belt.
3.6While running, you should dress properly. Don’t dress too loosely in case your clothes are
entangled by the machine. And please wear sport shoes with soft sole.
3.7Before taking down the protecting cover of the treadmill, please keep the machine is power off.
3.8Don’t let children and non-sporters get close to the running treadmill to avoid unnecessary
injury.
3.9Please make sure one end of the safe key has been placed in the appointed position and the
other one has been nipped to your clothes when you are running on the machine. In this way, you
can pull the safe key for the machine’s sudden stop under the dangerous condition. Then you will
not be injured.
3.10 If you are enjoying other entertainment while running such as watching TV, reading. Please
be particularly careful. These activities will distract your attention, which may make you lose your
balance and get hurt.
3.11 Please pull the plug off from socket and keep the safe key, when the treadmill is unused.
3.12Please don’t put anything under treadmill and don’t let your children play near it after folding.
3.13 Please consult your doctor at first before running, if you have one of the following diseases.
a) Cardiopathy, hypertension, sugar diabetes, respiratory disease, smoking, and other
chronic diseases, complication disease.

- 4 -
b) If you are over 35 years old and heavier than common weight.
c) Women in pregnant or in breasting period.
3.14 Please stop exercising immediately and consult your doctor if you’re feel giddy, surfeit, thorax
ache or other symptoms.
3.15 Please drink adequate water after taking exercise.
4. Installation: See “Installation sketch”
5. Use and Operation
5.1 Panel Keys and Function
（1）MP3 （2）Prog
（3）speed shortcut key （4）speed shortcut key
（5）set-up
（7）start
（10）set-down
（9）Mode
（6）speed-down
（8）stop
（11）speed-up
（12）safety key

- 5 -
（1）“MP3”
Press this key to open or shut the speaker amplify.
（2）“PROG” (could be pressed continuously to your expected mode)
Press the “PROG” key once again to enter “24 direct selected programs” there are 24 programs.
（3）Speed short cut key:
Under running condition, press this key, speed can be set to the value directly.
（4）“Speed short cut key”
Under running condition, press this key, speed can be set to the value directly.
（5）Set up:
Under the “mode “condition, we only could press the “set up “key to up speed
（6）“Speed down”
Under running condition, press this key, speed can be speeded down to the one you need.
（7）Start: Under ready condition, press this key, it runs at the speed of 1.0km/h.
（8）Stop: Under running condition, press this key, if it runs at speed more than 3.5km/h, it will
slow down then stop. During this stopping process, other keys are not available. If it runs at speed
less than 3km/h, then it stops immediately.
（9）“Mode”
Under ready condition, press this key to set time, distance and calorie accordingly. Press “set-
up” or “set-
down” keys to set the value of time, distance and calorie. Then press “start” key, the machine will
run at 1.0km/h. And the set figures will be counted down, when it comes to “0”, machine stops.
（10）Set down:
Under the “mode” condition, we only could press the” set down” to down the speed
(11 ) Speed up:
Under running condition, press this key, speed can be speeded up to the one you need.
（12）“safety key”
Under urgent condition, pull this key, machine stops immediately.

- 6 -
5.2 Unload operating
1. Insert power plug into the socket with earth wire, turn the switch to “1” position which is on the
frame
2. Put the safe key in the right position, then circuit is on, press “on/off”, keep it run in unload
condition. Test the condition of running belt (testing from low speed to high ones), after testing,
press “on/off”.
3. If everything is ok, then start to run.
5.3 Meter operating instruction
5.3.1
1. Insert power plug into the socket with earth wire, turn the switch to “1” position which is on the
frame. Place the safe key to the appointed position. After a few seconds, panel will show that the
machine is ready.
2. Nip another end of safe key to your clothes, and stand on the footplate on both sides.
3. Press “on/off” key, running belt moves at the lowest speed (1.0km/h). Speed windows will
displayyour running speed.
4. Start to run.
5. Press speed key or incline key to adjust speed and incline, speed window and incline window will
display your speed and incline.
6. To end your exercise in a safe way, please first press “on/off” key to close the treadmill. Please
leave the running belt until it stops slowly. Turn off the power.
5.3.2 Heart Rate Testing
Our treadmill can test your heart rate via the heart rate sensor. The data is only for reference.
5.4 Folding and Opening Treadmill
5.4.1 Folding
Firstly, lift and fold the back part of the frame board by hand till you hear a light sound, which
means the folding system has been locked. At this time running board can’t be turned to the
opposite direction
5.4.2 Opening
Put the folded treadmill in a capacious position when you want to run. Then pull the adjusting parts
by hand to keep it is unlocked. Press the back part by your hands down to about 10%, release it,
then it will open automatically.
6. Maintenance
6.1 Identification ways for the degree of tightness of running belt and poly V-belt.
When the running belt skips, please follow the steps as follows to make sure which belt needs to be
adjusted, running belt or poly V-belt.
a) Cut off power, screw off the bolt on cover of protection. Then take down the protecting cover
from the treadmill
b) Turn the speed to be around 3km/h, step on the running belt by pressure and try your best to
make the running belt stop. If running belt stops, together with the front roll, but the motor still

- 7 -
runs, under this condition, it means the poly V-belt needs to be adjusted.
c) Turn the speed to be around 3km/h, step on the running belt by pressure and try your best to
make the running belt stop. If running belt stops, but front roll still runs, under this condition, it
means the running belt needs to be adjusted.
6.2 The adjustment steps for poly V-belt
Cut off power firstly and take down the cover of protection.
a) Loosen the four screws for the motor, adjust them in a circuit clockwise, then screw down the
loose screws.
b) Keep the power on, and adjust the poly V-belt is loose or not following the point 3.1 above, if
yes, please repeat the action same to point a) above.
6.3Adjustment steps for running belt
a) Turn the speed to be 5.6km/h. for running
b) Turn the bolts at both right and left sides to be half a circuit or a circuit by the 8mm spanner.
(diagram1 and diagram 2)
c) After adjustment, running belt still skips, please repeat the steps above.
Tighten the running belt (diagram 1) loosen the running belt (diagram 2)
6.4 The adjustment steps for running belt deflection
The running belt will be deflected more or less under using. Then it needs to be adjusted. The steps
are as follows:
a) Place the treadmill on a horizontal floor, turn the speed to be 5.6km/h for running.
b) If the running belt is deflected to the right, adjust the bolt on the right by turning it for half a
circle clockwise, then adjust the bolt on the left by turning it for half a circle. (See diagram 3)
c) If the running belt is deflected to the left, adjust the bolt on the left by turning it for half a circle
clockwise, then adjust the bolt on the right by turning it for half a circle. (See diagram 4
d) After the adjustment, the running belt still keeps deflecting, please repeat the steps above.
running belt deflected to right running belt deflected to left
The adjustment for right deflection (diagram 3) The adjustment for left deflection (diagram 4)
6.5 Running board lubrication
The treadmill is equipped with lubricated running board, which needs constant maintenance.

- 8 -
The friction between running board and running belt has a great effect on the treadmills’ e life. So
please lubricate your machine termly. The steps are as follows:
a) Cut off the power
b) Wipe out the dust between running board and running belt with a clean cloth.
c) Daubing the Silicon oil on the running board and running belt equably.
d) While adding lubrication oil, please keep your clothes away from the machine for avoiding the
injury.
6.6 Cleaning
a) Please power off and pull the plug cap out before cleaning.
b) Wipe out the dust stuck on the surface and running board frequently.
c) Please clean the surface of frame and running belt with a soft cloth dipped with suds, don’t use
things like eradicator and naphtha. (After cleaning, please dry it for use)
d) Please take the protecting cover off every two months, use vacuum dust-collector to suck the
dustremaining inside of the protecting cover. (The dust will make the components of circuitry
board short circuit)
6.7 Cautions, folding, depositing
6.7.1 Cautions
Please make sure that the plug cap has been pulled out before cleaning or maintenance.
6.7.2 Depositing
The treadmill should be deposited indoor in case of being damp. Water can’t be spattered and
nothing can be laid and inserted on the treadmill.
Please keep the air a little humid in winter. And please void the big static electricity, it may disturb
the operation of meters or even damage them.
7. Guides for malfunction
7.1 Analyzing and eliminating malfunction
Item
.
Malfunction
Reasons
Solution
1
Treadmill can’t be started
The safe key isn’t in the
right position
Put the safe key in the right
position
The electrical switch is
placed to “0”
Turn the electrical switch to “1”
creepage switch is not
right
Replace creepage switch
2
Meter can’t display
The meter control line
and control panel are
unconnected
Pull the bolt out and open the
motor cover and reconnect it
Turn on the meter and reconnect
3
Heart rate can’t be displayed
The pole of heart rate
sensor is not wet enough
Wet the pole with water or liquor
for hard contact lenses
Disturbed
electromagnetism
by
Stay away
electromagnetism
from
4
Incline doesn’t work
The motor wire is not
Open the motor
cover
and

- 9 -
well connected
reconnect it
5
Running belt runs faster or
slower than what has been
displayed
Unadjusted
Readjust it
6
Running belt slips
Running belt is not tight
enough
Please read point 3.3 Adjustment
steps for tightening running belt
for reference
7
Running belt is deflected
The running belt is
unadjusted.
Please read point 3.4 The steps
for adjusting the deflected
running belt for reference
7.2 If you still can’t solve the problems after taking the solutions above, we hope that you can
contact our dealer or company as soon as possible.
8Error
8.1 ErrorTreadmill gives the following error code if anything wrongplease contact the professional
service people soon if it happens.
Error Code
Reason
E00
please check if the safety key was in the right position,
without any shifting.
E01
Please check if the main line was in good connection
E02
Change the MCB if still with the problems after restarted the treadmill
E03
Please check if the speed sensor on the motor was in the right position,
without any shifting.
E04
Self-inspection if both incline motor and connect line were well, if still not
OK, please change the MCB.
E05
Change the MCB if still with the problems after restarted the treadmill
E06
Change the MCB if still with the problems after restarted the treadmill

- 10 -

- 11 -

- 12 -
Bluetooth App:
Scan QR code below to download cultsport APP that tracks your Health data by connecting to your health
equipment and your fitness band and tracking all your health data in once place. cultsport app tracks Exercise
(steps), Calories burnt and Sleep besides other health data. We connect to most fitness bands so our customers do
not need to invest on another product. cultsportcertified panel of Nutritionists will interact (speak) and build
customized plans for each customer. Our certified panel of Fitness Experts will build customized plans of each
customer based on their equipment and age/health. We keep all your data in one place- on the cultsport app sothat it
can be referenced by you, your Coach or medical practitioners.
Scan QR code below to download cultsport APP
QR CODE:
Scan QR code below to download cultsport play APP
Cultsport play combines the fun of video games with the intensity of serious workouts,
helping you achieve your fitness goal. Pair a Cultsport play -supported Treadmill to ourapp,
and get started today.

- 12 -
Customer Care Support
❖Write to us:[e-mail]
❖Web site:www.cult.fit
❖Contact Number: 1800-572-6303/1800-572-6402
❖Customer Support: Monday to Saturday-
From 09:00AM- 06:00 PM
