Flagro FRHR-100N Instruction Manual

OPERATING INSTRUCTIONS MANUAL
(Please retain for future reference)
For
FRHR-100N/P RADIANT CONSTRUCTION HEATERS
CERTIFIED FOR USE IN CANADA AND U.S.A.
As per Standard ANSI Z83.7 2000/
CSA 2.14 2000 Gas Fired Construction Heaters Unvented /Unattended Type.
FLAGRO INDUSTRIES LIMITED
ST. CATHARINES, ONTARIO
CANADA

- 2 -
GENERAL HAZARD WARNING:
FAILURE TO COMPLY WITH THE PRECAUTIONS AND INSTRUCTIONS
PROVIDED WITH THIS HEATER, CAN RESULT IN DEATH, SERIOUS BODILY
INJURY AND PROPERTY LOSS OR DAMAGE FROM HAZARDS OF FIRE,
EXPLOSION, BURN, ASPHYXIATION, CARBON MONOXIDE POISONING, AND/OR
ELECTRICAL SHOCK.
ONLY PERSONS WHO CAN UNDERSTAND AND FOLLOW THE INSTRUCTIONS
SHOULD USE OR SERVICE THIS HEATER.
IF YOU NEED ASSISTANCE OR HEATER INFORMATION SUCH AS AN
INSTRUCTIONS MANUAL, LABELS, ETC. CONTACT THE MANUFACTURER.
WARNING:
FIRE, BURN, INHALATION, AND EXPLOSION HAZARD. KEEP SOLID
COMBUSTIBLES, SUCH AS BUILDING MATERIALS, PAPER OR CARDBOARD, A
SAFE DISTANCE AWAY FROM THE HEATER AS RECOMMENDED BY THE
INSTRUCTIONS. NEVER USE THE HEATER IN SPACES WHICH DO OR MAY
CONTAIN VOLATILE OR AIRBORNE COMBUSTIBLES, OR PRODUCTS SUCH AS
GASOLINE, SOLVENTS, PAINT THINNER, DUST PARTICLES OR UNKNOWN
CHEMICALS.
WARNING:
NOT FOR HOME OR RECREATIONAL VEHICLE USE.
This heater is designed and approved for use as a
construction heater under ANSI Z83.7 2000 and
CSA 2.14 2000 Gas Fired Construction Heaters
We cannot anticipate every use which may be made
of our heaters. CHECK WITH YOU LOCAL FIRE
SAFETY AUTHORITY IF YOU HAVE QUESTIONS
ABOUT APPLICATIONS.
Other standards govern the use of fuel gases and heat
producing products in specific applications. Your local
authority can advise you about these.

- 3 -
WARNING:
INTENDED USE IS PRIMARILY THE TEMPORARY HEATING OF BUILDINGS
UNDER CONSTRUCTION, ALTERATION, REPAIR OR EMERGENCIES ONLY.
ALWAYS PROVIDE ADEQUATE VENTILATION. 1 SQ. IN. OF FRESH AIR MUST
BE SUPPLIED FOR EVERY 1000 BTUH OF HEAT.
THIS HEATER SHALL BE INSTALLED SUCH THAT IT IS NOT DIRECTLY
EXPOSED TO WATER SPRAY, RAIN AND/OR DRIPPING WATER.
MINIMUM CLEARANCE TO COMBUSTIBLES
TOP: 48 inches
SIDES: 30 inches
BOTTOM: 0 inches
INLET PRESSURES
FRHR-100N Natural gas MINIMUM Supply Pressure 7" W.C.
MAXIMUM Supply Pressure 14" W.C.
FRHR-100P/PQD Propane MINIMUM Supply Pressure 11" W.C.
MAXIMUM Supply Pressure 14" W.C.
MAINTENANCE
1. This construction heater should be inspected before each use. All burner ports should remain clear and the
valve should be inspected for any possible damage. The heater should be test fired before each use. High
pressure air may be used to blow out the inside of the burner.
2. The heater should be inspected annually by a qualified service person.
3. The heater must be kept clear and free from combustible materials, gasoline and other flammable vapors
and liquids.
4. The hose assembly shall be visually inspected prior to each use of the heater. If it is evident there is
excessive abrasion or wear, or the hose is cut, it must be replaced prior to the heater being put into
operation. The replacement hose assembly shall be supplied by Flagro Industries Limited. Please see Parts
List.

- 4 -
INSTALLATION
All natural gas heaters must be installed by a qualified gas fitter and must conform to local installation codes or, in
the absence of local codes, with the National Fuel Gas Code ANSI Z223.1/NFPA 54 and the Natural Gas and
Propane Installation Code, CSA B149.1. The natural gas heater is provided with a ½" male quick disconnect fitting.
The hose assembly used to install this heater must be a Type 1 CGA/AGA approved hose assembly equipped with a
½" female quick disconnect socket to mate with the inlet fitting. Before lighting the heater, all connections must be
leak checked using a soap and water solution. The heater must be installed on a level surface.
FOR A HEATER CONNECTION TO AN LP-GAS SUPPLY CYLINDER
1. The installation must conform with local codes or, in the absence of local codes, with the Standard for the
Storage and Handling of Liquefied Petroleum Gases, ANSI/NFPA 58 and the Natural Gas and Propane
Installation Code, CSA B149.1.
2. The hose assembly used to install this heater must be a Type 1 CGA/AGA approved hose assembly. The
heater must be located at least 20-ft (6.10m) from any LP-gas cylinder.
3. The heater should be installed using a LP-gas cylinder with a minimum capacity of 30-lbs up to a
maximum capacity of 100-lbs.
4. The cylinders used to supply this heater must provide for vapor withdrawal only.
5. The heater must be connected with a “low pressure” regulator and POL inlet fitting. The POL fitting is
connected to the LP-gas cylinder by turning the POL nut counter clockwise and tightened using a wrench.
All connections must be checked for leaks using a soap and water solution or approved leak detector
solution. Use a wrench and turn the POL nut clockwise to disconnect the heater from the cylinder.
6. The cylinder must be disconnected from the heater when not in use.
7. The heater is to be stored indoors, the connection between the LP-gas supply cylinder(s) and the heater
must be disconnected and the cylinder(s) removed from the heater and stored in accordance with Chapter 5
of the Standard for the Storage and Handling of Liquefied Petroleum Gases, ANSI/NFPA 58 and CSA
B149.1, Natural Gas and Propane Installation Code.

- 5 -
LIGHTING INSTRUCTIONS
1. Ensure the heater is connected to the proper source of gas and proper
inlet pressures are supplied. The heater must be installed by a
qualified installer.
2. Set thermostat knob (green button) to high position. Rotate the control
knob (black) counter clockwise to 'PILOT' position. Depress and hold
control knob.
3. Light the pilot burner using a long reach lighter through lighting hole
provided.
Release the knob after 60 seconds. Pilot will remain lit. Main burner
will remain off.
4. Turn control knob counterclockwise to 'ON' position. Main burner
will light.
5. If the main burner fails to light, turn the control knob clockwise to the
'OFF' position, wait 5 minutes and repeat step 3.
6. The green knob controls the thermostat option. This will light and
extinguish the main burner as the temperature fluctuates.
SHUT OFF INSTRUCTIONS
1. Turn the control knob clockwise to the 'OFF' position. Both main
burner and pilot burners will extinguish.
2. Turn off source of fuel.

- 6 -
IMPORTANT NOTES FOR SUCCESSFUL LIGHTING AND OPERATIONAL SAFETY
1. For safety purposes, this heater model is equipped with a “tip over switch” which will prevent the heater from
operating or being lit if it is bumped, jarred, knocked over or positioned on an angle. In order to light and
operate properly, this heater MUST be placed on a flat horizontal surface in an upright position.
9 8
CORRECT POSITION
INCORRECT POSITION
2. The tip over switch is interlocked with the
thermocouple. The connections on the
thermocouple block must be kept clean and tight at
all times to ensure proper operation of these
components.
Thermocouple block
Tip over switch
3. While the heater unit does not require a filter, the unit must be kept clean and
the burner and pilot assembly must be kept free of dust and dirt to ensure
optimal and safe operation at all times
Store the unit in a clean environment and make sure that the unit is leak
checked and cleaned before every use. Do not clean the unit with volatile
substances. (see maintenance on Page 3)

- 7 -
PARTS LIST 2009/2010
FRHR-100N/P RADIANT CONSTRUCTION HEATERS
PART # DESCRIPTION LIST PRICE
FRHP-01NG Gas Control Valve c/w thermostat – NG 198.00
FRHP-01LP Gas Control Valve c/w thermostat – LP 198.00
FRHP-02NG Pilot Assembly – NG 19.00
FRHP-02LP Pilot Assembly – LP 19.00
FRHP-03 Pilot Line 12.00
FRHP-04 Thermocouple 36.90
FRHP-04A Cut-off Switch 21.00
T-18 18” Thermocouple 17.05
FRHP-05RLP Burner Orifice LP 20.25
FRHP-
05RNG Burner Orifice NG 20.25
FRHP-07RLP Burner Assembly – LP 56.50
FRHP-
07RNG Burner Assembly – NG 56.50
FRHP-08R Stainless Emitter Grid c/w shield and feet 191.20
FRHP-09 Tip-over Switch c/w wire 28.00
FRHP-10 ⅜" Low Pressure Fire Line c/w Flare Nuts 12.50
FRHP-11 Reducing Nipple ½" x ⅜" 4.80
FRHP-12 Safety Screen Assembly (Two required) 66.00
FRHP-13A Single Stage Regulator-LP c/w POL 25.00
FRHP-15 NG Regulator (used with WR Control) 48.00
FRHP-18 Thermo Bulb Bracket c/w Grommets 8.50
FRHP-21 1/4" Compression Nut & Sleeve for Pilot
Line
5.65
FRHP-22 1/4" Extended breakaway for Pilot Line 8.05
FRHP-50 Conversion Kit for FRHR NG TO LP 106.00
FRHP-51 Conversion Kit for FRHR LP TO NG 123.00
100-006 ⅜" Quick disconnect socket – Female Socket 31.90
100-506 ⅜" Quick disconnect plug – Male Socket 17.60
100-008 ½" Quick Disconnect – Female Socket 82.50
100-508 ½" Quick Disconnect – Male Socket 33.00
100-010 ¾" Quick Disconnect – Female Socket 121.00
100-510 ¾" Quick Disconnect – Male Plug 44.00
2009-1

FRHR-100 Parts List
1
2

FRHR-100 Parts List
3
4
5
67
8, 9, 10
6

FRHR-100 Parts List
11, 12
13
14
15

FRHR-100 Parts List
16, 17
11, 12
19, 20 18

FRHR-100 Parts List
Accessories
HOSES
Item # Description P/N
1 Removable Screen Assy FRHP-12
2 SS Emitter Grid Assy FRHP-08R
3 3/8" Low Pressure Line FHRP-10
4 3/8" Flare x 3/8" MP Elbow 49-6C
5 Gas Control Valve FRHP-01 LP/NG
6 Green Control Knob/Black Knob FRHP-23/FRHP-19
7 Pilot Line FRHP-03A
8Propane QD Model 122-CD/100-506
9 Natural Gas QD Model 122-DC/100-506 MANIFOLDS
10 Propane SAE Model 48-6C
11 Propane Burner Assy FRHP-07RLP
12 Natural Gas Burner Assy FRHP-07RNG
13 Burner Fitting 46-6C
14 Tipover Switch FRHP-09
15 ECO Cutoff Switch FRHP-04A
16 Main Burner Orifice-NG FRHP-05RNG
17 Main Burner Orifice-LP FRHP-05RLP
18 Thermocouple T-18
24
Not shown
26 Not shown
19 Pilot Assembly- LP FRHP-02LP
20 Pilot Assembly- NG
FRHP-02NG
METER
21 50 FT Propane Hose FRHP-101600LP
22 50 FT NG Hose FRHP-101
23 Union Gas Single Manifold MAN-U1
24 Union Gas Douible Manifold MAN-U2
25 Enbridge Manifold MAN-E1
26 Enbridge Double Manifold MAN-E2
27 Enbridge Nipple MAN-NP
28 Enbridge Meter Key MAN-Key
21 22
23
27
28
25
