Flash SO/PPS500W User manual

500W Portable Power Station
SO/PPS500W Instruction Manual
AC 230V 500W MAX

Instruction Manual
SO/PPS500W Portable Power Station (500W)
Don't worry about the lack of outdoor power, use the Portable Power Station, you can easily
maintain a state of charge on the go. There is no need to worry about sudden power failure or
the dark night outdoors, portable power station oers you great power supply and condence
in the wild!
Attention:
1. Specications and images in this manual are for reference only.
2. This product is for emergency use only.
3. Fully charge the product before using it for the rst time (minimum 10 hours). Once the battery
bar no longer ashes, the device is fully charged.
11
Battery percentage
Fan status USB-A output AC output
USB-C output
Output Power
Fault alarm code
AC output frequency
Output remaining time
Input Power
Temperature alarmDC output
Battery indicator
LIGHT Button
LED Light
Power Button
Display Button
AC output 230V
DC Button
DC5521 Input
Quick Charger 3.0
USB-C PD60W Output
USB-C PD100W Input / Output
USB Button
AC Button
DC Car Port
output 12V 10A
DC5521 output 12V 10A
AC 230V 500W MAX

2
AC 230V 500W MAX
Charging Your Product
ATTENTION: If the ambient temperature is too high or the battery temperature is higher than
60°C due to continuous high-power discharge, the product cannot be charged. When the
battery temperature is less than 55°C, the charging function will automatically resume. If it is not
used for a long time, it is best to fully charge it every three months before storing; It is best to fully
charge the battery.
There are 5 segments to the battery, approximating 20%-40%-60%-80%-100% capacity.
As you use your product, segments will disappear from the display, indicating the remaining
charge. When charging your product you will notice a battery segment blinking at a 1 second
interval status. Once your product is fully charged, all battery segments will be lit and remain solid.
1. LCD Battery Display
2. Charge Through Flash Portable Solar Panel
A. Place your Flash Portable Solar Panel where it will get as much strong direct sunlight as possible.
B. Connect the output port of the Flash Portable Solar Panel with the input port of the product to
start charging. You will know the product is being charged when the LCD display indicators
blink. The product is fully charged when all battery indicators stop blinking and remain solid.
Notes:
The actual charging eciency can vary widely depending on weather, ambient temperature,
sunlight’s strength, the angle that the Flash Portable Solar Panel faces to direct sunlight and other
factors. The maximum output voltage of the Flash Portable Solar Panel should not exceed 23.5V.
It is recommended to use Flash Portable Solar Panels with an open circuit output voltage
of 10.8-23.5V.

3. Charge Through AC Adapter
Notes:
A. The product is fully charged when all battery indicators stop blinking and remain solid.
After the product is fully charged, please unplug the AC wall charger in time.
B. Usually, it takes around 7 hours to fully charge the machine using the AC power adapter.
C. When you charge the battery using the DC input port the PD100W port will not provide
power output.
A. Plug the orginal car charger into the cigarette lighter socket of your 12V car, and then plug
into the DC input port of the machine.
B. The original car charger features a 10A protector tube to protect your car.
C. You will know the machine is being charged when the battery indicators blink.
D. Depending on your car you may not get a full charge with this method of charging.
E. If the charging voltage of your car is too low, the battery can’t be charged using this method.
Notes:
To avoid car battery power loss, you should charge this product through your car cigarette lighter
only when your car engine is started. This function is for a 12V car only.
AC Adapter
Plug the original adapter into the machine’s
DC input port and you will see the battery
indicators blink on the screen.
3
AC 230V 500W MAX
4. Charge Through Your Car
AC 230V 500W MAX
Protection mode (DC Input)
A. Due to the dierent models of your car, it may not be full.
B. Undervoltage protection: The power generator can’t be charged if the voltage of your car is too low.

4
5. Charge Through PD Charger
(PD charger not included)
Plug your PD charger to the
PD 100W IN/OUT Dock.
Using Your Product
AC 230V 500W MAX
1. Buttons
AC 230V 500W MAX
A. Long press the power button for 3 seconds to turn the Solar Power Station on.
B. Press the AC button to turn the AC function (The AC icon will display on the screen at the same
time.) Press the AC button again to turn o the AC function when not in use.
C. Press the DC button to turn on the DC function (The DC icon will display on the screen at the
same time.) Press the DC button again to turn o the DC function when not in use.
D. Press the display button to turn o the screen display, press the display button again to turn
on the screen display. Long press the display button to turn o the sound.
E. Press the power button and light button simultaneously to switch the frequency of the machine.
F. Press the power button and AC button simultaneously to reset the machine.
G. Press the USB button to turn on the USB function. (The USB icon will display on the screen at
the same time) Press the USB button again to turn o the USB function.
A. Press this button to turn on the light in high-light mode.
B. Press this button again to change the light mode into low-light mode.
C. Press this button again to change the light mode into SOS.
D Press this button again to change the light mode into ash mode.
E. Press this button again to turn o the light.
2. Light Modes
Warning! DO NOT stare straight into the light
PD charger (not included)

5
A. Press the DC button to enter DC mode, DC/CAR port will be available.
B. These two DC5521 (5.5mm in diameter) 12V port oer max 10A output current and
automatically distribute max current.
C. The DC5521 port is connected in parallel with the car charger port (the total output power
requirement does not exceed 120W).
3. USB Output Function
4. DC Output Function
A. Press the USB button to enter USB mode,
UBS-A/UBS-C PD60W port will be available.
When two UBS-A ports are used simultaneously,
the two ports can only output 5V/3.8A in total.
AC 230V 500W MAX
DC Output 12V 10A
AC 230V 500W MAX
Notes:
When the products AC, DC, UBS output at full power for 3 minutes at the same time, the product
buzzer will alarm, and the LCD screen will display E10 code, if the alarm persists for more than
30 seconds and is not cleared. The product will forcibly turn o the DC output to reduce the
total output of the product output power to ensure product safety. If the DC output shuts down
due to overload, do not force it by pressing the key open. When the remaining charge of the
machine is less than 10%, the DC output function will be forcibly turned o, and it needs to be
charged to restore. If idle for more than 4 hours, the DC output will automatically shut down.
When not in use, please press the DC button to turn o the DC function.
Protection mode (DC Output)
Short circuit protection: when short-circuit occurs with external devices, the machine
starts beeping and stops output.

Battery Type
USB 1-2 Port (Output)
DC5521 Port (Output)
Car Charger (Output)
DC5521 Port (Input)
USB-C Port (Output)
2*DC5521 + 1*Car Charger 12V 10A
(Max 120W)
Adapter/Solar Panel: DC 10.8~23.5V (100W Max)
6
6
Notes:
If no operation is performed, the LCD backlight will automatically dim after 2 minutes. When the machine battery is below 10%,
the AC output function will be forcibly turned o and needs to be charged to be restored. If idle for more than 8 hours, the AC output
will automatically turn o. When not in use, press the AC button to turn o the AC function.
Protection mode (AC Output)
A. This product has undervoltage protection; overload protection; short circuit protection. The overtemperature
protection adopts double isolation circuit, which is safe, reliable and ecient.
B. When overload, over temperature or short circuit occurs, this machine will start beeping and the ER03 icon appears
on the screen, and then the AC function automatically shuts down to ensure safety.
AC output 230V
AC 230V 500W MAX
5. AC Output Function
A. Plug the power cable of AC appliance into the AC outlet of
the Solar Power Station. Press the AC button to enter AC mode.
B. Make sure the power of the connnected AC
appliance is less than 300W.
Product Specications
Battery
Port
General

AC Module Abnormal
7
can then be
can then be
can then
charger
prompted
overloaded
can then
to drop
Place
Place hot
to rise
Cold Weather Usage
Cold temperature can aect the product’s battery capacity due to the battery’s chemical reactions.
If you live in an environment below zero degrees Celsius, it is recommended to place the product
in an adiabatic cooling environment and connect the power source (12V car power supply /
AC adapter / Flash Portable Solar Panel). The natural heat generated in the adiabatic cooling
environment will keep the battery capacity at the highest level.
Disposal and Recycle
This product should not be disposed along with household waste. Please dispose or recycle this
product and the battery inside according to the local rules and regulations.
Battery Information
A. This product has an internal, non-removable, LiFePO4 Rechargable battery.
Do not attempt to remove the battery, as you may damage the device.
B. The battery can be charged and discharged over 2000 cycle times.
Error Codes:

8
FAQ
Q1: Which devices can this SO/PPS500W portable power station support?
A: AC output: Rated 500W; DC output: 12V/10A (120W max)
Q2: Does SO/PPS500W Power Station support pass through charging?
A: Yes, this SO/PPS500W Power Station support pass through charging, you can use all other
outputs while charging.
Note: The PD 100W cannot be used when you recharge the power station with DC input
(PD cable not included).
Q3: Does the product have a power saving function?
A: Yes, our power station has a power saving function:
For the AC output, when the output power is less than 3W, the AC output
will shut down automatically after 8 hours.
For the DC output, when the output is less than 50mAh, the DC output will shut down
automatically after 4 hours.
For the USB output, when the output is less than 30mAh, the USB output will shut down
automatically after 30 seconds.
Q4: How to remove the button beep?
A: Long press AC button for 3-5 seconds to turn o, then long press AC button for 3-5
seconds to turn on.
Warning:
1. Do not short circuit the product. To avoid short-circuiting, keep the product away
from all metal objects.
2. Do not heat the product, or dispose of it in re, water or other liquids. Keep it away from high
ambient temperature. Do not expose the product to direct sunlight.
3. Keep the product away from humid, dusty places.
4. Do not dissassemble or reassemble this product.
5. Do not drop, place heavy objects on, or allow strong impact to this product.
6. This product is not intended to be used by persons with reduced physical, sensory
or mental capabilities
7. Please keep this product away from children.
8. Do not cover this product with towels, clothing or other items.
9. Do not overcharge this product.
10. When fully charged, disconnect the product from the power source immediately.
11. If you are not going to use this product for a long time, please disconnect the cable before
storing it away.
12. To charge some portable electronic device, you may need to set those devices in charge
mode rst. Refer to the corresponding user manual of those devices for conrmation.

9
Pure Sine Wave Output
This product generates Pure sine wave, which is compatible with AC electric appliances that work
with Sinusoidal waveform (power<500W).
Package Content
1 x Portable Power Station
1 x AC Adapter
1 x Car Charger Cable
Guarantee
Our company provides customers with a guarantee of 24 months from the date of purchase.
