FlashLogic FLCAN User manual

NOTICE: The manufacturer will accept no responsibility for any electrical damage resulting from
improper installation of this product, be that either damage to the vehicle itself or to the installed
device. This device must be installed by a certified technician. This guide has been written for
properly trained technicians; a certain level of skill & knowledge is therefore assumed. Please
reviewtheInstallation Guide carefullybefore beginning any work.
!
Push To Start
PLEASE VISIT www.flash-it.com FOR COMPLETE PRODUCT DETAILS
Audiovox Electronics Corp.
INSTALL GUIDE
flc-al(Dl)-ma2-EN
availablE for: flcaN
MA2
The brand names and logos found in this guide are property of their respective owners. Audiovox Electronics Corp. © 2013
Rev. Date: February 28, 2013
Doc. No.: ##11050##
20130227

INSTALL TYPE SELECTION
MAKE MODEL YEAR INSTALL TYPE
FEATURES
ARM OEM ALARM DISARM OEM ALARM DOOR LOCK DOOR UNLOCK PRIORITY UNLOCK SECURE TAKE OVER DOOR STAT OUTPUT TRUNK STAT OUTPUT HOOD STAT OUTPUT* BRAKE PEDAL STAT OUTPUT E-BRAKE OUTPUT TACHOMETER OUTPUT
MAZDA
6 PTS AT 14 2 • • • • • • • • • • • •
CX-5 PTS AT 13 1 • • • • • • • • • • • •
* Hood status is only available when a factory hood switch is present.
Page 2 of 12 FLC-AL(DL)-MA2-EN 20130227
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2013
ALL IN ONE
Mazda
Doc. No.: ##11050##

COMPONENT LOCATOR
A
D
B
C
Page 3 of 12 FLC-AL(DL)-MA2-EN 20130227
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2013
ALL IN ONE
Mazda
Doc. No.: ##11050##

TYPE 1 - WIRE CROSS REFERENCE CHART
MAKE MODEL YEAR WIRE DESCRIPTION
CONNECTOR
POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR NAME COLOR TYPE
MAZDA
CX-5
PTS
AT
13
12V 0940-103B White 24 pin 12 Yellow (+) Start stop unit, under the steering column B
Brake 0940-103A White 32 pin 02 Red/Blue (+) Start stop unit, under the steering column B
Ignition 0940-103A White 32 pin 17 Violet (+) Start stop unit, under the steering column B
PTS 0940-103A White 32 pin 20 Green/White (-) Start stop unit, under the steering column B
RX 0940-103A White 32 pin 16 White (DATA) Start stop unit, under the steering column B
CanH 0940-103B White 24 pin 07 White/Black (DATA) Start stop unit, under the steering column B
CanL 0940-103B White 24 pin 08 Red/Yellow (DATA) Start stop unit, under the steering column B
Doorlock ~ ~ ~ ~ White/Green (DATA) Driver side running board C
Parking Light 1 ~ White 06 pin 03 Yellow (-) Parking light switch D
Parking Light 2 ~ White 06 pin 04 Green (-) Parking light switch D
Page 4 of 12 FLC-AL(DL)-MA2-EN 20130227
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2013
ALL IN ONE
Mazda
Doc. No.: ##11050##

TYPE 1 - WIRING DIAGRAM - 1 OF 2
Page 5 of 12 FLC-AL(DL)-MA2-EN 20130227
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2013
ALL IN ONE
Mazda
8 7 6 5 4 3 2 110 9
20212223 14 131819
12 11
17 16 1524
2 31 4 65
3 4
86
30
87
87A
85
654321 7 8 9
2
18
3
19
1
17
9
25
10
26
4
20
11
27
8
24
6
22
7
23
5
21
12
28
13
29
14
30
15
31
16
32
78
16
20 17
2
10
12
1N4001
DIODE
12V (+)12V (+)
PARKING LIGHT 1 (-) PARKING LIGHT 2 (-)
DO NOT CONNECT BRAKE
STATUS FROM RS
0940-103A - WHITE
0940-103B - WHITE
VEHICLE SIDE
CONNECTOR SIDE
START STOP UNIT
UNDER STEERING COLUMN
PARKING LIGHT SWITCH
LEFT OF STEERING COLUMN
5-6 LOOPS
BACK SIDE OF KEYFOB
REMOVE VALET KEY
AND BATTERY
WHITE CONNECTOR
VEHICLE SIDE
CONNECTOR SIDE
CANL
CANH
RX
IGNITION (+)
PTS (-)
BRAKE (+)
12V (+)
Doc. No.: ##11050##

TYPE 1 - WIRING DIAGRAM - 2 OF 2
Page 6 of 12 FLC-AL(DL)-MA2-EN 20130227
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2013
ALL IN ONE
Mazda
654321 7 8 9 10
N/A
1N4001
DIODE
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
REQUIRED ->
REQUIRED ->
REQUIRED ->
REQUIRED ->
OPTIONAL ->
OPTIONAL ->
YELLOW/BLACK - DOOR STATUS (-) OUTPUT
YELLOW/BLACK - DOOR STATUS (-) OUTPUT
GWR INPUT - BLUE/WHITE
GWR INPUT - BLUE/WHITE
BROWN/RED - CANH
BROWN/RED - CANH
BLUE/RED (NC)
LOCK/ARM (-) INPUT - GREEN/BLACK
LOCK/ARM (-) INPUT - GREEN/BLACK
WHITE/BLACK - RX VEHICLE SIDE
WHITE/BLACK - RX VEHICLE SIDE
BRAKE STATUS (+) INPUT
BRAKE STATUS (+) INPUT
E-BRAKE STATUS (-) INPUT
E-BRAKE STATUS (-) INPUT
TRUNK STATUS (-) INPUT
TRUNK STATUS (-) INPUT
DOOR STATUS (-) INPUT
DOOR STATUS (-) INPUT
WHITE/RED - RX CONNECTOR SIDE
WHITE/RED - RX CONNECTOR SIDE
- RX CONNECTOR SIDE
WHITE - RX CONNECTOR SIDE
YELLOW/RED - TRUNK STATUS (-) OUTPUT
YELLOW/RED - TRUNK STATUS (-) OUTPUT
YELLOW - DOORLOCK/ALARM (MUX) OUTPUT
YELLOW - DOORLOCK/ALARM (MUX) OUTPUT
BROWN/YELLOW - CANL
BROWN/YELLOW - CANL
ORANGE/BLACK - PTS (-) OUTPUT
ORANGE/BLACK - PTS (-) OUTPUT
ORANGE/WHITE (NC)
ORANGE - BRAKE STATUS (+) OUTPUT
ORANGE - BRAKE STATUS (+) OUTPUT
PINK/BLACK (NC)
PINK/BLACK (NC)
PINK - IGNITION (+) INPUT
PINK - IGNITION (+) INPUT
BLUE/YELLOW (NC)
GREEN/RED (NC)
GREEN/YELLOW (NC)
GREEN/YELLOW (NC)
GRAY/RED - E-BRAKE STATUS (-) OUTPUT
GRAY/RED - E-BRAKE STATUS (-) OUTPUT
GRAY/YELLOW (NC)
GRAY/YELLOW (NC)
(NC) WHITE
(NC) WHITE
GROUND - BLACK
GROUND - BLACK
12V (+) - RED
12V (+) - RED
UNLOCK/DISARM (-) INPUT - BLUE/BLACK
UNLOCK/DISARM (-) INPUT - BLUE/BLACK
(NC) RED/WHITE
(NC) RED/WHITE
(NC) BROWN
(NC) BROWN
PURPLE/YELLOW
(NC) PURPLE/BLACK
(NC) PURPLE/BLACK
(NC) WHITE
(NC) WHITE
STARTER 2 (+) INPUT - BLACK/WHITE
STARTER 2 (+) INPUT - BLACK/WHITE
HOOD STATUS (-) OUTPUT - GREEN
HOOD STATUS (-) OUTPUT - GREEN
TACH (AC) OUTPUT - PURPLE/WHITE
TACH (AC) OUTPUT - PURPLE/WHITE
IGNITION (+) INPUT
IGNITION (+) INPUT
UNLOCK (-) OUTPUTUNLOCK (-) OUTPUT
TACH (AC) INPUT
TACH (AC) INPUT
HOOD STATUS (-) INPUT
HOOD STATUS (-) INPUT
STARTER 2 (+) OUTPUT
STARTER 2 (+) OUTPUT
PARKING LIGHT (-) OUTPUT
PARKING LIGHT (-) OUTPUT
STARTER 1 (+) OUTPUT
STARTER 1 (+) OUTPUT
LOCK (-) OUTPUT
LOCK (-) OUTPUT
12V (+)
12V (+)
GROUND (-)
GROUND (-)
GROUND WHEN RUNNING (-) OUTPUT
GROUND WHEN RUNNING (-) OUTPUT
12V (+) INPUT
12V (+) INPUT
DOORLOCK (22G) (MUX)
DRIVER RUNNING BOARD
CONNECT TO GROUND
ONLY IF VEHICLE
IS EQUIPPED WITH
FACTORY HOOD SWITCH.
NOT REQUIRED IN DATA MODE (1-WAY)
NOT REQUIRED IN DATA MODE (2-WAY)
LEGEND
USE DATA MODE
OR HARDWIRE MODE
DATA MODE
DATA MODE
DRIVER KICK PANEL
REMOTE STARTER
Doc. No.: ##11050##

TYPE 2 - WIRE CROSS REFERENCE CHART
MAKE MODEL YEAR WIRE DESCRIPTION
CONNECTOR
POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR NAME COLOR TYPE
MAZDA
6
PTS
AT
14
12V 0940-103B White 24 pin 12 Yellow (+) Start stop unit, under the steering column B
Brake 0940-103A White 32 pin 02 Red/Blue (+) Start stop unit, under the steering column B
Ignition 0940-103A White 32 pin 17 Violet (+) Start stop unit, under the steering column B
PTS 0940-103A White 32 pin 20 LtGreen/Red (-) Start stop unit, under the steering column B
RX 0940-103A White 32 pin 16 Green (DATA) Start stop unit, under the steering column B
CanH 0940-103B White 24 pin 07 White (DATA) Start stop unit, under the steering column B
CanL 0940-103B White 24 pin 08 Red (DATA) Start stop unit, under the steering column B
Doorlock ~ ~ ~ ~ White/Green (DATA) Driver side running board C
Parking Light 1 ~ White 06 pin 03 Yellow (-) Parking light switch D
Parking Light 2 ~ White 06 pin 04 Green (-) Parking light switch D
Trunk Release 0914-221 White 04 pin 01 Green/Red (-) Trunk release switch ~
Page 7 of 12 FLC-AL(DL)-MA2-EN 20130227
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2013
ALL IN ONE
Mazda
Doc. No.: ##11050##

TYPE 2 - WIRING DIAGRAM - 1 OF 2
Page 8 of 12 FLC-AL(DL)-MA2-EN 20130227
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2013
ALL IN ONE
Mazda
8 7 6 5 4 3 2 110 9
20212223 14 131819
12 11
17 16 1524
2 31 4 65
3 4
86
30
87
87A
85
654321 7 8 9
2
18
3
19
1
17
9
25
10
26
4
20
11
27
8
24
6
22
7
23
5
21
12
28
13
29
14
30
15
31
16
32
78
16
20 17
2
10
12
1N4001
DIODE
12V (+)12V (+)
PARKING LIGHT 1 (-) PARKING LIGHT 2 (-)
DO NOT CONNECT BRAKE
STATUS FROM RS
0940-103A - WHITE
0940-103B - WHITE
VEHICLE SIDE
CONNECTOR SIDE
START STOP UNIT
UNDER STEERING COLUMN
PARKING LIGHT SWITCH
LEFT OF STEERING COLUMN
5-6 LOOPS
BACK SIDE OF KEYFOB
REMOVE VALET KEY
AND BATTERY
WHITE CONNECTOR
VEHICLE SIDE
CONNECTOR SIDE
CANL
CANH
RX
IGNITION (+)
PTS (-)
BRAKE (+)
12V (+)
Doc. No.: ##11050##

TYPE 2 - WIRING DIAGRAM - 2 OF 2
Page 9 of 12 FLC-AL(DL)-MA2-EN 20130227
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2013
ALL IN ONE
Mazda
23 14
654321 7 8 9 10
1
N/A
1N4001
DIODE
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
REQUIRED ->
REQUIRED ->
REQUIRED ->
REQUIRED ->
OPTIONAL ->
OPTIONAL ->
YELLOW/BLACK - DOOR STATUS (-) OUTPUT
YELLOW/BLACK - DOOR STATUS (-) OUTPUT
GWR INPUT - BLUE/WHITE
GWR INPUT - BLUE/WHITE
BROWN/RED - CANH
BROWN/RED - CANH
BLUE/RED (NC)
LOCK/ARM (-) INPUT - GREEN/BLACK
LOCK/ARM (-) INPUT - GREEN/BLACK
WHITE/BLACK - RX VEHICLE SIDE
WHITE/BLACK - RX VEHICLE SIDE
BRAKE STATUS (+) INPUT
BRAKE STATUS (+) INPUT
E-BRAKE STATUS (-) INPUT
E-BRAKE STATUS (-) INPUT
TRUNK STATUS (-) INPUT
TRUNK STATUS (-) INPUT
DOOR STATUS (-) INPUT
DOOR STATUS (-) INPUT
WHITE/RED - RX CONNECTOR SIDE
WHITE/RED - RX CONNECTOR SIDE
- RX CONNECTOR SIDE
WHITE - RX CONNECTOR SIDE
YELLOW/RED - TRUNK STATUS (-) OUTPUT
YELLOW/RED - TRUNK STATUS (-) OUTPUT
YELLOW - DOORLOCK/ALARM (MUX) OUTPUT
YELLOW - DOORLOCK/ALARM (MUX) OUTPUT
BROWN/YELLOW - CANL
BROWN/YELLOW - CANL
ORANGE/BLACK - PTS (-) OUTPUT
ORANGE/BLACK - PTS (-) OUTPUT
ORANGE/WHITE (NC)
ORANGE - BRAKE STATUS (+) OUTPUT
ORANGE - BRAKE STATUS (+) OUTPUT
PINK/BLACK (NC)
PINK/BLACK (NC)
PINK - IGNITION (+) INPUT
PINK - IGNITION (+) INPUT
BLUE/YELLOW (NC)
GREEN/RED (NC)
GREEN/YELLOW (NC)
GREEN/YELLOW (NC)
GRAY/RED - E-BRAKE STATUS (-) OUTPUT
GRAY/RED - E-BRAKE STATUS (-) OUTPUT
GRAY/YELLOW (NC)
GRAY/YELLOW (NC)
(NC) WHITE
(NC) WHITE
GROUND - BLACK
GROUND - BLACK
12V (+) - RED
12V (+) - RED
UNLOCK/DISARM (-) INPUT - BLUE/BLACK
UNLOCK/DISARM (-) INPUT - BLUE/BLACK
(NC) RED/WHITE
(NC) RED/WHITE
(NC) BROWN
(NC) BROWN
PURPLE/YELLOW
(NC) PURPLE/BLACK
(NC) PURPLE/BLACK
(NC) WHITE
(NC) WHITE
STARTER 2 (+) INPUT - BLACK/WHITE
STARTER 2 (+) INPUT - BLACK/WHITE
HOOD STATUS (-) OUTPUT - GREEN
HOOD STATUS (-) OUTPUT - GREEN
TACH (AC) OUTPUT - PURPLE/WHITE
TACH (AC) OUTPUT - PURPLE/WHITE
IGNITION (+) INPUT
IGNITION (+) INPUT
UNLOCK (-) OUTPUTUNLOCK (-) OUTPUT
TACH (AC) INPUT
TACH (AC) INPUT
HOOD STATUS (-) INPUT
HOOD STATUS (-) INPUT
STARTER 2 (+) OUTPUT
STARTER 2 (+) OUTPUT
PARKING LIGHT (-) OUTPUT
PARKING LIGHT (-) OUTPUT
STARTER 1 (+) OUTPUT
STARTER 1 (+) OUTPUT
TRUNK RELEASE (-) OUTPUT
TRUNK RELEASE (-) OUTPUT
LOCK (-) OUTPUT
LOCK (-) OUTPUT
12V (+)
12V (+)
GROUND (-)
GROUND (-)
GROUND WHEN RUNNING (-) OUTPUT
GROUND WHEN RUNNING (-) OUTPUT
12V (+) INPUT
12V (+) INPUT
DOORLOCK (22G) (MUX)
TRUNK RELEASE (-)
DRIVER RUNNING BOARD
CONNECT TO GROUND
ONLY IF VEHICLE
IS EQUIPPED WITH
FACTORY HOOD SWITCH.
NOT REQUIRED IN DATA MODE (1-WAY)
NOT REQUIRED IN DATA MODE (2-WAY)
LEGEND
USE DATA MODE
OR HARDWIRE MODE
DATA MODE
DATA MODE
DRIVER KICK PANEL
REMOTE STARTER
0914-221
AT TRUNK RELEASE BUTTON
Doc. No.: ##11050##

INSTALLATION MODE SELECTION
1Press and release
programming button
to select installation mode.
2Press and hold
programming button
until LED turns solid GREEN
to register selection.
!After registration, follow Factory Reset Procedure to
change installation mode and restart this procedure.
LED fl ashes (1X) once = DATA MODE
LED fl ashes (2X) twice = STANDARD HARDWIRE MODE
MODULE PROGRAMMING PROCEDURE - PUSH TO START
4Module Programming
Procedure completed.
1DO NOT PRESS BRAKE PEDAL
Push start button twice [2x] to
ON position.
x2
3DO NOT PRESS BRAKE PEDAL
Push start button once [1x] to
OFF position.
x1

2Wait, LED will turn solid GREEN
for 2 seconds.
Page 10 of 12 FLC-AL(DL)-MA2-EN 20130227
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2013
ALL IN ONE
Mazda
Doc. No.: ##11050##

XX-XX PAGE X-XCLASSIC PAGE 1-1
LED STATUS
DIAGNOSTICS
DURING PROGRAMMING DURING REMOTE START WITH IGNITION OFF
Flashing RED Missing/wrong information from
fi rmware or vehicle Incorrectly programmed Incorrectly programmed or connected
Solid RED Waiting for more vehicle information Incorrectly programmed Not programmed waiting for more
vehicle information
Flashing GREEN Additional steps required to complete
programming
Correctly programmed and
operational
False ground when running status
from remote starter
Solid GREEN then OFF Correctly programmed Reset in progress Reset in progress
OFF No activity or already programmed Invalid ground when running status
from remote starter
At rest and ready for a remote start
sequence
MODULE DIAGNOSTICS
FACTORY RESET PROCEDURE
7Repeat programming procedure.
!Failure to follow procedure may result with a DTC or a
CHECK ENGINE error message.
1DISCONNECT all connectors
from module EXCEPT the black
4-PIN standard or optional data
connector.





6RECONNECT all connectors.


 
2DISCONNECT black 4-PIN
standard or optional data
connector.

4When LED fl ashes red,
RELEASE programming button.
5LED will turn solid red for 2
seconds.
RESET COMPLETED.
3PRESS AND HOLD programming
button while connecting either
4-PIN standard or optional data
connector.
IDENTIFY VEHICLE YEAR
1Locate the Vehicle Identifi cation
Number (VIN) and identify the
10th character.
2Match the VIN’s 10th character
to its corresponding year.
L > 1990 S > 1995 Y > 2000 5 > 2005 A > 2010
M > 1991 T > 1996 1 > 2001 6 > 2006 B > 2011
N > 1992 V > 1997 2 > 2002 7 > 2007 C > 2012
P > 1993 W > 1998 3 > 2003 8 > 2008 D > 2013
R > 1994 X > 1999 4 > 2004 9 > 2009 E > 2014
4 Y 1 N53 A 5 T A L 8 D 5 R 0 X

Page 11 of 12 FLC-AL(DL)-MA2-EN 20130227
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2013
ALL IN ONE
Mazda
Doc. No.: ##11050##

NOTICE
WARNING: READ BEFORE REMOTE STARTING THE VEHICLE
IMPORTANT
I All vehicle doors must be closed and locked prior to remote start sequence. Failure to comply will result in remote starter malfunction.
PUSH TO START VEHICLE TAKE OVER PROCEDURE - TO THE VEHICLE OWNER
!Failure to follow procedure within time restriction will
result in vehicle engine shutdown.
3Push to Start vehicle take over
procedure completed.
2TIME RESTRICTI
 N
Within 45 SECONDS from
previous step:
Open vehicle door.
Enter vehicle.
Close vehicle door.
Press and release BRAKE pedal.
NOTE
I All vehicle doors must be closed and locked prior to remote
start sequence.
1Press UNLOCK on after-market
remote.
TIME RESTRICTI
 N COMING UP !
Page 12 of 12 FLC-AL(DL)-MA2-EN 20130227
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2013
ALL IN ONE
Mazda
Doc. No.: ##11050##
