FlashPoint FPBGMBD16 User manual

Vertical
Battery Grip
for the Nikon D750 FPBGMBD16

Part Names
Contact cap
AE-L/AF-L button
Main command dial
Multi selector
Mounting screw
Battery-
chamber latch
Battery-
chamber cover
Power/
signal contacts
Attachment
wheel
DC cord connector cover
Battery chamber
Holder for
contact cover

Control lock
Shutter-release button
Sub-command dial
Tripod socket
Li-ion battery holder
for EN-EL15 batteries
AA holder for AA batteries
IR receiver (For specied
models only)
IR receiver indicator

Attaching to the Camera
Please turn o the switch
on the camera and ensure
the control lock on the grip
is in the "L" position before
attaching.
1.
To prevent loss, place the
camera contact cover in
the contact cover holder
on the battery grip .
4. Align the attachment
screw with the camera's
tripod socket.
5. Turn the attachment
wheel to tighten
securely in the direction
of the arrow. If there is
some space left, please
reattach the battery grip.
6.
Remove the contact cap
from the battery grip.
2. The contacts for the
battery grip are on the
bottom of the camera
where they are protected
by a contact cover. Remove
the contacts cover before
mounting the grip.
3.
on the battery grip
on the camera

Install Batteries
For AA batteries: Place six
AA batteries of the same
type in the AA battery
holder, while ensuring
that they are in the correct
orientation. Mixing old
and new batteries may
cause accident.
4.
Ensure that the power is
turned o on the camera
and the Control Lock on
the battery grip is in the
"L" position. Turn the
battery-chamber latch
counter-clockwise to open
the battery chamber door.
1.
Insert the battery holder
into the grip. Close the
battery chamber and then
turn the latch clockwise to
lock. Turn on the camera
and switch the control lock
to be on "•" position and
then check the battery
level in the control panel
or viewnder.
5. To use the DC adapter (sold
separately): insert the
adapter into the EN-EL15
battery holder in the same
manner as a regular battery.
Open the latch and pass the
cable through.
6.
Remove the battery holder
from the battery grip. The
EN-EL15 Li-ion battery
holder comes preinstalled
when shipped .
2. For EN-EL15 Li-ion batteries:
Matching the indentations
on the battery with the
EN-EL15 holder, press the
battery down and slide it in
the direction of the arrow
until the power terminals
click into place.
3.

Power Sources
Fit Cameras
Replacement For
Operating Temperature
Dimensions
Weight
FPBGMBD16
1 x EN-EL15 or 6 x AA batteries
(LR6, HR6, FR6)
NIKON D750
Approx. 142.2x51.3x77.9 mm
About 220g(include EN-EL15 battery holder)
MB-D16
Type
Specications Sheet
0~40°C(32~104°F)
