Fleetwood 1994 Bounder User manual

/
BY FlEETWOOD®
1994

"
IMPORTANT NOTICE
Our forest product suppliers have advised that urea-formaldehyde is used
in the productionofparticleboard, hardwoodplywood orpaneling which they
supply us and which we utilize in our finishE;!d product.These suppliers have
requested that we communicate this to our customers,
Foryourinformation,
we arereproducing samplesof statementswhich have
been provided to us by our suppliers,
WARNING: THIS PRODUCT IS MANUFACTURED WITH UREA-FORM-
ALDEHYDE RESIN, FORMALDEHYDEVAPOR MAY IN SOME PEOPLE
CAUSE HEADACHES, EYE, NOSE AND THROAT IRRITATION, AND
AGGRAVATIONOFALLERGIESAND RESPIRATORY PROBLEMS, SUCH
AS ASTHMA. PROPER VENTILATION SHOULD REDUCE THE RISK OF
SUCH PROBLEMS,
Champion International Corporation
WARNING: IRRITANT: THIS PRODUCT CONTAINS AUREA-FORMAL-
DEHYDE RESIN AND MAY RELEASE FORMALDEHYDE: VAPORS IN
LOW CONCENTRATIONS, FORMALDEHYDE CAN BE IRRITATING TO
THE EYES AND UPPER RESPIRATORY SYSTEM OF ESPECIALLY
SUSCEPTIBLE PERSONS SUCH AS THOSE WITH ALLERGIES OR
RESPIRATORY AILMENTS. USE WITH ADEQUATE VENTILATION. IF
SYMPTOMS DEVELOP, CONSULT YOUR PHYSICIAN,
Georgia-Pacific Corporation
WARNING: THIS PRODUCT IS MANUFACTURED WITH A UREA-
FORMALDEHYDE RESIN ANDWILL RELEASE SMALL QUANTITIES OF
FORMALDEHYDE.FORMALDEHYDE LEVELS IN THE INDOORAIRCAN
CAUSE TEMPORARY EYE At:JD RESPIRATORY IRRITATION, AND MAY
AGGRAVATE RESPIRATORY CONDITIONS OR ALL~RGIES. VENTILA-
TION WILL REDUCE INDOOR FORMALDEHYDE LEVELS,
Weyerhaeuser Company
Ventilation is important in maintaining a comfortable environment and we
direct your attention tei the discussion of ventilation contained in your
Owner's Manual.

FOR MOTOR HOMES MANUFACTURED BY SUBSIDIARIES OF FLEETWOOD ENTERPRISES, INC.
SOLD IN THE UNITED STATES AND CANADA
COVERAGE PROVIDED
Your new molor home, including the structure, plumbing, heating and electrical systems, and all appliances and equipment installed by the manufacturer,
is warranted
under normal use to be free from manufacturing defects in male rial or workmanship.
The warranty extends to the first retail purchaser and his transferee(s) and begins on the dale of original retail delivery or the dale the motor home is
first placed into service as a rental, commercial or demonstrator unit (whichever occurs litSI).
The warranty extends for a period of one year from such
dale or until the unil has received 15,000 total miles of use as determined by the mileage shown on the odometer (whichever occurs first). Written notice
of
delects must be given to the selling dealer or the manufacturer not laterthan ten (iO) days after the expiration 01 the warranty period.
OWNER'S OBLIGATIONS
The owner is responsible for normal maintenance as described in the Owner's Manual; however. minor adjustments (such as adjustments to the interior
or exterior doors. LP·regulator pressure. cabinet latches. lV antenna ~ontrot, etc.) will be performed by the Qealer du~ng the first 90 days of warranty
coverage. Thereafter, such adjustments are the responsibility of the owner as normal maintenance unless required as a direct result of repair or replace·
ment of a defective part under this warranty.
II a problem occurs which the owner believes is covered by this warranty, the owner shall contact the selling dealer. or other authorized dealer, giving
that
dealer sufficient information to resolve the matter. The owner shall deliver the motor home to the dealer or manufacturing plant location for
warranty service.
DEALER'S OBLIGATIONS
By agreement with the manufacturer, the dealer is obligated to maintain the motor home prior to retail sate, to perform a detailed predelivery inspection
and to repair or replace ~.ny parts necessary to correct defects in material or workmanship.
WHEN THE DEALER DOES NOT RESOLVE THE PROBLEM
lithe dealer is unable or unwilling to resolve a problem which the owner is convir"]Ced is covered by the warranty, he should conlactlhe manufacturing
plant at the
address listed below and provide the manufactUrer with ~ description in writing of the problem an~ attempts made to resolve It.
MANUFACTURING PLANT OBLIGATIONS
Upon receipl of notice of a claim, where the dealer was unable or unwilling to resolve the problem, the manufacturing plant will repair or replace any
parts necessary
to correct defects in material or workmanship, or will take other appropriate action as may be required.
,
WHEN THE MANUFACTURING PLANT DOES NOT RESOLVE THE PROBLEM
If the representatives of the manufacturing plant are unable to resolve the problem and the owner is convinced that It is covered by this warranty, the
owner should call the toll·free number lisled below to describe the problem and the attempts made to resolve it.
WHAT IS NOT COVERED BY THE EXPRESS WARRANTY
THIS WARRANTY DOES NOT COVER:
1. THE AUTOMOTIVE SYSTEM (INCLUDING THE CHASSIS AND DRIVE TRAIN), TIRES AND BATTERIES, WHICH ARE COVERED BY THE
SEPARATE WARRANTIES OF THE RESPECTIVE MANUFACTURERS OF THESE COMPONENTS.
2. DEFECTS CAUSED BY OR RELATED TO:
A. ABUSE. MISUSE. NEGLIGENCE, OR ACCIDENT;
B. FAILURE TO COMPLY WITH INSTRUCTIONS CONTAINED IN THE OWNER'S MANUAL;
C. ALTERATION OR MODIFICATION OF THE MOTOR HOME;
D. ENVIRONMENTAL CONPITIONS (SALT. HAIL. CHEMICALS IN THE ATMOSPHERE, ETC.)
3. NORMAL DETERIORATION DUE TO WEAR OR EXPOSURE. SUCH AS FADING OF FABRICS OR DRAPES, CARPET WEAR. ETC.
4. NORMAL MAINTENANCE AND SERVICE ITEMS, SUCH AS LIGHTBULBS. FUSES, WIPER BLADES, LUBRICANTS. ETC.
5. MOTOR HOMES ON WHICH THE ODOMETER READING HAS BEEN' ALTERED.
6. TRANSPORTATION TO AND FROM DEALER OR MANUFACTURING PLANT LOCATION. LOSS OF TIME, INCONVENIENCE, COMMERCIAL
LOSS. LOSS OF USE. TOWING CHARGES. BUS FARES. VEHICLE RENTAL. INCIDENTAL CHARGES SUCH AS TELEPHONE CALLS OR
HOTEL BILLS. OR OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES.
SOME STATES DO NOT ALLOW THE EX9LUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATION
OR EXCLUSION MAY NOT APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC L.EGAL. RtGHTS, AND YOU MAY AL.SO HAVE OTHER RIGHTS WHICH VARY FR9M STATE TO STATE.
THEMANUFACTURER IS NOTRESPONSIBL.EFORANY UNOERT AKtNG, REPRESENTATION OR WARRANTY MADE BY ANy DEAL.ER OR OTHER PERSON BEYONDTHOSE
EXPRESSL.Y SeT
FOATH IN THIS WARRANTY.
Brand Name: _________________ _
FOR SERVICE ASSISTANCE:
Fleetwood Parts & Service
P.O. Box 5700
Riverside, CA 92507
(800) 854·4755
Fleetwood Parts & Service
P.O. Box 1007
Decatur, IN 46733
(800) 854·4755
Model:
___________ _
Serial No.
-----
Fleelwood Parts & Service
P.O. Box 106
Paxinos. PA 17860
(800) 854·4755
CORPORATE HEADQUARTERS:
Motor Home Division
Fleetwood Enterprises, Inc.
P.O. Box 7638
Riverside,
CA 92513·7638
[phone]
.,

TABLE OF CONTENTS
LP Gas System .......................... ,. ............................29 Windows, Door, Vents & Locks
... .......................37
LP Gas Safety Precautions .................................29 Rubber Roof System.........................................
37
System Components ...........................................30 Cleaning ............................................................
37
Hoses ................................................................. 30
Care ...................................................................38
LP Gas Regulator .............................................. 30
Sealant Renewal...............................................38
Using LP Gas At Low Temperatures ................... 30
Door, Window, Roof& Molding Resealing,........38
Filling LP Gas Tanks ..................:........................ 31
Interior ................................................:................38
LP Gas System Leak Checks .............................. 31
Fabrics .......................:.......................................38
LP Leak Detector .................................................32 Cutting Block......................................................
38
Lighting LP Gas Appliances .....:..........................32 Laminate Top Care ............................................
39
Appliances ..............................................................33
Water Heater .......................................................
33
Refrigerator.......................................................... 33
Furnace ............................................................... 33
Range...................................................................33
Walls & Ceiling Panels.............................,.........39
Fiberglass Bathtub & Plastic ShowerStall.........39
Floors & Carpeting .............................................39
Engine Access ...................................................39
Maintenance Checklist ........................................39
Range Exhaust Hood ...........................................34 Molor Home
Slorage ............................................. .41
Air Conditioner .....................................................34 Storage Checklists...............................................
41
Dual Air Conditioners .........................................34 Short·Term Storage ...........................................
41
Entertainment Equipment ....................................34 Long·Term Storage ............................................42
120-Volt VCR .....................................................34 Winterization ........................................................42
120112- Volt TV ................................................... 34 Water System Winterizing ..................................42
TV Antenna..........................................................34 Reactivating The Motor Home After Storage .......43
TV and Radio Interierence ..................................34 Maintenance Chart ................................................
45
Miscellaneous Appliances ...................................35
Maintenance ............................................................37
Exterior ................................................................37
Stains .................................................................37

TABLE OF CONTENTS
WARRANTY Sun Visors ..........................................................16
NOTICES AND WARNINGS Woven Wood Shades ..........................................16
Introduction ..............................................................1 Storage ................................................................
16
Exterior Compartments .....:................................ 16
Warranties .............................................................1 Interior Storage ..................................................16
Warrf)nty Service ...................................................2 Interior & Furnishings ............................., ..........
17
Reporting Safety Defects.......................................2 Dmette ConversIOn
.. .......................................... 17
Owner's Information Package ...............................3 Sofa/Lounge Conversion ...................................17
Chassis & Vehicle Identification Information .........3 Folding Doors/Dividers.......................................17
Driver's Controls ......................................................4 Interior Lighting ..................................................17
Overhead Vents ................................................. 17
On The Road .............................................................7 Monitor Panel ......................................................
17
Motor Home Loading .............................................7
Carrying Capacity ................................................7
Weighing Your Loaded
MotorHome ....................7
Loading Tips .................................:......................
8
Tires ., .........................................................:...........9
Tire Inflation .........................................................9
Tire Replacement.................................................9
If You Get a Flat Tire ............................................9
Spare Tire Carrier .. ..............................................9
Changing a Flat Tire .......................................... .. 9
ToWing A Vehicle ....................,..............................9
Seats And Seat Beits...........................................10
Combination Lap & Shoulder Belts ....................10
Seat Belts Maintenance .....................................10
Safety Restraints for Children ............................ 11
Safety Belts for Children .................................... 11
SafetySeats for Children ................................: .. 11 .
Driving & Parking ................................................. 11
Fuel & Fuel Systems ...........................................12
Fuel Fill .............................................................. 12
Fuel Types & Vapor Lock...................................12
Effects of Long-Term Occupancy ........................18
Ventilation & Controlling Condensation ....:........ 18
Fire Safety ........................................................... 18
Fire Safety Precautions......................................19
Smoke Detector ................................................. 19
Plumbing Systems ................................................. 21
Fresll Water System .. ,...,..................................... 21
City Water Connection ....................................... 21
Filling The Water Tank ........................................ 21
Water Pump ....................................................... 22
Water Filter ..................,.....................................22
Troubleshooting The Fresh Water System ........ 22
Leaks .................................................................22
Sanitizing The Fresh Water System ..................22
Exterior Shower .................................................23
Water Filter System ...........................................23
Waste Water System ...........................................23
TOilet ..................................................................23
Draining The Holding Tanks ..............................23
Holding Tank Care .............................................24
General Chassis Topics ...................................... 13
Electrical Systems .................................................25
Variable Speed Engine Fan ...............................13 Chassis Electrical System ...................................25
Exhaust System Heat ........................................13 Chassis Bulbs & Fuses ......................................25
Carbon Monoxide Safety Precautions .................13 12-Volt Coach System .........................................25
Carbon Monoxide Detector................................ 13 Battery Inspection & Care ..................................25
Emergency Towing..............................................14 Battery Charging ................................................25
Attaching Accessories To Your Motor Homes ..... 14 Solar Panel ..........................................................26
Living With Your Motor Home ...............................15
Hydraulic Leveling System ..................................15
Manual Entry Steps .............................................15
Power Entry Steps ............................................... 15
Entry Assist Handle ............................................. 15
Entry Doors & Screens ........................................15
WIndows ..........................,...................................15
Emergency Exi' Window ....................................15
Side Slider Windows ..........................................15
Selecting A Replacement Battery ......................26
120-Volt System ..................................................26
Power Converter................................................26
Ground Fault Interrupter ....................................26
Coach Fuses & Circuit Breakers ......................... 27
Generator ............................................................27
Generator Fuel Supply.......................................27
GeneratorOperation ..........................................27
Generator Operating Safety Precautions ...........27
Electrical System Wiring ......................................28

Welcome to the recreational vehicle life-style and the
growing family of motor home owners. We sincerely
thank you for choosing a Fleetwood motor home!
Your motor home has been designed to provide you with
years of carefree, pleasant traveling and vacationing.
Your motor home conforms with, or exceeds, the Ameri-
can National Standards Institute A119.2, CSA Standard
Z-249
(units built for C&nada), and applicable Federal
MotorVehicie SafetyStandards.These standardsestab-
lish the plumbing, heating, electrical and other require-
ments for quality and safety. Compliance with ANSI and
CSA standards is indicated by the seal attached just
outside
the entry door.
Like all finely crafted equipment, your motor home will
require care and regular maintenance
In order to deliver
maximum value and periormance. The dealer will give
you basic operating and' maintenance instructions;
however,
supplement this by reading all instructional
material furnished with the motor home in the Owner's
Information Package and Chassis Operator's Manual.
This Informationoutlines importantareas of maintenance
and provides amaintenanceschedulefor you tofollow for
safe, trouble free service from your motor home. Study
these instructions carefully before you operate the motor
home for the firsttime. A good working knowledge of your.
motorhomeand howtocare for
it will helpyouenjoymany
miles and years
of recreational living.
N()TE: This manualdescribes manyfeatures of
your motorhome and includesinstructions forits
safe use. This manual, including photographs
and illustrations, is of a general nature only.
Some equipment and features described or
shown in this manual may be optional. Because
of tfie continuous program of product improve-
ment conductedbyFleetwood, it is possible that
recent product changes
may not be included.
The instructions included in this manual are
intended
as a guide, and in no way extend the
responsibilities
of the manufacturing subsidiary,
parent company or affiliates beyond the stan-
dardwritten warranty as presented in thismanual.
In this manual, statements preceded by the following
words are of special significance:
"WARNING" means that there is the possibility
of personal injury to yourself and others.
1
INTRODUCTION
"CAUTION" means that there is the possibility
of damage to the vehicle.
"NOTE" indicates points of particularinterestfor
more efficient and convenient operation. ,
Please payclose attention to these statementswhile you
read this manual. .
NOTE: This product is designed for recrea-
tionaluse and shott term occupancyonly. Itis not
designed
or intended to be used as permanent
housing. Use
of this product for long term or
permanent occupancy may lead to premature
deterioration
of interiorfinishes, fabrics, carpet-
, ing, drapes,
and appliances and fixtures. Dam-
age or deterioration due to long term occupancy
is
not considered normal, and will under the
terms
of the warranty constitute misuse, abuse,
or neglect, thereby reducing your warrantypro-
tection. Before conSidering this motor home for
long term occupancy, consult the relevant sec-
tions in this manual.
If you have any questions regarding operation, mainte-
nance, or service, please contact your dealer immedi-
atelyso he canassistyou.Your dealer'sService or Sales
Department will handle any normal problems which
might occur.
WARRANTIES
Your motor home is covered by one of the most compre-
hensive warranty programs in the RV industry. Please
refertothewarranty in thefront
ofthis manual. Itexplains
your rights and obligations, as well as the rights and
obligations of the dealer and manufacturer. Please read
this section carefully.
You will be belter informed in case
you have a warranty-related problem, and your dealer
will be Qetterabletogetyouonthe road again. Ifyouhave
any questions aboutthe warranty
or what it does ordoes
not cover, please contact your dealer.
The materials in
your Owner's Information Packagecon-
tain warranty information and operating instructions on
the various appliances
and' components in your motor
home.Warranty registration cardsforthese itemsshould
befilled outandmailed as soonas possibleafteryoutake
delivery of yourmotorhome.
If you do not haveoperating
instructionsforaparticularappliance, contactyourdealer.

2
You will automatically receive an Ownercare Card ap-
proximately 3-4 weeks after delivery of your new motor
home.This plastic card is imprinted with your name, the
motor home serial number, and manufacturing subsidi-
ary location. If your motor home ever needs warranty
service, present this card to the dealer.
The motor home has been thoroughly inspected before
shipment. Your dealer is responsible for performing a
complete predelivery inspection of the chassis and all
motor home components as specified in the predelivery
checklists supplied
by the motor home and chassis
manufacturers. You
should receive a copy of these
completed checklists from your dealer when your
motor home is delivered to you.
As a part of the predelivery inspection procedure, the
dealer is responsible for road testing the motor home,
notingandcorrecting anysteering problemsbefore deliv-
ery. FLEETWOOD AND ITS SUBSIDIARIESWILL NOT
BE RESPONSIBLE FOR FRONT END ALIGNMENT
AFTER TI:IIS PREDELIVERY INSPECTION IS DONE.
You should return your motor home to the selling dealer
for warranty service. If this is not possible, you may
contact any other authorized Fleetwood motor home
dealer.,The service department at any of the locations
listed attheback ofthis manualcan helpyou find a dealer
in your area.
If, for some reason, a problem is not handled to your
satisfaction:
1. Discuss any warranty-related problems directly·
with the manager and/or owner of the dealer-
ship, giving them an opportunity to help the
service department resolve the matterfor you.
2. If a problem arises that has not been resolved to
yoursatisfaction
by yourlocal dealer, contactthe
manufacturing subsidiary service facility. The
locations are listed
in this manual. Please con-
tact the one nearest you.
3. We sincerely believe that your deal.er and the
factory representative will be able to solve any
problem which might arise. If their combined
efforts are not satisfactory, please send a letter
describing the circumstances to:
Fleetwood Enterprises, Inc.
Motor Home Division
P.O. Box 7638 Riverside, CA 92513-7638
Please include the brand name and serial num-
ber of your motor home. The serial number is
located
on the identification tag next to the entry
door.
4. If you wish to call for assistance, please use
this toll-free telephone number:
(800) 854·4755
There may be times when your motor home will need
repairs or parts while you are
on the road. If Y04r motor
home is repaired by a non-authorized repairfacility (non-
Fleetwood dealer), be sure to save receipts and espe-
cially anypartsthat are replaced.These parts will usually
have to be returned to your dealer before you can be
reimbursed for their cost.
WARRANTY SERVICE
If you need service or warranty information, please see
the booklets and other documents included
in your
Owner's Information Package.When contacting any of
the equipment manufacturers, always have the model
and serial numbers available. Appliance identification
numbers will be found on tags
or plates attached to the
app.liance.
Chassis component (engine, transmission, axles, etc.)
identification numbers will be located
in the manuals
inc.luded with your motor home.
REPORTING SAFETY DEFECTS
If you believe that your vehicle has a defectwhich could
cause a crash or could cause injury ordeath, you should
immediately inform the National Highway Traffic Safety
Administration (NHTSA) in addition to notifying Fleet-
wood Enterprises Consumer Affairs Department.
If NHTSA receives similar complaints, it may open an
investigation, and if it finds that a safety defect exists
in a
group
of vehicles, It may order a recall and remedy
campaign. However, NHTSA cannot become involved
in
individual problems between you, your dealer or
Fleetwood's manufacturing subsidiary.
To contact NHTSA, You may either call the Auto Safety
Hotlinetoll-free at 1-800-424-9393(or366-0123inWash-
ington, D.C.) orwrite to:
.NHTSA
U.S.
Department of Transportation
Washington, DC 20590_
You can also obtain other information about motor ve-
hicle safety.from the. Hotline.

OWNER'S INFORMATION PACKAGE
This package contains valuable documents about your
motorhomeanditsequipmentand systems.ThisOwner's
Manual is in the package. Since this manual does not
cover every possible detail of equipment and options
installedonor in yourmotorhome, there arebooklets and
instructional material in the package that will help you
safely operate, maintain and troubleshoot those items.
Be sure you read all this information and understand the
safety and operating instructions included
in the pack-
age. Additionally, you must fOllow all maintenance in-
structions to insure full warranty coverage. If you ever
decide to sell or trade your motor home, be sure the new
owner gets all the material
in this package ..
CHASSIS AND
VEHICLE IDENTIFICATION
Several numbers are used to identify the vehicle and
components used on the vehicle. The V.I.N. or Vehicle
Identification Number is the legal identification of the
completed vehicle and is the number of the vehicle
registralion. The V.I.N. is found on the Federal certifica-
tion tag attached to the interior left sidewall of the motor
home drivercompartment. Refertothis information whim
ordering,parts from the chassis manufacturer orchassis
dealerservice center.The Fleetwood Identification Num-
ber (F.I.N.) is located on the tag just outside the main
entry door or on the outside left front side of the motor
home. Use this numberwhen ordering partsthrough your
Fleetwood dealer or Service Center.
FEDERAL CERTIFICATION TAG
MANUFACTURED BY:
DATE OF MFR:
INCOMPLETE VEHICLE MFD. BY:
DATE OF INC. VEH. MFR:
GROSS VEHICLE WEIGHT RATE:
GAWR FRONT
WITH:
TIRES AT:
GAWR INTERMEDIATE
WITH:
TIRES AT:
GAWR FRONT
WITH:
TIRES AT:
RIMS
PSI COLD SINGLE
RIMS
PSI COLD SINGLE
RIMS
PSI COLD SINGLE
This vehicle conforms to all applicable Federal Motor Vehicle
Safety Standards in effect in:
r- - VEH. IDE NT. NO.:
TYPE VEHICLE: MUL TI·PURPOSE PASSENGER VEHICLE
The tires Of! this unit may be different from those
shown abov~. Check tire sidewalls for maximum
inflation pressures.
Replacement tires must be rated not less than the
axle capacity (GAWR).
Located on the left interior sidewall of the motor
. home driver compartment.
-V.I.N. (Vehicle Identification No.)
FLEErvVOOD.
MOTOR HOMES
OF INC.
PLAN APPROVAL NO.
-F.LN.
MFD. 10. NO. MODEL
DATE OF MFA. MO: YR:
Located on the left of the main entry
door
or on exterior left front side of the
motorhome.
'-- F.I.N. (Fleetwood Identification No.)
j

G
G
II
®
~
QY'®
,
0
~
®
I--a:
ZUJ
.00
QQ
(JZ
(/)~
G
-0
ffim
>
C)C2)
-
a:
©
c

,
BOUNDER
1. Auxiliary Start Switch
The Auxiliary Start System permits using the coach battery (see "ELECTRI-
CAL SYSTEM"chapter) to start the motorhome engine if thechassis battery
is discharged.
Simultaneouslypush button and turn ignition
key. Releasewhen engine starts.
If both the chassis and coach batteries are dead, the engine will not crank.
Sufficient cranking charge may be restored tothe coach batteries by plugging
in to an external 11 OV AC electrical source or by running the generator.
The Auxiliary StartSystem has noeffect onthe vehicle exceptto aid
in starting
the motor home engine. If the vehicle alternator is operating properly, the
batteries will be recharged while driving (see "ELECTRICAL SYSTEM"
chapter).
NOTE: Ifextended normaldriving does not recharge the batteries, see an
authorized Fleetwood motorhome service center.
2. Headlight Switch
3. Windshield WiperlWasher (some chassis)
2·SpeedWindshieldWiperlWasher with Delay· Turn knob clockwise for wiper
action.
OFF· No wiper action.
1st
notch· Wiperdelay ON.Turn outerknob clockwisefor longerdelaybetween
wiper strokes.
2nd notch -Slow wiping action.
3rd notch -Fast wiping action.
To WASH, press inner knob, then release. One press of washer knob cycles
wipers once.The washer nozzles are located on the wiper arms close to the
wiper blades and move with the blades to provide continuous washer
coverage.
4. Instrument Cluster
Consult chassis operator's manual for details on instruments.
6. Radio/Cassette Player
7. Heater/Air Conditioner Controls
Temperature Control Lever- Usedtoadjuslthetemperatureofthedelivered air.
Move lever to the left for cooler, and to the right for warmer.
-.
Fan Speed Switch -Turns fan on and off and adjusts speed.
Air Intake Button (RECIRC) -Selects source of intake air. When the button is
pressed
in (RECIRC), interior air is recirculated through the system. When
button isout, airfrom outside tha vehicleis drawn through the system. Normally,
set the button outto circulatefresh airfrom outside.The RECIRC mode maybe
used when you desire faster cooling or heating, or if outside air is unusually
dusty or odorous.
Air Flow Control Buttons -Selects outlet for the delivered air.
VENT· Air is delivered from theadjustable dash mounted outlets.Vent airwill be
either heated
or cooled depending on position of the temperature lever.
B/L -Bi·level. Air is delivered from both the dash and floor outlets.
FLOOR· Air is delivered Irom floor outlets, with SOme directed tothe windshield
to prevent fogging.
DEF -Air is delivered to the windshield from the top dash outlets. Set fan switch
to
HI and temperature lever to far right for maximum defrosting.
Air Conditioning On-Off Button -Turns AlC compressor on and off. When air
conditioning is desired, press this button
in and set fan switch to any position
except OFF.
AlC Indicator Light will light when the AlC button is on. In the defrost (DEF)
mode, the compressor will automatically be engaged regardless of the button
position.
8. Generator Hour Meter (Optional)
9. Generator Start Switch (Optional)
10. Entry Step Switch
11. Cigarette Lig hter
12. Hood Light Switch
13. Radio Mode Switch
Switches power to the radio between the chassis battery and the coach
battery.
.,

MOTOR HOME LOADING
Your motor home chassis is designed to carry a certain
maximumload. This load includes everything; the weight
of the motor home itself, all occupants and their belong-
ings, fuel, fresh water, waste waterand anything else that
may be in or attached to the motor home.
The
ma;imum loadforwhich the motorhome is designed
is called the GROSS VEHICLE WEIGHT RATING
(GVWR). Modifications to your motor home, i.e., chang-
ing tires or spring load capacities, will not in any way
increase this rating or the axle ratings.
Anothercrilicalweightfactoristhe GROSSAXLEWEIGHT
RATING (GAWR).This
is the maximum weight a specific
axle is designed to carry. Each axle has its own GAWR.
The GAWR's do not necessarily add up to the GVWR.
The GVWR and the GAWR for your motor home are
shown on the Federal certification tag located on the left
interior sidewall of the driver compartment.
Other important weight factors arethe TRAILER HITCH
RATING and the GROSS COMBINED WEIGHT
RAT·
ING (GCWR). The trailer hitch rating is the maxiumum
load the hitch and motor home structure is designed to
accomodate. Changes to the hitch will not increase this
rating. The GCWR is the maximum weight of the loaded'
motorhome andthe loadedtowed vehicle. These ratings
are shown on the wardrobe doortag.
WARNING
DO NOT EXCEEDTHE RATED LOAD OFTHE
MOTOR HOME, OR THE RATED LOAD OF
ANY AXLE. EXCEEDING THE GVWR, GAWR
OR GCWR OF '(OUR MOTOR HOME WILL
REDUCE YOUR WARRANTY PROTECTION,
CAN CAUSE UNDESIRABLE HANDLING
CHARACTERISTICS AND MAY CREATE A
SAFETY HAZARD.
In addition to knowingtheoverallweightthatcanbesafely
loaded
or attached to the motor home, you must know
how to dislribute the weight so that correct amounts of
weight are placed on the axles. The allowable carrying
capacityof
Ihemotorhomeisfoundbyweighingthemotor
homeempty, andsubtractingthisweightfromthe GVWR.
ON THE ROAD
Carrying Capacity
During the design and development of Fleetwood motor
homes, the number and size of storage compartments,
the liquid tank capacities and number of belted seating
positions are optimized forvalue and convenience. If you
fill all liquidtankstocapacity, fill all storage comjJartments
and cupboards to maximum volume and fill all available
seatingpositions with passengers, the motorhomewill be
overloaded.
You' are responsible for analyzing the conditions under
which the motor home
Will be used for each trip. The
numberof passengers and placement of cargo will affect
the amount of water and cargo that you can carry (see
"Loading Tips").
NOTE: Carrying capacities of your motor home
are specified on a label affixed to the inside
of a
wardrobe door. The label includes aI/ factory in-
stal/edoptions. Ifotherequipmentsuchasleveling
jacks, awnings, roofpods, etc., are instal/ed after
the motorhome leaves the factory, the weight
of
these items must be subtracted from the total of
the passengerand cargo carrying capacities.
Weighing Your Loaded Motor Home
Refer to your local telephone directory to find a public
weigh station. The following weighing procedures will
help you determine whether your loaded motor home
(complete with cargo, fluids, passengers, driver and
towedvehicle)
is within GAWR,GVWRandGCWRlimits.
When you arrive at a weigh station, the attendant will
guide you through the correct positioning of the motor
home on the scales.
1.Centerthefront wheelsonthe scaleandtakeareading.
This is the front Gross Axle Weight (Reading
1).

2. Center the vehicle (all axles) on the scale and take a
reading. This is the Gross Vehicle Weight (Reading 2).
3. Center both rearaxles on the scale and take a reading.
This reading is the rear Gross Axle Weight for motor
homes with tag axles (Reading 3).
4. Centerthetowed vehicle on thescaleand take a reading
(Reading 4).
.
MOTOR HOME READINGS
Compare the readings taken on the scales to the weight
ratings on the Federal certification tag and wardrobe door
tag. Fill
in the chart at the bottom of the page to aid in
comparing weights.
Ifanyreadings are higherthan the rating, adjustorremove
the load.
EXCEEDING WEIGHT RATINGS WILL:
Cause damage to the motorhome, drive train or fhassis;
Cause unstable driving andhandling characteristics;
Cause unsafe braking;
Reduce
your warrantyprotection.
Periodicallyreweigh yourmotor home andlog the weights
in the back of this manual to help loading for future trips.
Loading and weight patternswill change according to use.
. NOTE: Somestatesandprovinces require brakes
and safetychains on towed vehicles. Consult the
properauthorities
in thestatesorprovincesthrough
which
you will be traveling.
Loading Tips
Do not load heavy items
in upper cabinets.
Secure and brace items so they won't move during
travel, thereby shifting the load.
Do not load heavy items near either end of the motor
home or on the bumpers.
Adjustcargostorageto keeptheside
to sidewheel loads
as equal as possible.
Water weighs 8.33Ibs. per gallon. Carry only as much
water as needed
for travel use or to balance the load.
Whenever possible, empty the holding tanks before
traveling.
GVWR ____________ _
Front GAWR ____ _
Rear GAWR ____ _
MOTOR HOME
FRONT
AXLE
REAR AXLE .
SCALE READINGS
Reading 2
Reading 1
.Reading 3
___ _
Hitch Rating
GCWR ______ _ TOWED VEHICLE
COMBINED VEHICLES
Reading 4 ___ _
Add 2 and 4 ____ _

WARNING
MODIFICATION OF YOUR VEHICLE BY ADDI-
TION OF RACKS NOT ORIGINALLY
EQUIPPED BY THE MANUFACTURER TO
CARRY ADDITIONAL EQUIPMENT, VE-
HICLES, OR CARGO WILL REDUCE YOUR
WARRANTY COVERAGE AND MAY CAUSE
PERSONAL INJURY OR PROPERTY DAM-
AGE.
Make a loading diagram of your properly loaded motor
home. It will help you locate where specific items are
stored, and will help speed the loading process. Store
emergencyitemsin areadily accessible location. Include
afire extinguisher, tools, first aid, rain gear, flashlight,
highway warning devices and an electric cord with light.
TIRES
Your motor home is equipped with truck tires. Under
normal circumstances and with proper maintenance, you
should receive thousands of miles of trouble·free service.
Tire Inflation
For safety and maximumtire life, proper inflation pressure
must I;>e maintained.Properly inflated tiresalsocontribute
to overall motor home stability and safety. Referto the tire
section in your chassis operator's manual for information
on maintenance, inflation pressure, and tire care.
WARNING
FOR SAFETY AND MAXIMUM TIRE LIFE,
CHECK TIRE PRESSURES (INC,"UDING THE
SPARE) OFTEN. PAY SPECIALATIENTIONTO
INSIDE REAR .DUALS. ALWAYS CHECK
PRESSUREWHENTIRESARE COLD, AND DO
NOT BLEED AIR OUT OFWARM TIRES. FOL-
LOWTHETIREPRESSURE INSTRUCTIONS IN
THE CHASSIS OPERATOR'S MANUAL.
NOTE: Check the wheel covers periodically.
They could work loose during driving.
Tire Replacement
Replacement tires must be the same size, and have at
least the same weight carrying capacity as the original
equipment. All tires of the same size and rating may not
have the sameweightcarrying capacity. Consult yourtire
dealer. The original equipment tires supplied on your
motor home have weight carrying capacities to support
gross axle weight ratings (GAWR) as stated on the
Federal Certification Tag located on the sidewall nearthe
driver's seat.
9
If You Get a FlatTire
In Case of sudden tire failure, avoid heavy brake applica-
tion. Gra.dually decrease speed. Hold steering wheel
firmly and move slowly to a safe, off-road place. Park on
a firm level spot, turn off the Ignition, and turn on the
hazard flasher system.
Spare Tire Carrier
The spare tire is located in an exterior storage compart-
ment. ,
WARNING
TRl)CK WHEELS AND TIRES ARE EX-
TREMELY HEAVY AND MAY WEIGH 100
POUNDS OR MORE. DO NOT ATIEMPT TO
REMOVETHE SPARETIRE UNLESSYOU ARE
CAPABLE OF HANDLING THE WEIGHT.
NOTE:Your motor home is not equipped with a jack.
(Spare tire is optional.)
Changing a FlatTlre
Even with good tire maintenance and normal driving, you
may experience a fiat tire. Summon professional help
through your autoclub or travel service, or a localtruck
servicefaCility.Your motor home is not equippedwith a
jack or other lifting device. 00 not attempt to lift the
motor homewith a jack Consult the Chassis Operator's
Manual for additional information on tire inflation and
proper torque.
WARNING
TO AVOID PERSONAL INJURY AND/OR
PROPERTY DAMAGE IF A BLOWOUT OR
OTHER TIRE DAMAGE OCCURS, OBTAIN
EXPERT TIRE SERVICE HELP. DO NOT AT-
TEMPT TO CHANGE THE TIRE YOURSELF.
TOWING A VEHICLE
If you expect to pull a vehicle with your motor home,
please use these guidelines when choosing a hitch and
trailer:
Hitchclassification: Class II. Do notuseaload equalizing
hitch. It could cause structural damage to the frame
members.
Limit the tongue weight of trailer or towing device to a
maximum of 250 pounds. Heavier tongue weights can
damage your motor home frame and body, cause un-
stable driving and handling characteristics, and will re-
strict your rights under the Ownercare warranty.

Do nottowa vehicle weighing morethan 3500 pounds, or
which would result in exceeding the GCWR recom-
mended by the chassis manufacturer. Heavier vehicles
can cause braking problems, damage the hitch, the
. motor home structure or drive train, cause unstable
driving
or handling characteristics, and/or restrict your
rights under warranty. Changing the trailer hitch will not
increase the tow capacity of the motor home.
The GrossCombinedWeight Rating (GCWR) is listed on
the wardrobe door tag. The GCWR is the maximum
allowable weight of both the loaded motor home and
towed vehicle. Exceeding the GCWR can cause damage
to yourmotorhomedrivetrain
or chassis, unstabledriving
and handling charactetistics, and will reduce your war-
ranty protection.
SEATS AND SEAT BELTS
Seat belts help to restrain you and your passengers in
case of a collision. In most states, the law requires their
use.
Seat belts provide the best restraint when:
the seat back
is upright
the occupant is sitting upright (not slouching)
the I'lP belt
is snug and low on the hips
the shoulder belt
is snug against the chest
the knees arestraight forward
For your safety, your vehicle has combination lap and
shoulder belts for the driverand front seat passenger and
lap belts without retractors in most other designated
seating positions.
WARNING
MAKE SURE THAT YOU AND YOUR PASSEN-
GERS, INCLUDING
PREGNANT WOMEN,
WEAR SAFETY BELTS. BE SURE THAT LAP
BELTS FIT SNUGLY ANb AS LOW AS POS-
SIBLE AROUNDTHE HIPS.IF SAFETY BELTS
ARE NOT USEDPROPERLY,THE RISK OFYOU
OR YOUR PASSENGERS BEING INJURED IN
A COLLISION GREATLY INCREASES.
ALWAYS
DRIVE AND RIDE WITH YOUR
SEATBACK UPRIGHT AND THE
LAP BELT
SNUG AND LOW ACROSS THE HIPSTO RE-
DUCETHERISK OF SERIOUS INJURYTOTHE
ABDOMEN OR NECK THAT COULD BE
CAUSED
BY SLIDING UNDER THE SAFETY
BELTS
IN A COLLISION.
NEVER LET A PASSENGER HOLD A CHILD
ON HIS OR HER LAP WHILE THE VEHICLE IS
MOVING. THE PASSENGER CANNOT PRO-
TECT THE CHILD FROM INJURY IN A COL-
LISION.
CHILDREN SHOULD
ALWAYS RIDEWITH THE
SEATBACK IN THE FULLY UPRIGHT POSI-
TION.WHEN THE SEATBACK IS NOT FULLY
UPRIGHT, THERE IS A GREATER RISK THAT
THE CHILDWILL SLIDE UNDERTHE SAFETY
BELT AND BE SERIOUSLY INJURED IN A
COLLISION.
NEVER USE A SINGLE BELT FOR MORE
THAN ONE PERSON OR ACROSS MORE
THAN ONE SEATING POSITION. THIS
GREATLY INCREASES THE RISK THAT ONE
OR BOTH OFTHE PEOPLEWILL BE INJURED
IN A COLLISION. EACH DESIGNATED SEAT-
ING POSITION IN YOUR VEHICLE HAS A SPE-
CIFIC SAFETY BELT ASSEMBLY WHICH IS
MADE UP OF ONE BUCKLE AND ONE
TONGUETHAT ARE DESIGNEDTO BE USED
AS A PAIR.
WARNING
USETHE SHOULDER BELT ONTHE OUTSIDE
SHOULDER ONLY. NEVER WEAR THE
SHOULDER BELT UNDER THE ARM. NEVER
SWING IT AROUND THE NECK OVER THE
INSIDE SHOULDER. FAILURE TO FOLLOW
THESE PRECAUTIONS COULD INCREASE
. THE RISK AND/OR SEVERITY
OF INJURY IN
AN ACCIDENT.
Combination Lap and Shoulder Belts
While your vehicle
isin motion, the combination lap and
shoulder belt adjusts to your movement. However,
if you
brake. hard, corner hard
or if your vehicle receives an
impact, the lap and shoulder belt locks and prevents you
from
mOVing.
To fasten the belt, pull the lap-shoulder belt from the
extractor so that the shoulder portion of the belt crosses
your shOUlder and chest. Insert the belt tongue into the
proper buckle until you hear a snap and feel it latch.
T6tightenthe lapportionofthe belt, pull upon theshoulder
belt until it fits you snugly. The belt should rest as low on
your i)ips as possible.
Safety Belt Maintenance
Check your safety belt system periodically to make sure
that it works properly and isn't damaged. If the webbing
shows any wear, nicks
or cuts, have it examined by a

qualified technician to determine if replacement is neces-
sary. Always have your safety belt system checked after
a collision.
Safety Restraints
for Children
In most states, you are required by law to use safety
restraints for children.
If small children (less than four
years old, and under 40 pounds) ride
in your vehicle, you
must put them
in safety seats that are made specially for
children. Safety belts alone do not provide maximum
protection for these children: Check your local and state
laws for specific requirements.
WARNING
WHEN USING ANY INFANT OR CHILD RE-
STRAINT SYSTEM, IT IS IMPORTANT THAT
YOU FOLLOW THE INSTRUCTIONS AND
WARNINGS PROVIDED BY THE MANUFAC-
TURER CONCERNING ITS INSTALLATION
AND USE. FAILURE TO FOLLOW EACH OF
THE RESTRAINT MANUFACTURER'S IN-
STRUCTIONS COULD INCREASE THE RISK
OR SEVERITY OF
AN INJURY IN THE EVENT
OF A COLLISION OR SUDDEN STOP.
SAFETY BELTS AND SEATS CAN BECOME
HOT
IN AVEHICLETHAT HAS BEEN CLOSED
UP IN SUNNYWEATHER, AND COULD BURN
A
SMALL CHILD. OHECK SEATCOVERS AND
BUCKLES BEFORE YOU PLACE A CHILD
ANYWHERE NEAR THEM.
WARNING
NEVER LEAVE A CHILD UNATTENDED IN
YOUR VEHICLE. ALWAYS REMOVE THE KEY
FROMTHE IGNITION ANDTAKE ITWITH
YOU.
Safety Belts for Children
Children who are too large for child safety seats should
always wear safety belts.
WAijNING
IF SAFETY BELTS ARE NOT PROPERLY
WORN AND ADJUSTED AS DESCRIBED,THE
RISK OF SERIOUS INJURY TO THE CHILD IN
A COLLISION WILL BE.MUCH GREATER.
IFTHE SHOULDER BELT CANNOT BE PROP-
ERLY POSITIONED SO THAT IT DOES NOT
CROSS.OR REST IN FRONT OFTHE CHILD'S
FACE
OR NECK, MOVE THE CHILD TO ONE
OFTHE SEATSWITH A LAP BELT ONLY AND
USE THE LAP BELT.
_______________ 11
LAP BELTS ANDTHE LAP PORTION OF LAP
AND SHOULDER BELTS SHOULD ALWAYS
BE WORN SNUGLY AND BELOW THE HIPS,
TOUCHING THE CHILD'S THIGHS.
CHILDREN SHOULDALWAYS RIDEWITHTHE
SEATBACK IN THE FULLY UPRIGHT POSI·
TION. WHEN THE SEATBACK IS NOT FULLY
UPRIGHT,THERE IS A GREATER RISK THAT
THE CHILD
WILL SLIDE UNDERTHE SAFETY
BELT AND BE SERIOUSLY INJURED IN A .
COLLISION. '
Safety Seats
for Children
Use a safety seat that is recommended for the size and
weight of the child.
WARNING
CAREFULLY FOLLOW ALL OF THE
MANUFACTURER'S INSTRUCTIONS THAT
COME WITH THE SAFETY SEAT THAT YOU
PUT IN YOUR. VEHICLE. MAKE SURE THAT
THE
SHOllLDER BELT(IF PROVIDED ATTHE
SEATING POSITION WHERE THE SAFETY
SEATIS BEING USED)DOES NOTCROSS OR
REST IN FRONT
OF THE CHILD'S FACE OR
.NE;CK.IFYOU DO NOTINSTALLANDUSETHE
SAFETY SEAT PROPERLY, THE CHILD MAY
BE INJURED IN A SUDDEN STOP OR COL-
LISION.
SEATBACKSSHOULDBEUPRIGHTFOR USE
WITH CHILD SAFETY SEATS.
DRIVING AND PARKING
Onceyou become accustomed to the feel of the controls
and the reference points from the driver's seat, you will
find driving a motor home comparable to driving your
family car. Become familiar with the position of the home
in traffic, and be cautious when maneuveringto allow for
the length and with of the vehicle. Always allow room to
corner and to change lanes. Learn to use the side and
rear view mirrors to view the road behind.
Rernemberthat your motor home is heavier than a car,
making it less maneuverable and harder to stop. Also,
becf\use of its greater side surface aref\, it is more easily
affectedbycrosswinds.Allow extradistancesforpassing
alldstopping, anddrive at a moderate speed,particularly
in traffic and in gusty wind conditions.
. Driving on winding or mountain roads is not difficult if
done with reasonable care. Observe proper vehicle
speeds when ascending or descending hills and always

operate in the preper transmission range. Dewnshift on
hills te avoid .overheating .or undue engine loads. Down-
shift whendescendinggrades. Engine braking pewerwill
help centroI vehicle speed en gaseline powered ve-
hicles, (does not apply te diesel-powered vehicles) and
relieve seme .of the strain en the brakes.
Meuntaindriving .or deserttemperaturescan put extreme
demands en chassis cempenents. Under extreme use
cenditiens you may need te turn
.off the vehicle air
cenditiener to improve engine and transmissien ceoling.
Be aware of the extra height .of yeur motor home. Check
for lew hanging tree branches or ether .obstructions
whenever yeu drive
.or park. Aveid low .overhangs when
pulling in for service. Always check.overhead clearances
of .overpasses and bridges. This may be particularly
impertant if yeu drive with the .overhead vents .open .or if
the meter home is equipped with a roof air cenditioner,
roef rack, CB .or TV/radie antenna. Before leaving en a
trip, checkyeurroute.Semetunnelsprehibit meterhomes
with LP gas systems.
When parking parallel te acurb, be sure te allew fer peles
orebstructiens as the frentand rear pertiens .of the meter
heme swing widerthan an autemebile. When parking en
an inclif)e, turn the front wheels inte the curb in the
directien
of the rell to aid the parking brake. When
parking, always shift the transmissien to PARK ("P") and
set the parking brake, if applicable.
WARNING
DO NOT PARK OR IDLE THE MOTOR HOME
OVER COMBUSTIBLE MATERIALS SUCH AS
TALL GRASS OR DRIED LEAVES. THIS IS .
PARTICULARLY IMPORTANT IF THE EX-
HAUST SYSTEM HAS NOT BEEN PROPERLY
. MAINTAINED.
COMBUSTIBLE MATERIALS
MAY CATCH FIRE FROM THE HOT EXHAUST
GASES, SOOT OR SPARKS THAT COULD
ESCAPETHROlJGH CORROSION HOLES OR
.CRACKS.
If .operating, parking .or idling yeur vehicle .off-read is
unaveidable:
Beawarethatcembustible materialsceuld catch fire from
the vehicle's hot exhaust system.
Avoid driving your vehicle threugh or ever cembustible
materials such as leaves, grass, vegetatien
.or stubble
high eneugh te touch, catch .or cellect en its het exhaust
system.
Parking or idling sheuld be dene .only in an area where
there are ne cembustible materials under the vehicle.
FUEL AND FUEL SYSTEMS
See the Chassis Operator's Manual in the Owner's Infor-
matien Package fer chassisfuel recommendations. If your
moterheme is equipped with a generator, see the genera-
tor.operating instructiens in the Owner's Infermatien Pack-
age for fuel and maintenance recemmendatiens.
Fuel Fill
The fuel filler cap is lecated teward the rear
.of the ceach
.on gaseline-pewered medels, and near the frent wheel
en passenger side en diesel-pewered medels. Medern
gaselinefuel systems m<lY build up vaperpressu!e within
thetankas the gaselinewarmsduringuseorhetweather.
Under certain cenditiens,sudden release
.of this pres-
surewhen remeving thegaselinecap cancausegaseline
te spray frem
the fill .opening, creating a fire hazard.
WARNING
WHEN REMOVING THE.GASOLINE CAP, RO-
TATE SLOWLY ONLY FAR ENOUGH TO
AL·
LOW PRESSURE TO RELEASE. AFTER
"HISSING" SOUND STOPS, COMPLETETHE
REMOVAL OF THE CAP.
Te pretect the gaseline system frem excessive pressure
.or vacuum, .or frem sudden release .of pressure, replace
lest
.or damagedcaps with caps efthe samedesignwhich
are available frem yeur Fleetweod moter home dealer.
Clean up fuel spills immediately. Raw fuel spilled en the
meter heme ceuld damage the exterier finish, and is a
serieus fire hazard.
NOTE: Diesel fuel systems do not build up
pressure as do gasoline systems.
Fuel Types And Vapor Lock (Gasoline-Powered
Models Only)
Yeur moter heme's autemetive fuel and emissiens sys·
tems are sephisticated and highly engineered te meet
Federal and State emissiens standards.They are seme-
times sensitivete fuel types and blends, particularlyfuels
blended fer certain altitudes and climates. Fuel suppliers
previde custemers with the cerrect fuel fer their lecatien
andseasonalconditiens.Semetimes,theugh,fuel blended
fer winter is supplied during summer menths.
"Vapor leck" occurs when gasoline vaporizes, and vaper
peckets bleck
theflewef liquid fuel te the engine. If yeu
experience engine stall or stutter, yeu may be experienc-
ing vaperleck.lfyourengine and fuel system are properly
tuned and maintained, yeu sheuld not experience this
problem. If vapOr lock occurs, the fuel itself ceuld be the
caUse. If at all pessible, check with the service statien
eperater
as to the fuel blend before filling yeurfuel tank. If
you purchase your fuel from nationally recegnized fuel

dealers,yourchances of vapor lock can be reduced. If you
store yourmotorhome during the wintermonths, be aware
that when
you take the vehicle out of storage in the spring
or summer, winter fuel may cause vapor lock until it is
consumed.
GENERAL CHASSIS TOPICS
(Gasoline-Powered Models Only)
Variable Speed Engine Fan
When the engine is under load or requires maximum
cooling, the engine fan adjusts and turhS faster. The fan
may become very noisy at high speed and when maxi-
mum cooling is required. High speed fan noise can
sometimes be misinterpreted as transmission slippage.
This is notthe case. High engine speed and temperature
conditions, such as pulling away from a stop after long
freewaydriving, can cause loud fan noise untilthe engine
cools down.This fan noise indicates that the fan
is doing
what
it is supposed to do. This noise is not a defect in the
fan or the transmission.
Exhaust System Heat
Your motor home engine has been designed to conform
to Federal and State emission requirements.
To meet
these requirements, engine operating temperatures are
high.
As a result, the engine and exhaustsystems radiate
a great deal of heat.
Special heat shields are built into your motor home to
protect wiring and other components from possible heat
damage caused by the exhaust system.
Do not remove
these shields, modify the exhaust system, or add addi-
tional equipment, such as wiring, plumbing, or other com-
ponents, which will be affected by exhaust system heat.
CARBON MONOXIDE
SAFETY PRECAUTIONS
Carbon monoxide is acolorless, tasteless, odorlessgas.
It is a by-product of combustion in engines.The engines
in your motor home and generator system produce it
constantlywhiletheyare running. CARBON MONOXIDE
IS
DEADLY. Please read and understand the following
precautions to protect yourself and others from the ef-
fects of carbon monoxide pOisoning.
WARNING
EXHAUST GASES ARE DEADLY. DO NOT
BLOCK THE TAILPIPES OR SITUATE THE
VEHICLE IN A PLACE WHERETHE EXHAUST
GASES HAVE ANY POSSIBILITY OF ACCU-
MULATINGEITHER OUTSIDE,UNDERNEATH,
OR INSIDE YOUR VEHICLE OR ANY NEARBY
VEHICLES. OUTSIDE AIR MOVEMENTS CAN
CARRY EXHAUST GASES INSIDE THE VE-
HICLE THROUGH WINDOWS OR OTHER
OPENINGS REMOTE FROM THE EXHAUST
OUTLET. OPERATE THE ENGINE(S) ONLY
WHEN SAFE DISPERSION OF EXHAUST
GASES CAN BE ASSURED, AND MONITOR
OUTSIDE CONDITIONS TO BE SURE THAT
EXHAUST CONTINUES TO BE DISPERSED
SAFELY.
Beware of exhaust gas (carbon monoxide) poisoning
symptoms:
Dizziness
Vomiting
Nausea
Muscular Twitching
Intense Headache
Throbbing in Temples
Weakness and Sleepiness
Inability to Think Coherently
,
If you or others experience any of these symptoms, get
out into the fresh air immediately. If symptom persist,
seek medical attention. Shut down the unit and do not
operate until it has been inspected and repaired.
WARNING
00 NOT UNDER ANY CIRCUMSTANCES
OPERATE ANY ENGINE WHILE SLEEPING.
You would not be able to monitor outside conditions to
assure that engine exhaust does not enter the interior,
andyou would notbe alertto exhaustodors
or symptoms
of carbon monoxide poisoning.
Do not operate an engine with a damaged exhaust
system. Checkthe systemfrequently fordamage. Do not
under any circumstances modify the exhaust system(s)
in any
way.
Carbon Monoxide Detector
Your motor home is equipped with a carbon monoxide
(CO) detector. It is usually located in the main sleeping
area.
If the indicator sounds, it is an indication that carbon
monoxide gas is present. This may occur while idling
in
high traffic concentrations where other vehicles as well
as your motor home are contributing to the carbon
monoxide level in the surrounding air. Sounding of the
alarm does not indicate a faulty alarm. The detector is
doing its jobof warning you of potentially high concentra-
tions of carbon monoxide. See the section
on Carbon
Monoxide in this manual.

Test the CO detector after the motor home has been in
storage, before each trip, and at leastonce aweekduring
use. Replacethe sensorand batterywhen necessary.Do
not replace the battery without replacing the sensor.
Sensors are available through your Fleetwood dealer.
Please referto the operating instructions includedin your
Owner's Information Package.
EMERGENCYTOWING
The onlysafeand approvedtowing methodsare eitheran
under reach wheel lift device, as installed
on a minimum
3-ton towtruckchassis, oraflat bed trailer.Mosttowtruck
operators willing and able to tow motor homes will be
familiar with these devices. Be prepared to give the tow
truck operatorat leastthe following informationwhen you
call:
length and height of motor home
Chassis manufacturer
Gross vehicle weight rating
CAUTION
Do not tow the motor home from the rear.
Towingfrom the rear
will causeserious over-
loading of the front tires and suspension,
possibly resulting in tire or front suspension
failure. The rear frame extensions are
not
designed to withstand the load imposed by
lifting from the rear.
The vehicle must be towed from the front, either on the
rear wheels (if operational) or
on a heavy duty dolly, or
transported on a flat bed trailer. Consult your chassis
operator's manual.
To prepare your motor home for towing:
1. Secure any loose or protruding parts of the
disabled vehicle.
2. Secure any heavy, loose items in the interior.
>
3. Turn oH lP gas appliances and thelP gas tank
valve.
4. Do not allow any person to ride in the towed
vehicle.
A DACHING ACCESSORIES TO
YOUR MOTOR HOME
Structural members are located specifically to mount and
attachfactory-installed componentsand accessories, and
may not be located to support after-market accessories
notspecifically designed for use
on cir in yourmotorhome.
Please consultwith yourdealerbefore attemptingto install
or mount accessories
on the sidewalls of your motor
home. Holes drilled
in the sidewall may cause damage,
and
may· aHect portions of your warranty coverage.
