FlexRadio FLEX-6400M User manual

Turn on radio Press and hold VFO for
Receiver Menu
Press Power Knob for Transmit
Menu
FLEX-6400M & FLEX-6600M
Quick Start Guide
Make connections
Connect Earth Ground
Connect Key/Paddles
KEY
1 2
3 4
5 6
Connect power to
13.8VDC supply
Connect Ethernet to home router
(For updates or remote operation)
Connect Antenna
Connect Microphone
13.8 VDC
ANT1
MIC PTT
MIC PTT
Verify contents of the box
Radio
DWN FST UP
FHM-2
Microphone Power Cable Ethernet Cable
For additional information on safety and operation please refer to the User Manual at flexradio.com/downloads
For technical support go to helpdesk.flexradio.com
Multitouch Gestures
Double tap to tunePinch to zoomDrag to pan
x2

Turn on radio Download and install
SmartSDR
Select radio from chooser and
click connect
FLEX-6400 & FLEX-6600
Quick Start Guide
Software Controls
Verify contents of the box
Radio
DWN FST UP
FHM-2
Microphone Power Cable Ethernet Cable
For additional information on safety and operation please refer to the User Manual at flexradio.com/downloads
For technical support go to helpdesk.flexradio.com
Connect Earth Ground
Connect Key/Paddles
KEY
1 2
3 4
5 6
7
Make connections
Connect power to
13.8VDC supply
Connect Ethernet to home router
Connect Antenna
Connect Microphone
Connect
Powered Speaker
13.8 VDC
ANT1
MIC PTT
MIC PTT
Panadapter
Menu
Receiver
Menu
Transmit
controls
Mouse wheel to tune Double click to tune Drag to pan
flexradio.com/downloads
