Flick G1 User manual

PRODUCT MANUAL
V.4
FLICK G1
OPTICAL
MOUSE

FLICK OPTICAL GAMING MOUSE PRODUCT MANUAL
SOFTWARE INSTALLATION
DOWNLOAD SOFTWARE INSTALLER,
FROM DOWNLOAD.FNATIC.COM
RUN THE INSTALLER IF YOU ARE PROMPTED BY ANY POP’UPS DUR-
ING THE INSTALLATION, PLEASE ACCEPT (IT IS
A REQUIREMENT FOR THE SOFTWARE TO RUN
PROPERLY).
WHEN INSTALLATION IS COMPLETE, PLEASE
REBOOT YOUR COMPUTER

FLICK OPTICAL GAMING MOUSE PRODUCT MANUAL
CONTENTS
FEATURES 1
FEATURE DESCRIPTION 2
FUNCTIONS 3
BASIC SETTINGS 4
BUTTON ASSIGNMENT 5
COLOR SETTINGS 6
MACRO RECORDER 7
PRO TIPS 8
WARRANTY TERMS 9
PRODUCT SPECS 10

1
FLICK OPTICAL GAMING MOUSE PRODUCT MANUAL
FEATURES
Made with the solely purpose to give the E-sports gamer a keen edge over its opponents, the Fnatic Gear
FLICK has been designed with a performance driven components and interesting features. The curvature
of the body, yet uncomplicated but ergonomically shape has been studied through countless of hours,
carved from clay and in the end approved by the Fnatic Teams. Additionally, the Fnatic Gear FLICK features
seven programmable buttons and scroll wheel, three user proles, macro recorder and a customizable
LED-lightning system, making it completely customizable to your personal preferences.
PIXART 3310 SENSOR
The latest optical LED sensor on that market which focus on performance in terms of optimal tracking
speed and acceleration apart from other sensors that push for more CPI. Performs best of all sensors on
the market and is the rst choice of sensor for any member of the Fnatic teams.
OMRON SWITCHES
Omron switches with a MTBF of 10M clicks is chosen for the Left and Right click ensures a long life time
FLICK mouse.
DRAG REDUCTION CORD
The exit of the cord support has been angled upward in a 30 degree angle.
This prevents the cord from touching the surface in front of the mouse and in that way reducing the drag
of the cord.
COLOR SYSTEM
The scroll wheel is equipped with a RGB LED that lights up the scroll wheel.
The RGB LED can be congured in any color preferred by the end-user as well as be congured in various
brightness modes.
ONBOARD MEMORY
An onboard memory that stores up to three proles with three CPI steps each, as well as macros and light
congurations. Gives the user the ability to smoothly switch between systems without any hassle.

2
FLICK OPTICAL GAMING MOUSE PRODUCT MANUAL
FEATURE DESCRIPTION
EXAMPLES
LED’s lit while either Prole, CPI or both modes are active.
• If the user only has assigned a CPI changing function to the mouse,
the level LED’s present the CPI levels in orange.
• If both CPI and Prole functions is assigned, Orange is the primary
color which shows the CPI level. If the user decides to change prole
the LED’s change to white while the user is using a Prole changing
function.
• If only a Prole changing function is assigned, White is the primary
color which show the current Prole level. CPI level is not shown
since there isn’t a way to change it
• If none of the Prole or CPI changing functions are assigned, none
of the LED’s are lit
SCROLL WHEEL LED
Personalize your mouse by customizing the RGB LED in the scroll
wheel to any color you desire.
Pro Tip - A unique color can be set for each user prole
PROFILE LEVEL/CPI INDICATOR
Pressing the Prole cycle button cycles through three user dened
Prole levels. The number of lit LEDs in white corresponds to which
Prole level that is active.
White light indicates the current Prole level
Orange light indicates the current CPI level
Pro Tip - You can assign a button via the software to switch between
CPI. The number of lit LEDs in orange corresponds to which CPI level
is active.

3
FLICK OPTICAL GAMING MOUSE PRODUCT MANUAL
FUNCTIONS
The graphical interface contains of three buttons at the top which indicate which Prole that currently
is selected, on the right you nd the Backup/Restore functions in which you can Backup a the currently
selected Prole.
Beneath the Proles you nd the feature tabs where you can switch between; Basic Settings, Button
Assignment and Color Settings, to the right you have the Macro recorder. A more detailed explanation of
each of the features can be found in separate sections of the manual.
In the far down left corner the Restore Default button is located which Restores the mouse to its default
settings.
In the main header of the software window you nd the FW (Firmware) and SW (Software) versions.
Pro tip - Do not forget to back up your proles to a local storage device before restoring the mouse to its
default settings.
Pro tip - It is not necessary to run the settings software to change proles; the software is only needed to
setup and customize proles. Once set, proles are stored in the internal memory and will remain saved
until the mouse is restored to its default settings.
Pro tip - Proles can also be saved to an external device, such as a USB stick. This allows you take your
settings with you when you are not playing using your own system and/or mouse, or wish to share your
favorite settings with a friend

4
FLICK OPTICAL GAMING MOUSE PRODUCT MANUAL
BASIC SETTINGS
CPI SETTINGS
CPI (Counts Per Inch) is an expression of how
many counts that will be reported by the mouse
when it is moved one inch, a higher CPI indicates
therefore a higher mouse cursor velocity.
The horizontal and vertical CPI axes can as well
be separated from each other resulting in a higher
or lower speed in one axis.
Each prole contains of three levels which
corresponds to the CPI level indicator that is
located on the mouse.
POINTER SENSITIVITY
The Pointer Sensitivity is a operating system
setting which controls the speed of the mouse
cursor
(This function is global and used across all
proles)
Pro tip - We strongly encourage leaving this at six
(6). Six is the direct translation of data from the
mouse to the OS – anything below or above 6 gets
resampled by the OS, which could affect mouse
functionality.
DOUBLE CLICK SPEED
The Double Click Speed is a operating system
setting which controls how fast you would need to
double click the Left mouse button to for example
execute a program which you double click on.
(This function is global and used across all
proles)
DOUBLE CLICK SPEED
The Double Click Speed is a operating system
setting which controls how fast you would need to
double click the Left mouse button to for example
execute a program which you double click on.
(This function is global and used across all
proles)
SCROLL SPEED
Scroll Speed is an operating system deciding the
incremental movement of rows per scroll step.
Scroll by page indicates that instead of scrolling
across rows you scroll one page at a time.
(This function is global and used across all
proles)
POLLING RATE
The polling rate represents how often the mouse
communicates with the computer.
Pro tip - E-Sports professionals use 1000Hz

5
FLICK OPTICAL GAMING MOUSE PRODUCT MANUAL
BUTTON ASSIGNMENT
Every button on the FLICK is fully customizable.
To recongure a button, click on its respective dropdown, a menu will display all the available commands.
Buttons can be also be disabled to avoid miss-clicks when not being used.
When you are happy with your changes, press the Apply button, and the new commands are saved.
HOW TO ASSIGN A FUNCTION
A. Identify a button that you want to assign a function to
B. Locate the corresponding dropdown for that button
C. Select the preferred function
Pro tip - As a safety precaution, the software will not allow you save to without having “Left click” or “Right
click” functionality assigned.
Pro tip - As a safety precaution, the software will not allow you save to without having “Left click” or “Right
click” functionality assigned.
A
B

6
FLICK OPTICAL GAMING MOUSE PRODUCT MANUAL
COLOR SETTINGS
The scroll wheel of the FLICK Gaming Mouse have an LED that is customizable in 16 million different
colors. The LED’s can be congured in various brightness modes, a rainbow effect as well as been turned
of
The color settings is divided into two different areas; Color selection and Light conguration.
Turn on the LED by click the Off/On button [A]
The currently mixed color [H]
HOW TO PICK A COLOR
1a. Select a color with the Color slider [B]
OR
1b. Turn on Color cycle [G]
Color cycle switch cycles between all colors available
2. Select the Saturation [C] of that the selected color
(equals the amount of white that is mixed into the color)
HOW TO MODIFY THE LIGHT CONFIGURATION
3. Select one different brightness modes [D] that is available
(brightness congurations cannot be selected while Color cycle is enabled)
4a. If the mode CUSTOM were chosen you can specify the brightness [E] of the LED
OR
4b. If any of the other modes were chosen, you can set the Interval [F], in seconds, of that mode.
The interval slider does also control the Color cycle.
B
C
D
E
F
A
G H

7
FLICK OPTICAL GAMING MOUSE PRODUCT MANUAL
MACRO RECORDER
The macro recorder can record up to 254 actions where one key press is two actions, means that you can
record a 128 characters long macro.
While a macro is executed it is played with 1ms delays between each of the actions.
A macro that is eight characters long will execute in 16ms
HOW TO RECORD A MACRO
1. Press the record button [A]
2. Type the macro
The recorded keyboard and mouse clicks will be displayed in the Macro Recorder area [B]
3. Press the record button a second time [A]
4. Type a name in the name eld [C]
5. Press save [E]
MACRO LIBRARY
Recorded macros will be shown in the Macro Library [F] area where, the macros as well can
be deleted.
A ED
B
F

8
FLICK OPTICAL GAMING MOUSE PRODUCT MANUAL
PRO TIPS
CPI
Basically what you should ask your self is that how far you would like to swipe with the mouse to move
from one side of the screen to the other or to make a 360 degree turn in an fps game. Tune the CPI to
match that. If you are comfortable with lifting the mouse and repeat the swipe, divide the CPI on the
amount of swipes that you are willing to make.
PROFILES
To distinguish proles even further you can assign a different color to each prole so it will be easier
connect them to a specic area, weapon or hero, or whatever environment you are in.
MAINTENANCE
If you need to clean your product, please disconnect it from the computer and use a damp piece of cloth.
Do this every month or so depending on how much you use it.
TROUBLE-SHOOTING AND SUPPORT HAVE YOU SEEN OUR OTHER PRODUCTS?
If you are in need of technical support, go to the Fnatic Gear support section at www.fnaticgear.com.
Please log in or create an account. Once logged in, ll in the support form with relevant details. A support
ticket number will be issued. Use this number for future correspondence.
To speed up the process, please provide your product serial number.
IDENTIFY YOUR SERIAL
The product serial can be found on bottom of the product, and contains of 15 characters whereas one is a
letter.
Example: S/N:8585A1503010000

9
FLICK OPTICAL GAMING MOUSE PRODUCT MANUAL
WARRANTY TERMS
The Fnatic Gear FLICK has a 2-year warranty from the date of purchase.
Proof of purchase, with date of purchase are required for warranty claims.
The extra warranty is not valid for refurbished or second-hand purchases.
OBTAINING WARRANTY SUPPORT
Before submitting a warranty claim, visit the support section at www.
fnaticgear.com for technical assistance. Valid warranty claims are
generally processed through the point of purchase during the rst thirty
(30) days following purchase; however, this period of time may vary
depending on where you purchased your product – please check with
FNATIC GEAR or the retailer where you purchased your product for details.
Warranty claims that cannot be processed through the point of purchase
and any other product related questions should be addressed directly to
FNATIC GEAR. The addresses and customer service contact information
for FNATIC GEAR can be found in the documentation accompanying your
product and on the web at www.fnaticgear.com.
FNATIC LIMITED HARDWARE WARRANTY
FNATIC GEAR warrants to the original purchaser that FNATIC GEAR
hardware product is free from defects in material and workmanship for
the length of time from the date of purchase – specied on the product
package and/or contained in the user documentation.
Except where prohibited by applicable law, this warranty is
nontransferable and is limited to the original purchaser. This warranty
grants specic legal rights; other rights may apply under other variable
local laws.
FNATIC GEAR provides its products through a network of distributors
and resellers; FNATIC GEAR products cannot be ordered directly from
the manufacturer. As products cannot be purchased directly from the
manufacturer, FNATIC GEAR is unable to offer warranty services for
said products.The reseller shall be responsible for providing warranty
services for FNATIC GEAR products and therefor the customer will need
to make warranty claims with the reseller. If the reseller is no longer in
business or otherwise unable to fulll warranty obligations, responsibility
for warranty services shall default to – and the customer shall le the
warranty claim with -- the distributor.
In the United States, the retailer/reseller will handle warranty
replacement for the rst 30 days after the date of purchase. FNATIC GEAR
will then cover warranty replacement for the remainder of the warranty
period.. In the event a FNATIC GEAR product is sold from a company
located within the United States to a party or parties outside of the United
States, the product warranty is no longer valid and considered void.
REMEDIES
FNATIC GEAR’s entire liability and exclusive remedy for any breach of
warranty shall be at FNATIC GEAR’s discretion: (1) to repair or replace
the hardware, or (2) to refund the price paid, provided that the hardware
is returned to the point of purchase or such other place as FNATIC GEAR
may direct with a copy of the sales receipt or dated itemized receipt.
Shipping and handling charges may apply except where prohibited by
applicable law. FNATIC GEAR may, at its option, use new or refurbished or
used parts in good working condition to repair or replace any hardware
product. Any replacement hardware product will be warranted for the
remainder of the original warranty period or thirty (30) days, whichever is
longer or for any additional period of time that may be applicable in your
jurisdiction.
This warranty does not cover problems or damage resulting from: (1)
accident, abuse, misapplication, or any unauthorized repair, modication
or disassembly; (2) improper operation or maintenance, usage not in
accordance with product instructions or connection to improper voltage
supply; or (3) use of consumables, such as replacement batteries, not
supplied by FNATIC GEAR except where such restriction is prohibited by
applicable law.
LIMITATION OF LIABILITY
FNATIC GEAR SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT,
INCIDENTAL OR CONSEQUENTIAL DAMAGES WHATSOEVER, INCLUDING
BUT NOT LIMITED TO LOSS OF PROFITS, REVENUE OR DATA (WHETHER
DIRECT OR INDIRECT) OR COMMERCIAL LOSS FOR BREACH OF ANY
EXPRESS OR IMPLIED WARRANTY ON YOUR PRODUCT EVEN IF FNATIC
GEAR HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Some
jurisdictions do not allow the exclusion or limitation of special, indirect,
incidental or consequential damages, so the above limitation or exclusion
may not apply.
DURATION OF IMPLIED WARRANTIES
EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED
WARRANTY OR CONDITION OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE ON THIS HARDWARE PRODUCT IS LIMITED IN
DURATION TO THE DURATION OF THE APPLICABLE LIMITED WARRANTY
PERIOD FOR YOUR PRODUCT. Some jurisdictions do not allow limitations
on implied warranty length, so the above limitation may not apply.
NATIONAL STATUTORY RIGHTS
Consumers have legal rights under applicable national legislation
governing the sale of consumer goods. Such rights are not affected by the
warranties in this Limited Warranty.
NO OTHER WARRANTIES
No FNATIC GEAR dealer, agent, or employee is authorized to make any
modication, extension, or addition to this warranty.
WARRANTY PERIODS
In the European Union, all warranty period less than two years shall be
increased to two years.
COMPANY INFO
Address:
Fnatic Gear LTD
Crafters House at 5
76 East Road, LONDON N16AB
Contact: gearsupport@fnatic.com

10
FLICK OPTICAL GAMING MOUSE PRODUCT MANUAL
PRODUCT SPECS
TECHNICAL SPECIFICATIONS
MCU/Processor: Holtek HT68FB560
Main switches: Omron
Sensor: ADNS 3310
Memory: 256 kB
Resolution: 5000 CPI
Frames per second: 6500
Tracking speed: 130 IPS
Max acceleration: 30 G
Report rate: Adjustable, up to 1000Hz
Max acceleration: USB 2.0, Gold plated
(2 m braided cord)
PRODUCT DIMENSIONS & WEIGHT
126x68x40 mm
Net weight: 90 g / 0.19 lbs
RETAIL PACKAGE DIMENSIONS
56x160x218 mm
Package weight: 322 g / 0.70 lbs
SYSTEM REQUIREMENTS
Windows® compatible
Available USB port
10 MB free space on hard drive
RETAIL PACKAGE CONTENTS
Fnatic Gear FLICK
Quick Guide
COUNTRY OF ORIGIN
China
COMPLIANCE
CE, FCC
WARRANTY TERMS
2 Year Warranty from purchase date

Table of contents
