Flight Data Systems HHMPI User manual

ïç ß«¹«¬ îðïì
íðóðððë ×«» Ü
Operators manual
Handheld Multi-Purpose Interface (HHMPI)
Ú´·¹¸¬ Ü¿¬¿ ͧ¬»³ Ь§ Ô¬¼
íï Ó½Ù®»¹±® Ü®·ª»ô Õ»·´±® п®µô
Ê·½¬±®·¿ íðìîô ß«¬®¿´·¿ò
иò õêï í èííï îçðð
Ú¿¨ò õêï í çííê ïéëï
Û³¿·´æ «°°±®¬àº´·¹¸¬¼¿¬¿ò½±³ò¿«
Copyright © Flight Data Systems 2014
This manual is property of Flight Data Systems. This manual contains information in
which Flight Data Systems has a protected interest. This manual is a controlled document
and as such is subject to amendment. It is in the interest of the user to register this man-
ual with Flight Data Systems to ensure receipt of any amendments. The use, duplication,
and/or disclosure, by persons receiving this manual may be subject to restrictions. No
part of this document and/or data contained herein may be reproduced and/or used in
any form without written permission from Flight Data Systems.
To buy, sell, rent or trade-in this product please click on the link below:
https://www.avionteq.com/Flight-Data-Systems-HHMPI-FSD40-Data-Transfer-Unit.aspx
www.avionteq.com

ݱ²¬»²¬
îÑ°»®¿¬±® ³¿²«¿´
Ø¿²¼¸»´¼ Ó«´¬·óЫ®°±» ײ¬»®º¿½» øØØÓÐ×÷
Contents
Record of changes 4
List of figures 4
List of tables 5
2.0 Introduction 5
2.1 HHMPI models. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.2 HHMPI equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.3 Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.4 Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.0 Getting started 12
3.1 Terminology used in this manual . . . . . . . . . . . . . . . . . . 12
3.2 Using the HHMPI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.2.1 Connecting the HHMPI to an FDR . . . . . . . . . . . . . . . 13
3.2.2 Powering and charging the HHMPI . . . . . . . . . . . . . . 14
3.2.3 Charging the HHMPI with the docking cradle . . . . . 15
3.2.4 Turning on the HHMPI and self-test. . . . . . . . . . . . . . 16
3.2.5 Reset operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.3 Shortcuts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.4 Menu structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.5 HHMPI configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.5.1 Clock Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.5.2 Display Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.5.3 Memory Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.5.4 Network Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.5.5 Aircraft Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.5.6 Security Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.5.7 Live Data Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.5.8 Shortcut Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.5.9 Settings Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.6 Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.0 Operation 19
4.1 Download file name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.2 Aircraft lists. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.2.1 Loading aircraft details . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.2.2 Creating an Aircraft List on a PC . . . . . . . . . . . . . . . . . 20
4.2.3 Transferring the Aircraft List to the HHMPI . . . . . . . . 20
4.2.4 Creating the Aircraft List on the HHMPI . . . . . . . . . . 21
4.2.5 Adding Entries to the HHMPI Aircraft File . . . . . . . . . 21
4.2.6 Deleting an aircraft from the Aircraft list on the HHMPI
21
4.2.7 Saving the Aircraft list to the USB flash drive on the
HHMPI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.2.8 Deleting all aircraft from the Aircraft list on the HHMPI
22
4.2.9 Prompt for Tail No. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.3 Downloading flight data . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.3.1 Downloading recorded data from the FDR to a USB
flash drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.3.2 Decompressing CVR data at the aircraft . . . . . . . . . . 24
4.3.3 Decompressing CVR away from the aircraft . . . . . . . 25
4.3.4 Using the CVR rack adapter . . . . . . . . . . . . . . . . . . . . . 26
4.4 Viewing live flight data . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4.4.1 Live Data View Options. . . . . . . . . . . . . . . . . . . . . . . . . 28
4.4.2 Adjusting ARINC 717 settings . . . . . . . . . . . . . . . . . . . 28
4.4.3 Changing the display format . . . . . . . . . . . . . . . . . . . . 28
4.5 Viewing live flight data in engineering units . . . . . . . . 29
4.5.1 Assigning an Aircraft Definition file to an aircraft . . 30
4.5.2 Viewing Live Flight Data . . . . . . . . . . . . . . . . . . . . . . . . 30
4.6 File transfer operations . . . . . . . . . . . . . . . . . . . . . . . . . . 32
4.6.1 File transfer between HHMPI storage locations . . . . 32
4.6.2 Other storage operations . . . . . . . . . . . . . . . . . . . . . . . 33
4.6.3 File transfer PC to HHMPI. . . . . . . . . . . . . . . . . . . . . . . 33
4.7 Network operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
4.7.1 DHCP network settings. . . . . . . . . . . . . . . . . . . . . . . . . 33
5.0 Configuring an FTP connection 34

ݱ²¬»²¬
Ñ°»®¿¬±® ³¿²«¿´ í
ÚÜÍ ìððóíðï
5.1 Adding a new FTP server from the HHMPI. . . . . . . . . . 34
5.2 Configuring an existing FTP server from the HHMPI . 35
5.3 Testing an FTP server from the HHMPI . . . . . . . . . . . . . 37
5.4 Setting up an FTP connection from the web interface. .
37
5.4.1 Changing the HHMPI configuration via the web inter-
face . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
5.4.2 Backing up the HHMPI configuration . . . . . . . . . . . . 40
5.4.3 Restoring backup files via the web interface . . . . . . 41
5.4.4 Administration settings. . . . . . . . . . . . . . . . . . . . . . . . . 41
5.4.5 Logging out of the web interface . . . . . . . . . . . . . . . . 41
6.0 Wirelessly uploading files from the HHMPI to a server 42
6.1 Setting up a wireless network connection . . . . . . . . . . 42
6.1.1 Required equipment and wireless network information
42
6.1.2 Turning on wireless network support. . . . . . . . . . . . . 42
6.1.3 Connecting to a wireless network. . . . . . . . . . . . . . . . 43
6.1.4 Uploading files via FTP with a wireless network connec-
tion. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
7.0 Troubleshooting 44
8.0 FA2100, FA2200 and FA2300 Interface Supplement 48
8.1 Download Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
8.2 Recorder Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
8.3 FDR Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
8.4 CVR Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
8.5 FDR or CVR Fault Output. . . . . . . . . . . . . . . . . . . . . . . . . 49
8.6 Clear Latched Fault . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
8.7 Clear Fault Log. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
8.8 Dump Fault Log. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
8.9 Dump Debug Trace . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
8.10 Memory Marker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
8.11 Audio Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
8.12 Live Data View. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
8.13 Menu Tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
9.0 SRVIVR Interface Supplement 51
9.1 Download Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
9.2 Recorder Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
9.3 Audio Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
9.4 Live Data View. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
9.5 Menu Tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
10.0 FA5000/FA5001 Interface Supplement 55
10.1 Download Operations . . . . . . . . . . . . . . . . . . . . . . . . . . 55
10.2 Recorder Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
10.3 FDR Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
10.4 Audio Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
10.5 Live Data View. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
10.6 Menu Tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
11.0 SMITHS VADR Interface Supplement 60
11.1 Select Aircraft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
11.2 Download Operations . . . . . . . . . . . . . . . . . . . . . . . . . . 60
11.3 FDR Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
11.4 Upload OFP to the HHMPI . . . . . . . . . . . . . . . . . . . . . . 60

λ½±®¼ ±º ½¸¿²¹»
ìÑ°»®¿¬±® ³¿²«¿´
Ø¿²¼¸»´¼ Ó«´¬·óЫ®°±» ײ¬»®º¿½» øØØÓÐ×÷
1.0 Record of changes
List of figures
Figure 1.0 HHMPI front view. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Figure 2.0 HHMPI top view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Figure 3.0 HHMPI bottom view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Figure 4.0 HHMPI Mod 1 top view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Figure 5.0 HHMPI Mod 1 bottom view. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Figure 6.0 HHMPI kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Figure 7.0 Connecting the HHMPI to the FDR or CVR . . . . . . . . . . . . . . . . . . . . . . . . . 14
Figure 8.0 The Battery Status screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Figure 9.0 HHMPI power-on sequence. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Figure 10.0 Creating an Aircraft List in Notepad. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Figure 11.0 Adding aircraft to the Aircraft List on the HHMPI . . . . . . . . . . . . . . . . . . . 21
Figure 12.0 Configuring the prompt for tail number option . . . . . . . . . . . . . . . . . . . . 23
Figure 13.0 Downloading progress bar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Figure 14.0 Downloading and decompressing CVR data . . . . . . . . . . . . . . . . . . . . . . . 25
Figure 15.0 Decompressing Honeywell CVR file away from the aircraft. . . . . . . . . . . 26
Figure 16.0 Viewing live data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Figure 17.0 ARINC 717 settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Figure 18.0 Multiple live data view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Figure 19.0 Word offset adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Figure 20.0 Selected tail number on the shortcut screen . . . . . . . . . . . . . . . . . . . . . . . 31
Figure 21.0 Changing from Raw Mode to EU Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Figure 22.0 Accessing aircraft parameters alphabetically . . . . . . . . . . . . . . . . . . . . . . . 32
Figure 23.0 Four parameters populated with Engineering Units . . . . . . . . . . . . . . . . . 32
Figure 24.0 DHCP or manual IP configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Figure 25.0 Setting up the FTP client . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Figure 26.0 FTP type menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Figure 27.0 Login, password, remote path and FTP test . . . . . . . . . . . . . . . . . . . . . . . . 37
Table 1.0 Record of changes
Issue Date Comments
4 24 June 2011 New issue
5 20 July 2011 Added battery pack description
Added PCMCIA card description
Added appendices
6 9 September 2011 Added FTP setup
Added wireless USB
Added updated live data view
Added troubleshooting
Issue B 12 November 2013 Added CVR decompression instructions
Added CVR adapter instructions
Added HHMPI cradle features
Added aircraft settings
Issue C 3 December 2013 Updated references
Added screen captures to upload VADAR
Program
MOD table update
Issue D 22 May 2014 Updated layout
Added Engineering Units section

Ô·¬ ±º ¬¿¾´»
Ñ°»®¿¬±® ³¿²«¿´ ë
ÚÜÍ ìððóíðï
Figure 28.0 Viewing the wired IP address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Figure 29.0 Web interface login. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Figure 30.0 Web interface screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Figure 31.0 Device configuration screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Figure 32.0 Device configuration screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Figure 33.0 Device configuration screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Figure 34.0 Logout button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Figure 35.0 Connecting to a wireless network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Figure 36.0 Configuring security settings like the encryption type and key . . . . . . . 44
Figure 37.0 FA2100 Recorder Operations - Dump Debug Trace . . . . . . . . . . . . . . . . . 49
Figure 38.0 CVR Live Audio volume control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Figure 39.0 SRVIVR Download Operations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Figure 40.0 SRVIVR Recorder Operations - Information . . . . . . . . . . . . . . . . . . . . . . . . 53
Figure 41.0 SRVIVR Recorder Operations - Self Test . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Figure 42.0 FA5000/FA5001 Download Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Figure 43.0 FA5000/FA5001 Recorder Operations - FDR Status . . . . . . . . . . . . . . . . . . 57
Figure 44.0 FA5000/FA5001 Recorder Operations - Dump Log . . . . . . . . . . . . . . . . . . 57
Figure 45.0 CVR Live Audio volume control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Figure 46.0 VADR information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Figure 47.0 Uploading OFP to the VADR from the HHMPI . . . . . . . . . . . . . . . . . . . . . . 61
List of tables
Table 1.0 Record of changes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Table 2.0 HHMPI models and description of modifications applied . . . . . . . . . . . . . 6
Table 3.0 HHMPI equipment list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Table 4.0 Interface cables and software options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Table 5.0 Specifications HHMPI Mod 5 (no battery). . . . . . . . . . . . . . . . . . . . . . . . . . 10
Table 6.0 Specifications HHMPI Mod 1 and 5 (battery) . . . . . . . . . . . . . . . . . . . . . . . 11
Table 7.0 Troubleshooting common issues with the HHMPI . . . . . . . . . . . . . . . . . . 45
Table 8.0 File extensions of files downloaded from the FA2100 . . . . . . . . . . . . . . . 48
Table 9.0 Additional menu items for FA2100 CVFDR . . . . . . . . . . . . . . . . . . . . . . . . . 50
Table 10.0 File extensions of files downloaded from the SRVIVR. . . . . . . . . . . . . . . . 52
Table 11.0 Additional menu items for SRVIVR CVFDR . . . . . . . . . . . . . . . . . . . . . . . . . 54
Table 12.0 Additional menu items for FA5000/FA5001 CVFDR . . . . . . . . . . . . . . . . . 58
Table 13.0 File extensions of files downloaded from the Smiths VADR . . . . . . . . . . 60
2.0 Introduction
The Handheld Multi-Purpose Interface (HHMPI) is a portable instrument for downloading
data from a Flight Data Recorder (FDR) and audio from a Cockpit Voice Recorder (CVR). It
is connected to the recorder via an interface cable which identifies the attached recorder
type. The downloaded data is stored in one of the following memory options: internal
memory, USB flash drive, Compact Flash card, SD card, or optional PCMCIA card.

ײ¬®±¼«½¬·±²
êÑ°»®¿¬±® ³¿²«¿´
Ø¿²¼¸»´¼ Ó«´¬·óЫ®°±» ײ¬»®º¿½» øØØÓÐ×÷
2.1 HHMPI models
Figure 1.0 HHMPI front view
Table 2.0 HHMPI models and description of modifications applied
HHMPI modifications Description
Mod 1 External battery with PCMCIA card slot
Mod 2 Firmware enhancement FA2100 CVR software (ADF)
Mod 3 VADR software interface implemented (ADF)
Mod 4 MCR500 software interface implemented (ADF)
Mod 5 Version 2 HHMPI
Mod 6 Internal battery on HHMPI added
Mod 7 Docking cradle
Mod 8 Audio jack added for CVR capability (ADF)
Mod 9 New revision firmware added (ADF)
Mod 10 New revision firmware added (ADF)
Legend
External devices connected:
recorder, external memory device,
Ethernet, USB flash drive 1.
User programmable shortcut keys
(4) 2.
OK button and cursor keys (4) 3.
Cancel / exit 4.

ײ¬®±¼«½¬·±²
Ñ°»®¿¬±® ³¿²«¿´ é
ÚÜÍ ìððóíðï
Figure 2.0 HHMPI top view
Figure 3.0 HHMPI bottom view

ײ¬®±¼«½¬·±²
èÑ°»®¿¬±® ³¿²«¿´
Ø¿²¼¸»´¼ Ó«´¬·óЫ®°±» ײ¬»®º¿½» øØØÓÐ×÷
Figure 4.0 HHMPI Mod 1 top view
Figure 5.0 HHMPI Mod 1 bottom view

ײ¬®±¼«½¬·±²
Ñ°»®¿¬±® ³¿²«¿´ ç
ÚÜÍ ìððóíðï
Figure 6.0 HHMPI kit
2.2 HHMPI equipment
Table 3.0 HHMPI equipment list
Part number Description Applicable mod status
DF136 Quick reference guide, HHMPI All
FDS400-107 Cable USB, HHMPI to PC All
FDS400-301 HHMPI Mod 5
FDS400-301 HHMPI with internal battery Mod 5, 6
FDS400-301 HHMPI with external battery and PCMCIA card Mod 1, 5
FDS400-302 USB flash drive (2GB) All
FDS400-303 Compact flash card, HHMPI Option - all
FDS400-304 SD card, HHMPI Option - all
FDS400-321 Carry case, yellow All except Mod 1
FDS400-322 Power adapter kit, global, charger for internal battery Mod 6
FDS400-334 Carry case, black Mod 1
FDS400-373 Docking cradle Mod 7

ײ¬®±¼«½¬·±²
ïð Ñ°»®¿¬±® ³¿²«¿´
Ø¿²¼¸»´¼ Ó«´¬·óЫ®°±» ײ¬»®º¿½» øØØÓÐ×÷
2.3 Accessories
2.4 Specifications
Table 4.0 Interface cables and software options
Accessory part number Description
FDS400-107 Cable USB, HHMPI to PC
FDS400-201 Interface cable, L-3 AR, F1000
FDS400-202 Interface cable, L-3 AR, FA2100
FDS400-203 Interface cable, HNY, SSFDR, (DC or Battery HHMPI only)
FDS400-204 Interface cable, HNY, UFDR, SSDFDR
FDS400-208 Interface cable, HNY, AR series
FDS400-209 Interface cable, L-3 EDI, SRVIVR
FDS400-210 Interface cable, HNY, Light weight
FDS400-212 Interface cable, MCR500
FDS400-215 Interface cable, SSCVR, Rack adapter and aircraft
FDS400-216 Interface cable, HYN, SSCVR, Bench download cable
FDS400-223 Interface cable, L-3 AR, FA5000/FA5001
FDS400-224 Interface cable, UASC, CVFDR, CVR, FDR
FDS400-227 Interface cable, HNY, DVDR
FDS400-232 Interface cable, HNY, HFR5-D
FDS400-246 Interface cable, HNY, AR CVR/Combi
FDS400-241 Interface cable, L-3 Micro QAR
FDS400-257 Interface cable adapter, MCR500 to SCR500
FDS400-258 Audio breakout fixture, MCR500 to SCR500
FDS400-259 Audio test fixture, SCR500
FDS400-331 Card reader, PCMCIA, option
FDS400-332 Wireless interface, USB 802.11g, option
FDS400-379 L-3 FA2100 CVR download and decompression software
FDS400-380 HNY CVR download and decompression software
Table 5.0 Specifications HHMPI Mod 5 (no battery)
Parameter
Weight HHMPI: 330 g
HHMPI kit: 3 kg (see Figure 6.0, HHMPI kit, on page 9)
Shipping: 4 kg
Dimensions: L x W
x H
HHMPI: 145 x 95 x 35 mm
HHMPI kit: 365 x 270 x 135 mm
Power USB or FDR/CVR interface cable
Environmental
protection
IP-40
Temperature Operating: -20°C to +60°C
