FLUANCE@
08·200
Active
Powered
Subwoofer
Instruction
Manual
Read this manual carefully to get the best performance from this unit.
INTRODUCTION: Your choice
of
this product indicates that you are devoted to excellence
in
sound reproduction. We appreciate your patronage and take pride
in
the quality components that
our company produces.
To
ensure best performance, we suggest that you read this manual
before you hook up and operate your system. This will familiarize you with operating features and
connections so that your listening experience will be optimal.
You
will agree that
in
all aspects
of
our products we have anticipated your needs and desires and provided everything necessary to
resolve them.
WARNING: Read this section carefully to ensure safe operation. Units are designed for operation
as follows: AC 110V.
To
reduce risk
offire
or electric shock, do not expose this appliance to rain,
water or moisture.
Safetyprecautions
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
A
ACAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO
NOT
....
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
THE LIGHTING FLASH WITH ARROWHEAD SYMBOL, WITHIN
AN
EQUILATERAL TRIANGLE,
IS
INTENDED TO ALERT THE USER TO
THE PRESENCE OF UNINSULATED "DANGEROUS VOLTAGE" WITHIN
THE
PRODUCT'S
ENCLOSURE THAT MAY
BE
OF SUFFICIENT
MAGNITUDE TO CONSTITUTE ARISK OF ELECTRIC SHOCK TO
PERSONS.
THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE
IS
INTENDEDTOALERTTHE USERTO THE PRESENCE OF IMPORTANT
OPERATING AND MAINTENANCE (SERVICING) INSTRUCTIONS
IN
THE LITERATURE ACCOMPANYING THE APPLIANCE.
IMPORTANT SAFEGUARDS: Please read and follow all safety and operating instructions before
operating this product. Adhere to all warnings.
Power -Use with apower supply only of the type marked
on
the product. Power-supply cords
should be routed so that they are not likely to be walked
on
or pinched by other items or furniture.
Pay particular attention to cords at plugs and the point where they exit the product.
Do
not defeat
the safety purpose of the polarized or grounding type plug. These are there for your safety. If the
plug does not fit into your outlet, consult
an
electrician for replacement
of
the obsolete outlet.
Ventilation -
Do
not block or cover any of the slots or ventilation openings. These are there to
ensure the product does not overheat. Since this unit has abuilt
in
power amplifier, heat will
radiate from the rear panel. Place the unit at least 4inches away from the walls and on astable
floor with the feet
on
the floor. Be sure to install the subwoofer vertically. Ensure proper
ventilation
in
all
installations.
Water -The product should not be used near water or moisture of any kind. Clean only with adry
cloth and unplug from the power source before doing so.
Do
not attempt to clean with chemical
solvents. Protect and keep away from the rain.
Temperature -
Do
not install near any heat sources or appliances that produce heat. This product
may not function properly if operated
in
the cold below +5°C (41°F). Install unit
in
acool,
dry,
clean
place, away from windows, heat sources, sources of excessive vibration, dust, moisture and cold.
Page 1
Electric Shock -Ensure not to spill
or
drop objects into the enclosure through openings. Metal
objects that come into contact with the inside
of
this product may produce electric shock. Never
remove the enclosure. Ifthe internal parts are touched, aserious electric shock might occur.
Refer all servicing to qualified service personnel.
Accessories -Use only authorized accessories. Do not place this product on any shelf, table
or
any other unstable object. The product moves during operation and could fall and cause injury
or
damage to the unit. Optimum results are obtained by using the device on aflat floor surface close
to the wall. When acart is used, use caution when moving the cart and apparatus combination to
avoid injury from overturning.
Lightning -Unplug the apparatus during lightning storms
or
when unused for long periods
of
time.
This will prevent damage to the unit during lightning and power surges.
Servicing -Refer all servicing to qualified personnel only. The user should not attempt to service
the product. Never open the cabinet. Servicing is required when the product has been damaged
in
any way, such as power supply cord
or
plug damage, liquid has been spilled
or
objects have
fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally
or
has been dropped.
INSTALLATION: The subwoofer is avirtually omnidirectional speaker, so it can be installed
in
almost any location. The subwoofer's deep bass performs best when it is installed
in
acorner
or
near awall. Since the low bass portion
in
audio
is
monaural,
only one subwoofer is necessary to
obtain asufficient low frequency effect.
This unit does not only enhance bass frequency response
of
sound output
in
your audio system,
but by reproducing the bass frequencies, the subwoofer permits your existing amplifier and
speakers to operate under less strenuous conditions, improving overall system performance.
Super bass frequencies reproduced by this unit may cause aturntable to generate ahowling
sound.
In
such cases, move this unit away from the turntable.
Caution concerning operation -An excessive input level to the subwoofer may impair the sound
quality
or
damage the unit. If you hear distortion coming from this unit, reduce the volume level.
Extremely loud playing
of
prerecorded bass heavy sounds can damage this speaker system.
CONNECTIONS: Before connection set the power switches
of
the amplifier and subwoofer to off.
Ifthe amplifier
or
receiver is equipped with asubwoofer pre-outjack, connect this to the line input
connection on the subwoofer using aRCAtype pin-plug. Ifthe amplifier
or
receiver is not
equipped with asubwoofer pre-outjack, connect the left and right front speaker level outputs from
your component to the speaker inputs on the subwoofer using speaker wire. When connecting
the subwoofer to the amplifier, be sure to always connect the "+" terminals to the "+" terminals
and the "-" terminals to the "-" terminals. Ifterminals are connected incorrectly, the amplifier may
be damaged.
Page 2
CONTROLS AND INDICATORS: REAR PANEL
000
FLUANCE'
08-200
~lo.§LI
~~
~~
~
c00
~~·I
~~
~
~
0,0
~~
~~
~f,O
'.
0
-=
I
~.'1
<"
':0:
--
:0:
00
00
,~.
6
'"
,.£..-
.
eSl'lAICU
0
~~~~
~~~~
e0
"''--0
~~~~ ~~~~
0
!l
-'-
•.
~_.
.2
-"'._~
-
-
00
~
0
1
2
3
4
5
6
7
8
9
1.
Phase select -This switch changes the phase of the sound output from the subwoofer.
You
can select from "Normal" or "Reverse" phase settings.
2.
Power switch -Select the power to the subwoofer On/Auto/Off. When the switch is
in
"Auto"
position, the unit will automatically turn on when asignal input is received by the unit, the unit
will turn off automatically when there is no signal for 15 minutes.
3.
Volume control knob -Adjusts the volume level of the output
of
the subwoofer. Rotating the
knob clockwise increases the volume level, and rotating the knob counterclockwise decreases
the volume level.
4.
Crossover control knob -Turn the control knob to adjust the cutoff frequency
of
the high-
frequency components
in
the sound output from the subwoofer. Adjusts the high frequency
cutoff point for the bass signal.
5.
Line input jack -These jacks are used to connect the subwoofer pre-out jacks
of
the amplifier
using aRCA type pin-plug.
6.
Speaker input connectors -These terminals are used to connect the front speaker high-level
signal from the amplifier as input for the subwoofer using speaker wire.
7.
Power switch -Turns the power
on
and off. The subwoofer automatically
returns to "Standby" mode when no signal has been input.
8.
Power cord connection -Used to connect the power input plug to the AC outlet.
9.
Fuse -AC fuse protector.
Page 3
CONTROLS AND INDICATORS: FRONT PANEL
------I*--Blue
LED
v\
Front blue LED Indicator -Power switch to off: LED turns off. Power switch to auto: while no
signal input LED turns off, while signal input LED turns on, if no signal input for successive 15
minutes LED will turn off. Power switch to on: LED turns on.
SPECIFICATIONS:
Type -Active Servo Subwoofer system with bulit-in amplifier (magnetically shielded)
Amplifier
Rated Output Power -200 watts RMS (4D180Hz)
Phase Switching -Normal, Reverse
Input Sensitivity &Input Impedance
RCA-type pin-plug jack - 1
OOmV
/12k 0
200mV /12k 0(mono input)
Push-type terminals -
1.
7V /15k0
Speaker
Enclosure -Bass-reflex floor standing type
Speaker unit -300 mm (12") cone type
Norminal Impedance -
40
General
Power Supply -AC
11
OV
/60 Hz
Dimensions -Width 355 mm, Height 470 mm, Depth 450 mm.
Weight -22
kg
*Fluance follows apolicy
of
continuous advancements
in
development. For this reason
specifications may be changed without notice.
For your records -Record the serial number, found
on
the back of the unit,
in
the spaces
provided below. Refer to the model and serial numbers whenever you call upon your dealer for
information or service
on
this product.
Model: _Serial Number: _
Page 4
