KEF PSW 3000 User manual
SERVICE MANUAL
CONTENTS
PARTS LIST:
LED ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
PRE AMPLIFIER ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4
POWER AMPLIFIER ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7
SMPS ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-8
PACKING ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
POWER CORD ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
CASING ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
CASING LED ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-10
CASING PRE AMP ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
CASING POWER AMP ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
CASING SMPS ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11-12
SPEAKER ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12-13
BLOCK DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
SCHEMATIC DIAGRAMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15-18
PCB LAYOUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19-21
EXPLODED VIEW DIAGRAMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22-24
POWERED SUBWOOFER
POWERED SUBWOOFER
2
PARTS LIST
LED ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
11681-1000-A UL1007 AWG#20 BLACK L=310MM RF101
13700-4536-RG L-115W EGW/209EGW RED/GR LED301
13700-9528-0 LED DISP LR2x5-10B-YYB LED302
24860-8710-5 TR 9012H Q307,310
84860-8720-5 TR 9013H SAMSUNG Q301, 302, 303, 304, 305,
306, 308, 309
1157C-107M-5-IU CE 10V 100µF 20% RL 5x11 C301
54701-101J-2 RCF 1/8W 100R 5% AT R301,302,303,304,305
14701-102J-2 RCF 1/8W 1K 5% AT R320
74701-103J-2 RCF 1/8W 10K 5% AT R311, 312, 313, 314, 315,
321, 322
24701-203J-2 RCF 1/8W 20K 5% AT R317,318
54701-331J-2 RCF 1/8W 330R 5% AT R306,307,308,309,310
14701-331J-C RCF 1/8W 330R 5% ATS R121
24701-472J-2 RCF 1/8W 4.7K 5% AT R316,319
10 4840-8060-2 DIODE 1N4148 NS D301, 302, 303, 304, 305,
306, 307, 308, 309, 310
11725-546A-0001 LED PCB FC3T0C 94HB
PRE AMP ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
10 150D-104M-P-AC CC 16V 0.1µF 20% C120, 121, 122, 123, 124,
125, 126, 127, 128, 129
1150F-101K-5-IEA CC 50V 100pF 10% RL 5X3 C14
4150F-104M-N-FD CC 50V 0.1µF 20% RLF C19,30,109,110
5150F-224M-N-II CC 50V 0.22µF 20% RLF MO C20,21,22,23,29,
8150F-334M-N-JJA CC 50V 0.33µF 20% RLF MO C5, 10, 101, 102, 103,
104, 105, 106
1153H-123K-5-KUA CM 100V 0.012µF 10% RL C28
1153H-273J-5-MQA CM 100V 0.027µF 5% RL 7X C25
1153H-393K-5-MRA CM 100V 0.039µF 10% RL C24
1153H-683K-5-PSA CM 100V 0.068µF 10% RL C26
1153H-822J-5-WQ CM 100V 0.0082µF 5% RL C27
4153H-823K-5-QSA CM 100V 0.082µF 10% RL C2,4,8,9
1157C-108M-5-O5 10V 8*15.5 1000µF+-20% A C157
1157D-107M-5-KW CE 16V 100µF 20% RL 6x12 C17
1157D-227M-5-KW CE 16V 220µF 20% RL 6x12 C111
1157D-476M-5-IU CE 16V 47µF 20% RL 5x11 C18
3
POWERED SUBWOOFER
PARTS LIST
PRE AMP ASSEMBLY
CONTINUED
QTY PART NO DESCRIPTION LOCATION
1157D-477M-5-OVK CE 16V 470µF 20% RL C16
1157E-106M-5-IU CE 25V 10µF 20% RL 5x11 C15
13 157F-225M-5-IU CE 50V 2.2µF 20% RL 5x11 C1, 3, 7, 11, 13, 35, 150,
151,152,153,154,155,156
215CG-470J-7-IJ CTC 0/30 47pF 5% RM C107,108
21801-220K-M COIL 22µH 10% AL BL7 L101,102
21808-0670-0 FERRITE BEAD 26430000101 FB102,103
11808-9080-0 FERR BEAD 43120203106 1- FB101
12101-1357-0 WAFER JM2411-8 8PIN CN7
12101-1781-0 20 WAY IC SOCKET-DUAL IN U104
12101-9320-0 WAFER JM24182-11P CN102
12101-9790-0 4RCA JACK HSP-204V-03 GP RCA1
12703-0190-0 CR RESONATOR XTAL101
10 3131-6140-0 IC BA4560 ROHM U1,2,3,4,5,6,7,8,101,102
13131-7730-0 MCU AT89C4051-24PI ATMEL U104
13131-7740-0 EEPROM AT24C02-10PI U103
14132-1551-0 TERMINAL OUT PUT GND
24152-6890-0 RUBBER PAD 2617-19-0 W/B RF101
14701-100J-2 RCF 1/8W 10R 5% AT R129
24755-4746-2 SVR B470K 6MM TYPE VERTICAL TY TP104,105
34756-2026-3-05 SVR B2K H3 NVZ6TL1 HDK TP101,102,103
14859-014C-5 TR 9014C HFE 200-600 Q101
34860-8710-5 TR 9012H Q3,4,7
54860-8720-5 TR 9013H SAMSUNG Q1,2,5,6,16
74860-8770-0 TR FET J112 Q8,9,10,11,12,13,14
15200-3281-0-06 SW COMAX SW102
15200-4801-0 SW TACT X2 KPT-2105B SW101
17010-2221-0 3 PIN SHIELD WIRE ASSY CN1
17010-2222-0 3 PIN FLAT CABLE ASSY CN2
27011-3240-0 2254 1533 #26 2X2PIN BRN CN5,101
27011-4570-0 AMP108U AWG26 180MM BRWN CN4,6
28910-0042-0 CE 50V 300µF C6,12
18912-0003-0 RF RECEIVER MODULE DUAL RF101
14701-101J-2 RCF 1/8W 100R 5% AT R136
44701-102J-2 RCF 1/8W 1K 5% AT R10,22,37,40
24701-472J-2 RCF 1/8W 4.7K 5% AT R35,38
10 4701-103J-2 RCF 1/8W 10K 5% AT R5, 8, 18, 24, 25, 28, 36,
130, 132
POWERED SUBWOOFER
4
PARTS LIST
PRE AMP ASSEMBLY
CONTINUED
QTY PART NO DESCRIPTION LOCATION
12 4701-104J-2 RCF 1/8W 100K 5% AT R4, 16, 50, 52, 54, 55, 68,
91, 93, 126, 154, 157
13 4701-105J-2 RCF 1/8W 1M 5% AT R135, 140, 141, 143, 144,
146, 147, 149, 150, 153,
156, 158, 159
14701-123J-2 RCF 1/8W 12K 5% AT R44
44701-125J-C RCF 1/8W 1.2M 5% ATS R30,103,106,109
34701-184J-2 RCF 1/8W 180K 5% AT R101,105,108
34701-203J-2 RCF 1/8W 20K 5% AT R102,104,107
44701-222J-2 RCF 1/8W 2.2K 5% AT R9,23,33,34
64701-223J-2 RCF 1/8W 22K 5% AT R1,13,90,92,161,162
14701-224J-2 RCF 1/8W 220K 5% AT R27
14701-225J-2 RCF 1/8W 2.2M 5% AT R31
14701-273J-2 RCF 1/8W 27K 5% AT R42
14701-333J-2 RCF 1/8W 33K 5% AT R43
14701-362J-2 RCF 1/8W 3.6K 5% AT R59
44701-363J-2 RCF 1/8W 36K 5% AT R46,47,48,49
14701-433J-2 RCF 1/8W 43K 5% AT R45
24701-471J-2 RCF 1/8W 470R 5% AT R29,39
24701-472J-2 RCF 1/8W 4.7K 5% AT R35,38
64701-473J-2 RCF 1/8W 47K 5% AT R120, 121, 122, 123, 124,
125
24701-512J-2 RCF 1/8W 5.1K 5% AT R133,134
54701-513J-2 RCF 1/8W 51K 5% AT R142,145,148,151,160
24701-514J-2 RCF 1/8W 510K 5% AT R152,155
14701-562J-2 RCF 1/8W 5.6K 5% AT R131
14701-563J-2 RCF 1/8W 56K 5% AT R26
24701-682J-2 RCF 1/8W 6.8K 5% AT R56,57
24701-683J-2 RCF 1/8W 68K 5% AT R32,60
14701-752J-2 RCF 1/8W 7.5K 5% AT R53
14701-822J-2 RCF 1/8W 8.2K 5% AT R51
24701-912J-2 RCF 1/8W 9.1K 5% AT R2,14
44718-391J-2-X RMF 1W 390R 5% AT R11,12,20,21
14837-3V36-2 DZ 1/2W +-5% 3.3V "TEMIC" AT Z1
24837-5V16-2 DZ 1/2W 5.1V "TEMIC" AT Z2,3
24840-8060-2 DIODE 1N4148 NS D1,2
11725-541A-0001 PCB POWER AMP FC3T03C
5
POWERED SUBWOOFER
PARTS LIST
POWER AMP ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
4150F-101K-5-IEA CC 50V 100pF 10% RL 5X3 C204,222,224,226
6150F-104M-N-FD CC 50V 0.1µF 20% RLF C205, 207, 227, 252, 503,
504
1150F-470K-5-IEA CC 50V 47pF 10% RL 5X3 C225
2150F-471K-5-IEA CC 50V 470pF 10% RL 5x3 C202,217
2150F-681J-5-OI CC 50V 680pF 5% RL 8X5 C235,236
1153H-102K-5-INA CM 100V 0.001µF 10% RL C223
2153H-104K-5-QUA CM 100V 0.1µF 10% RL C209,211
2153H-224K-5-VYA CM 100V 0.22µF 10% RL C219,229
1153I-154J-9-NL CM 63V 0.15µF 5% RB 7.5x C201
2157D-107M-5-KW CE 16V 100µF 20% RL 6x12 C216,250
2157D-227M-5-KW CE 16V 220µF 20% RL 6x12 C206,208
4157D-476M-5-IU CE 16V 47µF 20% RL 5x11 C251,253,505,506
2157F-476M-5-OWK CE 50V 47µF 20% RL 8x12 C501,502
2157E-106M-5-IU CE 25V 10µF 20% RL 5x11 C220,232
2157F-105M-5-IU CE 50V 1µF 20% RL 5x11 C218,230
2157F-225M-5-IU CE 50V 2.2µF 20% RL 5x11 C228,248
1157F-474M-5-IU CE 50V 0.47µF 20% RL C233
2157I-107M-5-SX CE 63V 100µF 20% RL C221,234
1157Q-476M-5-LUA CE 35V 47µF 20% RL 6.5X11 C231
11806-2374-0 TT-9974 TOROIDAL CHOKE T L201
11806-2393-0 TT-9904 LE 1012A 1X12TX6 L202
12101-1380-0 HEADER 4P P=5MM VERTICAL CN201
12101-9120-0 JM24182-2P WAFER CN206
12101-9130-0 JM24182-4P WAFER CN501
13130-2020-2 IC 7805 REG 5V U205
13130-3550-0 IC TA7317P U206
13130-4080-0 IC TL072CP DUAL FET OP U204
13130-9150-0 IC LM3080N OTA NATIONAL U203
23131-7220-0 IC TL062 LOW POWER JFET U201,202
14132-1551-0 TERMINAL OUT PUT GND
24132-1551-0 TERMINAL OUT PUT SPK+,SPK-
14500-0890-0 RELAY 12VDC,250VAC,10A RLY202
14500-8090-0 RELAY RUDH-SH-124D "GOOD RLY201
14718-100J-C-X RMF 1W 10R 5% ATS METAL R249
4474B-0R1J-1 RWR 5W 0.1 5% AL R236,238,241,245
14756-2036-3-15 SVR B20K H3 VZ067TL7B TP201
14860-1260-5 TR 2N3906 SAMSUNG RL Q201
14860-2280-5 TR TIP42C SGS Q208
POWERED SUBWOOFER
6
PARTS LIST
POWER AMP ASSEMBLY
CONTINUED
QTY PART NO DESCRIPTION LOCATION
24860-8470-0 TR TIP41C SGS Q203,207
14860-8720-5 TR 9013H SAMSUNG Q202
24860-8890-0 TR MPS A06 VCE 80V NS Q205,206
24860-8910-0 TR MPS A56 VCE 80V NS Q204,213
28910-0115-0 CE 4700UF 63V 20% RL C210,212
18910-0196-0 THERMISTOR NTH4G 10K 1% TH201
10 4701-101J-2 RCF 1/8W 100R 5% AT R206, 207, 230, 234, 235,
237, 239, 240, 242, 244
24701-102J-2 RCF 1/8W 1K 5% AT R214,226
84701-103J-2 RCF 1/8W 10K 5% AT R204, 208, 209, 211, 213,
223, 224, 258
44701-104J-2 RCF 1/8W 100K 5% AT R203,215,253,254
34701-123J-2 RCF 1/8W 12K 5% AT R216,232,267
14701-125J-C RCF 1/8W 1.2M 5% ATS R219
34701-153J-2 RCF 1/8W 15K 5% AT R202,227,228
14701-154J-2 RCF 1/8W 150K 5% AT R210
24701-183J-2 RCF 1/8W 18K 5% AT R256,261
24701-202J-2 RCF 1/8W 2K 5% AT R221,225
24701-203J-2 RCF 1/8W 20K 5% AT R205,218
14701-272J-2 RCF 1/8W 2.7K 5% AT R231
24701-333J-2 RCF 1/8W 33K 5% AT R257,260
14701-334J-2 RCF 1/8W 330K 5% AT R222
24701-391J-2 RCF 1/8W 390R 5% AT R229,233
14701-392J-2 RCF 1/8W 3.9K 5% AT R271
14701-393J-2 RCF 1/8W 39K 5% AT R212
14701-473J-2 RCF 1/8W 47K 5% AT R201
14701-513J-2 RCF 1/8W 51K 5% AT R270
14701-514J-2 RCF 1/8W 510K 5% AT R220
44701-562J-2 RCF 1/8W 5.6K 5% AT R246,247,248,263
44701-563J-2 RCF 1/8W 56K 5% AT R251,252,255,259
14701-913J-2 RCF 1/8W 91K 5% AT R217
14705-181J-2 RCF 1/4W 180R 5% AT R137
14707-152J-2 RCF 1/2W 1.5K 5% AT R262
34718-100J-C-X RMF 1W 10R 5% ATS METAL R250,265,266
2471B-512J-1-X RMF 5W 5.1K 5% AL METAL R501,502
34804-0010-2 DIODE 1N4001 AT D210,211,212
10 4840-8060-2 DIODE 1N4148 NS D201, 202, 203, 204, 205,
206, 207, 208, 209, 213
7
POWERED SUBWOOFER
POWER AMP ASSEMBLY
CONTINUED
QTY PART NO DESCRIPTION LOCATION
22954-2606-0000 SCREW BT 2.6X6 U501,502
22954-3008-3000 T3X8MM SELF TAPPING U501,502
13130-2520-2 IC 7812H 12V REG, T0220F U502
13130-3800-0 IC UPC79M12HF REGULATOR U501,502
25400-9130-0 HEAT SINK FOR 7805 2438- U501,502
SMPS ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
8150F-104M-N-FD CC 50V 0.1µF 20% RLF C16, 17, 18, 19, 20, 22,
28, 32, 33, 34
1150N-101K-5-MHA CC 1KV 100pF 10% RL C7
2150N-471K-5-MHA CC 1KV 470pF 10% RL C9,10
2150R-332M-5-1OA CC 250V 3300pF 20% RL DE1 C3,4
1153H-102K-5-INA CM 100V 0.001µF 10% RL C23
2153H-103K-5-KNA CM 100V 0.01µF 10% RL C25,27
1153H-222K-5-INA CM 100V 0.0022µF 10% C26
1153H-472K-5-JNA CM 100V 0.0047µF 10% RL C24
2153Z-334M-5-YUM CM 275V 0.33µF 20% RL C1,2
1157F-107M-5-OW CE 50V 100µF 20% RL 8x12 C30
1157F-107M-5-OWK CE 50V 100µF 20% RL 8x12 C31
1157F-225M-5-IUK CE 50V 2.2µF 20% RL 5x11 C29
2157Q-477M-5-S9T CE 35V 470µF 20% 10X20 C8,13
2157I-108M-5-5$K CE 63V 1000µF 20% RL 16X C11,12
2157R-567M-5-#$T CE 250V 560µF 20% RL 105 C5,6
11681-1000-A UL1007 AGW#20 BLACK GND
11806-2372-0 TT-9972 GATE DRIVER TRAN T1
21806-2373-0 TT-9973 DIFFERENTIAL MOD L1,2
11806-2380-0 CURRENT TRANSFORMER T4
11806-2437-0 TT-01001 EE-42 POWER T3
11806-2442-0 CHOKE O/P T131-26 L5
11806-2443-0 COMMON MODE EE-35 L3
11806-2444-0 X-TRANSFORMER EI-28 T2
81808-0670-0 FERRITE BEAD 26430000101 FB5,6,7,8,9,10,11,12
11808-9030-0 ARRESTER 230V DC 5KA M2P G1
61808-9080-0 FERR BEAD 43120203106 1- FB1 TO FB4,FB13,14
12101-1343-0 WAFER 2219S-03-E2 P=7.92 CN1
13131-5550-0 IC KA3842B SAMSUNG U3
PARTS LIST
POWERED SUBWOOFER
8
SMPS ASSEMBLY
CONTINUED
QTY PART NO DESCRIPTION LOCATION
44154-0841-0 INSULATION BUSHING D8-D11
44154-0841-0 INSULATION BUSHING Q1-Q4
24705-103J-2 RCF 1/4W 10K 5% AT R24,26
14705-472J-2 RCF 1/4W 4.7K 5% AT R20
14719-101J-C-X RMF 2W 100R 5% ATS METAL R10
24719-470J-C-X RMF 2W 47R 5% ATS METAL R13,14
14756-1026-3-07 SVR B1K H3 VZ067TL7B TP1
44840-8210-0 DIODE MUR 1540 D8,9,10,11
14840-8240-0 DIODE BR108 BRIDGE RECTI D1
24853-9040-5 TR 2N3904 SAMSUNG Q6,7
14860-2390-5 TR 2N3906 NS Q5
44860-8950-0 TR FET IRF840 (IR) Q1,2,3,4
15202-0001-0 NTC THERMISTER SCK057 NTC1
45400-9320-0 2617-4-B HEAT SINK Q1-Q4 D8-D11
17010-0150-0 CN ASSY UL1007 #20 L=120 BROWN JPW1
17010-0160-0 CN ASSY UL1007 #20 L=120 RED JPW2
17010-2352-0 WIRE CON ASSY 4P+2P+2P CN2
17010-2355-0 WIRE CON ASSY 4P L=500MM CN3
54705-102J-2 RCF 1/4W 1K 5% AT R6,9,29,36,37
24705-152J-2 RCF 1/4W 1.5K 5% AT R31,32
14705-203J-2 RCF 1/4W 20K 5% AT R28
14705-204J-2 RCF 1/4W 200K 5% AT R23
14705-220J-2 RCF 1/4W 22R 5% AT R18
14705-241J-2 RCF 1/4W 240R 5% AT R19
14705-243J-2 RCF 1/4W 24K 5% AT R30
14705-471J-2 RCF 1/4W 470R 5% AT R21
24705-472J-2 RCF 1/4W 4.7K 5% AT R11,33
44705-510J-2 RCF 1/4W 51R 5% AT R4,5,7,8
14705-821J-2 RCF 1/4W 820R 5% AT R22
24707-104J-2 RCF 1/2W 100K 5% AT R2,3
14707-474J-2 RCF 1/2W 470K 5% AT R1
54804-0010-2 DIODE 1N4001 AT D13,14,15,16,17
44837-18V6-2 DZ 1/2W 18V 5% TEMIC AT Z1,2,3,4
14837-30V6-2 DZ 1/2W 30V 5% TEMIC AT Z5
54840-8060-2 DIODE 1N4148 NS D19,20,21,22,23
44840-8520-2 RECTIFIER UF4003 GI AT D4,5,12,18
24840-8530-2 RECTIFIER UF4006 GI AT D2,3
11725-542A-0001 SMPS PCB FC3T0C S/S FR4
PARTS LIST
9
POWERED SUBWOOFER
PACKING ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
11497-1932-0 POLYBAG 04x5x9" w/PE-LD REMOTE
12150-7001-0 NAME PLATE RF REMOTE REMOTE
24060-0530-0 GREENCELL 3A SIZE GP24G2 PACKING
44153-7941-0 K100081B BLANKING PIN BK SPK-
44153-7951-0 K100081J BLANKINGPIN RED SPK+
18912-0002-1 RF REMOTE DUAL CHANNAL PACKING
POWER CORD ASSEBLY
QTY PART NO DESCRIPTION LOCATION
17011-6220-0 H05VV-F 0.75MM/3C 2M BLK *EU
17011-5030-0 TC1490GP 3 CORE CORD 1/P *UK
17011-6210-0 SJT #18 /3C 2M BLK POWER CORD *US
12101-9140-0 WAFER JM24182-3P RF101
CASING ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
11403-6680-0 SWITCH POWER TOP COVER TOP COVER
11403-6690-0 SWITCH POWER BOTTOM BOTTOM
11403-6700-0 REAR PANEL FC3T0C HEATSINK
42103-7001-0 BINDING POST RED SPK IN+
42103-7101-0 BINDING POST BLK SPK IN-
82600-5008-1000 METAL WASHER M5X0.8X10MM SPK IN+
22606-3005-0643 INT TEETH WASHER M3X0.5X6.4MM REAR PANEL
82904-3006-3000 SCREW M3X6 BINDING (BLK) REAR PANEL
62944-3008-3000 S-TITE 3X8 (BLK) REAR PANEL
12954-3008-3000 T3X8MM SELF TAPPING RCA1
13100-5951-0 NET DUST FILTER FC3T0C REAR PANEL
14153-1250-0 2209 SW COVER 1-41-112 SW1
17010-2237-0 HOUSING ASSY JP2411-8P FOR SPK/IN
CASING LED ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
1153H-104K-5-QUA CM 100V 0.1µF 10% RL C158
11808-0170-0 CLAMP CORE FOR EMI/RFI FB104
13100-6051-0 LED HOLD
16360-1322-0 PLASTIC CABLE TIE 200MM FB104
PARTS LIST
POWERED SUBWOOFER
10
CASING LED ASSEMBLY
CONTINUED
QTY PART NO DESCRIPTION LOCATION
17011-9360-0 UL1007 AWG#26 RAINBOW CN301
18912-0003-0 RF RECEIVER MODULE DUAL RF101
64152-6890-0 RUBBER PAD 2617-19-0 W/DOUBLE RF101
17010-0060-0 CN ASSY UL2547 #26 L=210 3P M/F RF101
11681-1000-A UL1007 AWG#20 BLACK L=620MM RF101
CASING PRE AMP ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
42607-3009-0550 SPRING WASHER M3X0.9X5.5 PRE PCB
42904-3006-3000 SCREW M3X6 BINDING (BLK) PRE PCB
24135-0901-0 PCB BRACKET FC3T0C PRE PCB
CASING POWER AMP ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
42600-3005-0800 METAL WASHER M3X0.5X8MM PCB
42600-3005-0800 METAL WASHER M3X0.5X8MM Q209 TO Q212
42607-3009-0550 SPRING WASHER M3X0.9X5.5 H.S BRACKET
42607-3009-0550 SPRING WASHER M3X0.9X5.5 HEATSINK
42607-3009-0550 SPRING WASHER M3X0.9X5.5 PWRM PCB
42607-3009-0550 SPRING WASHER M3X0.9X5.5 Q209 TO Q212
42900-3010-3000 SCREW PH M3X 10 MM BZ CR HEATSINK
42904-3006-3000 SCREW M3X6 BINDING (BLK) PRE PCB
42954-3010-3000 B-TITE 3X10MM (BLK.ZN) H.S BRACKET
42954-3014-3000 B-TITE 3X14MM(BLK.ZN) Q209 TO Q212
43100-3171-0 MICA SHEET A (24X20) Q209 TO Q212
44133-9580-0 BRASS TUBE 2751-10-0 HEATSINK
24135-0911-0 HEATSINK BRACKET FC3T0C HEATSINK
24860-5050-5 TR 2SC5200 T0-3P (L) TOSHIBA Q210 Q211
24860-5060-5 TR 2SA1943 T0-3P (L) TOSHIBA Q209 Q212
15200-3570-0 SW CB-SL1412 AM1BCEI AC SW2
15400-3401-0 HEATSINK FC3T0C Q209 TO Q212
PARTS LIST
11
POWERED SUBWOOFER
CASING SMPS ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
11403-6680-0 SWITCH POWER TOP COVER TOP COVER
11403-6690-0 SWITCH POWER BOTTOM BOTTOM COVER
11806-2375-0 TT-9975 EARTH TOROIDAL C L7
11806-3556-0 CHOKE TRANSFORMER EI-41 L8
12113-9535-0 HALO BUSHING 0813C BOTTOM COVER
42600-3005-0803 METAL WASHER M3X0.5X8MM FAN1
42600-3005-0803 METAL WASHER M3X0.5X8MM PCB
22600-3005-0803 METAL WASHER M3X0.5X8MM TOP COVER
12606-4008-0853 INT TOOTH WASHER M4X0.8X L7
12606-4008-0853 INT TOOTH WASHER M4X0.8X RING T'NAL
42607-3009-0553 SPRING WASHER M3X0.9X5.5 FAN1
22607-3009-0553 SPRING WASHER M3X0.9X5.5 IEC1
62607-3009-0553 SPRING WASHER M3X0.9X5.5 PCB,L8
22607-3009-0553 SPRING WASHER M3X0.9X5.5 TOP COVER
12607-4010-0704 SPRING WASHER M4X1X7MM N L7
12607-4010-0704 SPRING WASHER M4X1X7MM N RING T'NAL
22640-3022-0544 M3 NUT NI IEC1
22640-3022-0544 M3 NUT NI L8
12640-4030-0704 NUT HEX M4 CN3
12640-4030-0704 NUT HEX M4 L7
42900-3008-3000 SCREW M3x8 PM BZ PCB
22900-3008-3000 SCREW M3x8 PM BZ SW2
22900-3008-3000 SCREW M3x8 PM BZ TOP COVER
42950-3008-0020 SCREW B-TITE PH M3X 8 MM D8-D11
42950-3008-0020 SCREW B-TITE PH M3X 8 MM Q1-Q4
62900-3010-3000 SCREW PH M3X 10 MM BZ CR FAN,L8
22900-3010-3000 SCREW PH M3X 10 MM BZ CR IEC1
42944-3008-3000 S-TITE 3X8 (BLK) TOP COVER
43100-8040-0 MICA T-400 8302 18X12.7M D8-D11
43100-8050-0 MICA T-400 T03P 25X20M T Q1-Q4
14135-1701-0 TERMINAL RING COPPER TIN CN2 CN3
14153-3331-0 EVA GASKET 5*500 TOP COVER
14153-3800-1 POWER INLET SOCKET IEC1
25120-9001-0 CERAMIC 5X20MM FUSE 250V F1
15200-3570-0-00 SW SY-113C12N AC SELECTO SW2
15200-9123-0 ROCKER SW 1P1T M372-499- SW1
16360-0011-0 PLASTIC CABLE TIE 97MM CN1
86360-0011-0 PLASTIC CABLE TIE 97MM CN2 CN3
16360-0011-0 PLASTIC CABLE TIE 97MM SW2
PARTS LIST
POWERED SUBWOOFER
12
CASING SMPS ASSEMBLY
CONTINUED
QTY PART NO DESCRIPTION LOCATION
16360-0011-0 PLASTIC CABLE TIE 97MM T4
16360-1322-0 PLASTIC CABLE TIE 200MM L3
17010-2353-0 WIRE CON ASSY 3P L=120MM CN1
27011-6720-0 UL1007 #18 500MM W/FUSE RING T'NAL
18900-9520-0 DC FAN CHA8012BS FAN1
SPEAKER ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
11403-4440-1 CABINET FOR PSW3000
11681-0000-C UL1015 AWG#18 BLACK
11681-0020-C UL1015 AWG#18 RED
82640-4070-1500 T-NUT M4
82911-3516-4400 M3.5*16 NICKEL SCREW
13000-6820-0 UPC LABEL FOR PSW3000-EU
14154-2351-0 LENS DISPLAY FOR PSW3000
18900-5780-0 10"SUBWOOFER FOR PSW3000
12901-4040-2000 MA SCREW 4*43 7.5MM WH/F
62901-5009-0000 SCREW M5*9
13000-6813-0 LABEL FOR 8900-5780-0
13300-0460-0 BACK CAN 166*160*65*2
13300-3500-0 CP 135*49.7*44*11
13300-6060-0 WH145*55.8*8 6M5 100C
13300-9270-0 FR-8900-5780-0
13800-4870-0 VC50.5KSV3.3*0.5*62
34104-4871-1 MAGNET 145*75*17 (C)
14134-5501-0 CHT BLACK BINDING PAST
14134-5501-1 CHT BLACK BINDING POST
14134-5511-0 CHT RED BINDING PAST
14134-5511-1 CHT RED BINDING POST
14153-0511-0 FOAM STRIP 5*5*1200MM
14159-0000-0 SHORTING RING 73.5*58
14159-0010-0 POLE TIP 48.7*36
14200-5160-0 DCAP D117*21.5 PP COATED
14200-8240-0 URBK-25P-51BK PPCTD
14301-5202-0 PSW3000 ADDENDUM SHEET
07010-4520-0 F.WIRE 24WW
18700-1390-0 DAMPER 160*51.2*2.8 0.4
PARTS LIST
13
POWERED SUBWOOFER
SPEAKER ASSEMBLY
CONTINUED
QTY PART NO DESCRIPTION LOCATION
1DUM-1403-4440-0 DUMMY 1403-4440-0
11497-7202-0 PE BAG 840X700X0.05
1OTHER-SPK-FC3T0C OTHER PARTS FOR PSW3000
1145A-7200-0 M.BOX FOR PSW3000
41490-7343-0 P.FOAM FOR PSW1000/S8
11490-7343-1 P.FOAM FOR PSW1000/S8
11497-4102-0 P.BAG 10'*12' W/ES GREEN
11497-4122-0 P.BAG 10'*14' W/ES GREEN
42640-4030-0704 NUT HEX M4
42901-6014-4000 FLAT COUNTER SINK HEAD
82908-4028-3400 SCREW M4*28 BLACK
42910-3012-3000 K320291B M3*12MM PAN HEA
82913-4016-3000 SCREW BINDING HEAD M4*16
23000-4447-0 LABEL, BARCODE BLANK
13000-6333-0 BARCODE S/N LABEL
13000-8902-0 MADE IN CHINA LABEL
03005-0360-1 RIBBON 60MMX300M
24134-5421-0 FEMALE TML #205
14153-0351-0 ACOUSTIC WOOL 860*320*30
14153-0461-0 ACOUSTIC WOOL 200*600*30
24153-3331-0 EVA GASKET 5*500
44153-9411-0 SUBWOOFER FOOT PSW2000
14154-2251-0 TEMPERED GLASS TINTED
44154-2461-0 SUBWOOFER FOOT PART B
14301-5190-0 MANUAL FOR PSW3000
14301-6016-0 W.CARD KAL926EFG REG
14301-6033-0 WARRANTY CARD FOR Q95C.2
PARTS LIST
POWERED SUBWOOFER
14
BLOCK DIAGRAM
RCA-1B
OUTPUT
CURRENT
AMPLIFIER
LIN-
MODULES
HI PASS
SMPS
LIN+
HIGH PASS OUTPUT
SPEAKER
INPUT
U1A
AUTO ON/OFF
Q207---Q212
OVER CURRENT/
SPK OUTPUTT
RCA-1D
INPUT
RIN-
R.CH
RIN+
HIGH PASS OUTPUT
SPEAKER
INPUT
U1B
+
U3
_
AUTO ON/OFF
BUFFER
U7A
RCA-1A
INPUT
L.CH
LOP-
LOP+ SPEAKER
OUTPUT
RCA-1C
OUTPUT
HI PASS
ROP-
ROP+ SPEAKER
OUTPUT U8B
SW102A
SW-2P2T
AGC
U201,U202,
U206
AUTO ON/OFF
BUFFER
U7A
LED301
DUAL LED COLOR
PROTECT
AUTO MANLIAL
GREEN/ON RED/OFF
-Vcc +Vcc0V
(35Hz/24dB)
LOW PASS FILTER
(40Hz-140Hz/24dB)
IEC1
IEC SOCKET
L
N
EAC 115V/230V
!
OFF SET PROTECT
HIGHT PASS FILTER
U4,Q8,Q9,Q10,Q11
LEVEL PHASE ADJUST
U5,Q12,Q13
(0-180)
140Hz/12dB
140Hz/12dB
130Hz/6dB
130Hz/6dB
U203,U204B
Q14
REGULATOR +5V
0V
U205
WIRELESS RECEIVER
MODULES RF101
TP101
2KB LEVEL CONTROL
U101B
MCU
U104 TP102
2KB FREQUENCY CONTROL
U102B
TP103
2KB PHASE CONTROL
U101A
LED DISPLAY
Q301---Q310,LED302
FAN CONTROL
Q202,Q203
DC
315MH 433MH
A
LEVEL MANUAL
CONTROL
SW101A
0V-12V
0V
+12V0V
SW2A
115V 230V
CRACKLING
+12V
ELIMINATE
315MH 433MH
UP
DOWN
SW1
REMOTE CONTROL
MODULES
A
433MH
315MH
+Vcc
RLY202
RLY201
FAN
15
POWERED SUBWOOFER
R54
100K
R52
100K
R50
100K
C29
220n
R55
100K
R51
8K2
R53
7K5
R46
36K
R2 9K1 C4
823
C2
823
-15V
RCA1C
L-L/OUT
RCA1A
L-L/IN
R12
390/1W
R11
390/1W
C6
300uF/50V NP
1
CN7A
H-L/IN+
2
CN7B
H-L/OUT-
3
CN7C
H-L/IN-
4
CN7D
H-L/OUT+
R5
10K
R8
10K
R10
1K
R9
2K2
C14
100p
R25
10K
R27
220K
C13
2u2/50V
Z1
3V3
C15
10u/25V
R26
56K
D1
1N4148
R28
10K
R39
470
R40
1K
R38
4K7
R37
1K
Q4
9012H
Q5
9013H
Z2
5V1
D2
1N4148
MANLIAL
AUTO
Auto On/Off
R29
470
C16
470u/16V
C18
47u/16V
C17
100u/16V
R31
2M2
R33
2K2
R30
1M2
R32
68K
R34
2K2
R35
4K7
Q1
9013H
Q2
9013H
Q6
9013H
Q3
9012H
C19
100n
SW102
SW2P2T
Z3
5V1
Q7
9012H
R36
10K
3
1
2
CN1
AF/OUT
R14
9K1
C8
823 C9
823
-15V
+15V
R18
10K
R24
10K
R22
1K
R23
2K2
C30
100n
R21
390/1W
R20
390/1W
C12
300uF/50V NP
5
CN7E
H-R/IN+
6
CN7F
H-R/IN-
7
CN7G
H-R/OUT-
8
CN7H
H-R/OUT+
Phase 0 to 180
3
2
1
84
U1A
BA4560
5
6
7
U7B
BA4560
3
2
1
84
U7A
BA4560
5
6
7
U1B
BA4560
5
6
7
U8B
BA4560
3
2
1
84
U5A
BA4560
+15V
-15V
3
1
2
CN2
15V/IN
-12V
+12V
RCA1B
L-R/IN
RCA1D
L-R/OUT
R1
22K
R13
22K
R4
100K
R16
100K
+15V
C5
330n
C10
330n
High Pass Filter
C20
220n
R43
33K
C21
220n
R42
27K
5
6
7
U3B
BA4560
C22
220n
R45
43K
C23
220n
R44 12K
3
2
1
84
U3A
BA4560
-15V
+15V
R47
36K
C24
393
R48
36K
R49
36K
3
2
1
84
U4A
BA4560
C26
683
C25
273
C28
123
Low Pass Filter
3
2
1
84
U2A
BA4560
+15V
-15V
-15V
+15V
5
6
7
U4B
BA4560
5
6
7
U5B
BA4560
C11
2u2/50V
C3
2u2/50V
C1
2u2/50V
C7
2u2/50V
C27
822
5
6
7
U2B
BA4560
R91
100K
R93
100K
R92
22K
R90
22K
D
G
S
PHASE
C152
2u2/50V
Q8
J112
R142
51K
R140
1M
R141
1M
Q12
J112
R154
100K
R152 510k
R153 1M
Q13
J112
R157
100K
R155 510k
R156 1M
Q14
J112
51K
R160
R158 1M
R159 1M
C153
2u2/50V
C151
2u2/50V
C150
2u2/50V
C155
2u2/50V
C154
2u2/50V
C156
2u2/50V
Q16
9013H
R68
100K
R69
4K7
MUTE
R59
3K6
R60
68K
R56
6K8
R57
6K8
C35
2u2/50V
1
2
CN5
A/O
1
2
CN6
A/O
1
2
CN4
A/O
1
2
CN3
A/O
LEVEL
FREQ
LED-R LED-G
D
G
S
Q9
J112
R145
51K
R143
1M
R144
1M
D
G
S
Q10
J112
R148
51K
R147
1M
R146
1M
D
G
S
Q11
J112
R151
51K
R150
1M
R149
1M
5
6
7
U6B
BA4560
R162
22K
R161
22K
2
31
TP104A
470K
2
31
TP105A
470k
SCHEMATICS DIAGRAMS
Pre Amp Schematic
POWERED SUBWOOFER
16
C505
100n
C506
100n
C209
104
C211
104
SIGNAL GND
C210
4700u/63V
C212
4700u/63V
C501
47u/50V
C502
47u/50V
R206
100
R207
100
R205
20K
R204
10K
R208
10K
R215
100K
R218
20K
C217
470P
-15V
C218
1u/50V
Q201
3906
D203
1N4148
R221
2K
R202
15K
+12V
-12V
R209
10K
AGC
R203
100K
R223
10K
R224
10K
R267
12K
R228
15K
R227
15K
R231
2K7
R232
12K
R229
390
R222
330K
R230
100
R234
100
R235
100
R237
100
R265
10/1W
R266
10/1W
R239
100
R238
r1/5W
R250
10/1W
R240
100
R236
r1/5W
Q205
A06
Q206
A06
Q207
TIP41C
Q210
2SC5200
Q204
A56
Q208
TIP42C
Q209
2SA1943
C222
100p
C223
102
C229
224
R233
390
D207
1N4148 C236
680p
D208
1N4148
C235
680p
R249
10/1W
L202
12T
C225
47p
C234
100u/63V
C221
100u/63V
C226
100p
1
2
3
4
5
6
7
8
9
U206
TA7317P
R252
56K
R251
56K
C232
10u/25V
R259
56K
R257
33K
R256
18K
C233
u47/50V
R261
18K
R255
56K
C231
47u/35V
R254
100K
R253
100K
C230
1u/50V
+15V
-15V
SPK
D210
1N4001
R262
1K5 1/2W
Q213
A56
R260
33K
D209
1N4148
3
2
1
84
U201A
TL062
5
6
7
U201B
TL062
3
2
1
48
U204A
TL072
3
2
1
84
U202A
TL062
3
1
2
CN205
12V/OUT
3
1
2
CN204
AF/IN
+12V
-12V
-12V
+Vcc
-Vcc
-Vcc
+Vcc
RLY201
RELAY
C220
10u/25V
R246
5K6
R247
5K6
R219
1.2M
AF/IN
R258
10K
AF/IN
R248
5K6
R244
100
R245
r1/5W
R242
100
R241
r1/5W
Q211
2SC5200
Q212
2SA1943
R212
39K
1
2
3
7
8
6
4
5
U203
CA3080N
TP201
20KB
+12V
-12V
-12V
+12V
C202
470P
5
6
7
U202B
TL062
5
6
7
U204B
TL072
D204
1N4148
D205
1N4148
R217
91K
R220
510K
R211
10K
R210
150K
R216
12K
+Vcc
-Vcc
R213 10K
+15V
R201
47K
C201
150n
D201
1N4148
D202
1N4148
-12V
+12V
R214
1K
R226
1K
R225
2K
TH201
10K
C224
100p
C204
100p
Q203
TIP41C
Q202
9013H
R263
5K6
D206
1N4148
1
2
CN206
2PIN
+12V
1
2
3
4
CN201
4PIN
L201
TT-9974
1
2
3
4
CN501
4PIN
Vin
1
GND
2
+5V 3
U205
7805
+12V
GND
C252
100n
C216
100u/16V
C253
47u/16V
1
2
CN203
2PIN
Text
RLY202
RELAY
+12VGND
R270
51K
R271
3K9
1
2
CN208
2PIN
D212
1N4001
D211
1N4001
C250
100u/16V
C251
47u/16V
1
2
CN2O7
2PIN
C248
2u2/50V
C228
2u2/50V
C219
2u2/50V
D213
1N4148
P-GND
C227
100n
C205
100n
C207
100n
SIGNAL GND
C206
220u/16V
C208
220u/16V
+12V
-12V
GND
Vin 1
GND
2
Vout
3
U501
7812
Vin 1
GND 2
Vout
3
U502
7912
C503
47u/16V
C504
47u/16V
R501
5K1
R501
5K1
+12V
SCHEMATICS DIAGRAMS
Power Amp Schematic
17
POWERED SUBWOOFER
SCHEMATICS DIAGRAMS
CPU
R102
20K
R101
180K
R124
47K
R106 1M2
R105
180K
R103 1M2
R120
47K
R108
180K
R122
47K
R109 1M2
C107
47P
C108
47P
TP101
2KB
TP102
2KB
-12V
TP103
2KB
-12V
-12V
R104
20K
R107
20K
LEVEL CONTROL
FREQUENCY CONTROL
PHASE CONTROL
C101
330n
C102 330n
C103 330n
RF101
US
A0
1
A1
2
A2
3
VSS
4SDA 5
SCL 6
WP 7
VCC 8
U103 AT24C02-10PI
RST/VPP
1
(RXD)P3.0
2
(TXD)P3.1
3
XTAL2
4
XTAL1
5
(INTO)P3.2
6
(INT1)P3.3
7
(TO)P3.4
8
(T1)P3.5
9
GND
10 P3.7 11
P1.0(AIN0) 12
P1.1(AIN1) 13
P1.2 14
P1.3 15
P1.4 16
P1.5 17
P1.6 18
P1.7 19
VCC 20
U104 AT89C4051-24PI
XTAL101
12MHz
R126
100K
C109
100n
MUTE
R125
47K
R123
47K
R121
47K
C104
330n
C105
330n
C106
330n
5
6
7
U101B
BA4560
3
2
1
8 4
U101A
BA4560
NPO NPO
EU
5V
1
2
CN101
2PIN
433.92MHz 315MHz
to Q6 E Pin
to Q5 E Pin
Q101
9014C
C111
220uF/16V
C110
100n
+5V
DATA
R132
10K
R130
10K
R131
5K6
DOWN
UPLEVEL
LEVEL
SW101
R134
5K1
R133
5K1
+5V
C157
1000uF/10V
R129
10
FB101
FB
CN7
11PIN
2
1
3
4
5
6
7
8
9
10
11
L102
22mH
L101
22mH
FB104
P-GND T10uH
5
6
7
U102B
1458
FB102
FB
FB103
FB
C120
104
C121
104
C122
104
C123
104
C124
104
C125
104
C126
104
C127
104
C128
104
R136
100
R135
1M
C158
104
433.92MHz 315MHz
R137
180
POWERED SUBWOOFER
18
SCHEMATICS DIAGRAMS
LED
R321
10K
R314
10K
R311
10K
Q301
9013H Q302
9013H Q303
9013H
LED302
10 LED DISPLAY
Q304
9013H
R312
10K R313
10K
Q305
9013H
Q308
9013H
R315
10K
+5v
Q309
9013H
D301
1N4148 D302
1N4148
D304
1N4148
D303
1N4148 D305
1N4148
D310
1N4148
D309
1N4148
D308
1N4148
D307
1N4148
D306
1N4148
Q310
9012H
R319
4K7
R320
1K
R301
100
R317
20K Q306
9013H
Q307
9012H
R316
4K7
R318
20K +5
R302
100 R303
100 R304
100 R305
100 R306
330 R307
330 R308
330 R309
330 R310
330
LED301
DUAL/LED
R322
10K
C301
100u/10V
P-GND
+5V
CN102
11PIN 2134567891011
19
POWERED SUBWOOFER
PCB LAYOUT
LED PCB Component Side LED PCB Copper Side
POWERED SUBWOOFER
20
PCB LAYOUT
Pre AMP PCB Component Side Pre AMP PCB Copper Side
Table of contents
Other KEF Subwoofer manuals
