SCHEMPP-HIRTH FLUGZEUGBAU GmbH., KIRCHHEIM/TECK

FLIGHT MANUAL

for Sailplane

Model: V e n t u s – 2c

Type sales name: Ventus-2c(x)

(S/N 82 and on when in compliance with MB-No. 349-46)

Serial-No.:

Registr.-No.:

Date of issue: N o v e m b e r 2 0 0 3

Pages as indicated by „LBA-app.“ are approved by

(Signature)

Luftfahrt-Bundesamt (Authority)

(Stamp)

(Original date of approval)

This sailplane is to be operated in compliance with information and limitations contained herein.

Approval of translation has been done by best knowledge and judgment.

In any case the original text in German language is authoritative.

SCHEMPP-HIRTH FLUGZEUGBAU GmbH., KIRCHHEIM/TECK

Ventus-2c FLIGHTMANUAL

0.1 Record of revisions

Any revisions of the present manual, except actual weighing data, must be

recorded in the following table and in the case of approved sections be en-

dorsed by the responsible airworthiness authority.

The new or amended text in the revised page will be indicated by a black

vertical line in the left hand margin, and revision number and the date will be

shown on the bottom left hand side of the page.

0.1.1

SCHEMPP-HIRTH FLUGZEUGBAU GmbH., KIRCHHEIM/TECK

Ventus-2c FLUGHANDBUCH / FLIGHT MANUAL

0.1 Erfassung der Berichtigungen / Records of revisions

Lfd. Nr.

der

Berichtigung

Abschnitt

Seiten

Datum

der

Berichtigung

Bezug

Datum der

Anerkennung

durch

das LBA

Datum der

Ein-

arbeitung

Zeichen

/Unter-

schrift

Revision

No.

Affected

section

Affected

page

Date of

issue

Reference

Date of

Approval by

LBA

Date of

Insertion

Signature

1

0

7

0.2.5

7.2.5

März / March

2006

Trimmung /

elevator trim

2

0

1

2

4

5

6

0.2.2

0.2.3

0.2.4

1.4.3

2.6

2.13

2.15

4.5.1.2

4.5.1.3

4.5.1.4

4.5.3.1

4.5.3.2

4.5.3.3

4.5.4.1

5.2.2

6.2.5

Mai / May

2006

TM-Nr. 349-32

Erhöhung der

max. Flugmasse

bei 18 m Spann-

weite auf 600 kg

TN-No. 349-32

Increase of the

max. permitted

all-up mass on

600 kg at 18 m

wing span

MB: Modification Bulletin – Änderungsblatt

TN : Technical Note – Technische Mitteilung

0.1.2

SCHEMPP-HIRTH FLUGZEUGBAU GmbH., KIRCHHEIM/TECK

Ventus-2c FLUGHANDBUCH / FLIGHT MANUAL

0.2 Verzeichnis der Seiten / List of effective pages

Abschnitt

Affected section

Seite

Affected pages Ausgabe-Datum

Date of issue Bezug

Reference

0

0.1.1

0.2.1

0.2.2

0.2.3

0.2.4

0.2.5

0.2.6

0.3.1

0.2.1

SCHEMPP-HIRTH FLUGZEUGBAU GmbH., KIRCHHEIM/TECK

Ventus-2c FLUGHANDBUCH / FLIGHT MANUAL

0.2 Verzeichnis der Seiten / List of effective pages

Abschnitt

Affected section

Seite

Affected pages Ausgabe-Datum

Date of issue Bezug

Reference

1

2

3

1.1.1

1.1.2

1.2

1.3

1.4.1

1.4.2

1.4.3

1.5

2.1.1

2.1.2

LBA-anerk. 2.2

LBA-anerk. 2.3

LBA-anerk. 2.4

LBA-anerk. 2.5

LBA-anerk. 2.6

LBA-anerk. 2.7

LBA-anerk. 2.8

LBA-anerk. 2.9

LBA-anerk. 2.10

LBA-anerk. 2.11

LBA-anerk. 2.12

LBA-anerk. 2.13

LBA-anerk. 2.14

LBA-anerk. 2.15

3.1.1

3.1.2

LBA-anerk. 3.2

LBA-anerk. 3.3

LBA-anerk. 3.4

LBA-anerk. 3.5

LBA-anerk. 3.6

LBA-anerk. 3.7

LBA-anerk. 3.8

LBA-anerk. 3.9.1

LBA-anerk. 3.9.2

November 2003

Mai 2006

November 2003

Mai 2006

November 2003

Mai 2006

November 2003

Mai 2006

November 2003

TN 349-32

0.2.2

SCHEMPP-HIRTH FLUGZEUGBAU GmbH., KIRCHHEIM/TECK

Ventus-2c FLUGHANDBUCH / FLIGHT MANUAL

0.2 Verzeichnis der Seiten / List of effective pages

Abschnitt

Affected section

Seite

Affected pages Ausgabe-Datum

Date of issue Bezug

Reference

4

4.1.1

4.1.2

LBA-anerk. 4.2.1

LBA-anerk. 4.2.2

LBA-anerk. 4.2.3

LBA-anerk. 4.3.1

LBA-anerk. 4.3.2

LBA-anerk. 4.3.3

LBA-anerk. 4.3.4

LBA-anerk. 4.4

LBA-anerk. 4.5.1.1

LBA-anerk. 4.5.1.2

LBA-anerk. 4.5.1.3

LBA-anerk. 4.5.1.4

LBA-anerk. 4.5.2

LBA-anerk. 4.5.3.1

LBA-anerk. 4.5.3.2

LBA-anerk. 4.5.3.3

LBA-anerk. 4.5.3.4

LBA-anerk. 4.5.3.5

LBA-anerk. 4.5.4.1

LBA-anerk. 4.5.4.2

LBA-anerk. 4.5.5

LBA-anerk. 4.5.6.1

LBA-anerk. 4.5.6.2

LBA-anerk. 4.5.6.3

LBA-anerk. 4.5.6.4

LBA-anerk. 4.5.6.5

LBA-anerk. 4.5.7.1

LBA-anerk. 4.5.7.2

LBA-anerk. 4.5.8

LBA-anerk. 4.5.9

November 2003

Mai 2006

November 2003

Mai 2006

November 2003

Mai 2006

November 2003

TN 349-32

0.2.3

SCHEMPP-HIRTH FLUGZEUGBAU GmbH., KIRCHHEIM/TECK

Ventus-2c FLUGHANDBUCH / FLIGHT MANUAL

0.2 Verzeichnis der Seiten / List of effective pages

Abschnitt

Affected section

Seite

Affected pages Ausgabe-Datum

Date of issue Bezug

Reference

5

6

5.1.1

5.1.2

LBA-anerk. 5.2.1

LBA-anerk. 5.2.2

LBA-anerk. 5.2.3

LBA-anerk. 5.2.4

5.3.1

5.3.2.1

5.3.2.2

6.1.1

6.1.2

6.2.1

6.2.2

6.2.3

6.2.4

6.2.5

6.2.6

6.2.7

6.2.8

November 2003

Mai 2006

November 2003

Mai 2006

November 2003

TN 349-32

0.2.4

SCHEMPP-HIRTH FLUGZEUGBAU GmbH., KIRCHHEIM/TECK

Ventus-2c FLUGHANDBUCH / FLIGHT MANUAL

0.2 Verzeichnis der Seiten / List of effective pages

Abschnitt

Affected section

Seite

Affected pages Ausgabe-Datum

Date of issue Bezug

Reference

7

7.1.1

7.1.2

7.2.1

7.2.2

7.2.3

7.2.4

7.2.5

7.2.6

7.3.1

7.3.2

7.4

7.5

7.6

7.7

7.8

7.9.1

7.9.2

7.9.3

7.10

7.11

7.12.1

7.12.2

7.12.3

7.12.4

7.13.1

7.13.2

November 2003

March 2006

November 2003

Rev. 1

0.2.5

SCHEMPP-HIRTH FLUGZEUGBAU GmbH., KIRCHHEIM/TECK

Ventus-2c FLUGHANDBUCH / FLIGHT MANUAL

0.2 Verzeichnis der Seiten / List of effective pages

Abschnitt

Affected section

Seite

Affected pages Ausgabe-Datum

Date of issue Bezug

Reference

8

9

8.1.1

8.1.2

8.2

8.3

8.4

8.5.1

8.5.2

9.1.1

9.1.2

9.2

November 2003

0.2.6

SCHEMPP-HIRTH FLUGZEUGBAU GmbH., KIRCHHEIM/TECK

Ventus-2c FLIGHTMANUAL

0.3 Table of contents

Section

General 1

(a non-approved section)

Limitations 2

(an approved section)

Emergency procedures 3

(an approved section)

Normal procedures 4

(an approved section)

Performance 5

(a partly approved section)

Weight & balance 6

(a non-approved section)

Aircraft and

systems description 7

(a non-approved section)

Aircraft handling,

care and maintenance 8

(a non-approved section)

Supplements 9

0.3.1

SCHEMPP-HIRTH FLUGZEUGBAU GmbH., KIRCHHEIM/TECK

Ventus-2c FLIGHTMANUAL

Section 1

1. General

1.1 Introduction

1.2 Certification basis

1.3 Warnings, cautions and notes

1.4 Descriptive data

1.5 Three-side view

November 2003

Revision-- 1.1.1

SCHEMPP-HIRTH FLUGZEUGBAU GmbH., KIRCHHEIM/TECK

Ventus-2c FLIGHTMANUAL

1.1 Introduction

The Flight Manual for this powered sailplane has been prepared to provide

pilots and instructors with information for the safe and efficient operation of

the sailplane.

This manual includes the material required to be furnished to the pilot by

„JAR“, Part 22.

It also contains supplemental data supplied by the manufacturer of the

aircraft.

November 2003

Revision-- 1.1.2

SCHEMPP-HIRTH FLUGZEUGBAU GmbH., KIRCHHEIM/TECK

Ventus-2c FLIGHTMANUAL

1.2 Certification basis

This sailplane, model designation

„Ventus-2c“

has been approved by the Luftfahrt-Bundesamt (LBA) in compliance with

„JAR“, Part 22 effective on June 27, 1989 (Change 4 of the English Original

Issue), including additional Amendment 22/90/1.

The LBA Type Certificate is No. 349 and was issued on

September 26, 1996

Category of Airworthiness: UTILITY

November 2003

Revision -- 1.2

SCHEMPP-HIRTH FLUGZEUGBAU GmbH., KIRCHHEIM/TECK

Ventus-2c FLIGHTMANUAL

1.3 Warnings, cautions and notes

The following definitions apply to warnings, cautions and notes used in this

flight manual:

„WARNING“ means that the non-observation of the corresponding

procedure leads to an immediate or important degrada-

tion of the flight safety

„CAUTION“ means that the non-observation of the corresponding

procedures leads to a minor or to a more or less long

term degradation of the flight safety

„NOTE“ draws the attention on any special item not directly related

to safety, but which is important or unusual

November 2003

Revision-- 1.3

SCHEMPP-HIRTH FLUGZEUGBAU GmbH., KIRCHHEIM/TECK

Ventus-2c FLIGHTMANUAL

1.4 Descriptive data

The “Ventus-2c” is a flap equipped, single-seat high performance sailplane,

constructed from fiber reinforced plastic (FRP), featuring a T-tail (fixed horiz.

stabilizer with elevator, fin and rudder).

It can be flown in 15 m or 18 m configuration.

Wing

The four-piece (15 or 18 m) wing with winglets is multi-stage trapezoid in

planform with double-panel “Schempp-Hirth” type airbrakes on the upper

surface. The flaps act as full-span ailerons.

The water ballast tanks are integral compartments in the fwd. section of the

inbd. panels (174 Liter [45.97 US Gal., 38.28 IMP Gal.]) and in the 18m-outbd.

panels (28 Liter [7.40 US Gal., 6.16 IMP Gal.]).

Their total capacity is approx. 202 Liter (53.40 US Gal., 44.40 IMP Gal.).

The wing shells are a CFRP/foam-sandwich construction with spar flanges of

carbon fiber rovings and shear webs made from CFRP/foam-sandwich.

Fuselage

The pilot has a semi-reclining position in the comfortable cockpit. The one-

piece canopy hinges sideways and opens to the right.

For high energy absorption the cockpit region is constructed as a Kevlar/

carbon/glass fiber laminate, which is reinforced by a double skin on the sides

with integrated canopy coaming frame.

The aft fuselage section is a pure carbon fiber (non-sandwich-) shell, stiffened

by carbon fiber bulkheads and glass fiber webs. The landing wheel is retract-

able an features a mechanical respective hydraulic brake; the tail wheel (or

rubber skid) is fixed.

Horizontal tailplane

The horizontal tailplane consists of a fixed stabilizer with elevator. The stabi-

lizer is a GFRP/CFRP/foam-sandwich construction, the elevator halves are a

pure GFRP/CFRP shell. The automatic elevator trim is linked to the flap

actuating rod and is infinitely adjustable.

Vertical tail

Fin and rudder are constructed as a GFRP/foam-sandwich.

On request a water ballast trim tank with a capacity of 7.8 Liter (2.06 US Gal.,

1.72 IMP. Gal.) is provided in the fin.

Controls

On rigging the wing panels, the control surfaces are automatically hooked up.

November 2003

Revision-- 1.4.1

SCHEMPP-HIRTH FLUGZEUGBAU GmbH., KIRCHHEIM/TECK

Ventus-2c FLIGHTMANUAL

Intentionally blank

November 2003

Revision-- 1.4.2

SCHEMPP-HIRTH FLUGZEUGBAU GmbH., KIRCHHEIM/TECK

Ventus-2c FLIGHTMANUAL

TECHNICAL DATA

Wing

Span 15,00 m 18,00 m

49,21 ft 59,06 ft

Area 9,67 m² 11,03 m²

104,09 ft² 118,73 ft²

Aspect ratio 23,3 29,5

MAC 0,673 m 0,648 m

2,210 ft 2,13 ft

Fuselage

Length 6,78 m

22,24 ft

Width 0,62 m

2,03 ft

Height 0,81 m

2,66 ft

Mass

Empty mass approx. 290 kg 310 kg

739 lb 783 lb

Maximum all-up mass 525 kg 600 kg

1157 lb 1323 lb

Wing loading range 37,7 – 54,3 kg/m² 34,9 – 54,4 kg/m²

7,7 – 11,1 lb/ft² 7,1 – 11,1 lb/ft²

May 2006

Revision 2 TN-No. 349-32 1.4.3

SCHEMPP-HIRTH FLUGZEUGBAU GmbH., KIRCHHEIM/TECK

Ventus-2c FLIGHTMANUAL

1.5 Three-side view

November 2003

Revision-- 1.5

15.0 m [ 49.21 ft ] 18.0 m [ 59.06 ft ]

6.81 m [ 22.34 ft ]

2.5 m [ 8.20 ft ]

SCHEMPP-HIRTH FLUGZEUGBAU GmbH., KIRCHHEIM/TECK

Ventus-2c FLIGHTMANUAL

Section 2

2. Limitations

2.1 Introduction

2.2 Airspeed

2.3 Airspeed indicator markings

2.4 (reserved)

2.5 (reserved)

2.6 Weights (masses)

2.7 Center of gravity

2.8 Approved maneuvers

2.9 Maneuvering load factors

2.10 Flight crew

2.11 Kinds of operation

2.12 Minimum equipment

2.13 Aerotow and winch launch

2.14 Other limitations

2.15 Limitation placards

November 2003

Revision-- 2.1.1

Flugzeugbau Ventus-2C Technical specifications

Popular Aircraft manuals by other brands
