Fluke OptiView User manual

OptiViewTM
Wireless Network Analyzer
Getting Started Guide
PN 1998593
August 2002, Rev. 3, 9/04
© 2002-2004 Fluke Networks, Inc. All rights reserved. Printed in USA
All product names are trademarks of their respective companies.

LIMITED WARRANTY & LIMITATION OF LIABILITY
Each Fluke Networks product is warranted to be free from defects in material and workmanship under normal use
and service. The warranty period is one year and begins on the date of purchase. Parts, accessories, product
repairs and services are warranted for 90 days. This warranty extends only to the original buyer or end-user
customer of a Fluke Networks authorized reseller, and does not apply to disposable batteries, cable connector
tabs, cable insulation-displacement connectors, or to any product which, in Fluke Networks' opinion, has been
misused, altered, neglected, contaminated, or damaged by accident or abnormal conditions of operation or
handling. Fluke Networks warrants that software will operate substantially in accordance with its functional
specifications for 90 days and that it has been properly recorded on non-defective media. Fluke Networks does
not warrant that software will be error free or operate without interruption.
Fluke Networks authorized resellers shall extend this warranty on new and unused products to end-user
customers only but have no authority to extend a greater or different warranty on behalf of Fluke Networks.
Warranty support is available only if product is purchased through a Fluke Networks authorized sales outlet or
Buyer has paid the applicable international price. Fluke Networks reserves the right to invoice Buyer for
importation costs of repair/replacement parts when product purchased in one country is submitted for repair in
another country.
Fluke Networks' warranty obligation is limited, at Fluke Networks' option, to refund of the purchase price, free of
charge repair, or replacement of a defective product which is returned to a Fluke Networks authorized service
center within the warranty period.
To obtain warranty service, contact your nearest Fluke Networks authorized service center to obtain return
authorization information, then send the product to that service center, with a description of the difficulty, postage
and insurance prepaid (FOB Destination). Fluke Networks assumes no risk for damage in transit. Following
warranty repair, the product will be returned to Buyer, transportation prepaid (FOB Destination). If Fluke
Networks determines that failure was caused by neglect, misuse, contamination, alteration, accident or abnormal
condition of operation or handling, or normal wear and tear of mechanical components, Fluke Networks will
provide an estimate of repair costs and obtain authorization before commencing the work. Following repair, the
product will be returned to the Buyer transportation prepaid and the Buyer will be billed for the repair and return
transportation charges (FOB Shipping Point).
THIS WARRANTY IS BUYER'S SOLE AND EXCLUSIVE REMEDY AND IS IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. FLUKE NETWORKS SHALL NOT BE
LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOSSES,
INCLUDING LOSS OF DATA, ARISING FROM ANY CAUSE OR THEORY.
Since some countries or states do not allow limitation of the term of an implied warranty, or exclusion or limitation
of incidental or consequential damages, the limitations and exclusions of this warranty may not apply to every
buyer. If any provision of this Warranty is held invalid or unenforceable by a court or other decision-maker of
competent jurisdiction, such holding will not affect the validity or enforceability of any other provision.
Fluke Networks, Inc.
P.O. Box 9090
Everett, WA 98206-9090
U.S.A.
6-01
Fluke Europe B.V.
P.O. Box 1186
5602 BD
Eindhoven
The Netherlands

i
Table of Contents
Title Page
Introduction...................................................................................................... 1
Before You Start .............................................................................................. 1
Safety Information..................................................................................... 1
Contacting Fluke Networks Sales, Service, and Support Centers............. 2
OptiView Wireless Network Analyzer Support ........................................ 2
OptiView Wireless Network Analyzer and Accessories ................................. 3
Installing the OptiView Wireless Network Analyzer Software....................... 4
Moving the Software to Your OptiView Integrated Network Analyzer ... 4
Downloading the Software File From the Fluke Networks Web Site
Directly to the Analyzer ............................................................................ 5
Transferring the Software from your PC to the Analyzer ......................... 5
Configuring for a Point-to-Point Connection........................................ 5
Using the Analyzer’s TFTP Server Application to Transfer the
Software from your PC to the Analyzer................................................ 6
Mapping a Drive and Transferring the Software File from your PC
to the Analyzer...................................................................................... 8
Installing the Software on the Analyzer.................................................... 9
Installing the Wireless LAN Card ................................................................... 10
Using the OptiView Wireless Network Analyzer............................................ 12
Starting the OptiView Wireless Network Analyzer .................................. 12
Initial Setup ............................................................................................... 14
WNA Modes of Operation ........................................................................ 15
Setting Up the Authorization List ............................................................. 16
Selecting the Country Location................................................................. 17
Packet Capture ................................................................................................. 18
Installing a Replacement Bail on an Older OptiView Analyzer...................... 21
Troubleshooting Your Analyzer ...................................................................... 22
Resetting and Powering the Analyzer Completely Off ............................. 22
Resetting the Analyzer.......................................................................... 22
Forcing Power Off ................................................................................ 22

OptiView
TM
Getting Started Guide
ii
Before Calling Technical Support ............................................................ 23
Do you suspect Windows has locked up? ............................................ 23
Do you suspect the analyzer has locked up? ........................................ 23
Does the analyzer power-up? ............................................................... 23
Does the taskbar overlay WNA? .......................................................... 23
Does the Windows wireless setup not support your network’s
security settings? .................................................................................. 23
Known Issues/Limitations.................................................................... 23
Using the Built-in Help System....................................................................... 24
Accessing and Navigating the Help System ............................................. 24
WLAN Card Specifications............................................................................. 25

1
Introduction
OptiView Wireless Network Analyzer, hereafter referred to as the "analyzer", brings the
ruggedness, portability, and ease-of-use of the OptiViewTM Network Analyzer to wireless
LANs. Whether you’re designing your first wireless LAN deployment, detecting rogue
Access Points, verifying a recent installation, monitoring or troubleshooting wireless
connectivity problems, the OptiView Wireless Network Analyzer gives you the vision you
need to manage your wireless network.
Note
The OptiView Wireless Network Analyzer is equipped with a wireless
network access card that supports 802.11a/b/g specifications.
Before You Start
Safety Information
The OptiView Wireless Network Analyzer complies with:
• FCC part 64, class A
• FCC part 15, class A
Refer to the back of the Wireless LAN card for compliance symbols.
WPLEASE READ MANUAL FOR SAFETY
WWarnings
To avoid possible electric shock or personal injury, follow
these guidelines:
•Do not operate the product around explosive gas,
vapor or dust.
•If this product is used in a manner not specified by the
manufacturer, the protection provided by the product
may be impaired.

OptiView
TM
Getting Started Guide
2
Contacting Fluke Networks Sales, Service, and Support Centers
Visit the Fluke Networks website at www.flukenetworks.com.Send email to
[e-mail].
For operator assistance in the USA, call 1-800-28-FLUKE (1-800-283-5853).
To order accessories or get the location of the nearest Fluke Networks distributor
or service center, call:
Anywhere in the world: [phone]
Australia: 61 (2) 8850-3333 or 61 (3) 9329-0244
Beijing: 86 (10) 6512-3435
Brazil: 11 3044 1277
Canada: 1-800-36-FLUKE (1-800-363-5853)
Europe: [phone]
Hong Kong: 852 2721-3228
Japan: [phone]
Korea: 82 2 539-6311
Singapore: [phone]
Taiwan: (886) 2-227-83199
USA: 1-800-28-FLUKE (1-888-283-5853)
OptiView Wireless Network Analyzer Support
As a registered user, you are entitled to entry level product support, including three
free telephone support incidents during the first 60 days of ownership, access to
entry level online Knowledge Base library of product operation and Software
information, and Web-based trouble ticketing. We will also be sending you Fluke
Networks company and product information updates.
Please take the time to register your analyzer. A registration card is supplied in the
shipping box. You can also register by going to www.flukenetworks.com, click
on support, then click on Registration. A Log in screen is displayed. Click on
create to setup an account password if you have not done so before. Then you will
be able to log in using your email address and password. Once logged in, you can
fill out the online registration form by clicking on Register a product, selecting
OptiView Models, selecting Select a Model, and choosing OptiView Wireless
Network Analyzer.

Wireless Network Analyzer
OptiView Wireless Network Analyzer and Accessories
3
OptiView Wireless Network Analyzer and Accessories
.
3
2
1
apo01f.eps
Item Description Model/Part
Number
A Wireless LAN Adapter 802.11a/b/g Wireless LAN PCMCIA card 2281050
B CD-ROM OptiView Wireless Network Analyzer CD-
ROM. Contains installation software and
documents.
1998606
C
OptiView Wireless
Network Analyzer
Getting Started Guide
Provides basic operating information,
accessory part numbers, and specifications
for the OptiView Wireless Network Analyzer.
1998593
Registration Card Fluke Networks can serve you best by
registering online at
www.flukenetworks.com. If you cannot
register online, please fill out and return the
supplied registration card.
688861
Warranty Card Factory 1 year warranty. N/A
For OptiView Classic Analyzers, the following is also included in the kit:
CD-ROM OptiView Resource CD-ROM. Contains the
latest OptiView Analyzer installation
software.
Note: The OptiViewTM Integrated Network
Analyzer installation software version must
be 3.52 or greater.
1626397
Bail OptiViewTM Integrated Network Analyzer
replacement bail. Used with Wireless LAN
Adapter.
1671671
Stylus Stylus used on the OptiViewTM Integrated
Network Analyzer touch panel display. 1671659
OptiView Series II
Integrated Network
Analyzer Getting Started
Guide
Provides basic operating information,
accessory part numbers, and specifications
for the OptiView Integrated Network
Analyzer.
2103831
Figure 1. The OptiView Wireless Network Analyzer and Supplied Accessories

OptiView
TM
Getting Started Guide
4
Installing the OptiView Wireless Network Analyzer
Software
If the OptiView Wireless Network Analyzer icon does not appear on your
OptiView Series II Integrated Network Analyzer desktop, you will need to install
the software. There are three steps involved in the installation:
•Move the self-extracting software file onto the Analyzer's hard disk
•Install the software on the Analyzer
•Installing the Wireless LAN Adapter card
Note
The OptiView Wireless Network Analyzer software must be installed
BEFORE installing the 802.11a/b/g Wireless LAN Card.
Older OptiView Integrated Network Analyzers (running Win98) must
be running with OptiView software version 3.52 or greater. All
newer OptiView Series II Analyzers work with the OptiView Wireless
Network Analyzer application.
Moving the Software to Your OptiView Integrated Network Analyzer
There are three methods for moving the software file:
•Copy the file from your OptiView Wireless Network Analyzer CD to your
analyzer using an external USB CD-ROM drive
•Copy the file from your OptiView Wireless Network Analyzer CD to your
PC, and then transfer the file to the Analyzer using one of the methods
listed below:
•Use a direct point-to-point connection
•From the Analyzer, use Microsoft Networking to map a drive on the
PC, and copy the file to the Analyzer (analyzer and PC must be in
same subnet)
•Transfer the software file to the Analyzer Using the Analyzer’s
TFTP Server software
•Download the software file from the Fluke Networks Web Site directly to
the Analyzer
Once the software file is on your Analyzer, you will need to install it as described
in Installing the Software on the Analyzer.

Wireless Network Analyzer
Installing the OptiView Wireless Network Analyzer Software
5
Downloading the Software File From the Fluke Networks Web Site Directly to
the Analyzer
If your Analyzer is connected to a network that has Internet connectivity, perform
this procedure.
1. Connect the Analyzer to your network and correctly configure the IP
configuration. Refer to the Analyzer documentation for help if needed.
2. Start your web browser and point it at the following Fluke Networks web
page:
http://www.flukenetworks.com/us/LAN/Handheld+Testers/OptiView/_softw
are.htm
3. Select the OptiView Wireless Network Analyzer link to download the
software file to your Analyzer.
4. You are now ready to Install the Software on the Analyzer.
Transferring the Software from your PC to the Analyzer
You can transfer the software file from your PC to the Analyzer either by:
•Using a Point-to-Point Connection to transfer the software file
•Using the Analyzer’s TFTP Server application to transfer the software file
•Mapping a drive and copying the software file to the Analyzer
Configuring for a Point-to-Point Connection
If you are connecting the Analyzer directly to your PC's network interface card
(NIC) through an Ethernet connection, you will need to configure the Analyzer
and PC Network Properties.
If your PC is using a static address, you will need to configure the Analyzer to the
same subnet, and select an IP address (that is different than the PC IP address). To
do so, perform the following:
1. Go to your PC's Network Properties window and determine what the IP
address and subnet (mask) are set to.
2. Go to the Analyzer Setup | TCP/IP screen and set the Source and Mask
addresses. You do not need to set the router address. The Mask needs to be set
to the same subnet as the PC, and the Source address needs to be set to an
unused IP address.
Note
You should see link on the Analyzer once these settings are set.

OptiView
TM
Getting Started Guide
6
If your PC is configured for DHCP, it will "time out" after several minutes to the
Microsoft default address. Follow the procedures above to configure the Analyzer
to the same subnet, and different IP address.
Note
Some Ethernet card vendors' auto speed detection may conflict with
the Analyzer's auto speed detection. In this case, manually set the
Analyzer link speed to 10Mb half duplex in the Analyzer's Setup |
Ethernet screen. If this does not work, manually set the PC NIC to
10Mb half duplex.
Using the Analyzer’s TFTP Server Application to Transfer the Software from your
PC to the Analyzer
Note
If you are connecting the Analyzer directly to your PC via an
Ethernet connection, see the section Configuring for a Point-to-Point
Connection.
1. Make sure the PC and Analyzer have a valid IP configuration.
Note
Do not change the Analyzer IP configuration for the TCP/IP -> Intel
8255x-based PCI Ethernet Adapter (10/100). The IP must stay at
192.168.111.111 or the Analyzer will not work.
2. On the Windows desktop of your Analyzer, select Start | Programs | Start TFTP
Server. The TFTPD32 by Ph. Jounin server dialog is displayed as shown below:
Figure 2. TFTP Startup Screen

Wireless Network Analyzer
Installing the OptiView Wireless Network Analyzer Software
7
Note
Do not change the server address 192.168.111.111. This is an
internal IP address used by the Analyzer to communicate with the PC
portion of the Analyzer.
3. Select Settings. The Tftpd32: Settings dialog is displayed as shown below:
Figure 3. TFTP Setup Screen
4. Set Security to None.
5. Specify an Analyzer Base Directory (D:\temp recommended) for the OPVWNA-
V2.EXE file to be copied to.
Note
If you put the OptiView Wireless Network Analyzer software on the
D: drive, you can perform a disk recovery on the C: drive and not
lose the OptiView Wireless Network Analyzer setup file.
6. Select OK to save the settings.
7. On your PC, open a DOS window.
8. Change directories to the directory where the OPVWNA-V2.EXE file resides.
9. Type tftp -i <ip address> PUT OPVWNA-V2.EXE, and press Enter.
Note
The <ip address> is the IP address of the Analyzer as shown in the
OptiView Front Page screen, not the IP address 192.168.111.111
shown above.

OptiView
TM
Getting Started Guide
8
10. On the Analyzer, close the TFTP server dialog to terminate the TFTP
session.
11. You are now ready to Install the Software on the Analyzer.
Mapping a Drive and Transferring the Software File from your PC to the Analyzer
Microsoft Networking allows you to share a folder on your PC as a network drive
that you can then access across your local network from your Analyzer, thus
allowing you to copy the software file from your PC to the Analyzer.
Note
You may need to first go to the Network Properties on your Analyzer
(right-click on the Desktop Network Neighborhood and select
Properties), highlight Clients for Microsoft Networking and select
Properties, and setup Logon Validation for your network domain.
Then you will need to restart the Analyzer and log into your network
domain.
The file sharing procedure is slightly different for each Windows operating
system. Generally, you will need to perform the following procedure on your PC:
1. On your PC, determine the directory to be shared (default is C:\temp) that
contains the software file OPVWNA-V2.EXE. From Windows Explorer, set
the folder to be shared by right-clicking on the folder name and selecting
the Sharing tab. Select the Shared As: radio button and enter a Share
Name.
Note
You don’t actually have to copy the software file to the PC hard disk
before transferring it to the Analyzer. You can map the CD-ROM
drive and copy the file directly from the OptiView Wireless Network
Analyzer CD to the Analyzer.
2. Connect the Analyzer to the same local network as the PC.
3. On the Analyzer, open Windows Explorer.
4. Select Tools | Map Network Drive.
5. In the Path field, enter the IP address of the PC followed by the Share
Name (e.g. \\010.010.010.012\sharename .) Click OK when done.
6. Copy the file OPVWNA-V2.EXE from your PC to the Analyzer
(recommended is d:\temp.)
7. You are now ready to Install the Software on the Analyzer.

Wireless Network Analyzer
Installing the OptiView Wireless Network Analyzer Software
9
Installing the Software on the Analyzer
After the file OPVWNA-V2.EXE has been copied to the Analyzer (preferably to the
D: drive), perform the following steps to complete the installation:
Note
The Wireless Network Analyzer PCMCIA Card must NOT be
installed in the analyzer during the software installation. After the
software installation, the card can be inserted into the PCMCIA slot.
Windows will then detect the card and add it as new hardware using
the correct driver.
1. Run OPVWNA-V2.EXE file.
2. Follow the InstallShield Wizard instructions to install the software.
Reboot the Analyzer as indicated in the InstallShield Wizard.
3. Once the Analyzer reboots, stop the OptiView application if it is running.
Note
Running both the OptiView application and the OptiView Wireless
Network Analyzer at the same time is NOT recommended.
4. Install the 802.11a/b/g wireless LAN card in the PCMCIA slot on the side
of the OptiView Integrated Network Analyzer. The New Hardware
Wizard will detect the card and properly configure the Analyzer.
5. Click on the OptiView Wireless Network Analyzer icon to start the
software.

OptiView
TM
Getting Started Guide
10
Installing the Wireless LAN Card
Note
The OptiView Wireless Network Analyzer software must be installed
BEFORE installing the 802.11a/b/g Wireless LAN Card.
The WLAN PC Card is installed in the PC Card (PCMCIA) card slot located on
the right side of the OptiViewTM Integrated Network Analyzer. When inserting the
card, make sure it is aligned and installed properly in the slot holder. It should
slide in freely. Do not force it into the slot.
apo06f.eps
Figure 4. Wireless LAN Card Installation

Wireless Network Analyzer
Installing the Wireless LAN Card
11
If you are running Windows Service Pack 2 on Windows XP, and the firewall is
turned on, you will be prompted with the following screen after the WLAN card
has been inserted for the first time:
Figure 5. Forcing Windows to Look for the WLAN Card Driver Locally
Select No, not at this time, and select Next.
On OptiView Series II analyzers, running Windows XP, you will also be prompted
with the following message telling you that the driver has not passed Windows
testing. Press Continue Anyway to complete the installation:
Figure 6. Hardware Installation Message

OptiView
TM
Getting Started Guide
12
Using the OptiView Wireless Network Analyzer
Starting the OptiView Wireless Network Analyzer
At the desktop, press the OptiView Wireless Network Analyzer
(OPVWNA-V2) icon to launch the software.
Note
The OptiView WNA, running on an OptiView Classic ( running
Windows 98), and the OptiView
TM
Integrated Network Analyzer
software should not be run at the same time. Shut down the
OptiView
TM
Integrated Network Analyzer user interface software
before starting the OptiView Wireless Network Analyzer software.
Note
If you are running Windows Service Pack 2 on the Windows XP
operating system, the firewall should be turned off for efficient
discovery. If the firewall is turned on, you will be prompted with the
following screen after launching the software:
Figure 7. Allowing Discovery Through the Windows XP Firewall
Select Unblock to allow limited discovery by the OptiView Wireless
Network Analyzer on the wireless network. The wireless discovery
will take about a minute longer to update the screen and some
discovery will be compromised. If you select Keep Blocking, no
discovery will take place.

Wireless Network Analyzer
Using the OptiView Wireless Network Analyzer
13
The firewall security settings are configured in the Windows
Security Center screen. Select the icon (in the taskbar) to open
the Windows Security Center screen. At the bottom of this screen,
select Windows Firewall. It is in this screen that you can turn off or
on the firewall. Within this screen, the Exceptions tab allows you to
turn on and off the OptiView Wireless Network Analyzer program
block.
Upon a successful launch of the software, the OptiView Wireless Network
Analyzer Front Page will appear as shown below. Monitoring of your WLAN is
automatically started. Access Points present on your wireless network are
discovered and displayed.
Figure 8. OptiView Wireless Network Analyzer Front Page Screen
•The top of the screen gives immediate visibility into the security level and
potential security vulnerabilities.
•The lower-left area of the screen displays discovery information about the
highlighted device. Note: IP and Name information can be discovered if
the analyzer has been configured to autolink using a default SSID. See the
Wireless Discovery Process section later in this guide for more details.
•Key configuration parameters are displayed.

OptiView
TM
Getting Started Guide
14
•The overall network health is displayed by continuously monitoring
802.11a/b/g channels and reporting key statistics important for
maintaining your network (e.g., signal strength, retry rates, signal-to-noise,
etc.).
Initial Setup
The color coding and icon legend on the Front Page screen and throughout the
user interface can be viewed by pressing the Legend button located at the bottom
of the screen.
The icons shown to the left of the SSID list are designed to provide immediate
visibility into potential unauthorized use of your network by unauthorized devices.
Device authorization is configured in the Details | Authorization screen.
indicates the device is set to Authorized
indicates the device has been set to Neighbor
indicates the device has been set to Unauthorized
Note
Initially, all devices are set to Unauthorized. See “Setting Up the
Authorization List” on page 16.
Country selection and global settings are configured in the Setup | Options screen.
Global settings include:
•Enable Active Channel Scan - This allows you to disable the wireless card
from transmitting and actively querying devices for richer discovery when the
Scanning indicator is shown in the upper-right corner of the screen.
•Enable Vendor Prefix for MAC - When this is selected, the vendor prefix (if
known) is displayed along with the last 3 bytes of the MAC address. When
this is not selected, the entire MAC address is displayed as a hexadecimal
value.
•Show signal strength in dBm - When this is selected, signal strength is
displayed in dBm units. When this is not selected, the signal strength is
displayed as a percentage.
•Enable Control Frame Packet Parsing – Turns on and off the display of
control frames in the Top Talkers and Packet Stats… screens.
•Enable Sounds for Wireless Discovery Events – When enabled, SSIDs that
become inactive for a specified time (see next item), are discovered for the
first time, or are re-discovered from an inactive state will cause a beep to
occur.

Wireless Network Analyzer
Using the OptiView Wireless Network Analyzer
15
•Remove Devices not seen for <time> - This is the time that a device can be
inactive before the device will be removed from the list of discovered devices.
Inactive devices are shown in red in the Link SSID and Authorization screens.
WNA Modes of Operation
Depending on what screen you are viewing, the OptiView Wireless Network
Analyzer operates in the following three different modes.
Active Channel Scan is the active and default state for the Front Page, Channels
and Survey screens.
In Active Channel Scan mode, the wireless radio card steps (sweeps) through all
channels (250 msec each channel) and then performs an active scan (sends out a
probe request from for Access Points to respond) at the end of sweep. To disable
the active phase option while scanning, navigate to the Setup | Options screen and
uncheck Enable Active Channel Scan.
Monitor mode is the active state for all Detail screens except the Top Talkers
screen. While in Monitor mode, the WLAN card is parked on a channel and
reporting key packet and WLAN statistics. This includes packet type and
destination, retries, utilization and signal strength. An inventory of WLAN devices
and details about their configuration (passively discovered) is also provided.
Linked mode is the active state for all the Tools screens, and the part-time state
on the Front Page screen. When a Tools screen is selected, you will be asked to
link (or connect) to an Access Point (SSID). When you leave any of the Tools
screens, the link with the SSID will be disabled. On the Front Page screen,
periodically, link will be re-established for about 15 seconds with the default and
configured SSID, and then it resumes Active Channel Scan. To enable active
discovery of WLAN devices, select the default SSID for autolink from the list and
then select the Default SSID button. The configured default SSID will be
indicated by an * next to the SSID name. Green text indicates the SSID is the
active default SSID. You may also select a default SSID from the Detail |
Authorization screen. Highlight an SSID and select the Default SSID button.
Note
The default SSID is set up by going to a Tools screen and selecting
the Link to… button. Select an SSID and select Edit Security… Enter
any security settings such as WEP or WPA/RADIUS settings and
press OK. Then select the Link button to link with it.

OptiView
TM
Getting Started Guide
16
Setting Up the Authorization List
The Detail |Authorization screen allows you to configure the application to aid in
the detection of rogue Access Points or Clients. All discovered devices are initially
classified as Unauthorized (rogue). You can use the Detail | Authorization
screen to re-classify them as Authorized or Neighbor .
A Neighbor (checkmark) is a classification of a device that is neither
Authorized or Unauthorized. A discovered device owned by an adjacent
company is typically classified as a Neighbor device.
Figure 9. Authorization Screen
To change an SSID’s authorization icon that will be displayed to the left of the
SSID:
1. From the Selected SSID list (left column), highlight an SSID.
2. Click on the Authorized or Neighbor radio button.
3. Select the Add Active button.
Changes are automatically applied when you exit this screen. You may also
establish or change a device’s authorization status from the Detail | Network and
Detail | Client screens. From these screens, select the drop-down found next to
the device and choose its authorization category. See next page.
