Flycatcher smART sketcher Projector User manual

The toy should be periodically examined
for potential hazardous parts to be repaired or replaced.
SIMPLE SET UPSIMPLE SET UP
Control Buttons
Paper Holder
On/O Switch (back)
AC Adapter
connection (back)
*Battery Compartment (bottom)
Adjustable
Focus Stability Legs
LED Indicators
Content
Card Slot
R
CAUTION-
ELECTRIC TOY:
N ot recommendedfor children
under
3 years of ages. A s with
all electric products, precautions
should be observed during handling
and use to prevent electric shock.
AC adapter: INPUT:100-240VAC, 0.3A MAX 50/60H z;
OUTPUT: 5.9V 1.0A
1. Separate the blue projector head from the white base unit.
2. Insert blue unit into top of white base until you hear a click.
3. Plug the AC adapter (included) into the back of the unit and into
a power outlet. If you wish to use batteries instead, insert 4 D
batteries (not included) according to the directions below.
Enable "eciency mode" by pressing the blue circle button for 2 seconds.
4. Pull out the blue legs to stabilize the projector and create a paper holder.
5. Flip the switch on the back to turn on the projector.
6. Insert the pre-loaded activity pack into the top of the projector.
7. After 10 minutes with no activity the projector light will
automatically turn o. Reactivate the light by using the buttons
in the app or on the projector.
For more fun, additional Creativity and Learn-A- Language
Alphabet Packs are available at: www.smartsketcher.com.
2s
USER MANUALUSER MANUAL

1 2
1. Download the “smART sketcher Projector” app on your mobile device or tablet.
2. Open the app and enable Bluetooth on your device.
3. If you haven’t registered yet: Click the “I have a smART sketcher” button and
follow the instructions to complete the one-time registration process.
If you have already registered: Click the “Login with Flycatcher ID” link.
4. Once the device is connected to the projector, choose your mode
of play: Learn to Draw (pre-loaded activity card), or Trace Pictures
(taken from your own device).
5. Trace Pictures:
- Click the camera button (you will need to enable permission
for access to camera and photos)
- Select an image from your photos or take your own
using the in-app camera.
- Select a lter.
- Drag the slider button to adjust darkness.
- Press the “check” button to transfer
the image to the smART sketcher® Projector.
- Begin tracing on paper.
6. Learn to Draw:
- Insert the preloaded activity card or
a smART sketcher Creativity Pack
(purchased separately) into the top
of the projector.
- The app will display the loaded content.
- Scroll to nd the image you want to draw and select it.
- The image will be projected onto your paper.
- Begin drawing!
Go to Home / Animate
Go Back a Step
Go Forward a Step
Previous Drawing
Repeat Last Step/AutoPlay
Next Drawing
In exceptional circumstances batteries may leak uids
that can cause a chemical burn injury or ruin your
product.
To avoid battery leakage:
To insert or change the batteries, twist the screw counter-clockwise to loosen. Remove old batteries and
insert 4 D batteries with the correct polarity. Replace the screw and twist clockwise to close.
Transformers / charger used with the toy are to be
regularly examined for damage to the cord, plug,
enclosure and other parts, and that, in the event of
such damage, the toy must not be used with this
transformer/charger until the damage has been
repaired.
The toy is not intended for children under 3 years old;
Note:
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from
that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician
for help.
1)
2)
3)
4)
The toy shall only be used with a transformer for toys
The model number XY06J-0601000Q-EW (EU
only/ XY06J-0601000Q-BW (UK only)/
XY06S-0601000Q-UW/XY06S-0591000Q-UW/
XY-0601000-A (Aus-NZ only) or specication of
Input Voltage:
AC 100-240V 50-60 Hz, Output Voltage: DC 5.9V, 1A,
transformer for use with the toy
The transformer is not a toy;
Toys liable to be cleaned with liquid are to be
disconnected from the transformer
before cleaning.
Non-rechargeable batteries are not to be recharged.
Rechargeable batteries are to be removed from the toy
before being charged.
Rechargeable batteries are only to be charged under
adult supervision.
Do not mix alkaline, standard (carbon-zinc), or
rechargeable (nickel-cadmium) batteries.
Do not mix old and new batteries.
Only batteries of the same or equivalent types as
recommended to be used.
Batteries are to be inserted with correct polarity.
Exhausted batteries are to be removed from the
product.
The supply terminals are not to be short circuited.
Dispose of battery(ies) safely.
Do not dispose of this product in a re.
BATTERY INSTALLATION
AC ADAPTER: RADIO STATEMENT
BATTERY SAFETY INFORMATION
For more detailed instructions,
questions or problems, please visit
www.smartsketcher.com.
smART sketcher® is a
trademark of Flycatcher Inc.
Copyright © 2017 Flycatcher
Inc.
All rights reserved.
Visit us at:
www.smARTsketcher.com
Requires Android 5.0+
Requires Apple iOS 8.0+
