Flycatcher smART STIX User manual

smART STIX™ is an innovative, building toy that encourages kids to engineer their projects
using bendable aluminum rods, assorted connectors, and a unique smART Workbench.
Kids can build open-ended designs using their imagination or they can download the free
smART STIX™ app or go to www.flycatcher.toys/smart-stix/models to access step-by-step
instructions for projects ranging from easy to awesome.
Once they choose a project, kids use the smART Workbench to measure and cut the exact size and
number of aluminum rods needed, bend them into the desired shapes, and connect them using the
connectors to complete their design.
1) Download the “smART STIX™” app on your mobile device or tablet*.
2) Open the app.
3) If you already have a Flycatcher account, sign in with your account.
If you do not have a Flycatcher account, go ahead and create a new one.
QUICK BUILDING GUIDE:
Once you have a blueprint for your design from the smART STIX™ app or website,
there are four simple steps to follow:
1) Measure
2) Cut
3) Bend
4) Connect
Note – sometimes these
steps occur in a dierent
order (for example, you
may bend and then cut)
Ages
8 to 108
USER MANUAL
-1-
Rod Bending Wrench
Main Rod Channel
Rod Holder Dial
Rod Cutter Fastner
Rod Cutter
Aluminum Rods
*Requires Android 8.0+
Requires Apple iOS 12.0+
QUICK BUILDING GUIDE:QUICK BUILDING GUIDE:
DOWNLOAD THE smART STIX™ APPDOWNLOAD THE smART STIX™ APP
The smART WORKBENCH:The smART WORKBENCH:

Measure:
Following the instructions on your smART STIX™ app or from the website, use the smART Workbench
and its built-in measuring surface to measure the aluminum rods to the desired length.
1) Loosen the Rod Cutter Fastener by turning it counterclockwise.
2) Loosen the Rod Holder Dial by turning it counterclockwise.
3) Slide a rod through the Rod Cutter and into the Main Rod Channel.
4) Align the rod with the desired length unit shown on the Measuring Surface.
Cut:
Once you’ve measured your rods, cut them using the smART Workbench built-in Rod Cutter:
1) Once your rod is set to the desired length using the Measuring Surface, and to ensure that your
rod will not roll during the cutting process, turn the Rod Holder Dial clockwise until it has pressed
down on the rod firmly.
2) To begin the rod cutting process, turn the Rod Cutter Fastener until the Rod Cutter Blade is
touching the rod you wish to cut (see illustrations below).
3) Once the Rod Cutter Blade is touching the rod you wish to cut, spin the Rod Cutter one full
revolution, tighten the Rod Cutter Fastener by rotating it clockwise half a revolution and then
spin the Rod Cutter another revolution. Repeat this until your rod is cut, which takes
about 6-8 revolutions.
Rod Cutter Blade
touching the Rod
Rod Cutter Blade
NOT touching the Rod
-2-
NOTE: Use the blue-colored measuring surface when measuring to cut a rod.
150
180
120
120
Rod Bending Wrench
Main Rod Channel
Degree Measurer
Rod Measuring Surface
Rod Holder Dial
Rod Cutter
Rod Holder Dial
Rod
Rod Cutter
Fastner
Rod Cutter
Rod Cutter Blade
Rod Cutter Blade
Rod
MEASURE:MEASURE:

Bend:
To bend your cut rods into the desired shapes, use the Rod Bending Wrench on your smART Workbench.
Depending on the part you are making, your Rod Bending Wrench may call for either the Small Diameter
Circle (“RADIUS 10”) or the Larger Diameter Circle (“RADIUS 20”).
Diameter Circles:
To change the Diameter Circle of your Rod Bending Wrench, follow these simple steps:
1) Pull out the Large Pin of the Rod Bending Wrench.
2) Pull out the Small Pin of the Rod Bending Wrench.
3) Insert the Diameter Circle you wish to use (“RADIUS 10” or “RADIUS 20”).
4) Replace the Small Pin:
a. In the second hole for “RADIUS 20”.
b. In the first hole for “RADIUS 10”.
5) Replace the Large Pin of the Rod Bending Wrench and insert it into the smART Workbench.
Now you’re ready to use the Rod Bending Wrench:
1) Take the rod you wish to bend and thread it between the Large Pin
and the Small Pin of the Rod Bending Wrench.
2) Depending on which Diameter Circle you are using, the rod will either rest in the Main Rod
Channel (“RADIUS 10”) or against the outside wall of the Main Rod Channel (“RADIUS 20”).
-3-
R
A
D
I
U
S
1
0
R
A
D
I
U
S
2
0
Rod Bending Wrench (RADIUS 20)
Large Pin
Small Pin (in second hole for “RADIUS 20”)
Rod Bending Wrench (RADIUS 10)
Large Pin
Small Pin (in second hole for “RADIUS 10”)
R
A
D
I
U
S
2
0
Rod Rod Bending Wrench (RADIUS 20)
R
A
D
I
U
S
1
0
Rod Rod Bending Wrench (RADIUS 10)
BEND:BEND:

-4-
3) Use the degrees marked on your smART Workbench along with the markers on your
Diameter Circle to bend your rod to the desired shape.
4) With one hand holding the smART Workbench, use the other hand to rotate the
Rod Bending Wrench to the desired bend. Once the desired bend is achieved,
pull your rod out and continue with your project.
To connect the cut and bent rods when building a project, use any of the various connectors:
• 1 smART Workbench.
• 30 ready-to-cut aluminum rods - 15 Black, 10 Blue, 5 Silver.
• 150+ assorted connectors.
• Free smART STIX™ app.
• User manual.
NOTE: Use the orange-colored measuring surface when measuring to bend a rod.
R
A
D
I
U
S
2
0
150
120
120
Degree Measurer
Connector
Rod
Rod
Rod
Rod
CONNECT:CONNECT:
CONTENTSCONTENTS

-5-
CONNECTORS INCLUDEDCONNECTORS INCLUDED
A1
A2
A3
B
C3
C4
D
E
F
G
26
23
8
8
8
14
11
16
37
8
QUANTITYNAME IMAGE

-6-
PARTS INCLUDEDPARTS INCLUDED
QUANTITYNAME IMAGE
FP1
FP2
S1
S2
S3
S4
S5
1
1
1
1
1
1
3
FP - Fighter Plane
S - Space Shuttle

-7-
PARTS INCLUDEDPARTS INCLUDED
QUANTITYNAME IMAGE
HC1
HC2
HC3
HC4
HC5
HC6
HC7
HC8
HC9
1
1
1
1
1
1
1
1
1
HC - Helicopter

-8-
smART STIX™
is a trademark of Flycatcher Inc.
Copyright © 2021 Flycatcher Inc.
All rights reserved.
Visit us at www.flycatcher.toys for more ways to play SMART.
Manufactured by:
Flycatcher Inc.
59 East 54th street
New York, NY 10022
Made in China
Please visit our website at www.flycatcher.toys/smART-STIX/Support
or reach out to our customer support team at info@flycatcherapps.com
FCM-IM-01 rev J
