Flyingvoice SR3000 User manual

User’s Manual
SR3000 & SR3000-lite

Chapter 1 Product Overview ......................................................................................................... 1
Product Description .......................................................................................................................2
Hardware Installation ....................................................................................................................4
Preparation of Installation ......................................................................................................4
Step of Installation ................................................................................................................. 4
Chapter 2 LCD Configuration .......................................................................................................5
Power On ...................................................................................................................................... 6
Mesh Networking .........................................................................................................................8
Basic Configuration ................................................................................................................... 10
Chapter 3 Web Configuration ..................................................................................................... 13
Two levels of administration .....................................................................................................14
URL Format ......................................................................................................................... 14
Password .............................................................................................................................. 15
Web Display and Configuration ................................................................................................16
Status ....................................................................................................................................17
Network ................................................................................................................................19
Management ............................................................................................................................... 31
Provision .............................................................................................................................. 31
SNMP ...................................................................................................................................33
TR069 ...................................................................................................................................34
Certification ......................................................................................................................... 35
System ........................................................................................................................................ 36
System Setting ......................................................................................................................36
System Management ............................................................................................................ 38
Backup/Upgrade ...................................................................................................................39
Chapter 4 Troubleshooting .......................................................................................................... 41
No Respond After Power On ...................................................................................................... 42
Unable to log in to the device's web page ...................................................................................42
Forget Your Password .................................................................................................................42
C a t a l o g s

Chapter 1 Product Overview SR3000 User's Manual
1
This chapter contains the following contents：
Product Description
Hardware Installation
Chapter 1 Product Overview

Chapter 1 Product Overview SR3000 User’s Manual
2
Product Description
Function/Model
SR3000
Product Picture
Power Supply
48V/0.32A (48V/1.2A Adapter is recommended if using PoE out)
Ports
1*WAN,10/100/1000Mbps，PoE out
3*LAN,10/100/1000Mbps
PoE
Passive PoE out 48V
WiFi 6
802.11 a/n/ac/ax, 2*2 MIMO , 1024-QAM@160MHz 2402Mbps, eFEM
802.11 b/g/n/ax, 2*2 MIMO , 1024-QAM@40MHz 573Mbps, eFEM
LCD
Supported
EasyMesh
Supported
Ports
Description
LAN
Connect local network device
WAN
Connect Internet, support PoE out
AC 100~220V
Connect power adapter

Chapter 1 Product Overview SR3000 User’s Manual
3
Function/Model
SR3000-lite
Product Picture
Power
48V/0.32A (48V/1.2A Adapter is recommended if using PoE out)
Ports
1*WAN/LAN,10/100/1000Mbps
WiFi 6
802.11 a/n/ac/ax, 2*2 MIMO , 1024-QAM@160MHz 2402Mbps, eFEM
802.11 b/g/n/ax, 2*2 MIMO , 1024-QAM@40MHz 573Mbps, eFEM
EasyMesh
Supported
LED
Status
Light On
Power on
Light Off
Power off
Red Light
Mesh unconnected
Flicker (Green)
Mesh connecting
Steady (Green)
Mesh connected

Chapter 1 Product Overview SR3000 User’s Manual
4
Hardware Installation
Preparation of Installation
Before installing the device, please check whether the product components and accessories are
complete and whether the installation conditions are available. Open the package of the device and
check whether the items in the box are complete against the list of items. If you find that the items in the
box do not match the list, please contact our company directly.
Step of Installation
Before setting up your gateway, you need to connect your device correctly：
Uplink Ethernet connection
·Connect the WAN port of the device to the modem with an Ethernet cable;
·Connect your computer to the LAN port of the device via RJ-45 cable；
·Connect one end of the power cord to the power connector of the device, and connect the other
end to a power socket；
·Launch the router；
·Check the power supply, LEDs of WAN port and LAN port and phone port indicators light for
proper.
NOTE:
·The installation site should be equipped with the conditions of equipment with external
connection (e.g. power line, network cable, PC, etc.), the AC power socket should be a
single-phase three-core power socket, and ensure that the ground wire is reliably grounded.
·The environment of the installation site should ensure sufficient air flow to facilitate the heat
dissipation of the device (the suitable working temperature of the device is 0℃～50℃).
·The installation site should have water-proofing, damp-proofing and shock-proofing
conditions (the appropriate environmental humidity for the equipment is 10% to 90%).
WARNING:
Please don't attempt to use an unsupported power adapter and do not disconnect the
power supply while configuring or changing the setting of the device. Use of other power
adapters may damage the device and void the manufacturer's warranty.

Chapter 2 LCD Configuration SR3000 User’s Manual
5
This chapter contains the following contents：
·Power On
·Mesh Networking
·Basic Configuration
Chapter 2 LCD Configuration

Chapter 2 LCD Configuration SR3000 User’s Manual
6
Power On
The SR3000 comes with a circular touch screen that allows you to swipe and click on the LCD to view the
time and date, instantaneous network speed, IP address, interface status, monthly traffic statistics, etc,
When the device is turned on, it automatically displays the loading progress and jumps to the standby
interface after loading is completed.
In standby screen, you can view the time, instantaneous upstream and downstream network speed, the
number of wireless access devices, and the number of agent devices in the mesh network. Swipe right to view
the WAN port IP address and router IP address, which is not available if your WAN port is not connected to a
modem.
Swipe right again to view the interface status of the device. If the interface is connected to the correct device,
the interface status will be lit up and deepened, and you can see that the interface has successfully
connected.

Chapter 2 LCD Configuration SR3000 User’s Manual
7
Swipe right again to view monthly traffic statistics, showing the upstream and downstream traffic within this
month.

Chapter 2 LCD Configuration SR3000 User’s Manual
8
Mesh Networking
The device can perform Mesh networking through LCD, support up to 2 agent devices to access the network,
and can view the information of the accessed agent devices, effectively extend the network coverage and
support fast roaming switching of terminal devices.
Slide down the standby interface to enter the Mesh interface.
The interface shows whether the agent device is currently connected or not, if it is not connected or only one
is connected, you can click the button to connect and you will be prompted for successful or failed connection.
After successful connection, it will automatically jump to show the connection status of master and agent
devices.

Chapter 2 LCD Configuration SR3000 User’s Manual
9
You can also click the button to view information about the agent device, including the device name, Mac
address, signal strength.

Chapter 2 LCD Configuration SR3000 User’s Manual
10
Basic Configuration
The device can be configured via LCD for basic configuration, which includes instantaneous network speed
test, current network diagnostics, backlight brightness adjustment, time setting, language setting, reboot, and
restore factory settings, language setting, reboot, and restore factory settings.
Swipe down 2 times on the standby screen to view the settings menu page and swipe right to view more
settings options.
Click the speed measurement icon to automatically test the current upstream and downstream Internet
speed.
Click the Network Diagnostics icon to diagnose the connection status of WAN port, IP address acquisition,
gateway address acquisition, DNS address acquisition, Internet connection, online status of Mesh devices.

Chapter 2 LCD Configuration SR3000 User’s Manual
11
Click the backlight adjustment icon to set the screen brightness for current operation, the screen brightness
when idle and not operating, and the interval time.
Click time setting to switch the time format and time zone.
Click language setting to switch between English and Chinese.

Chapter 2 LCD Configuration SR3000 User’s Manual
12
Click Reboot or Restore factory settings, you will be prompted to confirm twice to prevent accidental touch.

Chapter 3 Web Configuration SR3000 User’s Manual
13
This chapter contains the following contents：
·Two levels of administration
·Web interface management
Chapter 3 Web Configuration

Chapter 3 Web Configuration SR3000 User’s Manual
14
Two levels of administration
Our device supports two levels of administration: Administrator and User.
(1) For administrator mode operation, please type "admin / admin" on the username / password and
click the "Login" button to start system configuration, this level can configure all parameters to operate
the device.
(2) For user mode operation, please type "user / user" in the username / password, and click the
"Login" button to start system configuration, users at this level can browse and configure part of the
phone parameters, some parameters in SIP line that cannot be changed, such as server address and
port, cannot be configured by users at this level.
URL Format
The SR3000 has a built-in web server to respond to HTTP get/post requests. Users can use a web
browser, such as Microsoft Internet Explorer or Google Chrome, to log into the SR3000 pages and
configure the SR3000.
1. Login of LAN Port
Make sure your PC is properly connected to the LAN port of the router.
The URL format of the login web page is: http://<IP address of LAN port>, the default LAN port IP
address is generally: 192.168.1.1, please enter the corresponding address in the address blank:
http://192.168.1.1, then the page will jump to the login page of the device, as the following picture:
2. Login of WAN Port
Make sure your PC is properly connected to the WAN port of the router.
Obtain the WAN port IP address: You can log in to the device's Web management interface through the
LAN port and navigate to the Status - Basic Settings page,you can view the IP address of the WAN port
at this page.
Log in to the Web page: Open a Web browser on your PC and enter http:// <IP address of WAN port:
Port>, the default port is 50080 normally. The following login page will open, enter your user name and
password, and click “Login”.

Chapter 3 Web Configuration SR3000 User’s Manual
15
Password
There are two login levels for the device, the administrator level and the normal user level, with different
passwords for different levels.
The default login username/password for the administrator level is admin/admin.
The default login username/password for normal user level is user/user.
1. Change the password
Log in to WEB page of the device, switch to the System-Management page, find the "Reset Password"
tab, select the “user type”, then you can set a new user name and password, click "Save".
2. Forget your password
If the user changes the password for Web page and forgets it, resulting in the user being unable to
access the SR3000 configuration interface, please press and hold the restore factory key for more than
5 seconds to restore the device to factory settings, and then use the default password to login.
NOTE:
If the following prompt appears：
Please reboot the device to ensure the changes take effect

Chapter 3 Web Configuration SR3000 User’s Manual
16
Web Display and Configuration
This section describes the layout of the Web page ，providing a better experience in configuring the
device through the Web page.
Number
Name
Description
Position 1
Main Navigation bar
Click the navigation bar, the corresponding
sub-navigation bar will appear
Position 2
Sub-navigation bar
Click on the sub-navigation bar to go to the configuration
page
Position 3
Title bar
Title Configuration
Position 4
Configuration Bar
The firmware version, current time and management
mode of the phone are displayed. User can click Log out
to exit
Position 5
Device Name
Display the device model
Page button
information
You need to click this button to save after making
changes to the parameters. After clicking “Save”, you
need to restart the device if there is a reboot prompt.
Click to cancel the changes
Click to reboot the device
Click to exit Web page
Click to save and apply the configuration changes.
Click to refresh the page

Chapter 3 Web Configuration SR3000 User’s Manual
17
Status
1. System Information
This web page shows information of device, network, and system status , including product information,
memory, intranet information, wireless information, and network status.

Chapter 3 Web Configuration SR3000 User’s Manual
18
2. System Log
At this configuration page, users can view the system log, which contains important configuration
information for the SR3000. Users can use the Clear button to delete all logs and clear all information;
use the Refresh button to refresh the system logs; and use the Save button to save the logs to the local
computer, then you can export the logs.
