FM Electronics FM4000X User manual

FAULT FINDING GUIDE
CUSTOMERHADANALARM Ask them to press the Full set button and tell you
what indicators are on.
TheLED'sindicatethecauseofthealarmandalsothesettingstatusatthetime.
MAINSLEDFLASHING Mains failure (Restore supply)
ZONELEDFLASHING(inexit) Check that doors and windows are closed.
Flashing with tamper LED. (A detector has an open tamper).
Flashing with Battery LED. (The detectors battery needs replacing).
ALARMLEDON Full alarm. The LEDs indicate what caused the alarm.
If Engineer reset is programmed into the panel an engineer reset will be required before
the system can be re-armed.
FLASHINGWITHZONELED A detector on soak test has trig-
gered whilst the sys-
tem was armed. FLASHINGWITHOUTAZONELED An engineerresetis required.
BATTERYLEDON The control panel's battery is disconnected or needs re-
placement. FLASHING: Detector has a low battery. The zone LED will flash
to indicate which one.
SIGNALLING LED ON The system is being blocked by a continuous transmission.
FLASHING If flashing on its own, an external line monitor has
signalled that the telephone line is at fault.
Flashing together with a zone indicator. The system is set as a supervised
system and the detector indicated by the flashing zone LED has failed to report in. ( Re-
site the detector where there is good radio reception. Use the RSSI output to check.
CONTACT TRANSMITTER NOT WORKING Check the magnetic contact is operating
correctly. Openlidandcheckwhatzone itshouldbeon. Go intothepanel engineermode
and check if it has been programmed onto the correct zone.
Note: the panel will not allow you to program a detector onto two zones. When pro-
grammed onto a zone any previous zone allocation will be deleted.
PIRNOTWORKING The detector needs 6 minutes to settle on power up.
Set the control into operator walk test mode and walk test the detector with the cover
removed. Removing the cover opens the tamper and overrides the 2 minute inhibit timer.
If the test jumper inside is fitted and the cover replaced it overrides the 2 minute inhibit,
but allows you to walk test it without a tamper alarm.
CUSTOMERHASFORGOTTENTHEIRCODE Open the panel and short out the MEM
jumper. Theuser andengineer codes willbe restoredto the factorydefaults 1234&4679.
No other programming is affected.
15
OFF
PARTSET
FULLSET
ZONES PANIC FIRE
FM4000X and FM4001
CONTROL PANEL
INSTALLATION INSTRUCTIONS
SIGNALLING TAMPER LOW
BATTERYALARM
MAINS ON
CI-123 iSS 2
FM Electronics Ltd Manufacturer of quality wireless products
FM4000X
2 6 J u n 1 5 : 4 1 : 2
2
P a n e l d i s a r m e d

1
CONTENTS
14
++
_ _
5
6
8
7
9
10
11
12
13
4
3 2
1
5
6
7
8
4
3
2
1
ANTENNA
GROUND
TAMPER
MEM Jumper
ZONE 1
LINE FAULT INPUT
12VAUX Max500mA
+ LATCH
-ve SIREN
-veSTROBE
FULL SET IN
PARTSET IN
LED 2
LED 1
-veDIALLER
-veTAMPERRETURN
17V a.c.Input
EXIT SOUNDER Volume level adjust
Link 5 to 4 if -ve from SAB is not connected to 5.
Hard wired arming
Alarm outputs
DIALLER OUTPUTS
RSSI
RESET
Aux.
Armed
Panic
Fire
Jamming
Low battery
Auto report fail
Alarm
EXITTERMINATE
PUSH
ZONE 2 / PA
1AAUX
2ABAT
L.S.
FUSES
+VOLTMETER
CONNECTION
-
Plug lead from 4001 on here
FM4000X CONTROL PANEL
Controlpanelconnections.
Descriptionofoperation 2, 14
LCDdisplayconnections.
Descriptionofoperation 2, 13
Installationprocedure. 3
Programming 4
AddingDetectors 5
AddingRemotecontrols 6
Exit Entry times 6
Sirenoutputprogramming 6
Zoneoptionprogramming 7
Options 27 to 50 8 - 10
Remoteengineerreset 10
Antennatampermodule 11
Wiredarmingconnections 12
S.A.B. connections 12
LCDunitconnectiondiagram 13
FM4000XConnectiondiagram 14
Faultfinding 15
Page

2
FM4000X
CONNECTIONS
CONNECTIONS (RIGHTHANDSIDE)
1-4 12V Auxiliary supply output.
Maximum load current 500mA
5 Tamper -ve return. If connecting
a Self Actuating Bell (SAB) then connect
the
-ve tamper return to this terminal. If not
fitting a SAB this terminal must be
connected to -ve Aux..
6. This terminal provides a +ve
output on alarm which is reset next time
the panel is armed. It is provided for use
with hard wired detectors that have a
latching LED facility.
7. -ve to trigger Siren. Goes from
opencircuit to 0v to operate a bell or siren.
Max500mA.
Resets after the bell time set in engineer
program.
8. -veStrobe. Goesfromopencircuit
to0vinalarmtooperateastrobe.Remains
on until the system is disarmed.
9. Diallertriggeroutput. Is provided
for triggering an autodialler. This output
goes to 0v on full alarm.
Oncetriggered it remains until the panel is
disarmed so as not to trigger any more
until the system is turned off.
10 FaultLEDoutputforremotewired
arming. Indicates that a fault is present
which will prevent arming.
11. SystemOffLEDoutputforremote
hard wired arming. Indicates when
disarmed.
12. Part Set hard wired arming input.
Apply +12v to arm. Remove to unset.
13
PLUG ON DIALLER CONNECTORS
LCD CONTRAST ADJUST
8
76
5
4
3
2
1
TAMPEROUTPUT
FM4001 LCD DISPLAY
DIALLER OUTPUTS
+12V INPUT
0VINPUT
-BAT
+BAT
BATTERY FUSE1A MAINFUSE1A
PARALLEL PRINTER CONNECTOR
CLOSED
LOWBATTERY
AUXILIARY
JAMMING
AUTOREPORTFAIL
ALARM
P.A.
FIRE
13. Full Set hard wired arming input.
Apply +12v to arm. Remove to unset.
CONNECTIONS ALONG BOTTOMEDGE
HARD WIRED INPUTS 1 & 2
Must be linked out if not used. These
inputs are normally closed, opening in
alarm. Zone 2 can be programmed to be
aPA zone.
EXITTERMINATEPUSH
Connection for a normally open push
buttonwhichsetsthealarmwhenpressed
during the exit time.
LINE FAULT INPUT
Normally closed input. Open for line fault.
Totrigger with applied negative, leavethe
link in place and apply 0v for line fault.
DIALLER OUTPUTS 1-8
These outputs are for connection to a
digital communicator employing +ve
removed trigger inputs.
Theoutputs go from+5v to 0vin alarm.
These outputs are also available on the
FM4001
RECEIVEDSIGNAL STRENGTH
INDICATION (RSSI)
For connection to a digital voltmeter to
indicate the Signal Strength of a
transmission received from a detector.
(RefertosectiononusingtheRSSIoutput).
FM4001 CONNECTIONS
The FM4000 LCD unit is supplied with a
connecting lead which plugs into the
FM4000x expansion port connector.
MounttheLCDdisplayataheightofabout
4ft 6in. so that the display can be viewed
correctly.
Mount the FM4000X directly below the
LCD unit and plug in the connecting lead.

2. Complete the User Record
The back pages of the user instruction
booklet should be completed and left with
the operator for their reference. It gives
them information about the zones etc.
3. Complete a system record sheet
System record sheets should be
completed before commencing
programming. This acts as a reference
when programming and can form part of
the installation records.
4. Locate the control panel
For best radio coverage the control panel
is best located at a central point in the
building.
Thehigheritisthebetterforradioreception.
(Do not mount at floor level on a ground
floor)
Metal objects cause radio reflections
which oppose the signal being received
fromthedetectorwitharesultantreduction
inthereceivedsignalstrength. Metalwork
close by can result in complete
cancellation, therefore do not site the
control panel or detectors near to large
metal objects, metal piping, girders,
concentrations of mains cabling, fuse
boxes etc.
Considertheease ofwiring tothe external
siren when making your choice.
ThePanelmaybetemporarilysitedwhilst
a test is carried out to verify the reception
from distant detectors.
The panels must be fixed using the three
fixing points provided. Ensure that the
LCD display on the FM4001 is approx. 4ft
6 in. high for ease of viewing and that the
FM4000Xismounteddirectlybelowit. For
larger installations a remote tamper
protected antenna is available.
FM4001 CONNECTIONS cont..
312
11
12
13
10
1
470R
Resistors Fault LED (If required)
Armed LED (If required)
+12V
WIRED KEYPAD / KEYSWITCH ARMING
Part
Full
Off
Bell sw-
Bell sw+
Tamper feed
Tamper return
Strobe +
Strobe -
-ve Hold off
+ve Hold off
7
1358
Connections ontheFM4000main board
SABCONNECTIONTOTHEFM4000
12vSUPPLYTOTHEFM4001
Connect to the 12v aux output of the
FM4000x
TAMPEROUTPUT.
Clean contact normally closed output.
Tamperreturnfromthesirencanberouted
via this contact. If the tamper is operated
a tamper alarm will occur.
STAND-BYBATTERY
Connectionsareprovidedforanadditional
stand-by battery inside the FM4001 for
situations where a battery is required in
additiontotheonealreadyintheFM4000x
.
LINEFAULTOUTPUTTOFM4000X
This output is used when employing a
plug on dialler. The dialler should be
programmed for -ve applied on line fault.
Thisconnection can then be connected to
thelinefault inputontheFM4000. (Leave
the link fitted in the line fault input) .
DIALLEROUTPUTS1-8
Theseoutputsareidenticaltothe8outputs
in the FM4000x. They are provided for
convenience since it is easier to locate a
digi dialler into the FM4001.
See connection diagrams at back of
manual.
INSTALLATION
The factory defaults for the user and
engineercodesare:-
USER CODE = 1 2 3 4
ENG CODE = 4 6 7 9
The recommended installation procedure
is as follows:
1. Label detectors.
Label each detector with its zone number
for reference during installation and for
later service reference.

Mains supply to the control panel must be
provided bya competent electrician to the
current issue of the IEE regulations.
A 12v sealed lead acid stand-by battery
should be connected after all wiring has
been completed and tested. 12v 2.3AH is
recommended.
5. Program detectors onto the panel
Each detector has an internal "Learn"
jumper.
To add a detector to the system:
Go into the engineer program. Select the
zone and device number. Short out the
learn jumper on the detector. Removethe
learn jumper after programming.
Thedetectortransmitsitsidentitytogether
with a learn bit. The panel stores the
detectors identity code and adds it to the
chosen zone.
(Refer to engineer programming section)
6. Carry out range test
Ifyoukeepa4174remotecontrolfortesting,
you can program this onto the system and
then go to each detector location in turn
and verify that the control can be armed
and disarmed from all detector locations.
7. Mount the detectors
Refer to the detector instructions for
recommended mounting positions.
Asreflectionsfrommetalworkacttocancel
the transmission, avoid siting near to any
metalwork.
Reflectionslikethiscanoftenbeovercome
by a small movement in position of 15 to
20cm.
8. Making panel program changes.
Complete a system record sheet before
making any changes.
Once programmed the program is stored
innonevolatilememory,sodatawillremain
storedevenintheeventofcompletepower
failure.
INSTALLATION cont... 9. Radio test using the RSSI output
To measure the signal strength received
from a detector.
i) Connect a Voltmeter to the RSSI
output terminals.
ii) Pressthereset buttonnext tothe
RSSIterminals.Thevoltmetershould now
read zero volts.
iii) Go to the detector and operate
the learn jumper.
iv) Returntothepanel.Thevoltmeter
now displays a voltage representing the
strength of the transmission received.
It will ignore any other transmissions and
only respond to the learn message or a
Panic or Off message from a remote
control or panic button.
Thevoltage reading should be a minimum
of1.0v.
The readings for each detector can be
recorded on the system record sheet for
future reference.
10. Full system test
A walk test facility is provided in the
Operating instructions. This may be used
to do a test of the detectors only.
Once the Sounders and dialler have been
connected and the installation completed
a full test with remote signalling should be
carried out.
PROGRAMMING
1. Enter the engineers code 4 6 7 9
The Alarm led will flash slowly to indicate
that you are in the program mode.
2. Key in the two digit program number.
(The zone led's indicate which option is
set.)
3. Key in the option required
(The zone led's indicate your choice)
4. Press the Full Set key to exit that
4
11
Displays the software issue of the 4000X
panel, press full set to exit.
REMOTE ENGINEER
RESET FACILITY
When an alarm occurs which requires an
engineerreset,theusercancalltheCentral
Station and obtain the access code
number to key in to the panel.
The panel zone LED's will illuminate
randomly.
From the LED's the Central Station
operatorcanrefertoareference tableand
instruct the user what code to enter to
perform an engineer reset.
Next time the alarm operates the reset
code number will have changed.
Coax to FM4000 Antenna input termi-
nals ( Inner to top terminal outer to
bottom terminal ).
Remove link to make antenna
tamper active.
+12V 0V
If LED is ON tamper is
open ( Antenna
disconnected ).
BNC connector for remote
antenna.
GND/OUTER
SIGNAL/INNER
Alternative connection for
remote antenna.
Tamper return
To FM4000
terminal 5.
-ve tamper feed
from SAB ( If SAB
not used link this
terminal to 0V ).
Mount the module to the right hand side of the transformer in the FM4000 with
the single screw supplied.
4005 ANTENNA TAMPER MODULE
The 4005 is for use with tampered remote antennas.
When fitted into the FM4000 panel the -ve tamper return from an external
siren is connected to this module as shown below.
Always mount the remote antenna away from other wiring, any other metal objects and
as high as practically possible to obtain the best working range from the 4000X control
panel.

Theoutput from thereceiver can be heard
on the panel loudspeaker.
Press the full set key to exit.
46 DISPLAYENGINEERSLOG
Presskeys1to 8toview thelast 8events.
Most recent is displayed on key 1.
Key 9 shows the last "First to Alarm"
Press the full set key to exit.
47 CHANGEENGINEERSACCESSCODE
Key in a 4 digit code twice.
48 LEAVEENGINEERMODE
If any devices have their tampers open,
the display shows which zones are
tamperedand willgenerate an errorbeep.
The tampers must be restored before
leaving engineer mode by pressing 48
again.
49. DIALLEROUTPUTFORPA
1= PA Triggers PA dialler output
0=PATriggersbothPAandALARMdialler
outputs*
Press the full set key to exit.
50. HARDWIREDPAONZONE2
1= Zone2 is a PA zone
0= Zone2 is a standard zone*
Press the full set key to exit.
This feature enables hardwired PA
buttons to be connected to the panel
via the zone 2 hardwire input.
CAUTION: Radio devices including PIRS
and contacts programmed onto zone 2
will also trigger a PA alarm if this option is
selected.
51 FINALEXITSET
1= Yes 0= No*
If yes the exit time will terminate when the
final exit door is closed.
52 REMOTECONTROLFULLSET
EXIT TIME
5
program step.
5. When finished with programming key
in 48 to exit engineer mode.
ERRORCORRECTIONVIAPARTSETKEY
If you accidentally enter an engineer
program number and change an option
value, you can undo the change by
pressing the Part Set key before exiting
the program step via the Full Set key.
EXAMPLE: TosettheFullsetexittimerto
1 minute.
Key in 4 6 7 9 The alarm indicator will
illuminate to indicate that you are now in
engineer program mode
Key in 1 2 To select Full set exit
time (program No. 12.)
Key in 6 To select the 1 minute option.
Zone 6 LED indicates your choice
Press the Full Set button to exit program
step.
Note:TheFullsetbuttonmustbepressed
to exit from each program step.
UntiltheFullSetbuttonispressedanykey
press just changes your choice of option.
Keyin thenext programNumber youwish
to change.
When all programming is complete Key
in 48 to exit engineer mode
LEARNINGDEVICES
When installing the system you may find
it easier to label each detector with its
zone number and learn them into the
panel before installation. Once
programmed into the panel's memory,
DETECTOR
PROGRAMMING
the information will not be lost even when
power is removed from the panel.
01 PROGRAMDEVICESONTOZONE1
Select program number 01.
TheLCDdisplaywill show"LEARNZONE
1 DEVICE ?
The LEDs 1 to 8 indicate which of the 8
devices are already programmed onto
zone 1.
Use keys 1 to eight to select the device
number.
Short out the learn jumper on the detector
andensurethatthelearnpinsarenotleft
permanently shorted.
Thepanel willemit 2short blips toindicate
that it has learnt the detector.
The corresponding LED will illuminate
and the LCD will display the unique 5 digit
identity code of the device with the
message LEARNT OK.
If the device was already programmed on
the system at a different location the
messagewillsayMOVEDFROMxx (where
xx is the old zone and device number).
Ifadevicewasalreadyprogrammedinthe
location the LCD will show the message
ALREADYSTORED
and the new device will overwrite it.
Automatically deleting the old one.
Press the Full Set key to exit.
DELETINGDEVICES FROM ZONE 1
Select program number 01.
The LCD display will show
LEARN ZONE 1 DEVICE ?
The LEDs 1 to 8 indicate which of the 8
devices are already programmed onto
zone 1.
Use keys 1 to eight to select the device
number to be deleted.
IfadevicedidexistatthatlocationtheLCD
will show ALREADY STORED. 10
1=2s 2=5s 3=10s 4=15s 5=20s 6=30s
7=1min 8=infinite
Thisappliestoremotecontrolandremote
keypad only.
The exit time when armed from the panel
keypad (option 12) is not affected.
53 REMOTECONTROLPARTSETEXIT
TIME
Enablesthe exit time to be set for part set
via the remote control / keypad. The exit
time set by option 13 still applies when
arming from the panel keypad.
1=2s 2=5s 3=10s 4=15s 5=20s 6=30s
7=1min 8=infinite
54 ABORT (not operational on this
version)
55 VERIFICATION (not operational on
this version)
56 DIALLERTEST
Key in 56 followed by a number key to
operate a dialler channel. The number
selected will be displayed.
1= Jamming
2= Low Battery
3= Alarm
4= Supervisory failure
5= Auxilliary Alarm
6= System Armed
7= Panic Alarm
8= Fire Alarm
Pressfull set key when test is completed.
57. DIALLERTRIGGERINVERT
All the dialler outputs are positive
removed as the default setting, but can
be inverted to Negative removed if
required. To invert an output key in 57
followed by the required output to be
inverted, using the same list as used for
the dialler test.
Press full set key when outputs have
been selected, outputs will change to the
selected settings when the full set key is
pressed.
58.DISPLAYSOFTWARE ISSUE.

programming).
Upto8 Firedetectors canbeprogrammed
ontotheFire zone,i.e. devices101to 108.
The LCD display will refer to the Fire
detectors as F1 to F8.
Press the Full Set key to exit.
11 REMOTECONTROLS
Key in 111 to program the first Remote
Controlontothe system. ThePanic button
is operated instead of a learn jumper.
Up to 8 Remote Controls can be
programmed onto the system, i.e. devices
111 to 118.
The LCD display will refer to the remote
controls as R1 to R8.
Press the Full Set key to exit.
EXIT ENTRY
12 FULLSETEXITTIME
1= 2 secs 2= 1O secs 3= 2O secs*
4= 3O secs 5= 45 secs 6= 1 min.
7= 2 mins. 8= Infinite
Press Full Set to exit
*=FACTORYDEFAULT
13 PARTSETEXITTIME
1= 2 secs 2= 5 secs 3= 1O secs*
4= 15 secs 5= 20 secs 6= 30 secs
7= 1 mins. 8= As full set exit time.
Press Full Set to exit
14 ENTRYTIME
1= 1 sec 2=10 secs 3 =
20 secs 4= 30 secs* 5= 40secs 6=
50 secs 7= 1 min. 8= 2 mins.
Press Full Set to exit
SIREN
00 INVERTSIRENOUTPUT
Normally -veappliedinalarm.(0vinalarm)
0 = -ve applied in alarm
DETECTOR
PROGRAMMING cont...
6
To delete the device press PART SET and
OFF keys together.
The LCD will show that the device has
been deleted.
Press the Full Set key to exit
02 PROGRAMDEVICESONTO
ZONE 2
03 PROGRAMDEVICESONTO
ZONE 3
04 PROGRAMDEVICESONTO
ZONE 4
05 PROGRAMDEVICESONTO
ZONE 5
06 PROGRAMDEVICESONTO
ZONE 6
07 PROGRAMDEVICESONTO
ZONE 7
08 PROGRAMDEVICESONTO
ZONE 8
09 RADIOPANICBUTTONS
Key in 091 to program the first PA button
onto the system. The Panic button is
operated instead of a learn jumper.
Upto 8 Panic buttons can be programmed
onto the PA zone, i.e. devices 091 to 098.
The LCD display will refer to the panic
buttons as P1 to P8.
Press the Full Set key to exit.
10FIREALARMDEVICES
Keyin101toprogramthefirstFiredetector
ontothesystem. Shortoutthelearnjumper.
(Ensure learn jumper is removed after
entry time when unsetting from Full Set.
(If a mains relay was connected via this
output a mains courtesy light could be
switched on by disarming from outside
with a remote control.)
1= Courtesy strobe on O=off*
Press the full set key to exit.
33 WALKTHROUGHZONESBECOME
FINALEXITINPARTSET
To prevent false alarms in part set it is
often useful to make walk through zones
initiate the entry timer.
1= Yes O= No*
Press the full set key to exit.
34 JAMMING
1= Jamming generates afull alarm when
set
O= indicator only*
Press the full set key to exit.
(Jamming is signalled to the dialler
outputs.)
35 MAINSFAILURE&PANELLOW
BATTERYPREVENTSARMING
1 = Mains failure or Panel battery failure
prevents arming.
O = Does not prevent arming*
Press the full set key to exit
36 REMOTECONTROLUNSETS
ONLY IN ENTRY
1= Unset only after entry timer has been
started.
O= Unset not inhibited*
Press the full set key to exit.
37DIALLERDELAYED(20secondabort
time)
1= Delayed O= Instant *
Press the full set key to exit
9
38NOEXTERNALBELLORDIALLERIN
PARTSET
(Internal bells only in Part Set).
1= Internal sounder only in Part Set.
O=DiallerandsirenInbothfullorpartset*
Press the full set key to exit
39LINEFAULTINDAYTIMEAUDIBLE
1= Audible and visual 0= visual
only*
Press the full set key to exit.
40 SUPERVISORY
Do not select supervisory unless all your
detectors are 4600 series.
Do not select supervisory if using zoned
Panic buttons.
1= Supervision O= No supervision*
Press the full set key to exit.
41 SUPERVISORYFAULT
1= audible when unset O= silent
when unset*
Press the full set key to exit
42 ENGINEERRESET
1= Engineer reset O =
No*
Press the full set key to exit.
43 REARMING
1=none 2=once 3=twice 4=always*
Press the full set key to exit
44 RESTORE ENTIRE NV RAM TO
FACTORYDEFAULTVALUES
Shortout theMEM linkwhile keyingin 44.
AllzoneLED's willcome on,the panelwill
emit a long bleep and will go out of
engineering mode into the day state.
WARNING: This will delete all detectors
from the system.
45AUDIBLERECEIVEMODE

28 DOUBLEBUTTONP.A.
(Toactivateapanicfromaremotecontrol,
both PA & OFF buttons must be pressed
simultaneously)
The factory default is single button.
1= Double O= Single*
Press the full set key to exit.
29 SILENTPARTSET
1= Silent O= Audible*
Press the full set key to exit.
30 UPSTAIRS/DOWNSTAIRS
This option tells the panel to accept part
set button as a separate alarm system.)
e.g.. The Part Set button becomes the
alarm system in the flat & the Full set
button is a separate alarm system in the
office. Inthismodethe usercan seteither
one or the other, or both systems by
selection when arming.
1 = Select Upstairs/Downstairs mode.
O= Normal Part / Full set mode.*
Press the full set key to exit.
31 8SECONDSTROBEWHENFINALSET
ANDUNSET
If selected the strobe output operates for
8 seconds at the moment the panel is full
set. i.e. when the exit timer terminates.
The strobe also operates for 8 seconds
when the panel is Unset from Full Set.
1 = 8 sec. Strobe 0 = No 8 second strobe
Press the full set key to exit.
32 COURTESY STROBE IN FULL SET
ENTRY/EXIT
If selected the strobe output terminal 8
operates when Full setting the panel.
The strobe output also operates for the
The factory default is all zones allowed to
be omitted except zone 1.
Thezone LED's indicatewhich zones are
allowed to be omitted.
Use the keys 1 to 8 to select or deselect
zones. The 0 key deletes all.
Press the full set key to exit.
2O FINALEXITZONES
(Zones that start the entry time)
The factory default is zone 1 only.
Thezone LED's indicate which zones will
start the entry timer.
Use the keys 1 to 8 to select or deselect
zones.
The 0 key deletes all.
Press the full set key to exit.
21 WALKTHROUGHZONES
The factory default is none.
Thezone LED's indicatewhich zones are
walk through during entry.
Use the keys 1 to 8 to select or deselect
walk through zones.
The 0 key deletes all.
Press the full set key to exit.
22 IGNOREZONEIFFIRSTTOALARM
(DoubleKnock)
Alarm only if two zones are triggered.
The factory default is none.
Thezone LED's indicatewhich zones are
double knock.
Use the keys 1 to 8 to select or deselect
double knock zones.
The 0 key deletes all.
Press the full set key to exit.
23 AUXILIARYZONES
Technical alarm. i.e.. Freezer giving
internal audible and technical alarm
channel of dialler.
The factory default is none.
The zone LED's indicate which zones
are auxiliary zones.
Use the keys 1 to 8 to select or deselect
aux. zones. 8
7
1 = -ve removed in alarm
15 BELLDURATION
1= Silent 2= 15 secs 3= 2
mins.
4= 3 mins. 5=10 mins. 6 =
15 mins.
7= 20 mins.* 8= Continuous
Press Full Set to exit
16 BELLDELAY
1= 0 mins.* 2= 1 mins. 3= 3
mins.
4= 4 mins. 5= 5 mins. 6 = 6
mins
7=7 mins* 8= 10 mins
Press Full Set to exit
ZONE PROGRAMMING
IMPORTANT: Remember that all devices
on a particular zone will respond to the
zoneoptionselected.Soif zone1hasfinal
exitdetectors,alldetectorsonzone1must
also be final exit.
17 FULLSETZONES
The factory default is all zones active.
The zone LED's indicate which zones are
active in full set.
Use the keys 1 to 8 to select or deselect
zones. The 0 key deletes all.
Press the full set key to exit.
18 PARTSETZONES
The factory default is zones 1 to 4 active.
The zone LED's indicate which zones are
active in part set.
Use the keys 1 to 8 to select or deselect
zones. The 0 key deletes all.
Press the full set key to exit.
19 OMITPERMITZONES
(Thezonesthattheuserisallowedtoomit)
The 0 key deletes all.
Press the full set key to exit.
24 24HOUR ZONES
The factory default is none.
The zone LED's indicate which zones are
24 hour.
Use the keys 1 to 8 to select or deselect
24 hour zones.
The 0 key deletes all.
Press the full set key to exit.
NOTE: If you do not want a 24 hour zone
to be omitted, remove the zone from omit
permit via program No.19.
25 SOAKTESTZONES
The factory default is none.
The zone LED's indicate which zones are
on soak test.
Use the keys 1 to 8 to select or deselect
soak test zones.
The 0 key deletes all.
Press the full set key to exit.
26 CHIMEZONES
The factory default is none.
The zone LED's indicate which zones are
on chime.
Use the keys 1 to 8 to select or deselect
chime zones.
The 0 key deletes all.
Press the full set key to exit.
OTHER PROGRAMS
27 P.A.SILENT/AUDIBLE
The factory default is audible.
1= Silent O= Audible *
Press the full set key to exit.

IMPORTANTNOTE
Programmingdetectorsisdifferentto the standard FM4000.
e.g. Key in 012 to select device 2 on zone 1.
TheLED'swillindicatewhichdevicesare already programmed on
that zone & if the LCD expansion unit is fitted the LCD will also dis-
playthezoneselected.
Refertopage5ofInstallationinstructions).
IMPORTANTNOTE
Programmingdetectorsisdifferentto the standard FM4000.
e.g. Key in 012 to select device 2 on zone 1.
TheLED'swillindicatewhichdevicesare already programmed on
that zone & if the LCD expansion unit is fitted the LCD will also dis-
playthezoneselected.
Refertopage5ofInstallationinstructions).
IMPORTANTNOTE
Programmingdetectorsisdifferentto the standard FM4000.
e.g. Key in 012 to select device 2 on zone 1.
TheLED'swillindicatewhichdevicesare already programmed on
that zone & if the LCD expansion unit is fitted the LCD will also dis-
playthezoneselected.
Refertopage5ofInstallationinstructions).
IMPORTANTNOTE
Programmingdetectorsisdifferentto the standard FM4000.
e.g. Key in 012 to select device 2 on zone 1.
TheLED'swillindicatewhichdevicesare already programmed on
that zone & if the LCD expansion unit is fitted the LCD will also dis-
playthezoneselected.
Refertopage5ofInstallationinstructions).
IMPORTANTNOTE
Programmingdetectorsisdifferentto the standard FM4000.
e.g. Key in 012 to select device 2 on zone 1.
TheLED'swillindicatewhichdevicesare already programmed on
that zone & if the LCD expansion unit is fitted the LCD will also dis-
playthezoneselected.
Refertopage5ofInstallationinstructions).
IMPORTANTNOTE
Programmingdetectorsisdifferentto the standard FM4000.
e.g. Key in 012 to select device 2 on zone 1.
TheLED'swillindicatewhichdevicesare already programmed on
that zone & if the LCD expansion unit is fitted the LCD will also dis-
playthezoneselected.
Refertopage5ofInstallationinstructions).
