FMI VFP18R Quick start guide

Save this manual for future reference.
WARNING: If the information in this manual
is not followed exactly, a fire or explosion
may result causing property damage, per-
sonal injury, or loss of life.
— Donotstoreorusegasolineorotherflammable
vaporsandliquidsinthevicinityofthisorany
other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas sup
plier, call the fire department.
— Installationandservicemustbeperformed
by a qualified installer, service agency, or
the gas supplier.
WARNING: Improper installation, adjust-
ment, alteration, service, or maintenance
can cause injury or property damage. Re-
fer to this manual for correct installation
and operational procedures. For assis-
tance or additional information consult a
qualified installer, service agency, or the
gas supplier.
WARNING: This appliance is for installa-
tion only in a solid-fuel burning masonry,
UL127 factory-built fireplace, or in an ap-
proved ventless firebox. It is design certi-
fied for these installations in accordance
with ANS Z21.11.2. Exception: Do not in-
stall this appliance in a factory-built fire-
place that includes instructions stating it
hasnotbeen tested or shouldnotbe used
with unvented gas logs.
EMBER MASTER™
OWNER’S OPERATION AND INSTALLATION MANUAL
P
I
L
O
T
O
F
F
O
N
LO
REMOTE
OFF
ON
HI
VFP18R
VFP24R
VFP30R
18", 24", and 30"
Remote-Ready
UNVENTED (VENT-FREE)
PROPANE/LP GAS LOG HEATER
VARIABLE MANUALLY-CONTROLLED MODELS ALSO DESIGN-CERTIFIED
AS VENTED DECORATIVE APPLIANCES
* Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer
This appliance may be installed in an aftermarket*, permanently located, manufactured
(mobile) home, where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate. This
appliance is not convertible for use with other gases.

2
105073
UNVENTED PROPANE/LP GAS LOG HEATER
FIREPLACE MANUFACTURERS INC.
SAFETY
INFORMATION
DANGER: Carbon monoxide
poisoning may lead to death!
CarbonMonoxidePoisoning:Earlysignsof
carbon monoxide poisoning resemble the flu,
with headaches, dizziness, or nausea. If you
have these signs, the heater may not be work-
ing properly. Get fresh air at once! Have
heater serviced. Some people are more af-
fectedbycarbonmonoxidethanothers.These
includepregnantwomen,peoplewithheartor
lung disease or anemia, those under the influ-
ence of alcohol, and those at high altitudes.
Propane/LP Gas: Propane/LP gas is odor-
less.Anodor-makingagentisaddedtothegas.
The odor helps you detect a gas leak. How-
ever, the odor added to the gas can fade. Gas
may be present even though no odor exists.
Make certain you read and understand all
warnings.Keepthismanualforreference.It
isyourguidetosafeandproperoperationof
this heater.
1. This appliance is only for use with the
typeofgasindicated on theratingplate.
Thisapplianceisnot convertibleforuse
with other gases.
2. Do notplacepropane/LP supply tank(s)
insideanystructure. Locate propane/LP
supply tank(s) outdoors.
3. If you smell gas
• shut off gas supply
• do not try to light any appliance
• do not touch any electrical switch; do
not use any phone in your building
• immediately call your gas supplier
from a neighbor’s phone. Follow the
gas supplier’s instructions
• ifyoucannotreach your gassupplier,
call the fire department
WARNINGS
IMPORTANT: Read this owner’s
manual carefully and completely
before trying to assemble, oper-
ate, or service this heater. Im-
properuseofthisheatercancause
seriousinjuryordeathfromburns,
fire, explosion, electrical shock,
and carbon monoxide poisoning.
4. This heatershallnotbeinstalledinabed-
room or bathroom, unless installed as a
vented appliance (see Installing
Damper Clamp Accessory for Vented
Operation, page 10).
5. Before installing in a solid fuel burn-
ingfireplace,thechimney flue and fire-
box must be cleaned of soot, creosote,
ashes, and loose paint by a qualified
chimney cleaner. Creosote will ignite
if highly heated. Inspect chimney flue
for damage. If damaged, operate heater
with flue damper closed.
6. If fireplace has glass doors, never op-
eratethisheater with glassdoorsclosed.
Ifyouoperateheaterwith doors closed,
heat buildup inside fireplace will cause
glass to burst. Also if fireplace open-
ing has vents at the bottom, you must
open the vents before operating heater.
7. To prevent the creation of soot, follow
the instructions in Cleaning and Main-
tenance, page 17.
8. This log heater is designed to be smoke-
less. If logs ever appear to smoke, turn
offheaterandcallaqualifiedserviceper-
son. Note: Duringinitialoperation,slight
smokingmay occurduetologcuringand
heater burning manufacturing residues.
9. Before usingfurniturepolish,wax,car-
pet cleaner, or similar products, turn
heater off. If heated, the vapors from
theseproductsmaycreatea white pow-
der residue within burner box or on
adjacent walls or furniture.
10. This heater needsfresh,outsideair ven-
tilation to run properly.This heater has
an Oxygen Depletion Sensing (ODS)
safety shutoff system. The ODS shuts
down the heater if not enough fresh air
is available. See Air for Combustion
and Ventilation, pages 4 through 6. If
heater keeps shutting off, see Trouble-
shooting, pages 18 through 20.
11. Do not run heater
• where flammable liquids or vapors
are used or stored
• under dusty conditions
12. Do not use this heater to cook food or
burn paper or other objects.
13. Do not use heater if any part has been
exposedtoorunder water. Immediately
call a qualified service technician to in-
specttheroom heater andtoreplace any
part of the control system and any gas
control which has been under water.
WARNING: Any change to
this heater or its controls can be
dangerous.
WARNING: Do not allow fans
toblowdirectlyintothefireplace.
Avoidanydraftsthatalterburner
flame patterns. Ceiling fans can
create drafts that alter burner
flame patterns. Altered burner
patterns can cause sooting.
WARNING: Do not use a
blower insert, heat exchanger
insert,orotheraccessorynotap-
proved for use with this heater.
Due to high temperatures, the
appliance should be located out
oftrafficand away from furniture
and draperies.
Do not place clothing or other
flammable material on or near
the appliance. Never place any
objects on the heater.
Heater base assembly becomes
veryhotwhenrunningheater.Keep
childrenandadultsaway fromhot
surfaceto avoid burns or clothing
ignition. Heaterwillremainhotfor
a time after shutdown. Allow sur-
face to cool before touching.
Carefully supervise young chil-
dren when they are in the room
withheater.Whenusingthehand-
held remote accessory, keep se-
lector switch in the OFF position
to prevent children from turning
on burners with remote.
Youmustoperatethisheaterwith
a fireplace screen in place. Make
sure fireplace screen is closed
before running heater.
Keeptheapplianceareaclearand
free from combustible materials,
gasoline, and other flammable
vapors and liquids.

3
105073
OWNER’S MANUAL
Figure 1 - Ember Master
Front
Logs
Control Knob
Rear Log
Base
Assembly
Front
Burner
Piezo
Ignitor
Rear
Burner
Crossover Log
Bottom
Middle
Log
Selector Switch
(Optional)
Flame
Adjustment
Knob
PRODUCT
IDENTIFICATION
LOCAL CODES
Install and use heater with care. Follow all
localcodes. Intheabsenceoflocalcodes,use
the latest edition of The National Fuel Gas
Code,ANSZ223.1,alsoknownasNFPA54*.
*Available from:
American National Standards Institute, Inc.
Batterymarch Park
New York, NY 10018
National Fire Protection Association, Inc.
1430 Broadway
Quincy, MA 02269
Note: Where listed vented decorative logs
are required, thermostat operation is not
permitted.
14. Do not operate heater if any log is bro-
ken. Do not operate heater if a log is
chipped (dime-sized or larger).
15. Turn heater off and let cool before ser-
vicing, installing, or repairing. When
using the hand-held remote accessory,
make sure the selector switch is in the
OFF position. Only a qualified service
person should install, service, or repair
heater.
16. Whenusingthehand-heldremoteacces-
sory, make sure the selector switch is in
the OFF position when you are away
from home for long periods of time.
17. This heater must not be connected to
any external electrical source.
18. Operating heater above elevations of
4,500 feet may cause pilot outage.
19. To prevent performance problems, the
useofapropane/LPfueltankoflessthan
100 lb. capacity is not recommended.
SAFETY
INFORMATION
Continued
PRODUCT
FEATURES
OPERATION
This heater is clean burning. It requires no
outsideventing.Thereisnoheatlossoutavent
or up a chimney. Heat is generated by both
realisticflamesandglowingcoals.Thisheater
is designed for vent-free operation with flue
damper closed. It has been tested and ap-
proved to ANS Z21.11.2 standard for
unvented heaters. State and local codes in
some areas prohibit the use of vent-free heat-
ers. This heater may also be operated as a
venteddecorative (ANS Z21.60) productby
opening the flue damper (non-thermostat
operation only).
SAFETY PILOT
This heater has a pilot with an Oxygen
DepletionSensing(ODS)safetyshutoffsys-
tem.TheODS/pilotis arequiredfeaturefor
vent-freeroomheaters.TheODS/pilotshuts
offtheheaterifthereisnotenoughfreshair.
PIEZO IGNITION SYSTEM
This heater has a piezo ignitor. This system
requires no matches, batteries, or other
sources to light heater.
Top Middle Log
UNPACKING
CAUTION: Do not remove the
metal data plates from the grate
assembly. The dataplates contain
important product information.
1. Remove logs and heater base assem-
bly from carton. Note: Do not pick up
heater base assembly by the burner.
This could damage heater. Always
handle base assembly by grate.
2. Remove all protective packaging ap-
plied to logs and heater for shipment.
3. Check all items for any shipping dam-
age. If damaged, promptly inform
dealer where you bought heater.
Continued

4
105073
UNVENTED PROPANE/LP GAS LOG HEATER
FIREPLACE MANUFACTURERS INC.
Today’s homes are built more energy effi-
cient than ever. New materials, increased
insulation, and new construction methods
helpreduceheatlossinhomes.Homeowners
weatherstripandcaulkaround windowsand
doorstokeepthecoldairoutandthewarmair
in. During heating months, home owners
want their homes as airtight as possible.
While it is good to make your home energy
efficient,yourhomeneedstobreathe.Fresh
air must enter your home. All fuel-burning
appliances need fresh air for proper com-
bustion and ventilation.
Exhaustfans,fireplaces,clothesdryers,and
fuel burning appliances draw air from the
house to operate. You must provide ad-
equate fresh air for these appliances. This
will insure proper venting of vented fuel-
burning appliances.
AIR FOR
COMBUSTION AND
VENTILATION
WARNING: This heater shall
notbeinstalledinaconfinedspace
or unusually tight construction
unless provisions are provided
foradequatecombustionandven-
tilation air. Read the following in-
structions to insure proper fresh
air for this and other fuel-burning
appliances in your home.
PROVIDING ADEQUATE
VENTILATION
The following are excerpts from National
Fuel Gas Code, NFPA 54/ANS Z223.1, Sec-
tion5.3,AirforCombustionandVentilation.
Allspacesinhomesfallintooneofthethree
following ventilation classifications:
1. Unusually Tight Construction
2. Unconfined Space
3. Confined Space
The information on pages 4 through 6 will
help you classify your space and provide
adequate ventilation.
Unusually Tight Construction
The air that leaks around doors and win-
dows may provide enough fresh air for
combustion and ventilation. However, in
buildings of unusually tight construction,
you must provide additional fresh air.
Unusually tight construction is de-
fined as construction where:
a. walls and ceilings exposed to the
outside atmosphere have a con-
tinuous water vapor retarder with
a rating of one perm (6 x 10-11 kg
per pa-sec-m2) or less with open-
ings gasketed or sealed and
b. weather stripping has been
added on openable windows and
doors and
c. caulking or sealants are applied
to areas such as joints around
window and door frames, be-
tween sole plates and floors,be-
tween wall-ceiling joints, be-
tween wall panels, at penetra-
tionsforplumbing,electrical,and
gas lines, and at other openings.
If your home meets all of the three
criteria above, you must provide ad-
ditional fresh air. See Ventilation Air
From Outdoors , page 6 .
If your home does not meet all of the
threecriteriaabove,proceedto Deter-
mining Fresh-Air Flow for Heater Lo-
cation, page 5.
Confined and Unconfined Space
The National Fuel Gas Code, ANS Z223.1
defines a confined space as a space whose
volume is less than 50 cubic feet per 1,000
Btu per hour (4.8 m3per kw) of the aggre-
gate input rating of all appliances installed
in that space and an unconfined space as a
space whose volume is not less than 50
cubicfeetper1,000Btuperhour(4.8m3per
kw) of the aggregate input rating of all
appliances installed in that space. Rooms
communicating directly with the space in
whichtheappliancesareinstalled*,through
openings not furnished with doors, are con-
sidered a part of the unconfined space.
This heater shall not be installed in a con-
fined space or unusually tight construction
unlessprovisionsare provided foradequate
combustion and ventilation air.
*Adjoiningroomsarecommunicatingonly
iftherearedoorlesspassagewaysorventila-
tion grills between them.
PRODUCT
FEATURES
Continued
OPTIONAL REMOTE
CONTROL ACCESSORIES
There are four optional remote controls that
canbepurchasedseparatelyforthislogheater:
• wall switch
• wall thermostat
• hand-held ON/OFF remote
• hand-held thermostat remote
See Accessories, page 24.
The wall thermostat or hand-held thermo-
stat control may not be used where vented
decorative listing is required.

5
105073
OWNER’S MANUAL
DETERMINING FRESH-AIR FLOW FOR HEATER LOCATION
Determining if You Have a Confined or Unconfined Space
Use this work sheet to determine if you have a confined or unconfined space.
Space:Includestheroominwhichyouwillinstallheaterplusanyadjoiningroomswithdoorlesspassagewaysorventilationgrillsbetween
the rooms.
1. Determine the volume of the space (length x width x height).
Length x Width x Height = _________________ cu. ft. (volume of space)
Example: Space size 20 ft. (length) x 16 ft. (width) x 8 ft. (ceiling height) = 2560 cu. ft. (volume of space)
If additional ventilation to adjoining room is supplied with grills or openings, add the volume of these rooms to the total volume of
the space.
2. Divide the space volume by 50 cubic feet to determine the maximum Btu/Hr the space can support.
____________(volume of space) ÷50 cu. ft. = (Maximum Btu/Hr the space can support)
Example: 2560 cu. ft. (volume of space) ÷50 cu. ft. = 51.2 or 51,200 (maximum Btu/Hr the space can support)
3. Add the Btu/Hr of all fuel burning appliances in the space.
Vent-free heater ______________ Btu/Hr
Gas water heater* ______________ Btu/Hr
Gas furnace ______________ Btu/Hr
Vented gas heater ______________ Btu/Hr
Gas fireplace logs ______________ Btu/Hr
Other gas appliances* +______________ Btu/Hr
Total =______________ Btu/Hr
* Do not include direct-vent gas appliances. Direct-vent draws combustion air from the outdoors and vents to the outdoors.
4. Compare the maximum Btu/Hr the space can support with the actual amount of Btu/Hr used.
_________________ Btu/Hr (maximum the space can support)
_________________ Btu/Hr (actual amount of Btu/Hr used)
Example: 51,200 Btu/Hr (maximum the space can support)
73,000 Btu/Hr (actual amount of Btu/Hr used)
ThespaceintheaboveexampleisaconfinedspacebecausetheactualBtu/HrusedismorethanthemaximumBtu/Hrthespacecansupport.
You must provide additional fresh air. Your options are as follows:
A. Rework worksheet, adding the space of an adjoining room. If the extra space provides an unconfined space, remove door to adjoin-
ing room or add ventilation grills between rooms. See Ventilation Air From Inside Building, page 6.
B. Vent room directly to the outdoors. See Ventilation Air From Outdoors, page 6.
C. Install a lower Btu/Hr heater, if lower Btu/Hr size makes room unconfined.
If the actual Btu/Hr used is less than the maximum Btu/Hr the space can support, the space is an unconfined space. You will need no
additional fresh air ventilation.
AIR FOR
COMBUSTION AND
VENTILATION
Continued
Example:
Gas water heater 40,000 Btu/Hr
Vent-free heater +33,000 Btu/Hr
Total = 73,000 Btu/Hr
WARNING:Iftheareainwhichtheheatermaybeoperatedissmallerthanthatdefinedasanunconfinedspace
or if the building is of unusually tight construction, provide adequate combustion and ventilation air by one of
the methods described in the National Fuel Gas Code, ANS Z223.1, Section 5.3 or applicable local codes.
Continued

6
105073
UNVENTED PROPANE/LP GAS LOG HEATER
FIREPLACE MANUFACTURERS INC.
AIR FOR
COMBUSTION AND
VENTILATION
Continued
Outlet
Air Ventilated
Attic
Outlet
Air
Inlet
Air
Inlet Air Ventilated
Crawl Space
To
Crawl
Space
To Attic
Or
Remove
Door into
Adjoining
Room,
Option
3
Ventilation Grills
Into Adjoining Room,
Option 2
Ventilation
Grills
Into Adjoining
Room,
Option 1
12"
12"
VENTILATION AIR
Ventilation Air From Inside
Building
Thisfreshairwouldcomefromanadjoining
unconfined space. When ventilating to an
adjoining unconfined space, you must pro-
vide two permanent openings: one within
12" of the ceiling and one within 12" of the
floor on the wall connecting the two spaces
(seeoptions1and2,Figure2).Youcanalso
remove door into adjoining room (see op-
tion 3, Figure 2). Follow the National Fuel
Gas Code, NFPA 54/ANS Z223.1, Section
5.3, Air for Combustion and Ventilation for
required size of ventilation grills or ducts.
Figure 2 - Ventilation Air from Inside Building
Ventilation Air From Outdoors
Provide extra fresh air by using ventilation
grills or ducts. You must provide two per-
manent openings: one within 12" of the
ceiling and one within 12" of the floor.
Connecttheseitemsdirectlytotheoutdoors
orspacesopentotheoutdoors.Thesespaces
include attics and crawl spaces. Follow the
National Fuel Gas Code, NFPA 54/ANS
Z223.1,Section5.3,AirforCombustionand
Ventilation for required size of ventilation
grills or ducts.
IMPORTANT: Donotprovideopeningsfor
inlet or outlet air into attic if attic has a
thermostat-controlledpowervent.Heatedair
enteringtheatticwillactivatethepowervent.
Figure 3 - Ventilation Air from Outdoors
WARNING: Rework work-
sheet, adding the space of the
adjoiningunconfinedspace.The
combined spaces must have
enough fresh air to supply all
appliances in both spaces.

7
105073
OWNER’S MANUAL
LOG SIZING REQUIREMENTS
Minimum Firebox Size
Log Front Rear*
Size Height Depth Width Width
18" 17" 14" 20" 14"
24" 17" 14" 26" 18"
30" 17" 14" 32" 22"
INSTALLATION AND
CLEARANCES
WARNING:Maintainthemini-
mum clearances. If you can, pro-
vide greater clearances from
floor, ceiling, and adjoining wall.
MINIMUM FIREPLACE CLEARANCE
TO COMBUSTIBLE MATERIALS
Log Size Side Wall Ceiling Floor*
18", 24", 30” 16" 42" 5"
*See Floor Clearances, page 9.
WARNING: Never install the
heater
• in a bedroom or bathroom un-
less installed as vented appli-
ance, see page 10
• in a recreational vehicle
• wherecurtains,furniture,cloth-
ing,orotherflammableobjects
arelessthan42inchesfromthe
front,top,orsidesoftheheater
• in high traffic areas
• in windy or drafty areas
CAUTION: This heater cre-
ates warm air currents. These
currents move heat to wall sur-
faces next to heater. Installing
heater next to vinyl or cloth wall
coverings or operating heater
where impurities (such as to-
bacco smoke, aromatic candles,
cleaning fluids, oil or kerosene
lamps, etc.) in the air exist, may
discolor walls.
CHECK GAS TYPE
Use only propane/LP gas. If your gas sup-
ply is not propane/LP gas, do not install
heater.Calldealerwhereyouboughtheater
for proper type heater.
IMPORTANT: Vent-freeheatersaddmois-
ture to the air. Although this is beneficial,
installing heater in rooms without enough
ventilation air may cause mildew to form
from too much moisture. See Air for Com-
bustion and Ventilation, pages 4 through 6.
WARNING: A qualified ser-
vice person must install heater.
Follow all local codes.
INSTALLATION
NOTICE: This heater is intended
foruseassupplementalheat.Use
this heater along with your pri-
mary heating system. Do not in-
stall this heater as your primary
heatsource.Ifyouhaveacentral
heating system, you may run
system’scirculatingblowerwhile
using heater.Thiswillhelpcircu-
late the heat throughout the
house. In the event of a power
outage, you can use this heater
as your primary heat source.
NOTICE:Stateorlocalcodesmay
onlyallowoperationofthisappli-
ance in a vented configuration.
Check your state or local codes.
WARNING: Seal any fresh air
vents or ash clean-out doors lo-
catedonfloororwalloffireplace.
If not, drafting may cause pilot
outage or sooting. Use a heat-
resistant sealant. Do not seal
chimney flue damper.
WARNING: Before installing
in a solid fuel burning fireplace,
thechimneyflueandfireboxmust
be cleaned of soot, creosote,
ashes and loose paint by a quali-
fied chimney cleaner. Creosote
willigniteifhighlyheated.Adirty
chimney may create and distrib-
utesootwithinthehouse.Inspect
chimney flue for damage. If dam-
aged, operate heater with flue
damper closed.
WARNING: Make sure the se-
lector switch is in the OFF posi-
tion before installing heater.
*Measured at 14” depth
(Vent-Free Operation Only)
Continued
Carefullyfollowtheinstructionsbelow.This
will ensure safe installation into a masonry,
UL127-listed manufactured fireplace, or
listed vent-free firebox.
Minimum Clearances For Side
Combustible Material, Side Wall,
and Ceiling
A. Clearances from the side of the fire-
place cabinet to any combustible ma-
terial and wall should follow the dia-
gram in Figure 4.
Example: The face of a mantel, book-
shelf, etc. is made of combustible ma-
terial and protrudes3 1/2"from the wall.
This combustible material must be 4"
from the side of the fireplace opening
(see Figure 4).
Note: When installing your gas logs
into a manufactured firebox, follow
firebox manufacturer’s instructions for
minimum clearances to combustible
materials.
B. Clearancesfromthetopof the fireplace
openingtotheceiling shouldnotbeless
than 42 inches.
Figure 4 - Minimum Clearance for
Combustible to Wall
.5 2
7/16
7/8
1
3
/ 4
3
1
/ 2
5
1
/ 4
7
8
3
/ 4
10
1
/ 2
12
1
/ 4
1 4 6 8 10 12 14 16
FIREBOX INCHES
INCHES
*Minimum 16 inches from Side Wall
*
Example

8
105073
UNVENTED PROPANE/LP GAS LOG HEATER
FIREPLACE MANUFACTURERS INC.
Noncombustible Requirements for
Material Distance (A) Safe Installation
12" or more Noncombustible material OK.
Between 8" and 12" Install fireplace hood accessory (HDABK or
HDABR, see Accessories, page 24).
18" model: Noncombustible material OK.
Less than 8" Noncombustible material must be extended to at
least 8". See Between 8" and 12", above. If you
cannot extend material, you must operate heater
with flue damper open.
Heat Resistant
Material (A)
Figure 5 - Heat Resistant Material (Slate, Marble, Tile, etc.) Above Fireplace
INSTALLATION
Continued
If Using Mantel
You must have noncombustible material(s)
above the fireplace opening. Noncombus-
tible materials (such as slate, marble, tile,
etc.) must be at least 1/2 inch thick. With
sheetmetal,youmusthavenoncombustible
material behind it. Noncombustible mate-
rial must extend at least 8 inches up. If
noncombustible material is less than 12",
you must install the fireplace hood acces-
sory. Even if noncombustible material is
more than 12", you may need the hood
accessory to deflect heat away from your
mantelshelf.SeeFigure5andFigures6and
7, page 9 for minimum clearances.
Minimum Noncombustible
Material Clearances
If Not Using Mantel
Note: If using a mantel, see If Using Man-
tel. If not using a mantel, follow the infor-
mation below.
You must have noncombustible material(s)
above the fireplace opening. Noncombus-
tible materials (such as slate, marble, tile,
etc.) must be at least 1/2 inch thick. With
sheet metal, you must have noncombustible
materialbehindit.Noncombustiblematerial
must extend at least 8" up (for all models). If
noncombustiblematerialislessthan12",you
mustinstallthefireplacehoodaccessory.See
Figure 5 for minimum clearances.
IMPORTANT: If you cannot meet these
minimumclearances,youmustoperateheater
with chimney flue damper open. See Install-
ing Damper Clamp Accessory for Vented
Operation, page 10.
NOTICE:Manualcontrolheaters
may be used as a vented prod-
uct. If so, you must always run
heaterwithchimneyfluedamper
open. If running heater with
damper open, noncombustible
material above fireplace open-
ing is not needed. Go to Install-
ing Damper Clamp Accessory
for Vented Operation, page 10.
IMPORTANT: If you cannot meet these
minimumclearances,youmustoperateheater
withchimney fluedamperopen.SeeInstall-
ing Damper Clamp Accessory for Vented
Operation, page 10.

9
105073
OWNER’S MANUAL
Figure 7 - Minimum Mantel Clearances When Using Hood
Continued
FLOOR CLEARANCES
A. If installingapplianceon the floorlevel,
you must maintain the minimum dis-
tance of 14" to combustibles (see Fig-
ure 8).
B. If combustible materials are less than
14" to the fireplace, you must install
applianceatleast5"above the combus-
tible flooring (see Figure 9).
INSTALLATION
Continued
Minimum Non-
Combustible
Material 8"
Min. 12" 15" 18"
All minimum
distances are
in inches
Log Sets
18" & 24" Models
20"
2 1/2"
6"
8"
10"
12"
Distances to
Underside of
Mantel
Hood
(HDABK,HDABR)
Top of Fireplace
Opening
Underside of
Mantel Shelf
MANTEL CLEARANCES
Inadditiontomeetingnoncombustiblemate-
rial clearances, you must also meet required
clearances between fireplace opening and
mantel shelf. If you do not meet clearances
listed in Figure 6 you will need a hood.
Determining Minimum Mantel
Clearance
If you meet minimum clearance between
mantel shelf and top of fireplace opening, a
hood is not required (see Figure 6).
Determining Minimum Mantel
Clearance When Using a Hood
IfminimumclearancesinFigure6arenotmet,
you must have a hood. When using a hood
there are still certain minimum mantel clear-
ances required. Follow minimum clearances
shown in Figure 7, page 9 when using hood.
NOTICE:Ifyourinstallationdoes
notmeettheminimumclearances
shown, you must do one of the
following:
• operate the logs only with the
flue damper open
• raise the mantel to an accept-
able height
• remove the mantel
Figure 6 - Minimum Mantel Clearances Without Using Hood
Minimum Non-
Combustible
Material
Minimum Non-
Combustible
Material Height
Distances to
Underside of
Mantel
Top of Fireplace
Opening
Underside of
Mantel Shelf
12"
8"
(A)
18"
14"
20"
16
3/4
"
22"
18
1/2
"
24"
20"
All minimum
distances are
in inches
Log Set
24" Models
18" Model
2
1/2
"
6"
8"
10" Mantel Shelf
14"
Min.
Combustible
Material
Non-Combustible
Material
Hearth
5"
Min.
Combustible
Material
Figure9 -MinimumFireplaceClearances
Above Combustible Flooring
14"
Min.
Combustible
Material
Noncombustible Material
Hearth Combustible
Material
5"
Min.
Figure8 -MinimumFireplaceClearances
If Installed at Floor Level
24" & 30" Models
All Models
NOTICE:Surfacetemperaturesof
adjacent walls and mantels be-
comehotduringoperation.Walls
and mantels above the firebox
may become hot to the touch. If
installedproperly,thesetempera-
turesmeettherequirementofthe
national product standard. Fol-
low all minimum clearances
shown in this manual.

10
105073
UNVENTED PROPANE/LP GAS LOG HEATER
FIREPLACE MANUFACTURERS INC.
INSTALLING HEATER BASE
ASSEMBLY
WARNING: You must secure
this heater to fireplace floor. If
not, heater will move when you
adjust controls. Moving heater
may cause a gas leak.
WARNING: If installing in a
sunken fireplace, special care is
needed. You must raise the fire-
place floor to allow access to
heater control panel. This will in-
sure adequate air flow and guard
against sooting. Raise fireplace
floor with noncombustible mate-
rial.Makesurematerialissecure.
CAUTION:Donotpickupheater
base assembly by burners. This
coulddamageheater.Onlyhandle
base assembly by grates.
IMPORTANT: Make sure the heater burn-
ersarelevel.Ifheaterisnotlevel,heaterwill
not work properly.
INSTALLATION
Continued
CAUTION:Donotremovethe
metal data plates attached to the
heater base assembly. The data
platescontainimportantwarranty
information.
Damper Damper
Clamp
Damper
Damper
Masonry Fireplace
Figure 10 - Attaching Damper Clamp
Damper Clamp
Manufactured Fireplace
INSTALLING DAMPER
CLAMP ACCESSORY FOR
VENTED OPERATION
Note: When used as a vented heater, appli-
ance must be installed only in a solid-fuel
burning fireplace with a working flue and
constructed of noncombustible material.
If your heater is a manually-controlled
model, you may use this heater as a vented
product. There are three reasons for operat-
ing your heater in the vented mode.
1. The fireplace does not meet the clear-
ance to combustibles requirements for
vent-free operation.
2. State or local codes do not permit vent-
free operation.
3. You prefer vented operation.
Ifreasonsnumber1or2aboveapplytoyou,
you must permanently open chimney flue
damper.Youmustinstallthe damperclamp
accessory (to order, see Accessories, page
24). This will insure vented operation (see
Figure 10). The damper clamp will keep
damper open. Installation instructions are
included with clamp accessory.
See chart below for minimum permanent
flue opening you must provide. Attach
damper clamp so the minimum permanent
flueopeningwillbemaintained atalltimes.
Area of Various Standard Round Flues
Diameter (ins.) Area (sq. ins.)
5" 20 sq. inches
6" 29 sq. inches
7" 39 sq. inches
8" 51 sq. inches
Chimney Minimum Permanent
Height (ft.) Flue Opening (sq. ins.)
6' to 15' 39 sq. inches
15' to 30' 29 sq. inches
Flexible Gas Hose (if
allowed by local codes)
Figure 11 - Attaching Flexible Gas Hose
to Heater Gas Regulator
Installation Items Needed
• hardwarepackage(providedwith heater)
• approvedflexiblegas hose (notprovided)
(if allowed by local codes)
• sealant (resistant to propane/LP gas,
not provided)
• electric drill with 3/16" drill bit
Gas Control
Note: Install optional FHRC or FHRCT
Receiver and Hand-Held Remote Control
Kit (see Accessories, page 24) before in-
stalling gas log heater. See installation in-
structions included with the kit.
1. Apply pipe joint sealant lightly to male
threadsofgas fitting. Connectapproved
flexible gas hose to inlet side of gas
control (see Figure 11).
2. Locate twomasonryscrewsin thehard-
ware package.
3. Positionheaterbaseassemblyinfireplace.
4. Place logs in their proper position on
heater base.
5. Center heater base and logs, front-to-
back and side-to-side in fireplace.
6. Carefully remove logs without moving
heater base.
7. Mark screw locations through holes in
front panel of base (see Figure 12, page
11). If installing in a brick-bottom fire-
place, mark screw locations in mortar
joint of bricks.
8. Remove heater base from fireplace.
9. Drill holes at marked locations using
3/16" masonary drill bit.
10. Attach base to fireplace floor using
masonryscrews(inhardware package).

11
105073
OWNER’S MANUAL
CONNECTING TO GAS
SUPPLY
WARNING: Aqualifiedservice
personmustconnectheatertogas
supply. Follow all local codes.
CAUTION: Never connect
heater directly to the propane/LP
supply.This heater requires an ex-
ternal regulator (not supplied). In-
stalltheexternalregulatorbetween
theheater and propane/LP supply.
Installation Items Needed
Beforeinstallingheater,makesureyouhave
the items listed below.
• external regulator (supplied by installer,
see Figure 13)
• piping (check local codes)
• sealant (resistant to propane/LP gas)
• equipment shutoff valve *
• test gauge connection *
• sediment trap
• tee joint
• pipe wrench
* AnCSA/AGAdesign-certifiedequipment
shutoffvalvewith1/8"NPTtapisanaccept-
able alternative to test gauge connection.
INSTALLATION
Continued
Figure 12 - Attaching Base Assembly to
Fireplace Floor
Masonry Screw
Figure 13 - External Regulator With Vent
Pointing Down
WARNING: Never connect
heater to private (non-utility) gas
wells. This gas is commonly
known as wellhead gas.
Installation must include an equipment
shutoffvalve,union, andplugged 1/8"NPT
tap. Locate NPT tap within reach for test
gauge hook up. NPT tap must be upstream
from heater (see Figure 14).
IMPORTANT: Installanequipmentshutoff
valve in an accessible location. The equip-
ment shutoff valve is for turning on or
shutting off the gas to the appliance.
Apply pipe joint sealant lightly to male
threads. This will prevent excess sealant
fromgoingintopipe. Excesssealantinpipe
could result in clogged heater valves.
CAUTION:Usepipejointseal-
ant that is resistant to liquid pe-
troleum (LP) gas.
We recommend that you install a sediment
trap in supply line as shown in Figure 14.
Locate sediment trap where it is within
reach for cleaning. Install in piping system
betweenfuelsupplyandheater.Locatesedi-
menttrapwheretrappedmatter is not likely
to freeze. A sediment trap traps moisture
and contaminants. This keeps them from
going into heater controls. If sediment trap
is not installed or is installed wrong, heater
may not run properly.
CAUTION: Avoid damage to
gascontrol.Holdgascontrolwith
wrenchwhenconnectingittogas
piping and/or fittings.
The installer must supply an external regu-
lator. The external regulator will reduce
incoming gas pressure. You must reduce
incominggaspressuretobetween11and14
inchesofwater.Ifyoudonotreduceincom-
ing gas pressure, heater regulator damage
could occur. Install external regulator with
the vent pointing down as shown in Figure
13. Pointing the vent down protects it from
freezing rain or sleet.
Tee
Joint
Pipe
Nipple
Cap
3" Minimum
Sediment
Trap
Gas
Control
From External
Regulator
(11" W.C.* to
14" W.C. Pressure)
CSA/AGA Design-Certified Equipment
Shutoff Valve With 1/8" NPT Tap
* Minimum inlet pressure for purpose of input adjustment.
Figure 14 - Gas Connection
Continued
Approved Flexible
Gas Hose (if allowed
by local codes)
CAUTION: Use only new,
black iron or steel pipe. Inter-
nally-tinned copper tubing may
be used in certain areas. Check
yourlocalcodes.Usepipeof1/2"
diameter or greater to allow
proper gas volume to heater. If
pipe is too small, undue loss of
pressure will occur.
WARNING:Thisappliancere-
quires a 1/2" NPT (National Pipe
Thread) inlet connection to the
pressure regulator. Propane/
LP Supply
Tank External
Regulator
Vent
Pointing
Down

12
105073
UNVENTED PROPANE/LP GAS LOG HEATER
FIREPLACE MANUFACTURERS INC.
ON
POSITI
O
POS
I
Open
Closed
Equipment
Shutoff
Valve
Equipment
Shutoff Valve
Pressure Testing gas Supply
Piping system
Test Pressures In Excess Of 1/2 PSIG
(3.5 kPa)
1. Disconnect appliance with its appliance
maingas valve(controlvalve)andequip-
ment shutoff valve from gas supply pip-
ing system. Pressures in excess of 1/2
psig will damage heater regulator.
2. Cap off open end of gas pipe where
equipment shutoff valve was con-
nected.
3. Pressurize supply piping system by ei-
ther using compressed air or opening
propane/LP supply tank valve.
4. Check all joints of gas supply piping
system. Apply mixture of liquid soap
and water to gas joints. Bubbles form-
ing show a leak.
5. Correct all leaks at once.
6. Reconnect heater and equipment
shutoff valve to gas supply. Check re-
connected fittings for leaks.
INSTALLATION
Continued
Figure 15 - Equipment Shutoff Valve
Figure 16 - Checking Gas Joints
WARNING:Neveruseanopen
flame to check for a leak. Apply a
mixture of liquid soap and water
to all joints. Bubbles forming
show a leak. Correct all leaks at
once.
WARNING: Test all gas pip-
ing and connections for leaks
after installing or servicing. Cor-
rect all leaks at once.
CHECKING GAS
CONNECTIONS
CAUTION: Make sure exter-
nal regulator has been installed
between propane/LP supply and
heater.Seeguidelinesunder Con-
necting to Gas Supply , page 11.
Test Pressures Equ al To or Less Than
1/2 PSIG (3.5 kPa)
1. Close equipmentshutoffvalve(see Fig-
ure 15).
2. Pressurize supply piping system by ei-
ther using compressed air or opening
propane/LP supply tank valve.
3. Check all joints from propane/LP sup-
plytankto equipment shutoffvalve (see
Figure 16). Apply mixture of liquid
soap and water to gas joints. Bubbles
forming show a leak.
4. Correct all leaks at once.
Pressure Testing Heater Gas
Connections
1. Open equipmentshutoffvalve(see Fig-
ure 15).
2. Open propane/LP supply tank valve.
3. Make sure control knob of heater is in
the OFF position.
4. Check alljointsfrom equipment shutoff
valve to gas control (see Figure 15).
Apply mixture of liquid soap and wa-
ter to gas joints. Bubbles forming show
a leak.
5. Correct all leaks at once.
6. Light heater (see Operating Heater,
pages 14 through 16). Check all other
internal joints for leaks.
7. Turn off heater (see To Turn Off Gas to
Appliance, page 15).
Propane/LP
Supply
Tank
Control Valve
Location

13
105073
OWNER’S MANUAL
Bottom Middle
Log (#2)
Metal Post
Metal
Post
Groove Groove
Grate
Figure 18 - Installing Bottom Middle
Log (#2)
Rear Log (#3)
Peg
Grate
Prong
Grate Prong
Groove
in Back
of Log
Groove in
Back of Log
INSTALLATION
Continued
Top Middle
Log (#4)
Hole
Peg
Figure 20 - Installing Crossover Log (#4)
INSTALLING LOGS
Each log is marked with a number. These
numberswillhelpyouidentifythelogwhen
installing. It is very important to install
these logs exactly as instructed. Do not
modify logs. Only use logs supplied with
heater.
1. Place front logs (#1L and #1R) on top
of the grate. Make sure the notches in
the bottom of the logs fit over the grate
prongs (see Figure 17). Push back of
logs flush with metal grate bar. Note:
18" model has only one front log.
2. Rest bottom middle log (#2) behind
metal posts on front burner. Make sure
the grooves in the bottom of the log fit
over the grate. Bring the log forward
next to the metal posts. The pegs on
the log must be on top (see Figure 18).
3. Slide the grooves in the back of the rear
log (#3) against the rear grate prongs.
Make sure the peg on the log is on top
(see Figure 19).
4. Place the top middle log (#4) on the
bottom middle log (#2). Make sure the
pegs of the bottom middle log fit se-
curely in the holes of the top middle
log (see Figure 20).
5. Place thecrossoverlog(#5) on theback
log and the top middle log. Make sure
the peg on the rear log is in the hole in
the bottom of the crossover log. The
crossover log should fit in the cutout
of the top middle log (see Figure 21).
Figure 17 - Installing Front Log (#1)
Grate
Prongs
Metal Grate Bar
Front Log (#1)
Notch
WARNING:Failuretoposition
thepartsinaccordancewiththese
diagrams or failure to use only
parts specifically approved with
this heater may result in property
damage or personal injury.
Figure 19 - Installing Rear Log (#3)
Crossover
Log (#5)
Hole
Peg
Cutout
Figure 21 - Installing Crossover Log (#5)

14
105073
UNVENTED PROPANE/LP GAS LOG HEATER
FIREPLACE MANUFACTURERS INC.
O
F
F
P
I
L
O
T
O
N
L
O
I
H
AUTO
OFF
ON
4. Pressin and turncontrolknobclock-
wise totheOFFposition (see
Figure 22).
5. Waitfive(5)minutestoclearoutany
gas. Then smell for gas, including
near the floor. If you smell gas,
STOP! Follow “B” in the safety in-
formation above. If you don’t smell
gas, go to the next step.
6. Pressinandturn controlknobcoun-
terclockwise to the PILOT
position. Press in control knob for
five (5) seconds (see Figure 22).
Note: You may be running this
heater for the first time after hook-
ing up to gas supply. If so, the con-
trol knob may need to be pressed in
for30secondsorless.This will allow
air to bleed from the gas system.
7. With control knob pressed in, press
and release ignitor button. This will
lightpilot.Thepilotisattachedtothe
front burner. If needed, keep press-
ing ignitor button until pilot lights.
Note: If pilot does not stay lit, con-
tact a qualified service person or gas
supplierfor repairs.Untilrepairsare
made,lightpilotwithmatch.Tolight
pilot with match, see Manual Light-
ing Procedure, page 15.
Figure 22 - Control Knob and Ignitor Button Location
WARNING:Burnerswillcome
on automatically within one
minute when the selector switch
is in the ON position after the
pilot is lit.
Control Knob
Ignitor Button Selector Switch
in OFF Position
Flame Adjustment Knob
1. STOP! Read the safety information,
column 1.
2. Make sure equipment shutoff valve
is fully open.
3. SetselectorswitchintheOFFposition.
OPERATING
HEATER
FOR YOUR SAFETY
READ BEFORE
LIGHTING
WARNING: If you do not fol-
low these instructions exactly, a
fireorexplosionmayresultcaus-
ing property damage, personal
injury or loss of life.
A. Thisappliancehasa pilotwhichmust
belightedby hand.Whenlightingthe
pilot,followtheseinstructionsexactly.
B. BEFORE LIGHTING smell all
aroundthe appliance areaforgas.Be
sureto smell next tothefloorbecause
some gas is heavier than air and will
settle on the floor.
WHAT TO DO IF YOU SMELL
GAS
• Do not try to light any appliance.
• Donottouchanyelectricswitch;do
notuseanyphonein yourbuilding.
• Immediatelycallyour gas supplier
from a neighbor’s phone. Follow
the gas supplier’s instructions.
• If you cannot reach your gas sup-
plier, call the fire department.
C. Useonlyyour handtopushinor turn
thegascontrolknob. Neverusetools.
If the knob will not push in or turn
by hand, don’t try to repair it, call a
qualified service technician or gas
supplier. Force or attempted repair
may result in a fire or explosion.
D. Do not use this appliance if any part
has been under water. Immediately
call a qualified service technician to
inspect the appliance and to replace
any part of the control system and
any gas control which has been un-
der water.
LIGHTING
INSTRUCTIONS
WARNING
• If fireplace has glass doors,
never operate this heater with
glass doors closed. If you op-
erateheaterwithdoorsclosed,
heat buildup inside fireplace
will cause glass to burst. Also
if fireplace opening has vents
at the bottom, you must open
the vents before operating
heater.
• You must operate this heater
withafireplacescreeninplace.
Make sure fireplace screen is
closed before running heater.
NOTICE: During initial operation
of new heater, burning logs will
give off a paper-burning smell.
Orangeflamewillalsobepresent.
Open damper or window to vent
smell. This will only last a few
hours.
Note: Home owners generally prefer to
operate their heater with the chimney
damper closed. This will put all the heat
into the room. However, there may be
timesyouwilldesirethefullflamesofthe
Hi heat setting but will find the heat
outputexcessive.Youcanopenthechim-
ney damper (if you have one) fully or
partially to release some of the heat.
WARNING: Damper handle
will be hot if heater has been
running.

15
105073
OWNER’S MANUAL
TO TURN OFF GAS TO
APPLIANCE
Shutting Off Heater
1. Turncontrolknobclockwise
to the OFF position.
2a. SetselectorswitchintheOFFposition.
2b. If Using Optional Hand-Held Re-
mote:SetselectorswitchintheOFF
position to prevent draining battery.
Shutting Off Burners Only (pilot
stays lit)
You may shut off the burners and keep
thepilotlitbydoingoneofthefollowing:
1. Turncontrolknobclockwise
to the PILOT position.
2. Use remote control manual OFF
button.
3. SetselectorswitchintheOFFposition.
Ignitor
Electrode
Pilot Burner
9. Slightly push in and turn control
knobcounterclockwise tothe
ON position.
10. Wait one minute and switch selector
switch to the ON position to light
burner. Note: AUTO is only func-
tional when using GWMT1 or
GWMS2 optional accessories.
11. Set flame adjustment knob to any
level between HI and LO.
CAUTION: Do not try to ad-
just heating levels by using the
equipment shutoff valve.
Figure 23 - Pilot
8. Keep control knob pressed in for 30
seconds after lighting pilot.After 30
seconds, release control knob.
• If control knob does not pop out
when released, contact a qualified
service person or gas supplier for
repairs.
Note: Ifpilotgoes out,repeatsteps
4 through 8.
WARNING: Make sure the
selector switch is in the OFF po-
sition when you are away from
home for long periods of time.
Heater will come on automati-
cally with selector switch in the
ON position.
OPERATING
HEATER
Continued
MANUAL LIGHTING
PROCEDURE
1. Followsteps1through6underLight-
ing Instructions, page 14.
2. Depress control knob and light pilot
with match.
3. Keep control knob pressed in for 30
seconds after lighting pilot.After 30
seconds, release control knob. Now
follow steps 9 through 11, Lighting
Instructions, column 1.
Continued
Note: Allremotecontrolaccessoriesmust
bepurchasedseparately(seeAccessories,
page 24). Follow instructions included
with the remote control.
Thermostat Control Operation
(Optional GHRCTA Series Only) The
thermostat control setting on the remote
control unit can be set to any comfort
levelbetweenWARMERandCOOLER.
The burners will turn on and off auto-
matically to maintain the comfort level
you select. The ideal comfort setting will
vary by household depending upon the
amount of space to be heated, the output
of the central heating system, etc.
OPTIONAL REMOTE
OPERATION
NOTICE: You must light the pilot
before using the remote control
unit.See LightingInstructions on
page 14.
1. Afterlighting,letpilot flameburn for
about one minute.Turn control knob
to ON position. Adjust flame adjust-
mentknobanywherebetweenHIand
LO. Slide the selector switch to the
REMOTE position. Note: The burn-
ersmaylightif hand-heldremote ON
button was on when selector switch
was last turned off.You can now turn
theburners on andoffwiththehand-
held remote control unit.
IMPORTANT: Do not leave the se-
lectorswitchinthe REMOTE orON
positionwhenthepilotisnotlit.This
will drain the battery.
IMPORTANT: BesuretopresstheON/
OFFbuttonson the hand-heldremote
control unit for up to 3 seconds to as-
sure proper operation
GHRC Series Operation:
2a. Press ON/OFF button to turn the
burner on and off. When turning
burner off, the pilot will remain lit.
GHRCTA Series Operation:
2b. Press theAUTO/ON/OFF button on
the hand-held remote control (see
Figure 25, page 16). The lights to the
left of the button will show AUTO,
ON, or OFF.
• In the ON mode, the burners will
ignite. The heater is in manual
mode when ON is lit.
• IntheAUTOmode,thethermostat
in the hand-held remote unit con-
trols the room temperature. To in-
creasetheroomtemperature,press
the top arrow of theTEMP button.
To lower the room temperature,
press the bottom arrow of the
TEMP button. At higher settings
the heater will run longer.
Forwallthermostatoperation,follow in-
struction supplied with thermostat ac-
cessory GWMT1. For wall switch opera-
tion follow instructions supplied with
GWMS2.

16
105073
UNVENTED PROPANE/LP GAS LOG HEATER
FIREPLACE MANUFACTURERS INC.
O
F
F
P
I
L
O
T
O
N
L
O
I
H
ON
OFF
REMOTE
OPERATING
HEATER
Continued
Figure 24 - Setting the Remote Selector Switch, Control Knob, and Flame Adjustment
Knob for Remote Operation
Selector Switch in Remote Position
Control Knob in
On Position
Flame
Adjustment
Knob
WARNING: If yellow tipping
occurs, your heater could pro-
duce increased levels of carbon
monoxide. If front burner flame
pattern shows yellow tipping,
follow instructions at bottom of
this page. Yellow flame on rear
burner is normal.
INSPECTING
BURNERS
Check pilot flame pattern and burner flame
patterns often.
PILOT FLAME PATTERN
Figure 26 shows a correct pilot flame pat-
tern. Figure 27 shows an incorrect pilot
flame pattern. The incorrect pilot flame is
not touching the thermocouple. This will
cause the thermocouple to cool. When the
thermocouple cools, the heater will shut
down.
If pilot flame pattern is incorrect, as shown
in Figure 27
• turn heater off (see To Turn Off Gas to
Appliance, page 15)
• seeTroubleshooting,pages 18 through 20
FRONT BURNER FLAME
PATTERN
Figure 28, page 17, shows correct front
burner flame pattern. Figure 29, page 17,
shows incorrect front burner flame pattern.
The incorrect burner flame pattern shows
yellow tipping at top of blue flame.
Pilot Burner
Thermocouple
Figure 27 - Incorrect Pilot Flame Pattern
Thermocouple
Figure 26 - Correct Pilot Flame Pattern
Pilot Burner
NOTICE: Do not mistake orange
flames with yellow tipping. Dirt
orotherfineparticlesareburned
by heater, causing brief patches
of orange flame.
If front burner flame pattern is incorrect, as
shown in Figure 29, page 17.
• turn heater off (see To Turn Off Gas to
Appliance, page 15)
• seeTroubleshooting, pages18through 20
Figure 24 - Thermostat Hand-Held Remote Control Unit Selections
(GHRCTA Series Only)
Increases Room
Temperature in
AUTO Mode
Decreases Room
Temperature in
AUTO Mode
Turns Burners
On or Off and
Allows You to
Choose the Auto
Setting
Shows
Temperature
Setting
The Log Heater
will Automatically
Cycle between
Pilot and the Heat
Setting that has
been Selected
IMPORTANT: This remote control
hasbeenspeciallyengineered to take
an air temperature sample every 5.5
minutes in the auto mode. It will not
respondimmediately to thetempera-
turesettingbeing turnedupor down.
IMPORTANT: Thehand-held remote
control unit must be near the heater.
Do not keep the hand-held remote
control unit too close to the heater.
The thermostat on the hand-held re-
mote control unit will heat up too
quickly and turn the heater off.
3. To turn the burner off, press the
AUTO/ON/OFF button until OFF
lights. The pilot will remain lit.
IMPORTANT: To turn the pilot off,
manually turn the control knob on
the heater to the OFF position.

17
105073
OWNER’S MANUAL
CLEANING AND
MAINTENANCE
WARNING: Turn off heater
and let cool before cleaning.
CAUTION: You must keep
control areas, burners, and cir-
culating air passageways of
heaterclean.Inspecttheseareas
of heater before each use. Have
heaterinspectedyearlybyaquali-
fied service person. Heater may
needmorefrequentcleaningdue
to excessive lint from carpeting,
bedding material, pet hair, etc.
LOGS
• If you remove logs for cleaning, refer to
Installing Logs, page 13, to properly re-
place logs.
• Replace log(s) if broken or chipped
(dime-sized or larger).
Figure 29 - Incorrect Front Burner Flame
Pattern
Figure 28 - Correct Front Burner Flame
Pattern
Yellow Tipping At
Top of Blue Flame
CLEANING BURNERS
INJECTOR HOLDER AND
PILOT AIR INLET HOLE
The primary air inlet holes allow the proper
amount of air to mix with the gas. This pro-
videsacleanburningflame.Keeptheseholes
clear of dust, dirt, lint, and pet hair. Clean
these air inlet holes prior to each heating
season.Blockedairholeswillcreatesoot.We
recommendthatyoucleantheuniteverythree
months during operation and have heater in-
spected yearly by a qualified service person.
INSPECTING
BURNERS
Continued
Figure 30 - Injector Holder On Outlet
Burner Tube
Burner
Tube
Pilot
Assembly
Pilot Air
Inlet Hole
Ports/Slots
Figure 31 - Pilot Inlet Air Hole
Burner
Tube
Injector Holder
Primary Air Inlet
Holes
Ports/Slots
Wealsorecommendthatyoukeeptheburner
tube and pilot assembly clean and free of
dustanddirt.Tocleanthesepartswerecom-
mend using compressed air no greater than
30 PSI. Your local computer store, hard-
ware store, or home center may carry com-
pressed air in a can. You can use a vacuum
cleaner in the blow position. If using com-
pressed air in a can, please follow the direc-
tions on the can. If you don't follow direc-
tionsonthecan, youcoulddamagethepilot
assembly.
1. Shut off the unit, including the pilot.
Allow the unit to cool for at least thirty
minutes.
2. Inspect burners, pilot, and primary air
inlet holes on injector holder for dust
and dirt (see Figure 30).
3. Blow air through the ports/slots and
holes in the burners.
4. Check the injector holder located at the
end of the burner tube again. Remove
any large particles of dust, dirt, lint, or
pet hair with a soft cloth or vacuum
cleaner nozzle.
5. Blow air into the primary air holes on
the injector holder.
6. In case any large clumps of dust have
now been pushed into the burner repeat
steps 3 and 4.
Clean the pilot assembly also. A yellow tip
on the pilot flame indicates dust and dirt in
the pilot assembly. There is a small pilot air
inlet hole about two inches from where the
pilot flame comes out of the pilot assembly
(see Figure 31). With the unit off, lightly
blowairthrough the airinlethole. You may
blowthroughadrinkingstrawifcompressed
air is not available.

18
105073
UNVENTED PROPANE/LP GAS LOG HEATER
FIREPLACE MANUFACTURERS INC.
WARNING: Turn off and un-
plug heater and let cool before
servicing. Only a qualified ser-
vice person should service and
repair heater.
CAUTION: Never use a wire,
needle, or similar object to clean
ODS/pilot.ThiscandamageODS/
pilot unit.
POSSIBLE CAUSE
1. Ignitor electrode not connected to igni-
tor cable
2. Ignitor cable pinched or wet
3. Piezo ignitor nut is loose
4. Broken ignitor cable
5. Bad piezo ignitor
6. Ignitor electrode positioned wrong
7. Ignitor electrode broken
1. Gas supply turned off or equipment
shutoff valve closed
2. Control knob not in PILOT position
3. Control knob not pressed in while in
PILOT position
4. Air in gas lines when installed
5. Depleted gas supply
6. ODS/pilot is clogged
7. Gas control setting is not correct
1. Control knob not fully pressed in
2. Control knobnotpressedin long enough
3. Equipment shutoff valve not fully open
4. Pilot flame not touching thermocouple,
which allows thermocouple to cool,
causing pilot flame to go out. This prob-
lem could be caused by one or both of
the following:
A) Low gas pressure
B) Dirty or partially clogged ODS/pilot
5. Thermocouple connection loose at con-
trol valve
6. Thermocouple damaged
7. Gas control damaged
REMEDY
1. Reconnect ignitor cable
2. Free ignitor cable if pinched by any
metal or tubing. Keep ignitor cable dry
3. Tighten nut holding piezo ignitortobase
panel of log set. Nut is located behind
base panel
4. Replace ignitor cable
5. Replace piezo ignitor
6. Replace ignitor
7. Replace ignitor
1. Turn on gas supply or open equipment
shutoff valve
2. Turn control knob to PILOT position
3. Press in control knob while in PILOT
position
4. Continue holding down control knob.
Repeat igniting operation until air is re-
moved
5. Contact local propane/LP gas company
6. Clean ODS/pilot (see Cleaning and
Maintenance, page 17) or replace ODS/
pilot assembly
7. Replace gas control
1. Press in control knob fully
2. After ODS/pilot lights, keep control
knob pressed in 30 seconds
3. Fully open equipment shutoff valve
4. A) Contact local propane/LP gas
company
B) Clean ODS/pilot (see Cleaning and
Maintenance, page 17) or replace ODS/
pilot assembly
5. Hand tighten until snug, then tighten 1/4
turn more
6. Replace thermocouple
7. Replace gas control
OBSERVED PROBLEM
When ignitor button is pressed, there is no
spark at ODS/pilot
When ignitor button is pressed, there is
spark at ODS/pilot but no ignition
ODS/pilot lights but flame goes out when
control knob is released
TROUBLESHOOTING
Note: For additional help, visit DESA
International’stechnicalservicewebsite
at www.desatech.com.
Note: Alltroubleshootingitemsarelistedin
order of operation.
www.desatech.com

19
105073
OWNER’S MANUAL
REMEDY
1. Contact local propane/LP gas company
2. Clean burner(s)(seeCleaning and Main-
tenance, page 17) or replace burner
orifice(s)
3. Contact qualified service person
4. Replace burner orifice(s)
5. Put selector switch in ON position
6. See Wiring Diagram, page 21
1. Contact local propane/LP gas company
2. Clean burner(s)(seeCleaning and Main-
tenance, page 17) or replace burner
orifice(s)
3. Contact qualified service person
1. Clean burner (see Cleaning and Mainte-
nance, page 17) or replace burner orifice
2. Replace damaged burner
3. Replace gas control
1. Check burner(s) for dirt and debris. If
found,cleanburner(s)(see Cleaning and
Maintenance, page 17)
2. Replace gas control
1. Problem will stop after a few hours of
operation
1. Refer to Air for Combustion and Venti-
lation requirements (page 4)
1. Turn control knob to LO position and
let warm up for a minute
2. Operate burners until air is removed
from line. Have gas line checked by lo-
cal Propane/LP gas company
3. Observe minimum installation clear-
ances (see pages 7 through 9)
4. Clean burners (see Cleaning and Main-
tenance, page 17) or replace burner
orifice(s)
1. Turn heater off when using furniture
polish, wax, carpet cleaners, or similar
products
1. Replace 9-volt batteries in receiver and
remote control
OBSERVED PROBLEM
One or both burners do not light after ODS/
pilot is lit
Delayed ignition of one or both burners
Burner backfiring during combustion
Yellow flame in front burner during burner
combustion
Slightsmokeor odorduringinitial operation
Moisture/condensationnoticedonwindows
Heater produces a whistling noise when
burners are lit
Whitepowderresidueformingwithinburner
box or on adjacent walls or furniture
Remote does not function (GHRC Series
and GHRCT Series only)
POSSIBLE CAUSE
1. Inlet gas pressure is too low
2. Burner orifice(s) clogged
3. Mislocated crossover tube
4. Burner orifice(s) diameter is too small
5. Selector switch in OFF position
6. Wire disconnected from gas control
1. Manifold pressure is too low
2. Burner orifice(s) clogged
3. Mislocated crossover tube
1. Burner orifice is clogged or damaged
2. Damaged burner
3. Gas control defective
1. Not enough air
2. Gas control defective
1. Residues from manufacturing processes
and logs curing
1. Not enough combustion/ventilation air
1. Turning control knob to HI position
when burners are cold
2. Air in gas line
3. Air passageways on heater blocked
4. Dirty or partially clogged burner
orifice(s)
1. When heated,vaporsfromfurniturepol-
ish, wax, carpet cleaners, etc. turn into
white powder residue
1. Battery is not installed. Battery power
is low
TROUBLESHOOTING
Continued
Continued
www.desatech.com

20
105073
UNVENTED PROPANE/LP GAS LOG HEATER
FIREPLACE MANUFACTURERS INC.
REMEDY
1. This is common with most heaters. If
noise is excessive, contact qualified ser-
vice person
1. Open windowtoventilate room. Stopus-
ing odor causing products while heater
is running
2. Refill supply tank
3. Locate and correct all leaks (see Check-
ing Gas Connections, page 12)
1. Open windowand/ordoor for ventilation
2. Contact local propane/LP gas company
3. Clean ODS/pilot (see Cleaning and
Maintenance, page 17)
1. Locate and correct all leaks (see Check-
ing Gas Connections, page 12)
2. Replace gas control
1. Take apart gas tubing and remove for-
eign matter
2. Locate and correct all leaks (see Check-
ing Gas Connections, page 12)
1. Move hand-held remote control unit far-
ther away from the heater
WARNING: If you smell gas
• Shut off gas supply.
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your
building.
• Immediatelycallyourgassupplierfromaneighbor’sphone.Followthe
gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fire department.
POSSIBLE CAUSE
1. Metal expanding while heating or con-
tracting while cooling
1. Heater burning vapors from paint, hair
spray, glues, cleaners, chemicals, new
carpet, etc. (See IMPORTANT state-
ment above)
2. Low fuel supply
3. Gas leak. See Warning statement
above
1. Not enough fresh air is available
2. Low line pressure
3. ODS/pilot is partially clogged
1. Gas leak. See Warning statement
above
2. Gas control defective
1. Foreign matter between control valve
and burner
2. Gas leak. See Warning statement
above
1. Hand-held remote control unit needs to
be moved away from heater
OBSERVED PROBLEM
Heater produces a clicking/ticking noise
just after burners are lit or shut off
Heater produces unwanted odors
Heater shuts off in use (ODS operates)
Gas odor even when control knob is in OFF
position
Gas odor during combustion
Log set cycles to pilot, but room tempera-
ture drops to a lower than ideal level before
logsetcomesbackon(GHRCTSeriesonly)
TROUBLESHOOTING
Continued
IMPORTANT: Operating heater where impurities in air exist may create odors. Cleaning
supplies, paint, paint remover, cigarette smoke, cements and glues, new carpet or textiles,
etc.,createfumes.Thesefumesmaymixwithcombustionairandcreateodors.Theseodors
will disappear over time.
www.desatech.com
