Focal 100 IWSUB8 User manual

Français : page 7
English : page 10
Deutsch : seite 13
Italiano : pagina 16
Español : página 19
Português : página 22
Nederlands : pagina 25
Русский: стр.28
中文：第31页
한국어 : 34 페이지
日本語 : ページ 37
100 IWSUB8™
Manuel d’utilisation / User Manual / Gebrauchsanleitung / Manuale d’uso / Manual de uso /
Manual de utilização / Handleiding / Руководство по эксплуатации /

使用手册 / 사용 설명서 / 取扱説明書 /
40

2
100 IWSUB8™
Manuel d’utilisation / User manual
A
C
D
B
1300
352
86
98
1300
352
86
98

3
100 IWSUB8™
Manuel d’utilisation / User manual
1
1
2
5
1
4
1
1
E

4
100 IWSUB8™
h
vv
h
v
F
G
Manuel d’utilisation / User manual

5
100 IWSUB8™
H
I
Manuel d’utilisation / User manual

6
100 IWSUB8™
100 IWSUB8
Type Subwoofer passif
Haut-parleur Woofer 21 cm en Polyglass
Bande Passante (+/-3 dB) 34 - 140 Hz
Coupure basse (-6 dB) 30 Hz
Impédance nominale 8 Ώ
Puissance ampli recommandée Max 200 W / 4 Ώ
Dimensions (L x P x H) 352 x 98 x 1 300 mm
Dimensions d'encastrement (L x H) 352 x 1 300 mm
Profondeur d'encastrement 86 mm
Poids net 14,6 kg
100 IWSUB8
Type Passive subwoofer
Speakers 8" (21cm) Polyglass Woofer
Bandwith (+/-3dB) 34-140Hz
Cut-off frequency (-6dB) 30Hz
Nominal impedance 8Ώ
Recommended amp power Max 200W / 4Ώ
Dimensions (WxDxH) 137/8 x 37/ 8 x 513/16" (352 x 98 x 1,300mm)
Cut-out dimensions (WxH) 137/8 x 513/16" (352 x 1,300mm)
Depth from wall 33/8" (86mm)
Net weight 32.3lbs (14.6kg)
Manuel d’utilisation / User manual

READ FIRST !
IMPORTANT SAFETY INSTRUCTIONS ! GB
An exclamation mark in an equilateral triangle warns the user that the manual
contains important instructions on how to use and look after the device.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all the instructions.
5. Do not use this device near water.
6. Only clean with a dry cloth.
7. Do not obstruct ventilation
openings. Follow the manufacturer’s
instructions for installing the device.
8. Do not install the device close
to a heat source such as a radiator,
cooker, heat vents or any other
appliance (including amplifiers) that
gives out heat.
9. Only use accessories
recommended by the manufacturer.
10. Only use trolleys, stands, tripods,
mounts or tables recommended
by the manufacturer or sold with
the device. If using a trolley, take
extra care when moving the trolley
and device together, to prevent the
device from falling o and causing
injury.
11. All maintenance tasks should
be performed by a qualified
professional. Maintenance is required
in case of any kind of damage to
the device (damaged cable or plug,
spillages or objects inserted into
the device, exposure to rain or
humidity, if the device malfunctions
or overturns, etc.).
12. To avoid damaging your hearing,
do not listen to loudspeakers at
high volumes for long periods of
time. Listening to loudspeakers at
high volumes can cause damage
to the user’s ears and may lead to
hearing problems (temporary or
permanent deafness, buzzing in the
ears, tinnitus, hyperacusis). Exposure
to excessive volumes (over 85 dB)
for more than one hour can cause
irreparable damage to your hearing.
(CEI 60417-6044)

11
100 IWSUB8™
Thank you for choosing the 100 Series 100 IWSUB8 subwoofer and for sharing our 'Listen Beyond' philosophy.
To get the most out of this product, we recommend that you read the instructions in this booklet, then store
it in a safe place to refer to in the future.
The 100 IWSUB8 is a high-power bass-reflex passive subwoofer, designed to be flush-fitted into walls with pre-
constructed 16" (40.64cm) OC studs. The installation depth is only 86mm (33/8"). This subwoofer is designed
to be used with the 100 IWSUB8 Amplifier. You can connect up to two subwoofers in parallel.
Attention
Warning: this product requires installation inside the wall structure. We recommend using a professional
installer who will know how to install the product properly and will understand the various mechanical and
vibratory constraints to ensure the product works at its best for years to come. Contact your Focal-JMLab
retailer who will be able to advise you. Focal cannot be held responsible for any consequences due to poor
installation.
Package contents
• 1 x 100 IWSUB8 subwoofer
• 4 x fixing brackets
• 36 x 13/16" (30mm) screws (24 for the brackets, 12 for the frame)
• 1 x grille support frame
• 1 x metal grille with logo
• 12 x shock-absorbing foam strips
• 1 x cut-out template
• 1 x quick start manual
Key points
• Bass-reflex subwoofer with low cut-off at 30Hz.
• Shallow depth (33/8"/ 86mm), for installation in walls with 16” (40.64cm) OC studs.
• 8" (21cm) woofer made with Polyglass technology. Glass microbeads added to the cone surface to help
stiffen the structure.
• Moulded internal vent for noiseless running.
• Nominal impedance of 8 Ohms, to enable installation in pairs with 100 IWSUB8 Amplifier.
• Slim grille with magnetic fastening, ready to paint.
Warranty terms and conditions
In the event of a problem, please contact your Focal dealer.
The warranty for France on any Focal equipment is 2 years, non-transferable in the event of resale, from the
date of purchase. In the event of faulty equipment, you must send it in its original packaging and at your own
expense to the dealer, who will analyse the equipment and determine the nature of the fault. If it is under
warranty, the equipment will be returned to you or replaced ‘carriage paid’. Otherwise, you will be offered an
estimate for repair.
The warranty does not cover damage resulting from inappropriate use or incorrect connection.
Outside France, Focal equipment is covered by a warranty for which the terms and conditions are determined
locally by the official Focal distributor for each country, in accordance with the laws in force in the region in
question.
Our policy of continual product improvement means that Focal-JMlab reserves the right to modify the technical specifications
of its products without notice. Product may vary from images.
Please validate your Focal-JMlab warranty,
it is now possible to register your product online: www.focal.com/warranty
User manual English

12
100 IWSUB8™
Positioning the subwoofer in the room
Unlike an acoustic loudspeaker that needs to be far enough away from the walls and corners of the room, we
recommend positioning the subwoofer in a corner. The resonances of the room will be stimulated in a more
linear, predictable way. Not only will this optimise bass perception, but this layout will also make it possible to
increase the bass level by + 6 dB.
In general, make sure the subwoofer is positioned more towards the front of the room (fig. A and B). Since
the frequency bands are omnidirectional, in principal the bass should not be affected by an object or piece of
furniture placed between the subwoofer and the point of listening.
Using two subwoofers will provide more powerful playback and enable use in larger rooms (fig. C).
Pre-installation wiring
You can only install your subwoofer once you have wired it up. Make sure you leave enough cable length to
be able to connect your product with ease (approximately 1911/16" / 50cm). We recommend using a cable with
a marker to ensure the polarity of the speaker drivers is respected (+/-). Choose good quality cables with a
cross-section appropriate for their length: your dealer will be able to advise you.
Installation
1- Stick the foam strips onto the sides, the front panel and the back of the cabinet. (fig. E)
2- Decide where you want to position the product and attach the bottom brackets perfectly horizontally
onto the studs with 6 screws. (fig. E)
3- Position the cabinet on the brackets, slightly set-back from the studs by around 1/16" (1mm) and screw in
with 6 screws.
4- Fix the upper brackets onto the studs with 6 screws then secure the cabinet using another 6 screws. (fig.
E)
5- Connect the cables to the terminal and check the subwoofer is working. (fig. E)
6- Mark the position of the subwoofer’s front panel with respect to the floor and the wall, then position the
template in the equivalent position on the partition, then finally cut the partition carefully. (fig. F)
7- Position the partition and check it fits properly around the subwoofer's front panel before attaching it to
the studs. (fig. G)
8- Position the grille support frame and fix with 12 screws. (fig. H)
9- Finally, place the grille onto its frame. (fig. I)
Painting
If you wish, you can paint the grille of your 100 IWSUB8 so that it is coordinated with your environment. We
recommend that you firstly remove the grille and paint it using a paint gun. The paint used can be the same
type as the paint used on the walls .
Amplification
This subwoofer is designed for optimum use with the 100 IWSUB8 Amplifier. You can connect up to two
subwoofers in parallel to this amplifier.
User manual

Focal-JMlab®- BP 374 - 108, rue de l'Avenir - 42353 La Talaudière cedex - France - www.focal.com
Tel. [phone] - Fax [phone] - SCAA-190214/1

100 SERIES
100IWSUB8
Démarrage rapide / Quick Start
EN Go to the user manual
FR Accédez à la notice d’utilisation
DE Bedienungsanleitung lesen
ES Acceda a las instrucciones de uso
IT Accedi alle istruzioni per l’uso
PT Ir para o manual de serviço
NL Ga naar de gebruiksaanwijzing
RU
Перейти к инструкции по эксплуатации
CN 访问使用说明
KR 사용설명서 보러가기
JP サービスマニュアルに移動します
AR 
https://www.focal.com/100series/usermanual

Le FOCAL 100IWSUB8 est un subwoofer bass-reflex passif de haute puissance,
conçu pour une installation encastrée dans un mur. Il peut être installé dans des
murs avec des montants de 16" OC en pré-construction ou en modernisation. Sa
profondeur d’encastrement est seulement de 86 mm. Ce subwoofer est conçu
pour être utilisé avec l’amplificateur FOCAL 100 IWSUB8 AMPLIFIER. Jusqu’à
deux subwoofers peuvent être connectés en parallèle.
The FOCAL 100IWSUB8 is an high-power passive bass-reflex subwoofer,
designed for in-wall installation. It fits between 16" OC studs for pre-construction
or retrofit. Its installation depth is only 33/8". This subwoofer is dedicated to be
powered by the FOCAL 100IWSUB8 AMPLIFIER. Up to two subwoofers can be
connected in parallel.
Attention : ce produit nécessite une mise en place dans la structure
murale. Nous vous recommandons de faire appel à un installateur
professionnel qui saura réaliser l’installation parfaitement et prendre
en charge les diérentes contraintes mécaniques et vibratoires afin d’assurer
un fonctionnement optimal du produit pour de nombreuses années. Contactez
votre revendeur Focal-JMlab qui saura vous renseigner. Focal se dégage de
toute responsabilité quant aux potentielles conséquences d’une mauvaise
installation.
Caution: this product requires placement in the wall structure. We
recommend that you hire a professional installer who will perform the
installation perfectly and will take care of the various mechanical and
vibratory constraints to ensure optimal product operation for many years.
Contact your Focal-JMlab dealer who will provide you with information. Focal
disclaims all liability for the potential consequences of improper installation.
DIMENSIONS
!
!
1300
352
86
98
1300
352
86
98

Coller les bandes de mousse sur les
côtés, la façade et le dos du coret.
Glue the foam pads to the sides, front
and back of the cabinet.
Définir la position souhaitée pour
le produit et fixer les équerres
inférieures parfaitement horizontales
sur les montants avec 6 vis.
Define the desired position for the
product and fix bottom brackets on the
wood stud perfectly horizontally with
6screws.
Positionner le coret sur les
équerres, avec un léger recul de
1 mm par rapport aux montants et le
visser avec 6 vis.
Place the cabinet on the bracket, with
a slight backward position of 1mm
compared to the studs and screw it with
6 screws.
Mettre en place les équerres
supérieures sur les montants avec
6 vis puis solidariser le coret avec
6autres vis.
Put the upper brackets on the studs
with 6 screws and then secure cabinet
with 6other screws.
Brancher les câbles sur le bornier
et vérifier le fonctionnement du
subwoofer.
Connect the cables to the terminal
and check the nominal function of the
subwoofer.
Repérer la position de la façade du
subwoofer par rapport au sol et au mur,
puis positionner le gabarit à la position
équivalente sur la cloison, et enfin
réaliser la découpe de la cloison avec
précision.
Identify the position of the subwoofer
facade in relation to the floor and the
wall, then place the cut-out template in
the equivalent position on the drywall,
and make precisely the cut.
1
2
3
4
5
Contenu de l’emballage
• 1 x Subwoofer FOCAL 100IWSUB8
• 4 x Équerres de fixation
• 36 x Vis de 30 mm
(24 pour équerres, 12 pour le cadre)
• 1 x Cadre de maintien de la grille
• 1 x Grille en métal avec son logo
• 12 x Bandes de mousse isolante
• 1 x Gabarit de découpe
• 1 x Guide de démarrage rapide
Package content
• 1x FOCAL 100IWSUB8 Subwoofer
• 4x L Brackets
• 36x30mm screws
(24 for brackets, 12 for frame)
• 1x Metal grille frame
• 1x Metal grille with logo
• 12x Isolation foam pads
• 1x Cut-out template
• 1x Quick start manual
1
1
2
5
1
4
1
1
h
vv
h
v
6

Positionner le cadre de maintien de la
grille et le fixer avec 12 vis.
Place the grille metal frame on the front
baffle and lock it with 12 screws.
Placer finalement la grille sur son
cadre.
Finally install the grid on its frame.
8
9
Positionner la cloison et contrôler le
bon ajustement autour de la façade
du subwoofer avant de la fixer sur les
montants.
Install the drywall and control the
proper fit around the subwoofer front
face before attaching it to the studs.
7

Pour validation de la garantie
Focal-JMlab,
il est maintenant possible d’enregistrer
son produit en ligne :
www.focal.com/garantie
Please validate your Focal-JMlab
warranty,
it is now possible to register your product
online:
www.focal.com/warranty
Focal-JMlab®- BP 374 - 108, rue de l'Avenir - 42353 La Talaudière cedex - France - www.focal.com
Tel. [phone] - Fax [phone] - SCAA-190204/2 - CODO1581
En cas de problème, adressez-vous à votre revendeur
Focal.
La garantie pour la France sur tout matériel Focal
est de 2 ans non transmissible en cas de revente,
à partir de la date d’achat. En cas de matériel
défectueux, celui-ci doit être expédié à vos frais,
dans son emballage d’origine auprès du revendeur,
lequel analysera le matériel et déterminera la nature
de la panne. Si celui-ci est sous garantie, le matériel
vous sera rendu ou remplace en “franco de port”.
Dans le cas contraire, un devis de réparation vous
sera proposé.
La garantie ne couvre pas les dommages résultant
d’une mauvaise utilisation ou d’un branchement
incorrect (bobines mobiles brûlées par exemple...).
En dehors de la France, le matériel Focal est couvert
par une garantie dont les conditions sont fixées
localement par le distributeur officiel Focal de
chaque pays, en accord avec les lois en vigueur sur
le territoire concerné.
1. Lisez les instructions.
2. Gardez ces instructions.
3. Respectez les instructions.
4. Ne pas exposer cet appareil directement avec de l’eau.
5. Nettoyez uniquement avec un chion sec.
6. N’installez pas près d’une source de chaleur telle qu’un
radiateur, four ou autres appareils produisant de la chaleur.
7. Utilisez uniquement les accessoires spécifiés par le
fabricant ou ceux fournis avec l’appareil.
8. Confiez toute réparation à du personnel qualifié. Une
réparation est nécessaire en cas, par exemple, de dégâts
sur le câble d’alimentation ou la prise, de liquide renversé
ou de choc entre un autre objet et l’appareil, ou encore
si l’appareil a été exposé à la pluie ou présente des
moisissures, ou s’il ne fonctionne pas normalement ou,
enfin, s’il a subi une chute.
9. Pour réduire le risque d’incendie ou de choc électrique,
cet appareil ne doit être exposé ni à de l’eau ruisselante
ni aux éclaboussures. Aucun objet rempli d’eau, tel qu’un
vase, ne doit être posé dessus.
10. Le point d’exclamation contenu dans un
triangle équilatéral a pour objet de prévenir
l’utilisateur de la présence d’instructions
importantes mentionnées dans le mode
d’emploi et relatives à la mise en œuvre et à
l’entretien de l’appareil.
11. Ne placer aucune flamme nue sur l’appareil.
Please contact your Focal retailer if you encounter
any problems.
The warranty in France for any Focal product is valid
for 2 (two) years from the date of purchase, and
rights are non-transferable in case of resale. In the
case of defective equipment, the equipment must be
shipped at your expense in its original packaging to
the dealer who will test the equipment in order to
determine the nature of the fault. If the product is
still under warranty, the product will be returned to
you or replaced, shipping pre-paid. If the product is
no longer under warranty, you will be given a quote
for the repairs.
The warranty does not cover damage resulting from
improper use or incorrect wiring (e.g. burnt out
moving coils, for example).
Outside of France, Focal products are covered by
a warranty whose conditions are determined locally
by the official Focal dealer in each country, in
compliance with the laws in force in the respective
territory.
1. Read the instructions.
2. Keep these instructions.
3. Follow the instructions.
4. Do not use this product with water.
5. Clean only with a dry cloth.
6. Do not install near any heat sources such as a radiator,
oven or other appliance that produces heat.
7. Only use accessories specified by the manufacturer or
those supplied with the unit.
8. Refer all servicing to qualified personnel. Repair will be
necessary, for example, in cases of damage to the power
cord or plug, spilled liquids or fallen object on the product,
or if the product is exposed to rain or moisture, or if it does
not operate normally, or if the product has been dropped.
9. To reduce the risk of fire or electrical shock, this unit
should not be exposed to dripping or splashing water. No
object filled with liquids, such as vases, should be placed
on it.
10. The exclamation mark in an equilateral
triangle is intended to alert users to the
existence of important instructions in the
manual relating to the use and maintenance
of the unit.
11. No naked flame source should be placed on the product.
Conditions de garantie
Consignes de sécurité
Conditions of warranty
Safety instructions
FR
FR
EN
EN
