Fonexion FX30 User manual

Bluetooth
FX30

The FX30 is a wireless headset equipped with Bluetooth technology.
It is specially designed for different kinds of Bluetooth cell phones.
How can I use my FX30 Bluetooth headset?
You can connect your FX30 headset to your mobile phone, PC or any device with Bluetooth technology that supports the Headset or the Hands
free profile. This user's guide focuses on how to use the headset with your mobile phone.
You need to have a phone with built-in Bluetooth capability, or a phone with a Bluetooth adapter connected to it. When the headset is connected to
your mobile phone, you can use voice control to make calls (if your phone supports this function). The phone can be tucked away in your pocket or
in a bag. You can handle incoming and out going calls, and adjust the volume, using the buttons on the headset.
Buttons

Package Contents
FX30 Bluetooth Headset
USB Charger
Inter-Changeable panel
User manual
Quick Start guide
1. Fully charge your FX30
The FX30 headset comes with a built - in rechargeable battery. We recommend that you charge the battery until the headset indicator turns off
before using the headset for the first time. During charging, the indicator light shows a steady red light and the headset is turned off. When the
battery is fully charged, the indicator will be off. It takes 3 to 3.5 hours to fully recharge the battery. Always use the manufacturer’s charger.
2. Switch on the Headset.
Press and hold the MFB (around 5 seconds) in power off mode until LED flashes 3 times and you hear 2 short beep tones. The headset is then on.
To turn the headset off press and hold the MFB (around 4 seconds) until the LED flashes 3 times and you hear 2 short beep tones. The LED will
turn off and the headset is then off.
3. Pairing the FX30 headset with a phone
a. Prepare your phone according to the phone's user manual on pairing.
b. Press MFB button for up to 8 seconds until the indicator light on the headset flashes blue and red alternatively. The FX30 is now in
pairing mode.
c. Continue according to the instructions in the phone's user manual and press yes or OK when asked if you want to pair the phone with
the FX30.
d. Enter passkey “0000” then press Yes or OK.

e. Your phone will confirm when pairing is complete.
You pair the headset with the phone by adding it to a list of paired devices in the phone. The two devices then recognize each other when they
connect. Once you have paired your headset with the phone, you do not need to pair it again until you want to use it with another device.
4. Putting on the headset
Make sure the ear hook forms an angle of 90
Place the ear hook behind your ear
Make sure the microphone is pointing towards your mouth
Make sure the speaker is positioned as shown in the picture
Features
Bluetooth V1.2
Profiles supported Headset & Handsfree
Range – up to 10 m (33 feet)
Security Pairing, Encryption & Authentication
Type of battery Rechargeable Lithium Polymer
Talk Time- up to 5 hours
Standby Time- up to 180 hours
Charging Time 3-3.5 hours
VoIP compatible Skype, Messenger etc…

Troubleshooting & Warning
No sound contact between headset and phone. The headset and the phone you are using with it have to be paired to recognize each other. They
also have to be within range of each other. Make sure that there are no solid objects, such as walls or furniture, in between the headset and the
phone.
The indicator light flashes red. This indicates that the headset has only limited talk and standby time left. Charge the headset battery for
approximately 3 to 3.5 hours.
Don't expose the Headset and Charger to any liquid, moisture or humidity as they aren't waterproof.
Don't use the Headset and Charger in extreme temperatures.
If you don't use the Headset for long periods, be sure store it in a cool, dry place away from extreme temperatures and dust.
Only use the supplied manufacturer’s charger when charging the headset.
Operation Guide
FUNCTION OPERATION LED INDICATION
AUDIO INDICATION
Turn on Press and hold the MFB for 5 seconds in power
off mode
LED flashing blue 3
times
2 short beep tones
Turn off Press and hold the MFB for 4 seconds in
standby mode
LED flashing red 3 times
then off
2 short beep tones
Pairing 1. In the power off mode press and hold the
MFB for 8 seconds
LED flashing in Blue
and
Red alternatively
2. Perform a device search from the phone
3. Press the YES soft key and enter the passkey
"0000" to pair
the headset with the phone
Pairing is successful
when the headset
indicator flashes 6 times

rapidly
Volume Adjustment Press the V(+) or V(-) repeatedly to increase or
decrease speaker volume
Short tones
Receive Call Press the MFB once Ringing tone stopped
End Call Press the MFB once A short beep tone
Voice Dialing * 1. Press MFB once A tone sounds to prompt the user to
speak the name of the person he
wishes to call
2. Say the voice tag name the phone finds the entry, pauses two
seconds, then places the call
Re-dialing Press and hold the V(-) button around 3 seconds Recall the last number dialed
Reject Call 1. Press and hold the MFB button around 3
seconds to reject the incoming call
Mute Press V(+) and V(-) buttons around 3 seconds 1 short beep tone, microphone is
muted.
Un-mute Press V(+) or V(-) button once 1 short beep tone
Power saving in standby
mode
Press V(+) or V(-) button once none flashing in blue or
red
1 short beep tone
Release power saving in
power saving mode
Press V(+) or V(-) button once 1 short beep tone
