Ani Wi-Fi Alarm System
MANUAL

TABLE OF CONTENTS
FEATURES
APPEARANCE
1
2
3
4
APP
REGISTER
CONNECTING TO WIFI NETWORK
DEVICE LIST
CHANGE THE DEVICE PASSWORD
APPLICATION OPERATION
5
ARM/DISARM
SMART HOME
ALARM CONTACT NUMBERS
ZONE SETTINGS
ARM/DISARM
ACCESSORIES
ADDING OTHER WIRELESS ACCESSORIES
REMOTE CONTROL MANAGEMENT ZONE NAME ZONE TYPE
ZONE TYPES AND THEIR FUNCTION SIREN DELAY SETTING RING TIME
PANEL OPERATION
6TECHNICAL PARAMETERS
ADD REMOTE CONTROL DELETE REMOTE CONTROLS ADD SENSORS
DELETE SENSORS
1
2
3
4
5
6
7
1
2
4
5
5
7-10
ALARM LOG
SCHEDULE ARM/DISARM
SCHEDULE OUTLET TIMER
MONITOR
PANEL SETTINGS
ALARM NOTIFICATION ALARM VOLUME RING TIMES ALARM AUDIO
BEEP VOLUME PANEL NAME PANEL PASSWORD PANEL TIME
SYSTEM SETTINGS
11
11
12
13
14
14-18
19
19
20
20-23
24
24-25 ADD STROBE SIREN ADD SMART OUTLET
STATUS LIGHT INDICATION
CONTROL THROUGH LAND LINE
26
27
28

APPEARANCE
FEATURES:
Operation by voice instruction.
Supports 2.4G WIFI wireless network.
Real-time host feedback to the application.
Supports multiple alarm operations.
Compatible with IOS/Android operating systems.
8 customizable zones with independent arm/disarm.
Zones can be named individually.
Up to 3 telephone alarm contacts.
Power failure notification.
4 arm/disarm scheduling groups.
Control 8 smart sockets, 1 alarm siren and 1 linkage switch.
4 linkage switch schedules.
Adjustable panel voice/alarm volume.
1

2
Press “Create an Account”.
Select “Email Register”.
Type in the email address you would like your account be assigned to.
Next, type in the password you would like to use.
Press Confirm.
APP
IOS/Android
Registration by Email
If you have not used the Ani application before, you will need to create an
account. Follow the below steps.
Scan the compatible QR code to download the app or search
“Fortress Ani WiFi” in the App Store or Google Play.
REGISTER

3
CONNECTING TO WIFI NETWORK
In the application go to the “Device list” and press the “+” button in the
top right hand corner.
Next, press the “I want to configure a new device” button at the button
of your screen.
Enter your WiFi network password then press Next.
Press and hold the button until the panel says “WiFi configuring, please
enter WiFi password on the app”. The light will start flashing white.
Press the “Start Configure Button”
A timer will start counting down from 60 seconds.
Once the ANI device connects the white flashing light will turn green.
In the Device List, click on the W1 device to use the application.

4
DEVICE LIST
CHANGE THE DEVICE PASSWORD
There are three options under the device list page; Bound Device, Find
New Device, and Offline Device.
Click on any device under the “Bound Device” list.
Click the button in the top right hand corner.
Select Settings
Click on “Device Password” then type in your new password.
Lastly, press confirm
STATUS DESCRIPTION
BOUND DEVICE
FINE NEW DEVICE
OFFLINE DEVICE
The device is connected to the network
successfully and the phone has
connected to the device.
The device is connected to the network
but the phone has not connected to
the device.
The device had previously been
connected to the network but has
become disconnected.

APPLICATION OPERATION
5
ARM/DISARM
SMART HOME
To arm in away mode, press the button.
To disarm the system, press the button.
To arm in home mode, press the button.
There can be up to 8 smart outlets on the ANI system. There is an
toggle switch and an toggle switch for each outlet. Each outlet
can be turned on/off by toggling the switch.
If you would like to rename each outlet, click on the outlet number and
enter a new name. Press confirm to finish.

6
ALARM CONTACT NUMBERS
Adding Phone Numbers
Delete Phone Numbers
To add a phone number open your Ani Wifi application.
Scroll to “ALARM NUM” on your menu bar.
Press the Add One button.
Type in the number that you would like to use.
Press Confirm to finish.
If you need a number in front of the phone number, insert the * icon
which will delay by 1s when dialing. For example: 0*12345678.
You can have a total of 3 phone numbers.
Open your Ani Wifi application.
Scroll to “ALARM NUM” on the menu bar.
Press the DELETE button.
Select which numbers you want to delete by pressing the red delete
button.

ZONE SETTINGS
Remote Management
The Ani system has 1 zone for remote management (8 zones). There are
8 different zones for sensors, all of which can hold 10 sensors. Each
defense zone can be armed/disarmed independently.
Open you Ani WiFi application.
Scroll to “ZONE SET” on your menu bar.
Click on “Remote Management”
If sound is turned on, the sirens will chirp when the system is
armed/disarmed.
Click on the sound toggle to turn it off.
Open your Ani WiFi application.
Scroll to “ZONE SET” on your menu bar.
Press on the zone you would like to change the name of.
Click on the icon.
Select from the preset option or create a custom name.
Press the button to finish.
Zone Name
There are 8 different zones that can be renamed. To modify their
names, follow the steps bellow:
7

8
Zone Type
Open your Ani WiFi application.
Scroll to “ZONE SET” on your menu bar.
Press on the zone you would like to change the zone type on.
Press on the icon.
Select which zone type you want then press the button to finish.
Each zone can have their type changed individually. There are 8
different zone types to choose from. To change the zone type follow
the steps bellow:

9
Siren
Zone Types And Their Function
TYPE DISARMED ARMED STAY ARMED ADDITIONAL FEATURES
ORDINARY
STAY ARM
INTELLIGENT
EMERGENCY
CLOSED
DOORBELL
CHIME
ELDER
Inactive
Inactive
Inactive
Active
Inactive
Inactive
Inactive
Active
Active
Active
Active
Active
Inactive
Inactive
Active
Active
Active
Inactive
Inactive
Active
Inactive
Inactive
Active
Active
Needs to be triggered twice within
30 seconds to activate the alarm.
The sensor will cause the panel to
play a doorbell sound
Sensor causes the system to play a
chime sound when the system is
disarmed
Open your Ani WiFi application.
Scroll to “ZONE SET” on your menu bar.
Choose the zone you are wanting to change.
Click the button to turn off any wireless sirens.
Click the button to turn off the built in siren on the Ani Hub.
Each of the 8 zones can have all sirens turned on/off or have just the
outside sirens turned off. To do so, follow the steps bellow:
Alarm will be triggered but no sirens
will sound.

10
Delay Settings
Each of the 8 zones can have entry and exit delays set individually. The
change the delay time, follow the steps bellow:
Note: Time is measured in seconds
Note: Time is measured in seconds.
Open your Ani WiFi application.
Scroll to “ZONE SET” on your menu bar.
Choose the zone you are wanting to change.
Press the button to change the arming delay time (exit delay).
Press the button to change the alarm delay time (entry delay).
Ring Time
Open your Ani WiFi application.
Scroll to “ZONE SET” on your menu bar.
Choose the zone you are wanting to change.
Press the button the change the alarm time.
Press the button to finish.
Each of the 8 zones can have an alarm time set individually. The change
the alarm time, follow the steps bellow:
Note: Time is measured in minutes.

11
ALARM LOG
Open your Ani WiFi application.
Scroll to ALARM LOG on the menu bar.
All alarm events will be saved in the alarm log. To find the alarm log
follow the steps below:
SCHEDULED ARM/DISARM
Open your Ani WiFi application.
Press the button in the top right hand corner.
Press the button which says “Arm Timing”.
Press the button in the top right hand corner of your screen.
Select the time you would like to use.
Select which days you would like the auto arm/disarm to take
place.
For example 1 = Sunday and 7 = Saturday.
Decide if you want the automation to be for arming or disarming
the system by toggling the arm/disarm switch.
Press “Setting” in the top right corner to finish.
The system can be set to arm/disarm at set times each day. To set
what time of day you want to arm/disarm your system, follow the
steps bellow:

12
SCHEDULED OUTLET
The system can be set to automatically turn its outlets on or off at a set
time every day. To set what time of day the outlets are turned on/off
follow the steps bellow:
Open your Ani WiFi application.
Press the button in the top right hand corner.
Press the button which says “Arm Timing”
Press the button in the top right hand corner of your screen.
Select which time of day.
Select which days the outlet turns on/off.
For example, 1 = Sunday and 7 = Saturday.
Decide if the automation event will be for turning on or off the outlet.
Select which outlet number will be effected by the automation.
Press “Setting” in the top right corner to finish

Open your Ani WiFi application.
Scroll top “MONITOR” on the menu bar.
Click on whichever camera you would like to view.
To close the live feed, press the button.
If you just want to quickly view your camera in real time on the Ani WiFi
application, follow the steps below:
4
13
Open the N62 application.
Press the Register button at the bottom of the screen.
Register by either email or phone.
Login with the account you have created.
For details on how to sync camera, refer to the camera manual.
MONITOR
In order to maximize the features available with the Fortress Eyesight
camera, an auxiliary application is needed. Download the N62
application from the Play Store for Android or the App Store for IOS. Once
the application has been downloaded, follow the steps bellow:
Open your Ani WiFi application
Press the button in the top right hand corner.
Press the button which says “Monitor”.
The N62 application will open.
Select the camera that you would like to view.
Once you have downloaded the N62 application follow the following
steps to get to it from the Ani WiFi application:

To receive alarm notifications, push notifications will need to be turned
on for the Ani WiFi system. If enabled, the application will send
notifications to your phone letting you know the alarm was set off.
Open your Ani WiFi application.
Press the button in the top right hand corner.
Press the button which says “Settings”.
Press and hold the “Alarm VOL” button while sliding it side to side to
adjust volume.
PANEL SETTINGS
Alarm Notification
Alarm Volume
14

Open your Ani WiFi application.
Press the button in the top right hand corner.
Press the button which says “Settings”.
Press and hold the “Ring Times” button while sliding it side to side to
adjust the ring time.
4
15
Ring Times
Open your Ani WiFi application.
Press the button in the top right hand corner.
Press the button which says “Settings”.
Select “Alarm Audio”.
Scroll through the list to select which tone you want.
Press the button to finish.
Alarm Audio
There are different alarm tones that you can choose from for the hub
alarm. To change those tones following the steps below:
The Ring time setting adjusted how long it will take before the Ani
system picks up when hooked to a land line.

16
BEEP VOLUME
The beep volume adjusts the voice/beep volume level. To change the
volume follow the steps bellow:
Open your Ani WiFi application.
Press the button in the top right hand corner.
Press the button which says “Settings”.
Press and hold the “Beep VOL” button while sliding it side to side to
adjust the volume.
Panel Name
The devices name can be changed to make managing your Ani WiFi
devices easier to manage. To change the name follow the steps below:
Open your Ani WiFi application.
Press the button in the top right hand corner.
Press the button which says “Settings”.
Press “Device Name”
Type in the name you want.
Press confirm to finish.
16

17
Panel Password
If you would like to change the password for your device, follow the steps
below.
Open your Ani WiFi application.
Press the button in the top right hand corner.
Press the button which says “Settings”.
Select “Device Password”.
Type in the password you would like to use.
Press confirm to finish.

18
Open your Ani WiFi application.
Press the button in the top right hand corner.
Press the button which says “Settings”.
To set manually, click on the date and time, then set the time
manually.
To automatically set, press “RESET”
Panel Time
The panel time can either be manually set or automatically set. To
change the time follow the steps below:
Open your Ani WiFi application.
Press the button in the top left hand
corner of the screen.
Press desired link!
System Setting
If you need to change your account
password, change device, get help, or check
the about page, follow the steps below:
