FortrezZ MIMOlite User manual

MIMOlite, Multiple Input – Multiple Output
Wireless Interface/Bridge Module, User Manual
1080 Centre Rd. Ste C
Auburn Hills, MI 48326
www.fortrezz. om
Phone: [phone]
sales@fortrezz. om
Made in USA
050515
Introduction
The MIMOlite Module is an interfa e / bridge module, apable of onverting a wired or wireless input to a wired or wireless output. The MIMO
is a Z-WaveTM Wireless devi e ompatible with other Z-WaveTM ertified produ ts. MIMOlite omes in a plasti en losure for indoor use only.
Specifications
Power: 12-16 VDC @~ 300mA
Frequen y Range: 908.4MHz (US); 868.4MHz (EU)
Distan e Range: Max 100ft line of sight in unobstru ted environment
En losure Size (L x W x D): 3 3/8" (85mm) x 2 1/2" (64mm) x 1 1/4" (30mm)
Weight: 4 oz (100 gram)
Operating Temperature: -10⁰C (14F) to +70⁰C (158F)
Input Signal 1 (SIG1): Digital or Analog Input, 0 to 16V DC, 16 Hz Max for pulse ounting (min. 32
ms high or low time). The trigger levels and hysteresis an be set via the Configuration Command Class. The
input an be a dry onta t losure (see open/shorted hara teristi s in Te hni al Appendix).
Input Signal Impedan e Input impedan e for SIG1 is Z=66 ohm at 10KHz. This impedan e is = 66 ohm = 34 ohm + j 540uH.
Output Relay 1: SPDT, Max. Swit hing power of 120W; 10uA to 10A; High Diele tri strength oil- onta ts: 1,000 VAC;
Open onta ts: 750 VAC; Conforms to FCC Part 68 requirements; Ag + Au lad bifur ated onta ts fully sealed.
System Requirement: Any Z-WaveTM -enabled network and ontroller.
Overview
The MIMOlite module provides one analog or digital input and one relay output (isolated dry onta ts, NO-COM-NC) and an be ontrolled by Z-
WaveTM. The system in ludes a program swit h for Z-WaveTM in lusion/ex lusion and a status light (LED) for various indi ations.
Input SIG1 is an analog input, internally pulled-up to the MIMOlite supply voltage. The system allows trigger onditions to be set based on the
input voltage being inside or outside a user-defined range ( onfigured via Z-Wave). This provides great flexibility for apturing events in a wide
variety of appli ations. The trigger status of the input an be read via Z-WaveTM and/or an be automati ally sent to a onfigured node, typi ally
the Controller. In addition, a ount of the trigger events that have o urred for the input hannel is internally re orded (and stored in the ‘pulse
ount’) and is available to be requested or automati ally sent via Z-Wave. The urrent triggered/un-triggered status an also be read via Z-
Wave. The SIG1 input an be asso iated with up to two other Z-WaveTM devi es, su h that an asso iated devi e will automati ally turn on (or
off) based on the o urren e of a trigger event. Finally, the analog input hannel an be onfigured so that the analog input level (not just binary
trigger status) is periodi ally sent to up to two other asso iated nodes.
The output relay is typi ally ommanded via Z-WaveTM ommands. In addition, the user an onfigure the input SIG1 trigger ondition to be
mapped to the output relay. For example, Relay 1 an be automati ally turned on based on Input SIG1 being triggered. The relay a tivation an
be set via a jumper or via Z-WaveTM for either momentary or lat hed operation - see Installation se tion.
Warnings and Precautions
* The dry contact relays are not capable of supporting higher-than-specified loads. Exceeding the specified switching power will cause damage to
the unit and may cause damage to property and or personal injury, including loss-of-life.
* WARNING – Do not attempt to use the re ays to switch residentia or industria A ternating Current (AC) ines. The re ays are to be
used for ow-power oad contro on y. Refer to above e ectrica specifications for re ays.
* Do not store highly flammable items such as oily rags or other combustibles near your MIMOlite.
* Do not apply electrical power to the unit unless the unit is fully assembled.
* Install unit in accordance with electrical codes and regulations. In case you are unsure about any parts of these instructions consult an
electrician or Z-WaveTM home automation specialist.
* Disconnect power source before working on or servicing the unit. Failure to do so could result in personal injury.
* WARNING - The MIMO ite must not be used in ife support and / or safety app ications.

MIMOlite, Multiple Input – Multiple Output
Wireless Interface/Bridge Module, User Manual
1080 Centre Rd. Ste C
Auburn Hills, MI 48326
www.fortrezz. om
Phone: [phone]
sales@fortrezz. om
Made in USA
050515
* MIMOlite functionality is based on wireless (RF) transmissions. Any wireless transmission can be subject to RF interference or loss-of-
communication. This interference or loss-of-communication may cause the unit to not operate as intended. You, the end-user, are responsible
for ensuring that the MIMOlite functionality and installation meet your desired requirements.
* Do not mount the MIMOlite inside a metal enclosure.
* Do not place MIMOlite on or near metal objects. This decreases range and or blocks wireless transmissions.
* Information provided in this manual is for your convenience and may be superseded by updates. The specifications and this manual are subject
to change without notice. It is your responsibility to ensure that the MIMOlite functionality meets your needs and specifications.
Using the MIMO ite in a Z-WaveTM Network
IN LUSION in (adding to) a network: 1) Set up the in lusion mode at the ontroller (for detailed dire tions, please refer to your ontroller user
manual); 2) If the LED has a periodi single blink, the unit will be automati ally in luded. Otherwise, the button has been previously pressed
and automati in lusion mode is no longer a tive. In this ase, briefly press the button on e and the ontroller will indi ate that the unit has
been in luded in the network. Also, the Status LED will blink when the in lusion ompletes. Inclusion and exclusion are always done at normal
transmit power mode.
EX LUSION from (removing from) a network: 1) Set up the ex lusion mode at the ontroller (for detailed dire tions, please refer to your
ontroller user manual); 2) Press the MIMOlite button and the ontroller will indi ate the unit has been removed from the network. The Status
LED will blink when the ex lusion ompletes.
ASSO IATIONS: On e in a network, your ontroller an be used to asso iate the MIMOlite with other devi es in the Z-WaveTM network, su h as
a light or remote audible alarm. Refer to your controller’s documentation on how to associate the MIMOlite with another device in your
network. The MIMOlite input supports five asso iation groups with a maximum of two asso iated devi es in ea h group.
Group 1: When the input is triggered/untriggered, a ommand is sent to turn on/off the devi e(s) asso iated with the input.
Group 2: The MIMOlite will periodi ally send a report indi ating the input’s analog voltage level.
Group 3: If a power dropout o urs, the MIMOlite will send a notifi ation (depending on available residual power)
Group 4: When the input is triggered or untriggered, a Binary Sensor report is sent to this group’s asso iated devi e(s).
Group 5: Pulse meter ounts will be sent to this group’s asso iated devi e(s).
STATUS INDI ATIONS: The MIMOlite provides a status light to indi ate various situations. As shown in the table below, the light blinks a
variable number of times, fast or slow, periodi ally or only on e.
Fast Blinks Slow Blinks Periodic? Description
1 Yes Network-Wide In lusion Mode (NWI mode is automati ally entered at
power-up when MIMOlite is not ‘in-network’)
2 No MIMOlite ‘in-network’ indi ation (after in lusion / power up)
4 Yes MIMOlite is not ‘in-network’ (after button is pressed during NWI mode or if
in lusion fails or after ex lusion)
1 Yes Power input has dropped out (voltage has dropped to below approx. 10.5V)
Input Ana og-to-Digita Characteristics
The input signal voltage onversion to Multilevel Sensor value (ADC reading or ount) is non-linear. A typi al onversion urve (Voltage to ADC
reading) is shown in the Te hni al Appendix on the FortrezZ website. These are the values returned via the Multilevel Sensor report in response
to a Multilevel Sensor Get request (or if asso iation Group 2 is set up). The onversion is a 12-bit onversion whi h allows values from 0 to 4095.
Input Configuration
The voltage onversion des ribed above also applies to the triggering onfiguration. Refer to the Te hni al Appendix for details on hanging the
triggering onfiguration. The default trigger onfiguration for the analog input, SIG1, is a threshold around 1V. That is, the input will trigger
when the level goes above approximately 1V and will untrigger when the level goes below approximately 1V. If the input is left open, the input
will remain triggered be ause of the internal pull-up resistor. The trigger ranges for SIG1 are very flexible and an be hanged to meet many
appli ation requirements. Refer to the Te hni al Appendix for details.

MIMOlite, Multiple Input – Multiple Output
Wireless Interface/Bridge Module, User Manual
1080 Centre Rd. Ste C
Auburn Hills, MI 48326
www.fortrezz. om
Phone: [phone]
sales@fortrezz. om
Made in USA
050515
Output Configuration
The MIMOlite an be onfigured to automati ally turn the relay on when the input is triggered or a Z-Wave ommand an also turn the relay on.
The Configuration Command Class, Parameter 3, is used to set the input-to-relay mapping (See Te hni al Appendix). When input-to-relay
mapping is enabled, Z-WaveTM ommands to set the relay are overridden. The default for the relay is no input-to-relay mapping. Momentary vs
Lat hed relay operation is sele ted by jumper P5 on the ir uit board. The Momentary / Latched jumper is read only at power on when the
MIMOlite is not in a ZWave network. When the jumper is off, momentary (default 500ms) operation is sele ted. If desired, on e in-network, a
Zwave onfiguration ommand (Parameter 11) an be used to override the jumper setting. The momentary onfiguration an be set from
100ms to 25.5ms (approximate) in in rements of 100ms via the ZWave ommand (refer to the Te hni al Appendix).
Power Dropout
A periodi Power Dropout indi ation (see above table) is shown if the supplied power drops below approx. 10.5 Volts. Also, the MIMOlite
implements the Alarm Command Class, whi h provides an alarm report (Alarm Type = 0x08, Alarm Level = 0xFF) when the supplied power drops.
The MIMOlite sends the alarm report to the node(s) in Asso iation Group 3. After a power dropout alarm event, the MIMOlite sends an alarm
report (Alarm Type = 0x08, Alarm Level = 0x00) when the supplied power rises above approx. 11 Volts.
Insta ation
Depending
on your intended application
,
place
jumper on P5 (2 pin connector beside P3): for
Latched relay function, leave jumper ON; for
Momentary relay function, remove jumper.
Apply DC
p
ower to P0.
Do not exceed 24VDC.
Program MIMOlite into your Z-Wave
controller with the button located next to P0.
Conn
ect monitored signal to SIG1
(P1, labeled
–
and +) and relay contacts NO NC COM on P4.
Follow polarity and do not exceed max input
voltage of 24V DC (or 16Hz, if counting triggers).
Troub eshooting
The MIMOlite has been tested with ontrollers from various vendors. However, it is not possible to test with every ontroller on the market.
For spe ifi troubleshooting pro edures, please refer to your ontroller instru tion manual and/or onta t your ontroller manufa turer. Also,
he k the FortrezZ, LLC website www.fortrezz.com for helpful FAQs, a Te hni al Appendix with more details, and updates to this User Manual.
Regu atory Information
FCC Compliance Statement Statements
This devi e omplies with Part 15 of the FCC Rules. Operation is subje t to the following two onditions:
1. This devi e may not ause harmful interferen e, and
2. This devi e must a ept any interferen e re eived, in luding interferen e that may ause undesired operation. ontains
Transmitter Module F ID: X T-Z3US
F Warning (Part 15.21). Changes or modifi ations not expressly approved by the party responsible for omplian e ould void he user’s
authority to operate the equipment.
F Interference Statement (Part 15.105 (b)). This equipment has been tested and found to omply with the limits for a Class B digital devi e,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable prote tion against harmful interferen e in a residential
installation. This equipment generates uses and an radiate radio frequen y energy and, if not installed and used in a ordan e with the
instru tions, may ause harmful interferen e to radio ommuni ations. However, there is no guarantee that interferen e will not o ur in a
parti ular installation. If this equipment does ause harmful interferen e to radio or television re eption, whi h an be determined by turning
the equipment off and on, the user is en ouraged to try to orre t the interferen e by one of the following measures:
- Reorient or relo ate the re eiving antenna.

MIMOlite, Multiple Input – Multiple Output
Wireless Interface/Bridge Module, User Manual
1080 Centre Rd. Ste C
Auburn Hills, MI 48326
www.fortrezz. om
Phone: [phone]
sales@fortrezz. om
Made in USA
050515
- In rease the separation between the equipment and re eiver.
- Conne t the equipment into an outlet on a ir uit different from that to whi h the re eiver is onne ted.
- Consult the dealer or an experien ed radio/TV te hni ian for help.
Industry Canada Statement per Section 4.0 of RSP-100
The term "I :" before the ertifi ation/registration number only signifies that the Industry Canada te hni al spe ifi ations were met.
Section 7.1.5 of RSS-GEN. Operation is subje t to the following two onditions: 1) This devi e may not ause harmful interferen e, and 2) This
devi e must a ept any interferen e re eived, in luding interferen e that may ause undesired operation.
From se tion 5.2, RSS-Gen, Issue 2, June 2007 Equipment Labels: ontains I : 8156A-Z3X
From se tion 7.1.1 RSS-Gen, Issue 2, June 2007
a) The host devi e, as a stand-alone unit without any separately ertified modules, omplies with all appli able Radio Standards Spe ifi ations.
b) The host devi e and all the separately ertified modules it ontains jointly meet the RF exposure omplian e requirements of RSS-102AA, if
appli able.
) The host devi e omplies with the ertifi ation labeling requirements of ea h of the modules it ontains.
Europe
The MIMOlite module has been ertified for use in European ountries.
Test standard: ETSI EN 300 328 V1.7.1 (2006-10)
The Waste Ele tri al and Ele troni Equipment (WEEE) dire tive (2002AA/96/EC) was approved by the European Parliament and the
Coun il of the European Union in 2003. This symbol indi ates that this produ t ontains ele tri al and ele troni equipment that
may in lude batteries, printed ir uit boards, liquid rystal displays or other omponents that may be subje t to lo al disposal
regulations at your lo ation. Please understand these regulations and dispose of this produ t in a responsible manner.
Limited Warranty
THE PRODU T IS PROVIDED WITH ONE YEAR LIMITED MANUFA TURER WARRANTY. FORTREZZ, LL warrants its products to
be free from defects in material and workmanship under normal use for one year, and is not responsible for consequential
damages or installation costs of any nature. FORTREZZ, LL . expressly disclaims all implied warranties, including but not limited
to the implied warranties of merchantability and fitness for a particular purpose. FORTREZZ, LL . does not warrant, guarantee,
or make any representations regarding the use or the results of the use of the products or any accompanying materials in
terms of their correctness, accuracy, reliability or otherwise. In no event shall FORTREZZ, LL . be liable to Purchaser hereunder
or in respect of any products ordered or delivered to Purchaser, whether in contract, tort including negligence or otherwise for
a loss of profits or loss of use or for any incidental, consequential, special or indirect damages howsoever caused whether or
not FORTREZZ, LL . has been advised of the possibility of such loss or damage. FORTREZZ, LL 's maximum liability to Purchaser
under these conditions shall in no event exceed the amount paid by Purchaser for the products that are the subject of the
claim and in respect of all claims for products ordered from FORTREZZ, LL . to which these conditions apply to the amount paid
by Purchaser for the products which are the subject of the claims. If you are not comfortable with your limited warranty, or not
completely satisfied with the MIMOlite, or the MIMOlite does not perform as expected we encourage you to return the
MIMOlite to your DISTRIBUTOR for an exchange or for a full refund within 30 days of purchase. Or, you can return the
MIMOlite to FORTREZZ with an RGA number.
All produ ts to be returned to FORTREZZ, LLC. must have a valid Returned Goods Authorization (RGA).
Send the returned unit to: FortrezZ, LL Warranty Replacement, 1080 entre Rd. Ste . Auburn Hills, MI 48326, postage prepaid with a
payment of US$ 9.95 to over the ost of return shipping, postage and handling. You must use the original pa kaging and in lude a proof of
pur hase (photo opy of re eipt) along with the RGA # and the returned produ t.
