Forza FH4818 Technical manual

USE +
INSTALLATION
MANUAL
Range Hoods
FH3011
FH3611
FH3018
FH3618
FH4818
FH3624
FH4824

2
Welcome to the Forza family!
Congratulations on your recent Forza purchase! Before you begin using your new Forza product, please take a moment
to review the Use + Installation Manual. You will find the answers to all of your questions as well as some very important safety
information. Your Forza product is ready and waiting to be used for your next gourmet creation!

3
Table of Contents
04 Dimensions and Specifications
10 Preparation for Installation
12 Installation
15 Installation Under Wall Cabinet with Cabling
16 Wall-Mounted Horizontal Vent
20 Cleaning and Maintenance
22 Technical Specifications
24 Warranty

4
Dimensions and Specifications
Model Number Voltage Frequency Power Weight
FH3011 120 V 60 Hz 233 W 35 lb / 15.90 kg
Tools Required
30"
12"
11"½
4"
24"
4"

5
Model Number Voltage Frequency Power Weight
FH3611 120 V 60 Hz 353 W 41.8 lb / 19 kg
Tools Required
36"
12"
11"½
4" 4"
24"

6
Model Number Voltage Frequency Power Weight
FH3018 120 V 60 Hz 353 W 43.6 lb / 19.80 kg
Tools Required
12"
4"
4"
24"
18"
30"

7
Model Number Voltage Frequency Power Weight
FH3618 120 V 60 Hz 353 W 52.8 lb / 24 kg
Tools Required
36"
12"
4"
4"
24"
18"

8
Model Number Voltage Frequency Power Weight
FH3624 120 V 60 Hz 706 W 68 lb / 30.95 kg
Tools Required
*(Dual blower)
36"
4" 4"
24"
24"
12"

Model Number Voltage Frequency Power Weight
FH4818 120 V 60 Hz 706 W
*(Dual blower)
12"
4" 4"
24"
18"
48"
Tools Required
9

Model Number Voltage Frequency Power Weight
FH4824 120 V 60 Hz 706 W
*(Dual blower)
12"
24"
24"
4" 4"
48"
Tools Required
10

11
Check the contents of the box before installing the product.
If any items are missing or damaged contact the manufacturer.
Remove the bag of component accessories from inside the
body of the hood.
Contents of bag according to model:
No. 2 – 3.5 x 9.5 mm
No. 4 – 4.5 x 40 mm
No. 4 – Dowel Ø8
No. 6 – 4.5 x 15 mm
No. 4 – M4 x 10 mm
FH3011 - FH3611FH3624
FH3018 - FH3618
FH4818 - FH4824

12
2. Remove the accessories.
Preparation for Installation
Remove the protective plastic film from the product before installing.
It is advisable to wear personal protective equipment during installation.
Before installing the product remove the indicated accessories from the body
of the hood, as shown in the figures. These parts must be removed even if they
are not used during installation. The screws provided are required during the
installation of the component.
1. Remove the filters.
FH3011
FH3611 FH3624
FH3018 - FH3618
FH4818 - FH4824
12

13
IMPORTANT: The minimum hood installation height requirements indicated in the cooktop / range instructions take
precedence over the requirements outlined in this manual. If missing from the cooktop manual, refer to the measures shown
in figure (1).
Figure 1

14
Installation
Horizontal Vent Option
(PRE-CUT)
FH3011
FH3011
FH3611 - FH3018 - FH3618
(Positioning of motor for horizontal vent)

15
FH3611 - FH3018 - FH3618

16
Closing

17
Installation Under Wall Cabinet with Cabling
Vent Option
(PRE-CUT)
FH3011
FH3611 - FH3018 - FH3618
25/32"
147
5" 25/32"
Ø155
6" 7/64"
FH3624 - FH4818 - FH4824
*(Only with reinforcing Wooden blocks)
151
6"15/16
127
5"
35
1"3/8
35
1"3/8
265
10"7/16
REAR
FRONT
Power Cable Channel
WALL CABINET INTERIOR
SEEN FROM ABOVE

Wall-Mounted Horizontal Vent
FH3011
FH3624 - FH4818 - FH4824
16
No. 4 SCREWS M4x10mm.
18

19
FH3011
Wall Installation Measurements
Installation Measurements
Reinforcement for Bottom of Wall Cabinet (not included)
501,5
19"3/4"
404
15"29/32"
760
29"59/64"
A
B
404
15"29/32"
C
L
FH3011 - FH3611- FH3018 - FH3618
FH3624 - FH4818- FH4824
FH3624 - FH4818- FH4824
FH3011 - FH3611- FH3018 - FH3618
Model Number
A
- Dimension Value
B
- Dimension Value
FH3011 51mm. 2" 176mm. 6"59/64"
FH3611 51mm. 2" 176mm. 6"59/64"
FH3018 51mm. 2" 357mm. 14"1/16"
FH3618 51mm. 2" 357mm. 14"1/16"
FH4818 81mm. 3"3/16" 327mm. 12"7/8"
FH3624 81mm. 3"3/16" 420mm. 18"7/64"
FH4824 81mm. 3"3/16" 420mm. 18"7/64"
- FH4818 -FH4824
- FH4818 - FH4824

20
Installation Under Wall Cabinet
- FH4818 - FH4824
Wooden
Blocks
