FOS Technologies Designer 2048 User manual

Designer 2048
Lighting Controller
User Manual
FOS Technologies LTD.
https://www.fos-lighting.eu

1. Introduction ......................................................................................................................................... 1
1.1. The Front Panel .............................................................................................................................. 1
1.2. The Rear Panel ............................................................................................................................... 4
2. Initialization and Backup...................................................................................................................... 5
2.1. Clear All Data ................................................................................................................................. 5
2.2. Backup and Load Show................................................................................................................... 5
3. Patching ............................................................................................................................................... 6
3.1. Patching Fixtures ........................................................................................................................... 6
3.2. Patch Selected Type ....................................................................................................................... 8
3.3. Unpatch.......................................................................................................................................... 8
3.4. Repatch .......................................................................................................................................... 8
3.5. Setup RDM Devices......................................................................................................................... 9
3.6. Fixture Parameter .........................................................................................................................10
4. Controlling Fixtures and Dimmers .......................................................................................................11
4.1. Setup Fixture Layout .....................................................................................................................11
4.2. Select Fixtures ..............................................................................................................................12
4.3. Manual Control Fixtures ................................................................................................................13
4.4. Groups...........................................................................................................................................16
5. Presets ................................................................................................................................................18
5.1. Edit Preset.....................................................................................................................................18
5.2. Preset Management.......................................................................................................................18
5.3. Using Presets ................................................................................................................................19
6. Shape Effects.......................................................................................................................................20
6.1. How Effect Generator Works .........................................................................................................20
6.2. Using Effect ...................................................................................................................................20
6.3. Effect Parameters..........................................................................................................................20
6.4. User Effect.....................................................................................................................................22
7. Playback ..............................................................................................................................................24
7.1. Playback Modes.............................................................................................................................24
7.2. Playback Edit Menu .......................................................................................................................24
7.3. Cue................................................................................................................................................24
7.4. Cue-lists ........................................................................................................................................24
7.5. Run Playback.................................................................................................................................27
7.6. Time for Playback..........................................................................................................................28
7.7. Playback Parameters and Advanced Settings ................................................................................29
7.8. Reload a Cue .................................................................................................................................31
8. Advanced Functions.............................................................................................................................32
8.1. Copy Function ...............................................................................................................................32
8.2. Delete Function .............................................................................................................................32
8.3. Move Function ...............................................................................................................................32
8.4. Lock the Controller........................................................................................................................32
8.5. Legend Manage .............................................................................................................................32
9. Macro Show .........................................................................................................................................34
9.1. The Built-in Music Player...............................................................................................................34
9.2. Record a Macro Show ....................................................................................................................34
10. Controller Setup Management ...........................................................................................................37
10.1. Controller Options .......................................................................................................................37
10.2. System Manage ...........................................................................................................................39
10.3. DMX/Network Setting .................................................................................................................41
11. Technological Specification ...............................................................................................................42

PRODUCT SAFETY INFORMATION
ENVIRONMENTAL MAXIMUMS
Do not operate the consoles if the humidity and ambient temperature cause condensation on the product;
allow the product to dry first before connecting to the mains.
DO not operate at ambient temperatures higher than 104°F (40°C).
ELECTRICAL SAFETY
The controller must be connected to protective earth (PE) when energized.
Do not use the product if the mains inlet is damaged.
Do not expose the product to rain or moisture.
ALWAYS disconnect from the power before servicing or replacing the fuse. Replace it with the same fuse size
and type.
Do not use the product if the mains system is not in accordance with the below information.
Do not open the product while connected to mains unless qualified to do so.
POWER CONSUMPTION
Power Consumption: 85W
Currents Input: 100-240VAC, 2.5A
Frequency: 50-60Hz
Button Cell BATTERY
The product motherboard contains a Lithium-Ion button cell (CR2032) for time data retention.
This battery is used to maintain time data when the product is not powered, this battery will need to be replaced at least
every five years. If the product is mostly off for long periods or in cold environments, then it may need an earlier
replacement.
Recycle the CMOS battery in accordance with local law.
Please be aware that Lithium-Ion button cells are a particular danger to small children.
TOUCH SENSOR GLASS SAFETY
Do not operate the console if the touch sensor is broken as glass particles may be released by the sensor.
Caution!
There are no user-serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the
unlikely event your unit may require service, please contact your local dealer.
Suggestion for Power Supply
We strongly suggest you connect with the UPS power supply to avoid any power cut accident during programming.
Please read these instructions carefully. They include
important information about the installation, usage and
maintenance of this product.

1
1. Introduction
Welcome to FOS Designer 2048 lighting controller users manual.
The manual is a guide to all the functions of the controller. Attention points will be highlighted by shading. The words
with a square represent a physical key, such as the Enter button. While words with square brackets represent the
virtual soft keys found on the LCD touch screen, such as [Playback Parameters]. Menu name or option name will
be marked with quotation marks, such as ‘LIVE SHOW’.
1.1. The Front Panel
1.1.1. Control Panel
There are 3 colors for the key backlighting (red, green, and yellow). You can change the combination of color
brightness as needed. Press the Shift and Thru keys to change the color, and then use the Shift key along with +
or –to adjust the backlight brightness. Of course, you can set it under the [Key Backlight]function in the ‘Setup
menu’.
1.1.1.1. Quick Record Key
You can quickly save backup copies of your show with a single press of the Store button.
1.1.1.2. Control Wheels
The 3 wheels on left, A, B, and C are used for setting fixture attributes, or effect parameters.
The one on right, Wheel D is used for scrolling the page on selected option windows and setting Cue-lists velocity.
The key in Wheel D can be used as an Enter button or a save key when pressed down while setting options.
Touch Screen
Working lamp &
Intensity control
Power
Store
Attribute
Shortcut &
Function keys
Setup
& Edit
Numeric keys
Function keys
Playback Section
USB Port
Headphone
interface
Volume
Control
Control Wheels
Grand Master
Fader
Display Switch
A
B
C
D

2
1.1.1.3. Attribute Keys
There are 9 attribute keys and 1 Locate key in this area. Each attribute key allows displaying 3 channels at most on
each page. The selected attribute key shows with high light color. Press the selected attribute key again can turn to
the next page, displaying more channels. You can control fixtures by using the different attribute keys with the
corresponding wheels A, B, and C.
1.1.1.4. Shortcut & Function Keys
The keys F1 to F5 are the shortcut keys for the soft keys on the lower right at the
touch screen.
Function buttons are distributed in multiple areas, providing soft-keyboard, copy, move,
delete, fixtures odd/even selection, fixtures finding.
Note: The functions of Pause, Go+ and Go-are not available in the edition yet.
1.1.1.5. Setup & Programming Keys
The keys are used for setting up the controller and editing playbacks.
1.1.1.6. Numeric Keypad Keys
You can use the numeric keypad to input numerical commands to change the
running state of the playback. Their functions will be introduced in a later chap t e r.
1.1.1.7. Playback Section
The fader backlight in the playback section can be set in the ‘Setup’ menu.
According to the 3 different states of the playback, you can set the backlight to display in different colors. The 3
playback fader states are: no saved playback, saved playback but no running, and the playback is running.
The playback section is composed of master faders, page keys, fader-playbacks with their faders and function keys,
key-playback keys.
There are 80 playback pages; each page has 15 faders and 15 keys for saving playbacks. You can turn pages by using
the ↑or ↓keys, and the indicator LED display will show the page number.
You can press the Func key under the master fader to switch the display of attribute setting and shortcut function
to the display of the key-playback name.

3
1.1.2. Touch Screen
The controller offers a 15-inch LCD capacitive touch screen for operating.
The operating options are on the right side of the touch screen. Most of the operations are worked on the touch
screen. Different working windows can be selected and displayed on the touch screen according to the needed.
There is a tool key in the upper right corner of each working window. When it is dark, it means there is no other
option. But there will be other options while it is white, then you can press the tool key for other functions.
1.1.2.1. Setting Up Working Windows
The position and size of the operation window are not fixed. You can hold the top bar of the window and then slide
your finger to change its position. You can adjust the size of the window as operations below:
Hold the bottom right corner of the window, and slide your finger after the frame turned in RED, then
release at the wanted position to confirm the size.
Hold the upper left corner of the window and slide your finger after the frame turned in RED, then release
at the wanted position to confirm the size.
Hold
Hold
Release
Release
The tool key

4
1.1.2.2. Setting Up Work Space
You can use the [Work Space] function to save different combinations for working windows, which can be switched
quickly when using.
1> Press key [Work Space] when finished setting up windows combinations on the screen;
2> Select an empty grid in the pop-up window;
3> Select the grid with highlight words ‘Press again to save’, to save the combination of workspace windows;
4> Press the saved backup to easily switch between different combinations of workspace windows.
Note: Please use the Delete key to delete the old backup first if you want to renew the backup of the workspace.
1.2. The Rear Panel
Audio Output --- one 3.5mm audio interface and one audio-optical interface allow you to connect with the audio
device.
MIDI Interface --- there are 3 MIDI interfaces, the ‘In’, ‘Out’, and ‘Thru’ for connecting with other MIDI devices.
Art-Net Interface --- offers network function to transmit maximums 2048 DMX channels under Ethernet protocol
over the Art-Net/DMX converter.
Wireless antenna --- provides WiFi signal for connecting App on mobile or tablet.
DMX Universes --- there are 4 DMX universes that sending out 512 DMX channels per output.
Power Supply --- the power supply offers quite a wide voltage range (100-240V AC, 50-60Hz). Thus, it can be used
worldwide. If you need to change the fuse, please cut off the power supply for safety operation.

5
2. Initialization and Backup
2.1. Clear All Data
We strongly recommend you clear all data on the new controller, so that you can avoid the unpredictable errors when
programming.
1> Press Backup to entry ‘BACKUP MENU’;
2> Press [New Show];
3> Press [Confirm] will clear all data and return to ‘LIVE SHOW’ automatic.
Note: All data created will be deleted (including the setup, patching, presets and programs). But the system fixtures
and user fixtures will be saved.
You can also press Delete and press [Delete All Data] twice and [Confirm] to clear all data.
2.2. Backup and Load Show
Note: Though turning off the controller by the power switch will not damage the system, any unsaved program
operations will be lost if the controller is turned off without backing up.
The backup show files can be saved into the internal RAM or external USB disk.
You can back up the Show by pressing the Store key for a quick save. The show file will be saved into the internal
RAM. By this operation, the files will be cyclic saved or covered as ‘defaultShow_0’, ‘defaultShow_1’,
‘defaultShow_2’ and ‘defaultShow_3’ by turns.
You can also define the name of backup file. If a
USB driver is inserted, press [Disk Source] can
switch the source path between [Internal Disk]
or [USB Disk].
1> Press Backup to entry ‘BACKUP
MENU’;
2> Press [Save Show];
3> Press Keyboard, input the file name and
[Enter] on soft keyboard;
4> Press [OK] to save.
When you save these backup files to the either
drive, the default file names will be renewed.
Note: We recommend that you back up frequently when programming, so that you will not lose any programs by
accident.
1
2

6
3. Patching
We have to patch fixtures to tell the controller what kinds of fixtures need to be controlled.
When patching, the controller offers a free initial DMX address automatically for each line. We can patch all fixtures
first then check over their DMX addresses before assigning on the fixtures. We may also assign the wanted DMX
addresses on fixtures first then set the right addresses when patching.
If the fixtures are RDM equipped, the controller can help the fixtures to change the setting of DMX address and
channel mode.
3.1. Patching Fixtures
To control the dimmer channels or intelligent fixtures, you should patch each of them to the unit keys in ‘Fixtures’
window. A maximum 1000 fixtures can be patched.
3.1.1. Patch Dimmers
Each unit key can control single or multiple dimmer channels.
1> Press Patch;
2> Press [Patch New Fixture];
3> Press [Patch Dimmer].
4> Press [▼]on ‘Start DMX Address’ option can find out other DMX lines (from 1 to 4). The number behind
shows the initial free address can be patched; you can entry a new number by numeric keypad or use the Wheel
D to change;
5> The option ‘Unit start number’ shows the initial unit ID to be patched;
6> We can enter a value on the column of ‘Quantity’ to set the patching quantity. Enter 1 means to patch a
single dimmer channel on a unit ID; while value more than 1 means to patch a sequence of dimmer channels on
a sequence unit ID. The range of dimmers will be patched to sequential DMX addresses;
7> Press [Confirm] to patch, the list of ‘Patch selected fixture’ will be updated;
8> You can also patch multiple dimmer channels on a same unit ID. For example, after we patched one dimmer
channel on a unit ID, the field of ‘Unit start number’ will display in Green. The DMX address will increase one
after patched. If we press [Confirm] again, the new DMX address will be patched onto the same unit ID. Those
dimmer channels had been patched on the same unit will be controlled together;
3.1.2. Patch Intelligent Fixtures
There is a slight difference between patching intelligent fixtures and dimmer channels. This is because intelligent
fixtures may have more attributes to control such as pan, tilt, color, or gobos; while dimmer channels only have one
attribute, which is intensity. To control intelligent fixtures, you need to select its fixture profile from your fixture
library.

7
The console offers two types of fixture libraries to choose from,
System fixture: the controller has its own fixtures in system library;
User fixture: if you cannot find out your fixture in system library, the controller offers you multi-way to
create or edit your fixture. (We will introduce you how to create or edit the user fixture on other chapter)
1> Press Patch;
2> Press [Patch New Fixture];
3> Press [Used Library = System] can switch to [Used Library = User];
When patching system fixture you can use the Wheel D or scroll bar to search the manufacture; or you can
recall the soft-keyboard by Keyboard and input the first letter of manufacturer name to search. Select the
manufacturer and [Confirm] to enter; you can select the fixture from the list.
You can select the fixture directly on touch screen if patch from user library list.
Note: The channels details will be listed on the right bar after a fixture is selected.
4> Select the fixture about to be patched and select [Confirm] to call out the patching menu;
5> Press [▼]on ‘Start DMX Address’ for other DMX lines (from 1 to 4). And enter the number by numeric
keypad or use Wheel D to set the start address;
6> Set the unit ID on ‘Unit start number’;
7> Enter the quantity number would like to patch on the column of ‘Quantity’;
8> Press [Confirm] to patch, the list of ‘Patch selected fixture’ will be updated;
If the field is shown in RED when you set the ‘Start DMX address’ or ‘Unit start number’
during patching, it means the number of the DMX address or unit ID has been used. It will not
allow you to continue patching on.
If the option ‘Load Preset’ is selected, the controller will help to load in the presets which had
written in the fixture profile automatically.
If the option ‘Auto Group’ is selected, the controller will help to group up all same model
fixtures.

8
3.2. Patch Selected Type
The function allows you to patch more same type fixtures you have selected without search from the fixtures pool
again.
3.3. Unpatch
You can select and delete one or more consecutive patched fixtures by pressing option [Unpatch].
3.4. Repatch
The function allows you to change the address and/or the line of the patched fixtures.
1> Select the fixture need to be changed;
2> Press [Repatch];
3> Select the DMX line and start address on the menu by touch. Or you may change them by typing the line
and address number on the top bar;
4> Press [Confirm] to change the address and/or DMX line.
Note: Unit ID will not be changed after re-patched.
Typing in numbers
to change the line
and address
1
2
1
2

9
The selected addresses will show in pink if they had been used. If you continue to press [Confirm] in this case or
input the used number of DMX line and address, the address of the selected fixture can be changed successfully but
the fixtures that previously used/included those addresses will be suspended. You have to patch them again.
3.5. Setup RDM Devices
The function allows the controller to interrogate the practical fixtures. Then it can patch itself to match the existing
DMX addresses. You can also remotely change the modes and other settings on the practical fixtures.
Note: Fixtures must be equipped with RDM for the function to work.
If you have connected with DMX buffers or splitters, they must be RDM enabled. Otherwise they will block the
information being sent back to the controller.
Press [RDM Discover] to start searching. All RDM supported fixtures will be listed here. Select the fixture and press
[RDM Info] to look over its details.
3.5.1. Remotely Setup Devices
We can also remotely change the address on the practical fixture.
1> Select the fixture on the list;
2> Press [DMX Start Address];
3> Enter the number of the DMX address to be changed, then press [Enter];
1
3
2
4

10
3.5.2. Match RDM Devices
1> Select the fixture on the list;
2> Press [Matched to];
3> Select the patched fixture from the list of ‘RDM Match Fixture’, then press [Match];
Press [Unmatch] if you do not want to match it to the patched fixture any more.
3.6. Fixture Parameter
You are allowed to swap or invert Pan and Tilt of the fixtures on the controller. So that you can control the moving
lights to run as mirror movement more conveniently. Dimmer channels can be inverted as well.
Press [Fixture Parameter] on ‘PATCH SETUP’ menu;
[Swap PAN/TILT] -------- to swap the controlling of Pan and Tilt channels;
[Invert TILT] -------- to invert the controlling of Tilt channel;
[Invert PAN] -------- to invert the controlling of Pan channel;
[Invert Dimmer] -------- to invert the controlling of Dimmer channel;
Note: All the same model of fixtures will be inverted if select [Invert Dimmer].
[Offset] -------- to offset the locate value of Pan and/or Tilt for the practical fixtures which without
perfectly placed. Offset values shown in percentage which are set by control wheels. We can cancel the offset
setting by [Reset Tilt Offset] or [Reset Pan Offset].
Set values by
control wheels
1
3
2
4
1
2
3

11
4. Controlling Fixtures and Dimmers
We will find the patched fixtures in the ‘Fixtures’ window. If the
‘Load Preset’ and ‘Auto Group’ options are selected during
patching, the corresponding option windows will be attached
with the data.
The patched fixtures show in dark blue, while selected ones are
shown in pale blue, and those fixtures that have been selected
are shown in gray.
Attributes of the fixtures are set by the control wheels and the
channel names are shown on the bottom of the screen.
If a fixture has multiple cells of control and its personality supports it, you can
select and control the fixture either as a whole or as independent cells. This is
particularly useful when using Shapes.
The patched sub fixtures occupy multiple consecutive fixture grids on the
‘Fixtures’ window. It will be shown as a master unit ID and its series cell IDs.
4.1. Setup Fixture Layout
All patched fixtures will be listed in the ‘Fixtures’ window, but we can also find them from the ‘Fixture Layout’
window.
The ‘Fixture Layout’ window offers 7 display areas, the area ‘All Fixtures’and the areas 1 to 6. Areas 1 to 6 do not
display any fixtures by default.
Select [All Fixtures] and set it to another area (Any of area 1 to 6);
Select [Edit] and select the fixtures to be displayed on the area;
Press [Add Selected] to display the selected fixtures, or [Remove Selected] to remove the selected
fixtures; Press the small frame on left top corner can help to select/unselect all fixtures.
The fixtures in the ‘Fixture Layout’ window will be initially listed in lines, each of which with 32 units. You can edit
a 2D position layout which to display the fixtures approximately as their actual physical location.
1
2
3

12
Press the soft-key [Move], you can reposition the
fixtures to anywhere in ‘Fixture Layout’ by selecting
and dragging them. You can select the fixture by
touching the unit one by one, or slide the finger to draw
a selection box to select a range of them. The frames of
selected fixtures will show in blue.
You can use the scroll bar on the bottom and on the
right to change the display center. Pressing [Reset] can
reset the fixture of unit ID 1 to the center. You can also
change the display position by using [Drag] and
dragging the window. The function key in the upper right corner of the window can help to re-center and
maximize display all fixtures.
Note: When using the [Drag] function, the fixtures are not allowed to be selected.
You can use the scroll bar on the left or the Wheel D
to zoom in or out the display window.
Pressing the tool key, you can set the display to show the
running states of the dimming or RGB channels.
4.2. Select Fixtures
There are several ways to select the fixtures:
Touch Screen
1> ‘Fixtures’ window --- you can select the fixtures one by
one by pressing the unit ID, the fixture order depends on the
sequence in which you select. Besides, you may slide the finger
across the unit keys to draw a selection box to select a range of
fixtures. The fixture order starts from the smaller unit ID number.
Note: The fixture order selected by drawing the selection box from 1
to 2 is the same as drawing from 2 to 1.
2> ‘Fixture Layout’ window --- you can select the fixtures in the ‘Fixture Layout’ window directly too.
There are 8 different ways for selecting fixtures by drawing the selection box. For example:
If a group of fixtures is selected by drawing a selection box from 1to 2to 4, the fixture order is from left
to right, and then top to bottom.
If the selection box is drawn from 1to 3to 4, the fixture order is from top to bottom, and then left to right.
If the selection box is drawn from 4to 3to 1, the fixture order is from right to left, and then bottom to top.
1
Slide the scroll bar
for more fixtures
1
2
2
3
4

13
Numeric keypad
In ‘LIVE SHOW’, typing in the command by numeric keys to select fixtures.
If you want to select a fixture, type in the unit number and press Enter.
If you want to select more than one fixture, use ‘+’ between each number. For example, press keys 1，
+，3，+，5，+，7in sequence and press ENTER will select fixtures 1, 3, 5, and 7.
If you want to select a range of fixtures, use the key THRU. For example, press keys 1，THRU，9and press
ENTER will select fixtures from 1 to 9.
We can use the ‘–’ to not select any from a range of fixtures. For example, press keys 1，THRU，5，-，
3in sequence and press ENTER will select fixtures 1,2,4, and 5.
Note: For the sub fixtures, the command selection can only help to select the master unit IDs.
The function key Even/Odd --- after selected a group of fixtures that can be non-sequential, press the key
Even/Odd can help you easier to select the even or odd units under the group.
4.3. Manual Control Fixtures
4.3.1. Light Up the Fixtures
You can double-tap the key Locate or press F1 / [Full] to light up the selected fixtures in open white and move
them to a central position, you can also press the key Locate and select [Locate Fixture] to light up the fixtures.
All attributes will be set to default.
If you want to locate the fixtures without re-center the position, press the key Locate and select [Locate Fixture
No PAN/TILT] to light up the fixtures. All attributes except Pan and Tilt will be set to default.
If you do not want to default other attributes, you can hold down the key Locate and press attribute key. The
channel attributes on that key will be set to default, but attributes on other keys will keep their latest values. For
example: hold down the key Locate, and press Tilt/Pan. Pan and Tilt of the selecting fixtures will be set to the
central position, but other channels will keep in their own value.
The operation of double-tap the key AT can set dimmer channel into value 255. Double-tap the key · can set
dimmer into 0. Besides, double-tap the key +or –can increase or reduce the brightness by 10%.
4.3.2. Change Attributes of Fixtures
Select the fixtures and attribute key, then change the values by using the control wheels.
Select the attribute key, and then you can enter the value by numeric keys and tap on the channel name on the touch
screen. So that it can be set to the value directly.
For the sub fixture (for example the LED fixture with multiple RGB channels), select the master unit ID that can
control the whole fixture, all cell channels will be controlled together. However, the master channels are not allowed
to be set under the cell ID, you can only control its cell channels individually.

14
4.3.3. Special Control of Attributes
You can call out the ‘Color Picker’ window from the ‘Select Area’box. Fixtures with RGB/CMY channels can be
easily mixing by the color picker. There are 3 color mixing modes for selection.
The controller can read the channels range preset from the
personality.
For example, select the fixtures and attribute key Color, press
the attribute name ‘Color’ on the touch screen can call out a
list for channel range. You can select the range options on the
list directly. You can also enter the value by numeric keys.
4.3.4. Find Fixture Function
After locating a group of selected fixtures, you can use the key ←or →to lamp one of the selected fixtures one by
one and change its attributes. It can help to find out where the fixture is.
You can also change the function as select the fixtures one by one but keep the brightness by setting the option [F4]
to [Hold L. On], or setting [Keep the brightness] in the setup menu. It is useful if we want to set all fixtures to
the same position.
You can press the Find key to re-select all fixtures in the group after finished setting.
4.3.5. Macro Function of Fixtures
Macro is a sequence of fixtures program, which run with time parameter. Some of the fixtures can run special
operations, such as Reset, Lamp on or off. After patched, the macro function from the fixture library will be loaded.
If you want to check whether the fixtures have a macro or to run the macro, please do as follow;
1> Select the fixtures;
2> Press Locate;
3> Press [Macro function]. All macro functions created in the library are displayed on the right menu bar;
4> Select the macro name to run. The soft-key shows in pale blue when the macro is running.
4.3.6. Fan Mode
The fan mode is widely used on Pan or Tilt attributes, but it can also be applied to other attributes, such as color-mix.
If the fixtures with tricolor channels, you can also mix a rainbow by fan mode.
We kindly suggest you not to use less than 4 fixtures in order to get a better effect.
4.3.6.1. Fan Align
1> Select the fixtures and locate them;
2> Select the attribute key, for example the Tilt/Pan;
3> Press the [Align Off];
4> Select one of the align modes;
Tap on the
attribute

15
There are several modes for fixtures align:
[<] ----- Fixtures align based on the rightmost
fixtures.
[>] ----- Fixtures align based on the leftmost fixtures;
[><] ----- Fixtures align based on the middle fixtures. The value increases changing from the middle to
both sides. The fixtures on both sides change in opposite directions;
[<|>] ----- Fixtures align based on the middle fixtures. The value increases changing from the middle to
both sides. The fixtures on both sides change in the same direction;
[<||>] ----- Fixtures align based on the middle fixtures. The value increases changing from both sides to
the middle. The fixtures on both sides change in the same way;
[Wings] ----- It divides the fixtures into two groups from the
middle. When it works with other align setting, two groups of fixtures
run exactly the same.
5> Set the Fan effect by the Wheel A, B or C.
4.3.6.2. Fan Align by Curves
1> Select fixtures and locate;
2> Press [Align Off];
3> Press [↑]to call out fan curve menu;
4> Press attribute key can switch to other attribute. Press the attribute name on the curve menu can switch
into other attributes in current attribute key;
5> Press [2 Points] can switch to [3 Points] mode; [Mirror] function can only be used on 2 Point mode.
6> Slide the cursors to set fan align.
Note: You can re-center the value of current attribute by pressing [Reset].
4.3.7. Clear Options
After finished editing, pressing the key Clear can deselect all fixtures.
However, you can hold it down to find more other clear options;
[Clear All Fixtures] ----- clear all fixtures from the programmer; press the option can switch to [Clear
Selected Fixtures] ----- only currently selected fixtures will be cleared.
[Clear All Presets] ----- clear all using presets from the programmer.
[Clear All Effects] ----- clear all running user effects from the programmer.
[Clear Mode = Normal] ----- clear fixtures and all channels except intensity will keep the last values;
press the option can switch to [Clear Mode = Default] ----- clear fixtures and all channels except intensity will
resume to default values.
e.g. Tilt changes by
[<|>] and [Wings]
Switch
attribute
Slide the
cursor for
the effect
Mirror
Mode
Set
points
Mode

16
4.4. Groups
One or more fixtures can be grouped for easier selection. The grid of group soft-key will turn brown after saved. The
group name and ID number will be displayed on the grid in the ‘Groups’ window.
4.4.1. Create a Group
1> Open the ‘Groups’ window if it is not visible on ‘LIVE SHOW’;
2> Press [Group];
3> Press [Save Group];
4> Select the fixtures for the group. they can be the same type or different type of fixtures;
5> Select a grid in the ‘Groups’ window. If there was a group in the grid, it will remind whether you want to
overwrite or not;
6> If you want to create more groups, you can repeat the steps from 3to 5;
7> Press [Return] or Exit to quit.
4.4.2. Group Management
1> Press [Group] to entry ‘Group Program’;
2> Press [Group Manage];
3> Select the group name can find all the fixtures included;
4> You will find details of included fixtures of the current group, such as the fixture unit ID, fixture name,
picture legend, and the sequence number.
4.4.2.1. Setting Fixture Order in Group
Fixtures in a group are stored with a selection order. Each fixture has its sequence ID. Different fixtures can have the
same or different sequence IDs.
The order is important when applying fans, shape effects, and overlap functions which will be distributed along with
the sequence.
You can change the fixture order in the group so that the fixtures will run in the sequence every time using this group.
1> Select [Fixture Order], the fixtures will be listed as the layout in ‘Fixture Order Setup’ window.
Note: Only the group of fixtures can be set, other fixtures will be displayed as the empty frames with the unit ID.
The big RED number means the fixture order, while the WHITE number shows the fixture unit ID.
