Foster EP700M User manual

Service Manual
EP700H, EP700M, EP700L, EP700G, EP700F, EP700SH,
EP700SL, EP700P, EP1440H, EP1440M, EP1440L, EP1440G,
EP700HH, EP700HL, EP700LL, EP700H2, EP700L2, EP700LW,
EP700L2MD, EP820HU, EP820MW, EP1440LG, EP1440HSTB.
Cabinets

2www.fosterrefrigerator.com
Three Steps
Operating Instructions
to maintain and service your appliance
Service Function
- Parameters
- Alarm Indicators
- Probe Data
- Relay Test
- Factory Reset
- Wiring Diagrams
Maintenance
Welcome to your interactive
Foster service manual.
Here’s how it works:
To return to the contents
at any point, click on the Foster
logo at the bottom of every page.

3G3 Cabinets - Service Manual
General Information
All installations must conform to local and municipal regulations and directives. In the case of doubt contact a Foster authorised
dealer or the Foster Technical Department. The information contained in this manual is current at the time of publication and is
subject to change without notice.
General Safety
- Do not store explosive substances such as aerosol cans with a ammable propellant in this
appliance.
- Keep all ventilation openings in the appliance or in the structure of a built in unit clear of any
obstructions.
- Do not use electrical appliances inside the storage compartment.
- Do not use steam cleaners, pressure washers or other jets/sprays of water on or around the
appliance.
- The appliance is air tight when the door is closed therefore under no circumstances should
any living body be stored or‘locked in’ the appliance.
- This appliance is heavy. When moving the appliance care should be taken and correct safe
practices followed. The appliance should not be moved over uneven surfaces.
- The emitted sound level of this appliance is not greater than 70dB(A).
- To ensure stability the appliance should be located on a at, level surface, correctly loaded.
- Do not use mechanical devices to accelerate the defrost process.
- Care should be taken not to damage the refrigeration circuit and/or system.
- If the supply cord is damaged, it must be replaced by the manufacturer, it’s service agent or
similarly qualied persons in order to avoid hazards.
- Care should be taken to avoid prolonged contact with cold surfaces with unprotected body
parts, correct PPE to be used at all time.
Climate Class
Climate class indicated on the serial plate shows the ambient temperature & humidity at which this appliance has been tested, for the purposes of
establishing values in line with European standards.
Climate Class Temperature Relative humidity
4 30˚C 55%
5 40˚C 40%
Disposal Requirements
This appliance contains components and materials which can be harmful to the environment if
not disposed of correctly. Disposal of this appliance should be carried out by a suitably licensed
waste contractor in accordance with national laws and regulations which may be in force at the
time.
Electrical Safety
This equipment shall be connected to an electrical supply protected by a Residual Current Device
(RCD). This may include a residual current circuit breaker (RCCB) type socket, or through a Residual
Current Circuit Breaker with overload protection (RCBO) supplied circuit.
Should it be necessary to replace the fuse, the replacement fuse must be of the value stated on
the serial label for the appliance.

4www.fosterrefrigerator.com
Locating the appliance
After unpacking, clean (cleaning directions supplied within this manual) and allow the appliance
to stand for 60 minutes before turning on.
Ensure the appliance is situated on a rm, level surface, away from both hot and cold air
sources, as this will aect its performance.
Place the appliance in a location so as not to exceed the maximum rated ambient
temperature.
The appliance produces warm air when operating normally and requires adequate
ventilation. The dimensions indicated are a minimum.
As the operating temperature has been pre-set no adjustments are required. Allow the
appliance to reach its normal operating temperature before loading with product.
Connect the appliance to a suitable power supply. Do not connect or disconnect the
appliance with wet hands. The appliance will turn on automatically displaying the actual
internal temperature of the appliance. If this does not happen and button 3 is‘pulsing’
press and hold button 3 for 3 seconds to turn on the appliance.
100mm
50mm
50mm

5G3 Cabinets - Service Manual
Display Icons and Buttons
Operating Instructions
1
Standby
Pressing button 3 for 3 seconds will turn the unit on or into standby. When in standby, only button 3 will be displayed. The remainder of the display
will be blank. When operating normally, the display will show the internal temperature and button 3.
Icon Button
1 Compressor running 1 Information menu
2 Keypad locked 2 Increase value
3 Evaporator fans running 3 Standby/Exit/Conrm
4 Defrost in progress 4 Decrease value
5 Alarm 5 Light (If tted)
6/7 Display units Centigrade or
Fahrenheit
8 Auxillary output operation
+2
Icon 2
Icon 3
Icon 1
Icon 6
Button 1 Button 2 Button 3 Button 4
Button 5
Icon 7
Icon 8
Icon 5Icon 4
Appliance internal
temperature
Note - Buttons 1, 2, 4 and 5 are only visible after pressing button 3

6www.fosterrefrigerator.com
40
KG
Defrost
The appliance has an automatic defrost function and will defrost periodically each day without
any user intervention. This process is normal and does not aect product stored in the appliance.
During defrost the appliance can be used as normal.
Keypad Security Settings
We advise that this function is used to prevent unauthorised adjustment of the appliance and it’s operating temperature.
Press and release button 3. Then press button 1 followed by button 4 to display‘Loc’. Press button 3 and use buttons 2 and 4 to change the value
to ‘Yes’to lock the keypad or ‘no’ to unlock it. Press button 3 to save the new value. If button 3 is not pressed the new value will not be stored.
The display will reset after 30 seconds or by pressing button 1.
Shelves, Supports, Loading and Air Flow
The appliance is supplied with adjustable, removable trayslides and shelves.
Each shelf is capable of holding up to 40kg of product evenly distributed.
Do not block air vents with product. A minimum of 25mm should be maintained between the
top of the product and the shelf above.
Do not place product on the base of the appliance. If it is required to store product on the base of
the appliance please contact the Foster parts team to purchase the necessary shelf and spacers.
Always ensure air can circulate around/through the stored product. It is important that for optimal
energy performance that adequate airow is maintained around the perimeter of the shelves, and
around all stored products.
Set Point
To display the appliance Set Point, with the display showing the temperature, press button 3. Then press button 1 and with the display showing ‘SP’
press button 3.
To amend the Set Point press button 3. Then press button 1 and with the display showing ‘SP’ press button 3. Adjust using button 2 and button 4.
Press button 3 to save the new value. If button 3 is not pressed the new value will not be stored.
If the Set Point cannot be adjusted to the value required please contact your authorised Foster dealer for advice.
The display will reset after 30 seconds or by pressing button 1.
Door Lock
To lock the door insert the key and turn 90°, turn in the opposite direction to unlock.
Internal Light (Applicable to model EP700G and EP1440G)
The light is operated using button 5. Press once to turn on the light and press again to turn o
the light.

7G3 Cabinets - Service Manual
Controller Menu’s
The controller contains 2 menu levels, user level and service level.
User Level Menu
To access user level settings, press button 3 and then press button 1. The display will show ‘SP’. Use buttons 2 and 4 to display the parameter
required. Press button 3 to display the current value. If it is required to amend the value use buttons 2 and 4 followed by button 3 to save the new
value.
User Level Parameters
Mnemonic
Description
SP Appliance Set Point
Loc Keypad Lock
tA Actual air probe value
tE Actual evaporator probe value (Not enabled on all models)
tLo Minimum air temperature during previous 24 hours
tHi Maximum air temperature during previous 24 hours
dEF Time until next scheduled defrost. Displayed in tenths of hours. For example 05.4 = 5 hours 40 minutes
tdy Display resolution
Service Function
2

8www.fosterrefrigerator.com
Service Level Parameters
Mnemomic
Description
MDL Do not adjust
SPL Minimum limit for SetPoint
setting
SPH Maximum limit for SetPoint
setting
SP Setpoint Temperature value to be maintained in the product
HY0 Thermostat OFF -> ON
dierential
In Cooling Mode - ‘MDL’ = ‘HYS’
HY1 Do not adjust
CMD Compressor start delay ‘run’
mode
The time between mains power being applied and the compressor starting when in ‘run’
mode (i.e. following a mains power cut)
CRT Compressor rest time Minimum time compressor is switched o following cycle operation (i.e. pull down, hot
gas defrost)
CT1 Compressor output on time Followed by ‘CT2’ when probe Ta (T1) is faulty
CT2 Compressor output o time Followed by ‘CT1’when probe Ta (T1) is faulty
PB Do not adjust
IT Do not adjust
DT Do not adjust
CT Do not adjust
AR Do not adjust
CMS Do not adjust
CRS Do not adjust
CRD Do not adjust
CDS Do not adjust
CFF Do not adjust
CSS Do not adjust
CSO Do not adjust
CST Do not adjust
DFM
Defrost start mode
Defrost start mode
‘NON’- defrost function is disabled - no defrosts will occur
‘TIM’ - Time. Defrosting occurs on a time base determined by‘DFT’, accumulated only in
run mode
‘FRO’ - Do not use
‘DoD’ - Do not use
‘TAD’ - Do not use
DFT Time interval between defrosts When this time has elapsed since the previous defrost (in run mode), a new defrost cycle
is initiated
DSP Do not adjust
DST Do not adjust
DMI Do not adjust
DLI Defrost end temperature
DTO Maximum defrost duration
DTY
Defrost type ‘OFF’- O cycle defrost (Compressor and Heater OFF)
‘ELE’ - Electric defrost (Compressor OFF and Heater ON)
‘GAS ‘ - Hot gas defrost (Compressor and Heater ON)
DSY
Defrost start synchronization ‘OFF’- none. The defrost will occur without delay
‘LO’ - defrost start will be postponed to compressor cut-out (SOD = max delay)
HI’- defrost start will be postponed to compressor cut-in (SOD = max delay)
SOD Do not adjust
DPD Evaporator pump down At the beginning of defrost, defrost outputs (determined by ‘DTY’) are ‘OFF’ for‘DPD’
seconds
DRN Pause after defrost (evaporator
drain down time)
DDM
Defrost display mode. RT’ - the real / actual temperature
LT’- the last temperature displayed before defrost initiation
SP’ - the setpoint value
dEF’ - ‘dEF’
Service Level Menu
To access service level menu, press button 3 then press and hold buttons 2 and 4 for 5 seconds and the display will show‘MDL’. Use buttons 2 and
4 to display the parameter required. Press button 3 to display the current value. If it is required to amend the value use buttons 2 and 4 followed
by button 3 to save the new value.

9G3 Cabinets - Service Manual
DDY Display delay The display shows the information selected with parameter‘DDM’ during defrost and for
‘DDY’ minutes after defrost termination
FID Evaporator Fans in defrost YES - Fans active during defrost and drain (‘DRN’) and recovery / NO - Fans o during
defrost and drain (‘DRN’) and recovery (fan start based on ‘FDD’or‘FTO’- whichever rst)
FDD Evaporator fan re-start
temperature after defrost
FTO Maximum evaporator fan stop
after defrost
FSD ‘Evaporator fan stop delay after
door opens
Time in seconds: ‘-1’ = fan(s) do not stop / ‘0’ = fan(s) stop instantaneously / ‘1’-’900’= fans
stop after prescribed time elapses
FCM
Thermostatic control fan mode ‘NON’- The fans remain ON all the time (subject to door switch operation and defrosts).
‘TMP’- Temperature-based control. The fans are ON when the compressor is ON. When
the compressor is turned OFF, the fans remain ON as long as the temperature dierence
Te-Ta is greater than‘FDT’
TIM’- Timed-based control. The fans are ON when the compressor is ON. When the
compressor is OFF, the fans switch ON and OFF according to parameters ‘FT1’, ‘FT2’ and
‘FT3’
FDT Evaporator fan compressor
stop over-run
Where Evaporator (Te) -Air (Ta) temperature dierence for the fans to turn OFF after the
compressor has stopped
FDH Temperature dierential for fan
re-start
Example: ‘FDT’= ‘-1’ and ‘FDH=3’. If compressor is stopped, the fans are OFF when Te> Ta
‘-1’ (‘FDT’), whereas the fans are ON when Te < Ta ‘-4’ (‘FDT’-’FDH’)
FT1 Fan stop delay after compressor
stop
FT2 Timed fan stop When ‘FT2’ = ‘0’ the fans remain on all the time
FT3 Timed fan run When ‘FT3’ = ‘0’, and ‘FT2’ > ‘0’, the fans remain OFF all the time
ATM
Alarm threshold management ‘NON’ - all temperature alarms are inhibited (the following parameter will be ‘ACC’)
‘ABS’ - the values programmed in‘ALA’ and ‘AHA’ represent the real alarm thresholds
‘REL’ - the alarm threshold is obtained by the sum of setpoint, thermostat dierential and
‘ALR’ / ‘AHR’
ALA Low temperature alarm
threshold
AHA High temperature alarm
threshold
ALR Low temperature alarm
dierential
With ‘ALR’ = ‘0’ the low temperature alarm is excluded
AHR High temperature alarm
dierential
With ‘AHR’ = ‘0’ the high temperature alarm is excluded
ATI Probe used for temperature
alarm detection
PAD
Delay before alarm
temperature warning at power
on
ATD Delay before alarm
temperature warning
ACC
Condenser periodic cleaning When the compressor operation time, expressed in weeks, matches the ‘ACC’ value
programmed, ‘CL’ ashes in the display. With‘ACC’ = ‘0’ the condenser cleaning warning is
disabled
ECO Do not adjust
ESP Do not adjust
EH0 Do not adjust
EH1 Do not adjust
EPB Do not adjust
EDM Do not adjust
EDF Do not adjust
EDL Do not adjust
EDO Do not adjust
EDR Do not adjust
EFD Do not adjust
EFT Do not adjust
EFC Do not adjust
ESD Do not adjust
EFS Do not adjust
EMF Do not adjust
DSM
Door switch mode ‘NON’- when ‘DI1’/’T3A’ = ‘DOR’there is no response to a state change
‘ALR’ - when ‘DI1’/’T3A’ = ‘DOR’ and the digital input is ON, an alarm is generated after
‘DAD’ minutes
‘STP’ - when ‘DI1’/’T3A’= ‘DOR’’ and the digital input is ON, in addition to the alarm, the
fans are stopped according to FSD and the compressor is stopped after ‘CSD’ seconds

10 www.fosterrefrigerator.com
DAD Delay before door open alarm
warning
CSD ‘Relay 1’ stop delay after door
open
‘0’ … ‘900’ - time in seconds (‘-1’ = ‘Relay’does not de-energise / ‘0’= instantaneous / ‘1’-
’900’ = de-energises after prescribed time elapses)
DOT
Door stop overide If the door switch remains open for longer than‘DOT’ minutes, the operating functionaity
returns to normal thermostatic control, howver the alarm will remain. When ‘DOT’ = ‘0’,
this function is disabled
DI1
‘DI1’ digital input ‘NON’- Digital Input 1 not active
‘DOR’ - door input
‘ALR’ - when the input is activated (set by ‘D1A’) alarm ‘Alr’ alarm is generated, the
compressor is stopped and the defrosts are suspended
‘ECO’- Do not use
‘RDS’- Do not use
D1A ‘DI1’ activation ‘OPN’ - on open
‘CLS’- on close
LCM
Light control mode ‘NON’- light output not controlled
MAN’- light output controlled through display operating button (when‘SR1’, ‘SR2’ or ‘RL2’
= ‘LGT’ )
‘ECO’- Do not use
‘DI1’ - Do not use
‘NI1’ - Do not use
‘DI2’ - Do not use
‘NI2’ - Do not use
SR1
SSR1 output operation ‘NON’- Relay output disabled (always O/Open)
‘LGT’ - Output enabled for light control
‘0-1’ - Relay contacts follow the on/standby state of controller
R1’ - Do not use
‘R1F’- Do not use
‘-R1’ - Do not use
‘FAN’ - Output enabled for evaporator fan switching
‘-FAN’ Do not use
‘DEF’- Output enabled for defrost switching
‘-DEF’- Do not use
‘ALO’- Contacts open when an alarm condition occurs
‘ALC’ - Contacts make when an alarm condition occurs
‘ACP’ - Do not use
‘AFH’ - Do not use
SR2 SSR2 output operation Same operations and selection as‘SR1’
RL2
RL2 output operation - same
operations and selection as
‘SR1’
Same operations and selection as ‘SR1’
ACN Do not adjust
ACF Do not adjust
AHS Do not adjust
AHU Do not adjust
AFT Do not adjust
PMD Do not adjust
MSV Do not adjust
2CD Do not adjust
SB Stand-by button enabling
BOS Button Operation Sounder YES’provides positive feedback (i.e. ‘beep’) every time a display button is pressed, ‘NO’
sounder is silenced during display button operation
RHC Do not adjust
OSA Probe TAir (T1) oset
TE Probe TEvaporator (T2)
enabling
OSE Probe TEvaporator (T2) oset
T3A
DI2 / TAuxiliary Probe Enabling
and Operation
‘NON’- DI2 / Auxiliary probe not tted
‘DSP’ - Auxiliary Probe - general purpose temperature measurement (i.e. stored product
temperature)
‘CND’ - Condenser probe - if measure temperature exceeds value of ‘AHT’ controller will
react as dened by ‘AHM’
‘2EU’ Do not use
‘DOR’ - Digital Input 2 used for door switch operation
‘ALR’ - Do not use
‘ECO’- Do not use
‘RDS’- Do not use

11G3 Cabinets - Service Manual
OS3 Auxiliary Probe 3 oset
D3A ‘DI3’ activation ‘OPN’ - on open
‘CLS’- on close
AHM
Operation in alarm when ‘T3A’
= ‘CND’
‘NON’- Audible and visual alarm is inhibited
‘ALR’ - when ‘T3A’ = ‘CND’ and temp. >‘AHT’ condenser high temperature‘HC’ alternates in
the display and the alarm sounder is activated
‘STP’ - in addition to the alarm signal, the compressor is stopped and defrosts are
suspended
AHT Condenser temperature alarm
(referring to TAuxiliary probe)
TLD
Delay for minimum
temperature (‘TLO’) and
maximum temperature (‘THI’)
logging
With ‘TLD’ = ‘0’ the logging is disabled
TDS
The temperature probe value
to be displayed
‘TA’ - actual Tair (T1) value
TAS’- actual Tair (T1) value slowed (rate of change toward setpoint = actual value, away
from setpoint = mathematical algorithm applied)
‘A-E’ - the AVG-weighted average between TAir (T1) and TEvaporator (T2) probes
‘T3’ - TAuxiliary (T3) probe value (when ‘T3A’ = ‘DSP’, ‘CND’ or ‘2EU’)
SIM Display slowdown. Active when‘TDS’= ‘TAS’, the SIM value is the controlling arithmetical value.
AVG
The relative weight of T2 in
respect of T1 (when ‘TDS’ =
‘A-E’)
SCL
Readout scale ‘°C’ with non adjustable resolution in User Function Menu
‘°C’with adjustable resolution in User Function Menu
‘°F’with non adjustable resolution in User Function Menu
‘°F’with adjustable resolution in User Function Menu
PRT Modbus communication type RTL or ASCII
ADR FD1-19 address for PC
communication
RFP Return to Factory Parameters. Allow options through‘User Menu’ to reset all controller parameters to factory production
values where controller has been programmed by Foster

12 www.fosterrefrigerator.com
Parameter Settings
INTEGRAL REMOTE
Mnemonic Default Single Section High Temperature Solid Door Single Section High Temperature Solid Door (Pass Through) Single Section High Temperature Glass Door Single Section Meat Temperature Solid Door Single Section Low Temperature Solid Door Single Section Fish Temperature Solid Door Single Section Dual Temperature Solid Door (Top Section) Single Section Dual Temperature Solid Door (Bottom Section) Double Section High Temperature Cabinet Solid Door Double Section High Temperature Cabinet Glass Door Double Section Meat Temperature Cabinet Solid Door Double Section Low Temperature Cabinet Solid Door Single Section High Temperature Solid Door Single Section Low Temperature Solid Door Double Section High Temperature Cabinet Solid Door Double Section High Temperature Cabinet Glass Door Double Section Low Temperature Cabinet Solid Door
MDL HYS HYS HYS HYS HYS HYS HYS HYS HYS HYS HYS HYS HYS HYS HYS HYS HYS HYS
SPL -2 1 1 1 -2 -21 -2 1 -23 1 1 -2 -21 1 -21 1 1 -21
SPH 10 5 5 5 5 -15 5 5 -15 5 5 5 -15 5 -15 5 5 -15
SP 3.5 2 2 2 -2 -21 -1 2 -23 2 2 -2 -21 2 -21 2 2 -21
HY0 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3
HY1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
CMD 30 5 5 5 5 5 5 5 5 5 5 5 5 0 5 5 5 5
CRT 90 180 180 180 180 180 180 180 180 180 180 60 60 0 0 0 0 0
CT1 4 4 4 4 5 5 4 4 5 4 4 5 5 4 5 4 4 5
CT2 7 6 6 7 5 5 7 6 5 6 7 5 5 6 5 6 6 5
PB 7 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5
IT 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100
DT 0 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6
CT 10 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5
AR 75 70 70 70 70 70 70 70 70 70 70 70 70 70 70 70 70 70
CMS 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100
CRS 35 90 90 90 90 90 90 90 90 90 90 90 90 90 90 90 90 90
CRD 15 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10
CDS 50 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60
CFF 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60
CSS 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60
CSO 1 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12
CST 60 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30
DFM TAD TIM TIM TIM TIM TIM NON TIM TIM TIM TIM TIM TIM TIM TIM TIM TIM TIM
DFT 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6
DSP -12 -12 -12 -12 -12 -12 -12 -12 -12 -12 -12 -12 -12 -12 -12 -12 -12 -12
DST 4 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15
DMI 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
DLI 10 10 10 6 15 15 6 10 15 10 10 15 15 10 15 6 10 15
DTO 20 15 15 15 20 20 15 15 20 15 15 20 20 15 20 15 15 20
DTY OFF OFF OFF OFF GAS GAS OFF OFF GAS OFF OFF GAS GAS OFF ELE OFF OFF ELE
DSY OFF OFF OFF OFF HI HI OFF OFF HI OFF OFF HI HI OFF HI OFF OFF HI
SOD 10 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5
DPD 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
DRN 60 0 0 0 90 90 0 0 90 0 0 90 90 0 90 0 0 90

13G3 Cabinets - Service Manual
INTEGRAL REMOTE
Mnemonic Default Single Section High Temperature Solid Door Single Section High Temperature Solid Door (Pass Through) Single Section High Temperature Glass Door Single Section Meat Temperature Solid Door Single Section Low Temperature Solid Door Single Section Fish Temperature Solid Door Single Section Dual Temperature Solid Door (Top Section) Single Section Dual Temperature Solid Door (Bottom Section) Double Section High Temperature Cabinet Solid Door Double Section High Temperature Cabinet Glass Door Double Section Meat Temperature Cabinet Solid Door Double Section Low Temperature Cabinet Solid Door Single Section High Temperature Solid Door Single Section Low Temperature Solid Door Double Section High Temperature Cabinet Solid Door Double Section High Temperature Cabinet Glass Door Double Section Low Temperature Cabinet Solid Door
DDM DEF SP SP SP SP SP DEF SP SP SP SP SP SP SP SP SP SP SP
DDY 2 1 1 2 1 1 2 1 2 1 1 1 1 1 2 1 1 2
FID YES YES YES YES NO NO YES YES NO YES YES NO NO YES NO YES YES NO
FDD 10 10 10 10 -5 -5 10 10 -5 10 10 -5 -5 10 -5 10 10 -5
FTO 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
FSD 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
FCM TMP NON NON NON NON NON NON NON NON NON NON NON NON NON NON NON NON NON
FDT -3 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
FDH 2 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
FT1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
FT2 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
FT3 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
ATM REL REL REL REL REL REL REL REL REL REL REL REL REL REL REL REL REL REL
ALA -30 -30 -30 -30 -30 -30 -30 -30 -30 -30 -30 -30 -30 -30 -30 -30 -30 -30
AHA -15 -15 -15 -15 -15 -15 -15 -15 -15 -15 -15 -15 -15 -15 -15 -15 -15 -15
ALR -5 -3 -3 -3 -3 -3 -3 -3 -3 -3 -3 -3 -3 -3 -3 -3 -3 -3
AHR 8 6 6 6 8 8 6 6 8 6 6 8 8 6 8 6 6 8
ATI T1 T1 T1 T1 T1 T1 T1 T1 T1 T1 T1 T1 T1 T1 T1 T1 T1 T1
PAD 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60
ATD 90 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60
ACC 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
ECO YES NO NO NO NO NO NO NO NO NO NO NO NO NO NO NO NO NO
ESP 3.5 3.5 3.5 3.5 3.5 3.5 3.5 3.5 3.5 3.5 3.5 3.5 3.5 3.5 3.5 3.5 3.5 3.5
EH0 2.5 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3
EH1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
EPB 10 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4
EDM TAD TIM TIM TIM TIM TIM TIM TIM TIM TIM TIM TIM TIM TIM TIM TIM TIM TIM
EDF 24 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12
EDL 10 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6
EDO 10 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15
EDR 20 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
EFD 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10
EFT 5 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
EFC NON NON NON NON NON NON NON NON NON NON NON NON NON NON NON NON NON NON
ESD 90 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60
EFS 12 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15
EMF 20 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30
DSM ALR STP STP STP STP STP STP STP STP STP STP STP STP STP STP STP STP STP

14 www.fosterrefrigerator.com
DAD 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
CSD 90 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30
DOT 2 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4
DI1 DOR DOR DOR DOR DOR DOR DOR DOR NON DOR DOR DOR DOR DOR DOR DOR DOR DOR
D1A OPN OPN OPN OPN OPN OPN OPN OPN OPN OPN OPN OPN OPN OPN OPN OPN OPN OPN
LCM NON NON NON MAN NON NON NON NON NON NON MAN NON NON NON NON NON MAN NON
SR1 NON FAN FAN FAN FAN FAN NON FAN FAN FAN FAN FAN FAN FAN FAN FAN FAN FAN
SR2 NON NON NON LGT DEF DEF NON NON DEF NON NON DEF DEF NON DEF NON NON DEF
RL2 NON 0-1 0-1 0-1 0-1 0-1 0-1 0-1 0-1 0-1 LGT 0-1 0-1 0-1 0-1 0-1 LGT 0-1
ACN 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
ACF 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
AHS YES NO NO NO NO NO NO NO NO NO NO NO NO NO NO NO NO NO
AHU 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15
AFT 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15
PMD NO NO NO NO NO NO NO NO NO NO NO NO NO NO NO NO NO NO
MSV 230 240 240 240 240 240 240 240 240 240 240 240 240 240 240 240 240 240
2CD 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
SB YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES
BOS YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES
RHC 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
OSA 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0
TE NO NO NO NO YES YES NO NO YES NO NO YES YES NO YES NO NO YES
OSE 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
T3A NON NON DOR NON NON NON NON NON NON DOR DOR DOR DOR NON NON DOR DOR DOR
OS3 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
D3A OPN OPN OPN OPN OPN OPN OPN OPN OPN OPN OPN OPN OPN OPN OPN OPN OPN OPN
AHM NON NON NON NON NON NON NON NON NON NON NON NON NON NON NON NON NON NON
AHT 0 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60
TLD 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30
TDS TAS TAS TAS TAS TAS TAS TAS TAS TAS TAS TAS TAS TAS TAS TAS TAS TAS TAS
SIM 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10
AVG 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
SCL oCn oCA oCA oCA oCA oCA oCA oCA oCA oCA oCA oCA oCA oCA oCA oCA oCA oCA
PRT RTU RTU RTU RTU RTU RTU RTU RTU RTU RTU RTU RTU RTU RTU RTU RTU RTU RTU
ADR 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
RFP YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES
INTEGRAL REMOTE
Mnemonic Default Single Section High Temperature Solid Door Single Section High Temperature Solid Door (Pass Through) Single Section High Temperature Glass Door Single Section Meat Temperature Solid Door Single Section Low Temperature Solid Door Single Section Fish Temperature Solid Door Single Section Dual Temperature Solid Door (Top Section) Single Section Dual Temperature Solid Door (Bottom Section) Double Section High Temperature Cabinet Solid Door Double Section High Temperature Cabinet Glass Door Double Section Meat Temperature Cabinet Solid Door Double Section Low Temperature Cabinet Solid Door Single Section High Temperature Solid Door Single Section Low Temperature Solid Door Double Section High Temperature Cabinet Solid Door Double Section High Temperature Cabinet Glass Door Double Section Low Temperature Cabinet Solid Door

15G3 Cabinets - Service Manual
Other Information
Alarms/Warnings:
During operation the current temperature inside the appliance will be displayed. At certain times this will change to indicate a particular appliance
operation or fault. The indicators you may see are as follows:
The temperature alarms are either relative to the set point or an absolute value. This is controlled by the value of parameter ‘ATM’. Where the alarms
are relative the low alarm is the set point minus parameter ‘ALR’ and the high alarm is the set point plus ‘AHR’. When the temperature has been
outside this value for the value of‘ATD’the relevant indicator will be displayed.
hi - The internal temperature of the appliance is higher than described above. Ensure that the door is closed and that the air ow inside is not
obstructed by excesive or poor loading of product. The alarm will reset if the temperature falls to a normal level. If this does not happen please
contact your authorised dealer or Foster Service.
Lo - The internal temperature of the appliance is lower than described above. Check to ensure that the appliance has not been loaded with
product at a lower temperature than the normal appliance operating temperature. If this is not the case please call your authorised dealer or Foster
Service.
dO - The appliance door is open. Close the door to cancel the alarm. Note - the door switch is a magnetic switch located in the bottom edge
of the front cover. If the cover is hinged up or removed for access purposes the door switch will not function and the door open alarm will be
displayed.
tA - Air probe has failed.. Call your authorised dealer or Foster Service to arrange for this to be replaced. During this time the appliance cannot
maintain an accurate temperature and all product should be removed and the appliance switched o.
tE - Evaporator probe has failed (not applicable to all models). Call your authorised dealer of Foster Service to arrange for this to be replaced.
PF - The mains power has been removed from the appliance for a period of time and has now been restored. This may have resulted in a rise in
appliance temperature. Caution should be taken when using products stored within to ascertain whether these products are suitable for use. Upon
restoration of the power supply the appliance will resume normal operation and the PF can be cancelled by pressing button 3 once.
HC - The condenser temperature is higher than it should be. If the appliance is being subjected to particularly high ambient temperatures steps
should be taken to reduce this. If the ambient temperature is not high or reducing the temperature does not rectify the fault please contact your
authorised dealer or Foster Service.
Cnd - The condenser clean period has expired. Please contact your authorised dealer or Foster Service.
While in an alarm condition icon 5 will also be illuminated.
(Some indications are only visible periodically during specic appliance operations such as defrost or when activated through use of the appliance).

16 www.fosterrefrigerator.com
1 - Air probe
2 - Evaporator probe
3 - Condenser probe
Probe Resistance
Length in decimeters
15 = 1.5m
20 = 2m
35 = 3.5m
P1 - Probe 1
P2 - Probe 2
P3 - Probe 3
1 - 1KΩ
2 - 2kΩ
4 - 10kΩ
N - NTC
T - PTC
Manufacture
Month - Year
Probe manufacturer
Probe Indentication
Probe Information
Tx LAEx x-xx Sx xK xx Px
NTC10K Temperature Resistance Table SN4K
TEMP. (°C) R-low (KW) R-mid (KW) R-high (KW)
-30 109.522 113.347 117.294
-25 84.823 87.559 90.374
-20 66.27 68.237 70.255
-15 52.229 53.65 55.104
-10 41.477 42.506 43.557
-5 33.147 33.892 34.651
0 26.678 27.219 27.767
5 21.63 22.021 22.417
10 17.643 17.926 18.21
15 14.472 14.674 14.877
20 11.938 12.081 12.224
25 9.9 10 10.1
30 8.217 8.315 8.413
35 6.854 6.948 7.043
40 5.745 5.834 5.923
The probe is a type 10k NTC. The probes are identical in characteristics with the T1 and T2 identication markings and dierent colours being for
ease of identication and not for functional reasons. Please refer to the image below for probe identication.

17G3 Cabinets - Service Manual
Refrigerant Charge
The refrigerant charge weight can be found on the serial label within the appliance. Where this is not available please refer to the table below. The
information below is correct time of printing but is subject to change without prior notice.
Evaporator Fan Motors
The appliance is tted with 2 speed evaporator fan motor(s). It is important that they are wired correctly to ensure optimum cooling and energy
performance from the appliance. High speed mode is active during compressor operation with low speed mode being active at all other times
subject to the parameter ‘FCM’.
Door Switch
The appliance is tted with a magnetic door switch located in the underside of the front cover. Where the door switch is open and following the
time set in parameter DAD, the controller will, indicate DO and an alarm will sound. At the point the door is opened the evaporator fan(s) will stop
and following the time set in parameter CSD relay 1 will open until such time as the door is closed.
EP700H 80gms
EP700M 80gms
EP700L 80gms
EP700G 95gms
EP700F 80gms
EP700SH 80gms
EP700SL 80gms
EP700P 110gms
EP1440H 140gms
EP1440M 150gms
EP1440L 150gms
EP1440G 140gms
EP700HH 65gms per system
EP700HL 65gms per system
EP700LL 65gms per system
EP700H2 80gms per system
EP700L2 80gms per system
EP700LL 65gms per system

18 www.fosterrefrigerator.com
Factory Reset
Where the controller was originally programmed by Foster and is dedicated to a specic appliance type it is possible to return the setting to they’re
original programmed state. If the controller was not programmed by Foster this function will return the parameters to the values in the original
factory settings.
To reset the parameters:
- Press button 3 to activate the display
- Press button 1 to enter the user level menu
- Press button 2 until the display shows ‘rFp’
- Press button 3 once and ‘rFp’will ash
- Press and hold button 3 for 3 seconds until the display shows ‘End’
The original parameters as described above have now been restored.
If at any point the sequence of button operations and display indications are not completed the controller will, after 30 seconds resume operation
with no changes to the parameters having been made.
Defrost Indication
During defrost icon 4 will be illuminated. The controller display will be determined by the value set in parameter ‘DDM’.
To start a defrost manually press and hold button 3 for 5 seconds. This will turn o the appliance. Continue to hold down button 3 after the
appliance has turned o. After a further 2 seconds the display will indicate a defrost has commenced (icon 4 illuminated) and the button can be
released. While the defrost function is operating the display will be determined by the value set in parameter DDM.
The defrost function will operate until either the time set in parameter DTO or the temperature set in parameter DLI is reached. Where parameter
TE is set to NO defrost will function on a time basis only. Upon completion of the defrost cycle the appliance will resume normal operation with
the current temperature displayed.
Relay Test
The controller contains a relay test function to enable the service engineer to operate individual relays, or a combination of relays for diagnostic
purposes.
To access the relay test:
- Place the controller in standby so that button 3 is pulsing
- Press button 3 once so that buttons 1, 2 and 4 are activated and ashing
- Press and hold buttons 2 and 4 for 5 seconds until the display shows ‘rLy’ and buttons 1 to 5 are all illuminated
The controller is now in relay test mode.
To activate relay 1 press button 1. Icon 1 will illuminate. To deactivate relay 1 press button 1 again and icon 1 will switch o.
To activate relay 2 press button 2. Icon 3 will illuminate. To deactivate relay 2 press button 2 again and icon 3 will switch o.
To activate relay 3 press button 4. Icon 4 will illuminate. To deactivate relay 3 press button 4 again and icon 4 will switch o.
To activate relay 4 press button 5. Icon 8 will illuminate. To deactivate relay 4 press button 5 again and icon 8 will switch o.
Multiple relays can be activated simultaneously to enable diagnostics.
Relay function:
Relay 1 - Red icon - Compressor
Relay 2 - Green icon - function determined by parameter SR1. Evaporator Fan
Relay 3 - White icon - function determined by parameter SR2. Where appliance has active defrost SR2 to will be set to DEF for defrost.
Relay 4 - Amber icon - function determined by parameter RL2.
To exit the relay test function press button 3 once.

19G3 Cabinets - Service Manual
Condenser Cleaning
The condenser is a Stayclear condenser which does not require cleaning as regularly as a traditional nned condenser may. Care should be taken
when cleaning the condenser. Never use a wire brush, abrasive or corrosive materials to clean the condenser.
Door Gaskets
Door gaskets should be inspected periodically and cleaned where necessary with a warm damp cloth. Do not use aggressive cleaning materials on
the door gaskets.
Where door gaskets are damaged or not sealing correctly, they are required to be changed. These can be removed by pulling the old gasket from
it’s locating prole and pushing the new gasket into the same location. Where the gasket will not locate securely in the locating prole use a
rubber mallet to locate the gasket securely.
Maintenance
3

20 www.fosterrefrigerator.com
Wiring Diagrams
EP700H Integral Condensing Unit
