Fostex DS-8 User manual

FOSTEX CORPORATION 3-2-35 Musashino, Akishima, Tokyo, Japan 196-0021
FOSTEX CORPORATION OF AMERICA 15431 Blackburn Ave., Norwalk, CA 90650, U.S.A. © PRINTED IN JAPAN OCT. 1999 8288786000
DS-8
Service Manual
Model
DIGITAL AUDIO SELECTOR

SAFETY INSTRUCTIONS
Read instructions - All the safety and operating instruc-
tions should be read before the appliance is operated.
Retain instructions - The safety and operating instructions
should be retained for future reference.
Heed warnings - All warnings on the appliance and in the
operating instructions should be adhered to.
Follow instructions - All operating and use instructions
should be followed.
Water and Moisture - The appliance should not be used
near water - for example, near a bathtub, washbowl,
kitchen sink, laundry tub, in a wet basement, or near a
swimming pool, and the like.
Carts and Stands - The appliance should be used only
with a cart or stand that is recommended by the manufac-
turer.
An appliance and cart combination should be moved with
care. Quick stops, excessive force, and uneven surfaces
may cause the appliance and cart combination to over-
turn.
Wall or Ceiling Mounting - The appliance should be
mounted to a wall or ceiling only as recommended by the
manufacturer.
Ventilation - The appliance should be situated so that its
location or position does not interfere with its proper ven-
tilation. For example, the appliance should not be situ-
ated on a bed, sofa, rug, or similar surface that may block
the ventilation openings; or, placed in a built-in installa-
tion, such as a bookcase or cabinet that may impede the
flow of air through the ventilation openings.
Heat - The appliance should be situated away from heat
sources such as radiators, heat registers, stoves, or other
appliances (including amplifiers) that produce heat.
Power Sources - The appliance should be connected to a
power supply only of the type described in the operating
instructions or as marked on the appliance.
Grounding or Polarization - The precautions that should
be taken so that the grounding or polarization means of
an appliance is not defeated.
Power Cord Protection - Power supply cords should be
routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying
particular attention to cords at plugs, convenience recep-
tacles, and the point where they exit from the appliance.
Cleaning - The appliance should be cleaned only as rec-
ommended by the manufacturer.
Nonuse Periods - The power cord of the appliance should
be unplugged from the outlet when left unused for a long
period of time.
Object and Liquid Entry - Care should be taken so that
objects do not fall and liquids are not spilled into the en-
closure through openings.
Damage requiring Service - The appliance should be ser-
viced by qualified service personnel when:
A.
B.
C.
D.
E.
Servicing - The user should not attempt to service the ap-
pliance beyond that described in the operating instruc-
tions. All other servicing should be referred to qualified
service personnel.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
TO PREVENT ELECTRIC SHOCK, MATCH
WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
POUR ÉVITER LES CHOCS ÉLECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE DE
LA FICHE DANS LA BORNE CORRE-
SPONDANTE DE LA PRISE ET POUSSER
JUSQU' AU FOND.
CAUTION:
ATTENTION:
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and mainte-
nance (servicing) instructions in the literature
accompanying the appliance.
The lightening flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product's en-
closure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
“WARNING”
“TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOIS-
TURE.”
1.
2.
3.
4.
5.
6.
7.
8.
The power supply cord or the plug has been damaged;
or
Objects have fallen, or liquid has been spilled into the
appliance; or
The appliance has been exposed to rain; or
The appliance does not appear to operate normally or
exhibits a marked changed in performance; or
The appliance has been dropped, or the enclosure
damaged.
9.
10.
11.
12.
13.
14.
15.
16.
17.
11
DS-8 DS-8
INPUT 1
(COAXIAL)
INPUT 2
(COAXIAL)
INPUT 3
(OPTICAL)
INPUT 4
(OPTICAL)
INPUT 5
(OPTICAL)
INPUT 6
(OPTICAL)
INPUT 7
(OPTICAL)
INPUT 8
(OPTICAL) INPUT SELECTOR
OUT 8
INPUT SELECTOR
OUT 7
INPUT SELECTOR
OUT 6
INPUT SELECTOR
OUT 5
INPUT SELECTOR
OUT 4
INPUT SELECTOR
OUT 3
INPUT SELECTOR
OUT 2
INPUT SELECTOR
OUT 1 OUTPUT 1
(COAXIAL)
OUTPUT 2
(COAXIAL)
OUTPUT 3
(OPTICAL)
OUTPUT 4
(OPTICAL)
OUTPUT 5
(OPTICAL)
OUTPUT 6
(OPTICAL)
OUTPUT 7
(OPTICAL)
OUTPUT 8
(OPTICAL)
BLOCK DIAGRAM

Parts marked with this sign are safety critical components. They must always be replaced with identical
components. Refer to the Fostex Parts List and ensure exact replacement.
CAUTION
TABLE OF CONTENTS
Owner's manual : 8288449000 (for export model)
: 8288450000 (for domestic model)
AC adaptor AD-12A : 8270727003 (for USA/CND)
: 8270727006 (for EUR)
: 8270727007 (for UK)
: 8270727010 (for JPN)
Parts List and circuit diagrams are given in this manual to assist the service technician in maintaining
the Model DS-8.
NOTES
The following accessories are supplied with DS-8 as the standard accessories.
*
*
Following is the packing material for the Model DS-8.
*
Carton, inner, DS-8 : 8228734000
Packing side, DS-8 : 8228436000
Packing, AC, DS-8 : 8228437000
!
1. SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2. CONTROLS, INDICATORS AND CONNECTORS . . . . . . . . . . . .
3. EXPLODED VIEW, PCB ASSEMBLY AND PARTS LIST . . . . . .
4. CIRCUIT & BLOCK DIAGRAMS . . . . . . . . . . . . . . . . . . . . . . . .
4
4
5
9
!
310
DS-8 DS-8
SW PCB
2
3
4
5
6
7
8
9
S11
SRBV18 S12
SRBV18 S13
SRBV18 S14
SRBV18 S15
SRBV18 S16
SRBV18 S17
SRBV18 S18
SRBV18
OUT1
INPUT SEL OUT3
INPUT SEL OUT4
INPUT SEL OUT5
INPUT SEL OUT6
INPUT SEL OUT7
INPUT SEL OUT8
INPUT SEL
OUT2
INPUT SEL
DGND
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
IN5
IN1
IN6
IN2
IN7
IN3
IN8
IN4
OUT8
OUT1
OUT7
OUT2
OUT6
OUT3
OUT5
OUT4
J2
FPC-17P
1
10
2
3
4
5
6
7
8
9
1
10
2
3
4
5
6
7
8
9
1
10
2
3
4
5
6
7
8
9
1
10
2
3
4
5
6
7
8
9
1
10
2
3
4
5
6
7
8
9
1
10
2
3
4
5
6
7
8
9
1
10
2
3
4
5
6
7
8
9
1
10

94
DS-8 DS-8
1. SPECIFICATIONS
Specifications and appearance are subject to change without notice for product improvement.
INPUT 1, 2 (COAXIAL IN)
Connector RCA pin jack
Input Impedance 75 Ω
Normal Input Level 0.5 Vp-p
Format S/P DIF (IEC60958 part 3)
INPUT 3 - 8 (OPTICAL IN)
Connector Square shape optical
Format S/P DIF (IEC60958 part 3)
OUTPUT 1, 2 (COAXIAL OUT)
Connector RCA pin jack
Input Impedance 75 Ω
Normal Input Level 0.5 Vp-p
Format S/P DIF (IEC60958 part 3)
OUTPUT 3 - 8 (OPTICAL OUT)
Connector Square shape optical
Format S/P DIF (IEC60958 part 3)
DC IN 12 V (Inner: Plus, Outer: Minus)
SAMPLING FREQUENCY 32 kHz ~ 96 kHz
DIMENSIONS 44 (H) x 482 (W) x 113 (D) mm
WEIGHT 1.4 kg (excluding accessories)
POWER REQUIREMENT JPN : 100 V AC
USA/CND : 120 V AC
UK/EUR : 230 V AC
POWER SUPPLY Fostex AC adaptor AD-12A
2. CONTROLS, INDICATORS & CONNECTORS
1. INPUT SELECTOR [INPUT SELECTOR 1 - 8]
2. Input connector 8 [S/P DIF INPUT 8]
3. Output connector 8 [S/P DIF OUTPUT 8]
4. Power switch / POWER LED [POWER]
5. Input connector 1, 2 [S/P DIF INPUT 1, 2]
6. Input connector 3 - 7 [S/P DIF INPUT 3 - 7]
7. Output connector 1, 2 [S/P DIF OUTPUT 1, 2]
8. Output connector 3 - 7 [S/P DIF OUTPUT 3 - 7]
9. DC IN connector [DC IN 12V]
S/P DIF DIGITAL AUDIO SELECTOR
8
S/P DIF OUTPUT
S/P DIF INPUT
INPUT SELECTOR
INPUT 8
OUTPUT 8
4
3
2
1
5
6
7
8
INPUT 7
4
3
2
1
5
6
7
8
INPUT 6
4
3
2
1
5
6
7
8
INPUT 5
4
3
2
1
5
6
7
8
INPUT 4
4
3
2
1
5
6
7
8
INPUT 3
4
3
2
1
5
6
7
8
INPUT 2
4
3
2
1
5
6
7
8
INPUT 1
4
3
2
1
5
6
7
8
POWER
OUTPUT 7OUTPUT 6OUTPUT 5OUTPUT 4OUTPUT 3OUTPUT 2OUTPUT 1
8
1234
< FRONT PANEL >
1234567
S/P DIF INPUTS/P DIF OUTPUT
12V
DC IN
1234567
56
7
8
9
< REAR PANEL >
